Wiring diagram: Headlights — Adaptive front lighting circuit BMW 3 series F30/F31
All systems — 40 systems
- Active bodyworks 4
- Air conditioning 5
- Anti-lock brakes 6
- Anti-theft 6
- Body control modules 3
- Computer data lines 4
- Cooling fan 4
- Cruise control
- Defoggers 12
- Electronic power steering 6
- Electronic suspension 3
- Engine performance 2.0l turbo
- Engine performance 3.0l
- Engine performance 3.0l turbo
- Engine performance 3.0l twin turbo 3
- Exterior lights 8
- Ground distribution 4
- Headlights 12
- Horn 4
- Instrument cluster 4
- Interior lights 12
- Memory systems 14
- Navigation 20
- Passive restraints
- Power distribution 4
- Power door locks 3
- Power mirrors 3
- Power seats 20
- Power top/sunroof 7
- Power windows 7
- Radio 22
- Shift interlock
- Starting/charging 2
- Starting/charging 2.0l turbo 2
- Starting/charging 3.0l 2
- Supplemental restraints 4
- Transmission 8
- Trunk, tailgate, fuel door 4
- Warning systems 4
- Wiper/washer 4
Headlights
# Adaptive front lighting circuit
# Adaptive front lighting circuit (1 of 2)
Components on the diagram
# Adaptive front lighting circuit (2 of 2)
Components on the diagram
Components on these wiring diagrams 26
Click a component to highlight it on every diagram it appears on.
