Navigation circuit, w/o hifi radio w/ active sound design for BMW 6 series GT G32 (2017-2020)

BASE PLATE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLUETOOTH ANTENNA BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 212 FUSE 216 FUSE 262 GPS AERIAL GRN WIRE GRN/BLU WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT HOT W/ NCA WIRE NIGHT VISION ELECTRONICS ORG/ WIRE ORG/GRN WIRE REAR POWER DISTRIBUTION BOX REAR SEAT ENTERTAINMENT REAR WINDOW ANTENNA RED/BLK WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED SDARS AERIAL TELEPHONE AERIAL VIDEO MODULE (LEFT SIDE OF LUGGAGE COMPT) W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WLAN ANTENNA YEL WIRE

AUDIO MODE/HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL BASIS HIGH W/ TELEMATICS W/O TELEMATICS BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM EMERGENCY LOUDSPEAKER FUSE 10 GPS AERIAL GRN WIRE GRN/BLU WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT HOT W/ BI-STABLE RELAY ENERGIZED MICROPHONE MICROPHONE 2 + NCA WIRE RED WIRE RED/BLK WIRE RED/GRY WIRE RED/YEL WIRE ROOF AERIAL SDARS AERIAL TELEMATIC COMMUNICATION BOX (W/ TELEMATICS) (CENTER REAR OF ROOF) TELEMATICS ANTENNA TELEPHONE AERIAL WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WIRELESS CHARGING ODDMENTS TRAY AERIAL AMPLIFIER WIRELESS CHARGING STORAGE WLAN AERIAL YEL WIRE YEL/BLK WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/VIO WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM CONTROLLER (IDRIVE) FUSE 47 GRN WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT HIGH VARIANT HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT MOST DATA BUS CIRCUIT NCA WIRE NFC READER (BEHIND GLOVE BOX) NFC READER ANTENNA ORG/ WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT POWER DISTRIBUTION BOX SOUND SYSTEMS USB CONNECTION USB PORT 2 USB- HUB W/O USB AUDIO INTERFACE W/ USB AUDIO INTERFACE WHT/BRN WIRE WHT/RED WIRE

ACTIVE SOUND DESIGN BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 218 GRN WIRE GRY/BRN WIRE GRY/RED WIRE HOT W/ TERMINAL LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER ORG/GRN WIRE REAR POWER DISTRIBUTION BOX RED/WHT WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER WHT/BRN WIRE WHT/RED WIRE
