BMW 6 series GT G32 (2017-2020) grn Wiring diagrams

This page contains all the electrical diagrams for the component. grn, in which he is found in the car BMW 6 series GT G32 (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

grn wiring diagram (21 of 127)

BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM EARLY PRODUCTION LATE PRODUCTION FUSE 208 GRN WIRE GRN/RED WIRE GRY WIRE HEAD UNIT NCA WIRE NIGHT VISION CAMERA NIGHT VISION ELECTRONICS ORG/ WIRE REAR POWER DISTRIBUTION BOX RELAY ENERGIZED WHT WIRE YEL/BLK WIRE YEL/WHT WIRE

Go to component -> Electronic night vision circuit -> GRN WIRE

grn wiring diagram (22 of 127)

48 VOLT BATTERY ACTIVE SOUND DESIGN ALL ROUND VISION CAMERA AUXILIARY WATER PUMP BASE PLATE BOOSTER BRAKE FLUID LEVEL SWITCH BRAKE LIGHT SWITCH BRN WIRE BRN/BLK WIRE CAN BUS TERMINAL RESISTOR 3 CAN BUS TERMINAL RESISTOR 4 CENTER WASHER NOZZLE HEATER CLUTCH MODULE COOLANT LEVEL SENSOR DIAGNOSTIC SOCKET ELECTRIC AUXILIARY HEATER ELECTRIC FAN ENGINE COMPARTMENT POWER DISTRIBUTION BOX CAPACITOR BOX ETHERNET SWITCH FRONT ELECTRIC AUXILIARY HEATER GRN WIRE HEAD UNIT HEADLIGHT WASHER PUMP CLEANING SYSTEM/ NIGHT VISION CAMERA HIFI AMPLIFIER HOOD CONTACT SWITCH INDEPENDENT AUXILIARY HEATER INDEPENDENT HEATING COOLANT CHANGEOVER VALVE INDEPENDENT HEATING FUEL METERING PUMP LEFT BACKREST REMOTE UNLOCKING ELECTRIC MOTOR LEFT FRONT DOOR SILL LIGHT STRIP LEFT FRONT LANE CHANGE WARNING SLAVE LEFT FRONT NEAR RANGE SIDE RADAR SENSOR LEFT HEADLIGHT LEFT REAR DOOR SILL LIGHT STRIP LEFT WASHER NOZZLE HEATER LIGHT EFFECT MANAGER NCA WIRE POWER CONTROL UNIT 48 VOLTS REAR SEAT ENTERTAINMENT RECEIVER AUDIO MODULE RIGHT FRONT LANE CHANGE WARNING SLAVE RIGHT FRONT NEAR RANGE SIDE RADAR SENSOR RIGHT WASHER NOZZLE HEATER TELEMATIC COMMUNICATION BOX SHIELD TOP HIFI AMPLIFIER USB PORT 2 USB- HUB VIDEO MODULE WASHER FLUID LEVEL SENSOR WIPER MODULE WIRELESS CHARGING ODDMENTS TRAY AERIAL AMPLIFIER

Go to component -> Ground distribution circuit (2 of 6) -> GRN WIRE

grn wiring diagram (23 of 127)

BASIC BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/BLK WIRE CAMERA-BASED DRIVER ASSISTANCE SYSTEMS CAN BUS TERMINAL RESISTOR 6 (ABOVE RIGHT KICK PANEL) ELECTRONIC TRANSMISSION CONTROL EXCEPT HYBRID FRONT ELECTRIC ACTIVE ROLL STABILIZATION FUSE 504 FUSE BOX GEAR SELECTOR SWITCH GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES NCA WIRE ORG/GRN WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/RED WIRE PNK/WHT WIRE POWER CONTROL UNIT REAR VIEW CAMERA RED WIRE RED/GRN WIRE RIGHT END OF DASH) W/O OPTIONAL EQUIPMENT WHT WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE

Go to component -> High/low bus circuit (1 of 9) -> GRN WIRE

grn wiring diagram (24 of 127)

AIR CONDITIONING BASIC BLU WIRE BRN WIRE CAN BUS TERMINAL RESISTOR 9 CRASH SAFETY MODULE DRIVER VEHICLE EXTERIOR MIRROR EXTERIOR MIRROR CAMERA ELECTROMECHANICAL POWER STEERING FRONT CAMERA FRONT PASSENGER VEHICLE EXTERIOR MIRROR EXTERIOR MIRROR CAMERA GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRY/VIO WIRE GRY/WHT WIRE HIGH VARIANT INSTRUMENT PANEL LEFT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL NCA WIRE ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/RED WIRE PNK/WHT WIRE REAR ELECTRIC ACTIVE ROLL STABILIZATION REAR VIEW CAMERA RED/GRN WIRE RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL W/ ALL ROUND VISION CAMERA W/O OPTIONAL EQUIPMENT WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE

Go to component -> High/low bus circuit (2 of 9) -> GRN WIRE

grn wiring diagram (25 of 127)

ACTIVE CRUISE CONTROL ACTIVE SOUND DESIGN BASIC BLU WIRE BRN WIRE BRN/WHT WIRE CAN BUS TERMINAL RESISTOR 4 CAN BUS TERMINAL RESISTOR 5 (LEFT END OF DASH) CONTROLLER (IDRIVE) GRN WIRE GRN/BLU WIRE GRN/GRY WIRE HEAD UNIT HIGH BASIS W/O ETHERNET SWITCH W/ ETHERNET SWITCH LIGHT EFFECT MANAGER NCA WIRE NIGHT VISION ELECTRONICS OPTIONAL EQUIPMENT SYSTEM (LEFT KICK PANEL) ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE PNK/BLU WIRE REAR SEAT ENTERTAINMENT RED/GRN WIRE TELEMATIC COMMUNICATION BOX W/ EXTENDED EQUIPMENT W/ OPTIONAL EQUIPMENT SYSTEM W/O OPTIONAL EQUIPMENT SYSTEM WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/WHT WIRE

