BMW 6 series GT G32 (2017-2020) right side reading light Wiring diagram
This page shows the only wiring diagram for the component.right side reading light, which is found in the car BMW 6 series GT G32 (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right side reading light (1 of 1)
AIR FRESHENER
AMBIENT LIGHT
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
FUSE 32
FUSE 41
FUSE 47
FUSE 60
FUSE 62
FUSE 64
FUSE 65
FUSE 66
FUSE 67
FUSE 68
GLOVE BOX LIGHT SWITCH
GLOVE COMPARTMENT LIGHT
GRY/BLK WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT BUTTON
INTERIOR LIGHT)
INTERIOR LIGHTING
INTERIOR LIGHTS BUTTON
INTERIOR LIGHTS LOCATOR LIGHTING BUTTON
LEFT READING LAMP BUTTON
LEFT READING LAMP BUTTON LOCATOR LIGHTING
LEFT SIDE READING LIGHT
REAR INTERIOR LIGHT (W/O PANORAMIC ROOF)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT VANITY MIRROR LIGHT
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT READING LAMP BUTTON
RIGHT READING LAMP BUTTON LOCATOR LIGHTING
RIGHT READING LIGHT
RIGHT SIDE READING LIGHT
ROOF FUNCTION CENTER (HIGH VARIANT)
VIO WIRE
VIO/GRN WIRE
Go to component -> Courtesy lamps circuit (1 of 6) -> RIGHT SIDE READING LIGHT
