Scheme 1
| Index | Explanation |
|---|---|
| 1 | Suspension/damping |
| 2 | Steering |
| 3 | Rear axle |
| 4 | Wheels |
| 5 | Brakes |
| 6 | Front axle |
EXPLANATION CHART
The chassis and suspension of the F10 are based on that of the F01, which set new standards in terms of driving dynamics and comfort. The chassis and suspension have been adapted to the F10 requirements resulting in exceptional driving dynamics with a continued very high level of comfort.
The familiar technological innovations from the F01 like Integral Active Steering, Integrated Chassis Management ICM, Dynamic Drive and Electronic Damper Control EDC are also installed in the F10.
Scheme 2
| Index | Explanation |
|---|---|
| 1 | Wakeable control units |
| 2 | Control units authorized to wake up the vehicle |
| 3 | Startup node control units, for starting up and synchronizing the FlexRay bus system |
| ACC-SEN | Active Cruise Control Sensor |
| ACSM | Advanced Crash Safety Module |
| AL | Active steering |
| AMPH | Amplifier High (high fidelity amplifier) |
| AMPT | Amplifier Top (top high fidelity amplifier) |
| BSD | Bit-serial data interface |
| BCU | Battery Charge Unit (charging unit for auxiliary battery) |
| CAS | Car Access System |
| CIC | Car Information Computer |
| CIC Basic | Car Information Computer Basic |
| CID | Central Information Display |
| CON | Controller |
| D-CAN | Diagnosis on Controller Area Network |
| DDE | Digital Diesel Electronics |
| DME | Digital Motor Electronics |
| DSC | Dynamic Stability Control |
| DVD | DVD changer |
| EDC SHL | Electronic Damper Control, rear left satellite unit |
| EDC SHR | Electronic Damper Control, rear right satellite unit |
| EDC SVL | Electronic Damper Control, front left satellite unit |
| EDC SVR | Electronic Damper Control, front right satellite unit |
| EGS | Electronic transmission control |
| EKPS | Electronic fuel pump control |
| EMF | Electromechanical parking brake |
| EPS | Electronic Power Steering |
| Ethernet | Cabled data network technology for local data networks |
| FD | Rear display |
| FD2 | Rear display 2 |
| FLA | High-beam assistant |
| FlexRay | Fast, preset and fault-tolerant bus system for use in automotive applications |
| FRM | Footwell module |
| FZD | Roof function center |
| GWS | Gear selector switch |
| HKL | Luggage compartment lid lift |
| HSR | Rear suspension slip angle control |
| HUD | Head-Up Display |
| ICM | Integrated Chassis Management |
| IHKA | Integrated automatic heating/air conditioning |
| JBE | Junction box electronics |
| KAFAS | Camera-based driver assistance system |
| K-Bus | Body bus |
| K-CAN | Body controller area network |
| K-CAN2 | Body controller area network 2 (500 kBit/s) |
| KOMBI | Instrument cluster |
| LIN-Bus | Local Interconnect Network bus |
| Local-CAN | Local Controller Area Network |
| MOST | Media Oriented System Transport |
| MOST port | Media Oriented System Transport port |
| NVE | Night Vision electronics |
| PDC | Park Distance Control |
| PMA | Parking Maneuvering Assistant Control Unit |
| PT-CAN | Powertrain CAN |
| PT-CAN2 | Powertrain controller area network 2 |
| OBD | Diagnosis socket |
| RSE | Rear seat entertainment system |
| SDARS | Satellite tuner |
| SMBF | Front passenger seat module |
| SMFA | Seat module, driver |
| SWW | Blind Spot Detection |
| SZL | Steering column switch cluster |
| TCU | Telematics Control Unit |
| TPMS | Tire Pressure Monitoring System |
| TRSVC | Control unit for reversing camera and side view |
| ULF-SBX | Universal charger and hands-free unit, interface box (Bluetooth telephone) |
| VDM | Vertical Dynamics Management |
| VM | Video Module |
| VSW | Video switch |
| ZGM | Central Gateway Module |
EXPLANATION CHART
5.1.2. System overview
The EPS enables average fuel consumption to be reduced by approx. 0.3 I/100 km (0.317 quart/62miles) compared to a conventional hydraulic steering system. This contributes to a reduction of CO 2 emissions.
Scheme 3
| Index | Explanation |
|---|---|
| 1 | Speed reducer |
| 2 | Steering-torque sensor |
| 3 | Track rod |
| 4 | EPS control unit |
| 5 | Electric motor with motor position sensor |
EXPLANATION CHART
The EPS steering replaces the conventional hydraulic steering system. EPS is always equipped with the Servotronic function. Using the drive dynamic control switch, two different adjustments can be achieved: "Normal" and "Sporty".
The EPS is less sensitive to disturbance variables such as bumps and steering wheel vibration. It also contributes to the driving safety of the F10 with an active roll damping.
Because there is no oil in the EPS, it is more environmentally friendly than conventional hydraulic steering systems.
The EPS has Active return to center, this delivers optimum driveability. The EPS also makes it possible for the parking assistance to be implemented for the first time in a BMW vehicle.