Go to component -> High/low bus circuit (4 of 9) -> GRN WIRE

grn wiring diagram (26 of 127)

AUDIO MODE/ HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL BLOWER MOTOR OUTPUT STAGE BLU/GRN WIRE BODY DOMAIN CONTROLLER CENTER CONSOLE CONTROL PANEL DIGITAL MOTOR ELECTRONICS DRIVER'S DOOR SWITCH BLOCK ELECTRIC STEERING COLUMN ADJUSTMENT GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/RED WIRE GRY/VIO WIRE LEFT MULTI-FUNCTION STEERING WHEEL SWITCH CLUSTER LIN POWER DISTRIBUTION BOX NFC READER PNK/BLU WIRE PNK/WHT WIRE REAR AXLE SLIP ANGLE CONTROL REAR POWER DISTRIBUTION BOX RED WIRE REMOTE CONTROL RECEIVER STEERING COLUMN SWITCH CLUSTER STEERING WHEEL MODULE TOUCH DETECTION ELECTRONICS VERTICAL DYNAMICS PLATFORM VIO/WHT WIRE W/ WIRELESS CHARGING STORAGE W/O WIRELESS CHARGING STORAGE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE WIPER MODULE WIRELESS CHARGING STORAGE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> High/low bus circuit (9 of 9) -> GRN WIRE

grn wiring diagram (27 of 127)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM COOLANT LEVEL SENSOR FUEL LEVEL SENSOR FUEL LEVEL SENSOR 2 FUSE 31 FUSE 41 FUSE 61 GRN WIRE HEAD-UP DISPLAY HOT AT ALL TIMES INSTRUMENT PANEL NCA WIRE ORG/ WIRE ORG/GRN WIRE OUTSIDE TEMPERATURE SENSOR RED WIRE RED/BLU WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX SOUND SYSTEMS WHT WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE

Go to component -> Instrument cluster circuit -> GRN WIRE

grn wiring diagram (28 of 127)

AUDIO MODE/HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL BLU/GRN WIRE BODY DOMAIN CONTROLLER BRN/BLK WIRE BRN/YEL WIRE CAMERA-BASED DRIVER ASSISTANCE SYSTEMS CAMERA-BASED DRIVER SUPPORT SYSTEM CAMERA HEATING COMPUTER DATA LINES SYSTEM DRIVER ASSISTANCE SYSTEM OPERATING UNIT W/ HAZARD WARNING SWITCH DRIVER VEHICLE EXTERIOR MIRROR DRIVER'S DOOR SWITCH BLOCK ETHERNET SWITCH FRONT PASSENGER VEHICLE EXTERIOR MIRROR FUSE 10 FUSE 90 GRN WIRE GRN/BLU WIRE GRN/GRY WIRE HOT W/ HOT W/ BI-STABLE RELAY ENERGIZED LANE CHANGE WARNING LED MIRROR ELECTRONICS NCA WIRE RED/BLU WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX STEERING COLUMN SWITCH CLUSTER W/ ETHERNET SWITCH W/O ETHERNET SWITCH WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/BRN/YEL WIRE WHT/GRY WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

Go to component -> Lane departure warning circuit, w/ camera -> GRN WIRE

grn wiring diagram (29 of 127)

BLK WIRE BLU WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM FUSE 214 FUSE 217 FUSE 47 GRN WIRE GRN/RED WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ HOT W/ TERMINAL NCA WIRE NFC READER ANTENNA ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/BLK WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX USB CONNECTION USB PORT 2 WHT WIRE WHT/RED WIRE

Go to component -> Navigation circuit, high level w/ receiver audio module (4 of 6) -> GRN WIRE

grn wiring diagram (30 of 127)

AIR CONDITIONING AUDIO MODE/HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL BLU/WHT WIRE BODY DOMAIN CONTROLLER COMPUTER DATA LINES SYSTEM FUSE 231 FUSE 501 FUSE BOX GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES LIN POWER DISTRIBUTION BOX NCA WIRE ORG/GRN WIRE REAR POWER DISTRIBUTION BOX REAR WINDOW DEFROSTER REAR WINDOW HEATED BAND ELIMINATION CIRCUIT 2 REAR WINDOW HEATING BUTTON REAR WINDOW HEATING RELAY RED WIRE WHT/BLK WIRE

Go to component -> Rear defogger circuit -> GRN WIRE

Page 3 of 13

1 2 3 4 5 6 7 8 9 10 11 12 13

BMW 6 series GT G32 (2017-2020) grn Wiring diagrams

grn wiring diagram (21 of 127)

List of components:

grn wiring diagram (22 of 127)

List of components:

grn wiring diagram (23 of 127)

List of components:

grn wiring diagram (24 of 127)

List of components:

grn wiring diagram (25 of 127)

List of components:

grn wiring diagram (26 of 127)

List of components:

grn wiring diagram (27 of 127)

List of components:

grn wiring diagram (28 of 127)

List of components:

grn wiring diagram (29 of 127)

List of components:

grn wiring diagram (30 of 127)
