E60, E61, E63, E64 - PDC Control Unit

Installation location

On the BMW 5-Series, the PDC control unit is located under the spare wheel in the luggage compartment well. The PDC control unit is fitted in the function carrier (illustration shows E60). On the BMW 6-Series, the function carrier is in front of the battery in the luggage compartment well.

Scheme 504

Scheme 504: E60, E61, E63, E64 - PDC Control Unit
KeyExplanationKeyExplanation
1Function carrier2PDC control unit

PDC CONTROL UNIT: E60, E61, E63, E64

Construction

The PDC control unit is connected to the rest of the vehicle electrical system by 3 plug connectors.

Pin assignment for X300, 12-pin

PinTypeDescription
1VPower supply, terminal 15 For vehicles from 03/2004: terminal 30g (active)
2E/ACAN high on K-CAN
3
4
5
6MEarth, terminal 31
7
8E/ACAN low on K-CAN
9
10
11
12
E/A = Input and output
M = Earth
V = Supply
For current specifications regarding pin assignment, please refer to BMW diagnosis system

PIN ASSIGNMENT FOR X300, 12-PIN

Pin assignment for X18013, 18-pin

PinTypeDescription
1AEarth for ultrasonic sensor, rear right
2AEarth for ultrasonic sensor, rear left
3
4
5APower supply for ultrasonic sensor, rear middle right
6APower supply for ultrasonic sensor, rear middle left
7APower supply for ultrasonic sensor, rear right
8APower supply for ultrasonic sensor, rear left
9
10AEarth for ultrasonic sensor, rear middle right
11AEarth for ultrasonic sensor, rear middle left
12ESignal from ultrasonic sensor, rear middle right
13ESignal from ultrasonic sensor, rear middle left
14ESignal from ultrasonic sensor, rear right
15ESignal from ultrasonic sensor, rear left
16
17
18
A = Output
E = Input
For current specifications regarding pin assignment, please refer to BMW diagnosis system

PIN ASSIGNMENT FOR X18013, 18-PIN

Pin assignment for X18362, 18-pin

PinTypeDescription
1AEarth for ultrasonic sensor, front right
2AEarth for ultrasonic sensor, front left
3
4
5APower supply for ultrasonic sensor, front middle right
6APower supply for ultrasonic sensor, front middle left
7APower supply for ultrasonic sensor, front right
8APower supply for ultrasonic sensor, front left
9
10AEarth for ultrasonic sensor, front middle right
11AEarth for ultrasonic sensor, front middle left
12ESignal from ultrasonic sensor, front middle right
13ESignal from ultrasonic sensor, front middle left
14ESignal from ultrasonic sensor, front right
15ESignal from ultrasonic sensor, front left
16
17
18
A = Output
E = Input
For current specifications regarding pin assignment, please refer to BMW diagnosis system

PIN ASSIGNMENT FOR X18362, 18-PIN

PDC incorporates the following functions

  1. Acoustic warnings
  2. Visual warnings
  3. Check Control
