12 1 300 Adapter set for 134-pin module plug

Minimum set: Measuring and testing equipment

In conjunction with	61 1 459
Note	For diagnosis and troubleshooting on DME and transmission control - from model year 98
Engine	M54, M56, M62, M73, N40, N42, N46, N62, N73
Storage location	N 201, N 202, N 203, N 204
SI number	2 04 97(248)
Order number	12 1 300
	Adapter set for 134-pin module plug
Consisting of
12 1 301	Adapter lead 9-pin
12 1 302	Measurement module 24-pin
12 1 303	Measurement module 40-pin
12 1 304	Measurement module 52-pin
	NOTE: Supplied from 08/2004 in conjunction with 12 1 305 (zero-coded cover cap for new SGM control unit in E6x)

NOTE
Supplied from 08/2004 in conjunction with 12 1 305 (zero-coded cover cap for new SGM control unit in E6x)

ADAPTER SET FOR 134-PIN MODULE PLUG SPECIFICATION

Scheme 159

12 7 050 Adapter lead

Minimum set: Measuring and testing equipment

Note	For engines with rod-type ignition coils for measuring secondary voltage
Engine	M54, M56, N40, N42, N46, N62, N73, S54
Storage location	F 104
SI number	2 01 01 (671)
Order number	12 7 050
	Adapter lead

ADAPTER LEAD SPECIFICATION

Scheme 160

12 7 060 Antistatic mat (ESD)

Note	ESD (Electro Static Discharge) For protection against ESD during repairs to electronic components. (Replaces the sub-number 12 7 192 from Eprom tool kit 12 7 190)
Series	E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53, RR1
SI number	2 06 04(128)
Order number	12 7 060
	Antistatic mat (ESD)

ANTISTATIC MAT (ESD) SPECIFICATION

Scheme 161

12 7 110 Socket wrench socket WAF 24

Minimum set: Mechanical tools

Note	For removing and installing pulley on alternator
Engine	M10, M21, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M57, M57TU, M60, M62, M67, M70, M73, N46, N62, N73, S14, S50B30, S50B32
Storage location	B21
SI number	1 12 93(701)
Order number	12 7 110
	Socket wrench socket WAF 24

SOCKET WRENCH SOCKET WAF 24 SPECIFICATION

Scheme 162

12 7 121 Counterholder wrench

In conjunction with	Socket
Note	Alternator N42 engine
Order number	12 7 121
	Counterholder wrench

COUNTERHOLDER WRENCH SPECIFICATION

12 7 122 Socket

In conjunction with	Counterholder wrench
Note	Hazet 8808 lg 10
SI number	1 28 03(051)
Order number	12 7 122
	Socket

SOCKET SPECIFICATION

12 7 190 Eprom tools / ID marking

Storage location	J 101
Rder number	12 7 190
	Eprom tools / ID marking
Consisting of
1 = 12 7 191	Eprom extractor pliers
2 = 12 7 192	Antistatic mat
NOTE: incl. armband

NOTE
Incl. armband

EPROM TOOLS / ID MARKING SPECIFICATION

12 7 200 Set of tools

Note	For opening & closing control unit box
Storage location	J 106
Order number	12 7 200
	Set of tools
Consisting of
1 = 12 7 201	Pliers
	NOTE: For bending open tab washers
2 = 12 7 202	Lever
	NOTE: For bending tab washers
3 = 12 7 203	Pliers
	NOTE: For closing tab washers
4 = 12 7 204	Torx socket T20
5 = 12 7 205	Torx socket T10
6 = 12 7 206	Fine pen
	NOTE: Black, waterproof
8 = 12 7 208	Slotted screwdriver 2 mm
9 = 12 7 209	Straightening tool
	NOTE: For Eprom connections

NOTE
For bending open tab washers

NOTE
For bending tab washers

NOTE
For closing tab washers

NOTE
Black, waterproof

NOTE
For Eprom connections

SET OF TOOLS SPECIFICATION

12 7 210 Control unit seal

Storage location	J 106
Order number	12 7 210
	Control unit seal
Consisting of
1 = 12 7 211	Seal marks
2 = 12 7 212	Hole punch
	NOTE: For seal mark dating

NOTE
For seal mark dating

CONTROL UNIT SEAL SPECIFICATION
