RIDE HEIGHT SPECIFICATIONS
| Application | In. (mm) |
|---|
| Normal Suspension |
| 16" Rim | 23.1 (589) |
| 17" Rim | 23.8 (605) |
| 18" Rim | 24.2 (617) |
| 19" Rim | 24.8 (630) |
| 20" Rim | 25.3 (643) |
| Low Slung Sports Suspension |
| 16" Rim | 22.5 (574) |
| 17" Rim | 23.2 (590) |
| 18" Rim | 23.7 (602) |
| 19" Rim | 24.2 (615) |
| 20" Rim | 24.7 (628) |
| Rough Road Package |
| 16" Rim | 23.8 (607) |
| 17" Rim | 24.5 (623) |
| 18" Rim | 24.9 (635) |
| 19" Rim | 25.5 (648) |
| 20" Rim | 26.0 (661) |
| (1) Specification range is .40" (10 mm). |
| (1) | Specification range is .40" (10 mm). |
RIDE HEIGHT SPECIFICATIONS (1)
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Shock Absorber Piston Rod On Thrust Bearing | 47 (64) |
| Spring Strut Mount-To-Wheel House | 25 (34) |
| Spring Strut Shock Absorber To Pivot Mount | 60 (81) |
Scheme 1
Scheme 1: WHEEL ALIGNMENT SPECIFICATIONS
Scheme 2
Scheme 3
