STARTER SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| At 1.4 KW Rated Power (1) | ||
| Hold-In Winding | 10.5 AMP | |
| Pull-In Winding | 54.5 AMP | |
| At 1.7 KW Rated Power (1) | ||
| Hold-In Winding | 9.5 AMP | |
| Pull-In Winding | 51 AMP | |
| At 1.8 KW Rated Power (1) | ||
| Hold-In Winding | 12 AMP | |
| Pull-In Winding | 50 AMP | |
| At 2.0 KW Rated Power (1) | ||
| Hold-In Winding | 10.5 AMP | |
| Pull-In Winding | 54.5 AMP | |
| At 2.2 KW Rated Power With Intermediate Transmission (1) | ||
| Hold-In Winding | 10 AMP | |
| Pull-In Winding | 60 AMP | |
| At 2.0 KW Rated Power With Intermediate Transmission (1) | ||
| Hold-In Winding | 12 AMP | |
| Pull-In Winding | 50 AMP | |
| Axial Armature Play | .1-.2 mm | |
| Carbon Brush Length | At least 13 mm | |
| Testing Voltage | 11.7-12.3 Volts | |
| (1) Current consumption at terminal 50 with rated voltage. | ||
| (1) | Current consumption at terminal 50 with rated voltage. |
STARTER SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Starter-To-Transmission Bell Housing | 33 (45) | |
| INCH Lbs. (N.m) | ||
| Electrical Leads-To-Starter | ||
| 5 mm | 44 (5) | |
| 6 mm | 62 (7) | |
| 8 mm | 115 (13) | |
Torque Specifications
