FRAME & UNDERBODY
The following illustration indicate areas (parts) of the underbody and frame which may be used to raise and support the vehicle, using either floor jack or hoist. These points are indicated by shaded areas on the frame. (Scheme 1)
Note. (Scheme 1) is not intended to represent the exact structure of each vehicle's frame, underbody or body outline. It is presented only to provide reference points.
Locating Jacking & Hoisting Points. Scheme 1
OUTERBODY
Those points designated on the outline of the body were specifically designed to facilitate the use of the vehicle's own jack. These jacking points are indicated by circular dots on the outline of the body. (Scheme 1) If using floor jack or hoist, exercise extreme care to avoid damaging outer body shell.
