Engine - Special Tools - E90-E91 (-08); E92/E93 (N51/N52): Other BMW 3 series E90/E91/E92/E93

Mechanical 10 illustrations ~575 words

11 0 240 Coupling

In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225

Note: For adapting test probes to pressure gauge 11 0 162

Engine: All models

Order number: 11 0 240

Coupling

Scheme 316

Scheme 316: 11 0 240 Coupling

11 0 290 Holder

Minimum set: Mechanical tools

Note: For removing and installing triangular drive (vacuum pump) on crankcase.

Engine: N51, N52, N53, N54

SI number: 1 17 04 (130)

Order number: 11 0 290

Holder

Identifying Holder (11 0 290). Scheme 317

Scheme 317: Identifying Holder (11 0 290)

11 0 300 Plug mandrel

Minimum set: Mechanical tools

Note: For locking flywheel in TDC position

Engine: N51, N52, N53, N54

SI number: 1 17 04 (130)

Order number: 11 0 300

Plug mandrel

Identifying Plug Mandrel (11 0 300). Scheme 318

Scheme 318: Identifying Plug Mandrel (11 0 300)

11 1 310 Drift

Note: For driving needle bearing out of crankcase (M20) and pressing out propeller shaft centring mount

Series: E28, E30, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E91, E92, RR1

Order number: 11 1 310

Drift

Scheme 319

Scheme 319: 11 1 310 Drift

11 2 030 Drift

Minimum set: Mechanical tools

In conjunction with: 00 5 500

Note: For driving the guide bearing into the crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving the centring support into the propeller shaft

Series: E28, E30, E32, E34, E36, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E92, RR1

Storage location: A28

Order number: 11 2 030

Drift

Scheme 320

Scheme 320: 11 2 030 Drift

11 3 340 Locking pin (2)

Minimum set: Mechanical tools

Note: For locking chain tensioner piston in position (e.g. when removing and installing cylinder head) as well as for locking drive belt tensioner

Engine: M41, M43, M44, M47, M47T2, M47TU, M51, M57, M57T2, M57TU, M62, N40, N42, N45, N45T, N46, N46T, N47, N51, N52, N53, N54, N62, N73

Storage location: B5, C5

SI number: 1 09 91 (416)

Order number: 11 3 340

Locking pin (2)

11 4 120 Locking pin

Minimum set: Mechanical tools

Note: For chain tensioner to lock chain tensioner piston in position (e.g. when removing and installing cylinder head)

Engine: M43, N51, N52, N53, N54

Storage location: C12

SI number: 1 12 93 (701)

Order number: 11 4 120

Locking pin

Identifying Locking Pin (11 4 120). Scheme 321

Scheme 321: Identifying Locking Pin (11 4 120)

11 4 190 1/4" extension piece

Minimum set: Mechanical tools

In conjunction with: 11 3 390, 00 2 050

Note: M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit

Series: All models

Storage location: B6

SI number: 1 06 94(801)

Order number: 11 4 190

1/4" extension piece

Scheme 322

Scheme 322: 11 4 190 1/4" extension piece

11 4 250 Gauge with adapter plate

Minimum set: Mechanical tools

Note: For securing oil spray nozzles.

Engine: N51, N52

SI number: 1 17 04 (130)

Order number: 11 4 250

Gauge with adapter plate

Consisting of

1 = 11 4 251 Gauge

2 = 11 4 252 Adapter plate

Identifying Gauge With Adapter Plate (11 4 250) Components. Scheme 323

Scheme 323: Identifying Gauge With Adapter Plate (11 4 250) Components

11 4 260 Box spanner

Minimum set: Mechanical tools

Note: For removing and installing lambda oxygen sensors.

Engine: N45T, N51, N52, N53, N54

Storage location: A52

SI number: 1 17 04 (130)

Order number: 11 4 260

Box spanner

Identifying Box Spanner (11 4 260). Scheme 324

Scheme 324: Identifying Box Spanner (11 4 260)

11 9 811 Holder

Order number: 11 9 811

Holder

Scheme 325

Scheme 325: 11 9 811 Holder

11 9 812 Screw

Order number: 11 9 812

Screw
