BMW 6 series GT G32 (2017-2020) light source 18 Wiring diagram
This page shows the only wiring diagram for the component.light source 18, which is found in the car BMW 6 series GT G32 (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light source 18 (1 of 1)
BRN WIRE
CENTER DRIVER'S DOOR TRIM PANEL LIGHTING
DRIVER'S DOOR POCKET LIGHTING
GRN WIRE
GRY/BLK WIRE
GRY/WHT WIRE
LEFT FRONT MID- RANGE SPEAKER LIGHTING
LEFT FRONT TWEETER LIGHTING
LEFT REAR SPEAKER LIGHTING
LIGHT
LIGHT SOURCE 1
LIGHT SOURCE 16
LIGHT SOURCE 17
LIGHT SOURCE 18
LIGHT SOURCE 2
LIGHT SOURCE 3
LIGHT SOURCE 6
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT MID- RANGE SPEAKER LIGHTING
RIGHT FRONT TWEETER LIGHTING
RIGHT REAR SPEAKER LIGHTING
SOURCE 4
SOURCE 5
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
Go to component -> Courtesy lamps circuit (4 of 6) -> LIGHT SOURCE 18
