61 0 021 Fuse link FF 3.15 A / 500 V
Note: For analog/digital multimeter M 2005, M 2007, M2008
Storage location: H 107
Order number: 61 0 021
Fuse link FF 3.15 A / 500 V
61 0 200 Crimping set (basic tool)
Minimum set: Measuring and testing equipment
Note: Consisting of case + basic crimping tool
Series: E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
SI number: 02 02 05 (194)
Order number: 61 0 200
Scheme 227
Crimping set (basic tool)
Consisting of
1 = 61 0 201 Plastic case
Note: As storage system for complete set.
2 = 61 0 202 Crimping tool
Note: Basic tool for assorted matrices (crimping insert set)
3 = 61 0 203 Allen key
Note: For securing individual matrices in crimping tool
61 0 210 Matrix LSK 8
In conjunction with: 61 0 202 (crimping tool)
Note: (crimping insert set for load current contact 8)
SI number: 02 02 05 (194)
Order number: 61 0 210
Matrix LSK 8
Scheme 228
61 0 220 Matrix for SLK 2.8
In conjunction with: 61 0 202 (crimping tool)
Note: (crimping insert set for load contact tube 2.8)
SI number: 02 02 05 (194)
Order number: 61 0 220
Matrix for SLK 2.8
Scheme 229
61 0 230 Stencil for contacts "DFK 40" and "MAK 8"
In conjunction 61 0 202 (crimping tool) with
Note: For crimping contacts when replacing passenger compartment fuse box (up to model year 09/2005)
Series: E46, E65, E66, E67, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
SI number: 02 07 05 233
Order number: 61 0 230
Stencil for contacts "DFK 40" and "MAK 8"
Scheme 230
61 0 300 Releasing tool (complete kit)
Minimum set: Measuring and testing equipment
Note: Replaces from 09/2005 special tool 61 1 150. From 06/2006 extended by tools 61 0 325 - 61 0 331.
Series: E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
Scheme 231
SI number: 2 05 05 (217)
Order number: 61 0 300
Releasing tool (complete kit)
Consisting of
1 = 61 0 301 Release tool for round contacts (diameter 1.5)
Note: Replaces from 09/2005 special tool 61 1 131
2 = 61 0 302 Replacement sleeve D=1.5
Note: Replaces from 09/2005 special tool 61 1 157
In conjunction with: 61 3 301
3 = 61 0 303 Release tool for round systems with D=2.5
Note: Replaces from 09/2005 special tool 61 1 132
4 = 61 0 304 Replacement sleeve (D=2.5)
Note: Replaces from 09/2005 special tool 61 1 156
5 = 61 0 305 Release tool for round contacts (D=3.5)
Note: Replaces from 09/2005 special tool 61 1 133
6 = 61 0 306 Replacement sleeve (D=3.5) for 61 0 305
Note: Replaces from 09/2005 special tool 61 1 155
7 = 61 0 307 Release tool for socket-side round contacts (D=2.5)
8 = 61 0 308 Replacement sleeve for special tool 61 0 307 (D=2.5)
9 = 61 0 309 Release tool for pin-side round contact (D=1.5) manufacturer: Kostal
Note: Replaces from 09/2005 special tool 61 1 139
10 = 61 0 311 Replacement sleeve for special tool 61 0 309
Note: Replaces from 09/2005 special tool 61 1 154
11 = 61 0 312 Release tool for flat spring contact with a detent lug (1.6 mm)
Note: Replaces from 09/2005 special tool 61 1 134
12 = 61 0 313 Release tool for flat spring contacts with a snap-in pin (1.9 mm)
Note: Replaces from 09/2005 special tool 61 1 137
13 = 61 0 314 Release tool for flat spring contact with a snap-in pin (2.7 mm)
Note: Replaces from 09/2005 special tool 61 1 135
14 = 61 0 315 Release tool for flat spring contacts with double snap-in pin "Micro-Timer 2"
Note: Replaces from 09/2005 special tool 61 1 151
15 = 61 0 316 Release tool for flat spring contacts with double snap-in pin "SPT 4.8" "JPT 2.8"
Note: Replaces from 09/2005 special tool 61 1 136
16 = 61 0 317 Release tool for LSK 8
Note: Replaces from 09/2005 special tool 61 1 200
17 = 61 0 318 Release tool for "Maxi Power Timer 9.5"
Note: Replaces from 09/2005 special tool 61 1 180
18 = 61 0 319 Release tool for sensor laminated contacts ("SLK2.8")
Note: Replaces from 09/2005 special tool 61 1 148
19 = 61 0 321 Release tool for sensor laminated contacts with unlocking element ("SLK 2.8")
20 = 61 0 322 Release tool for mini laminated contact ("MLK 1.2 mm")
21 = 61 0 323 Release tool for flat spring contacts with a detent lug (MQS)
Note: Replaces from 09/2005 special tool 61 1 152
22 = 61 0 324 Release tool for secondary locking
Note: Universal tool for damage-free opening/removal of secondary locks
23 = 61 0 329 Case with foam inlay without tools
Note: Storage system for release tools from set 61 0 300
24 = 61 0 325 Release tool "JPT"
25 = 61 0 326 Release tool "MQS"
Note: For releasing all micro contacts
26 = 61 0 327 Plug-in aid
Note: For inserting contacts (0.64 - 1.2 mm) in housing
27 = 61 0 328 Plug-in aid
Note: For inserting contacts (2.8 - 4.8 mm) in housing
28 = 61 0 331 Release tool "SLK 5.8"
Note: For releasing "SLK 5.8 mm" contacts
61 1 190 Pliers
Note: For insulation displacement connectors for repairing ribbon cables
Series: E60, E61, E63, E64, E65, E66, E67, E81, E82, E83, E86, E87, E90, E91, E92, R50, R52, R55, R56, RR1, RR2
SI number: 1 14 01 (766)
Order number: 61 1 190
Pliers
Scheme 232
61 2 250 V-adapter lead (rail pressure sensor)
Minimum set: Measuring and testing equipment
Note: For system check of rail pressure control for common-rail diesel engines. Also suitable for connection to: Crank-/camshaft sensor, boost pressure sensor, particulate filter pressure sensor, swirl flap actuator, oil level sensor etc.
Series: E39, E46, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, E87, E90, E91, E92, E93
SI number: 02 01 06 283
Order number: 61 2 250
V-adapter lead (rail pressure sensor)
Scheme 233
61 2 440 System connecting cable (country-specific)
Note: System connecting cable for battery trickle charger 61 2 410
Order number: 61 2 440
System connecting cable (country specific)
Consisting of
1 = 61 2 441 System connecting cable (country specific)
Note: Algeria / Armenia / Belarus / Belgium / Brazil / Denmark / Dubai / Egypt / Finland / France / Germany / Greece / Korea / Luxembourg / Martinique / Morocco / Norway / Saudi Arabia / Sweden / Spain and others
2 = 61 2 442 System connecting cable (country specific)
Note: Australia / New Zealand
3 = 61 2 443 System connecting cable (country specific)
Note: Italy
4 = 61 2 444 System connecting cable (country specific)
Note: Bahrain / Brunei Dar es Salaam / England / Hong Kong / India / Kuwait / Nigeria / Northern Ireland / Oman / Qatar / Singapore / Sri Lanka (Ceylon)
5 = 61 2 445 System connecting cable (country specific)
Note: Switzerland
6 = 61 2 446 System connecting cable (country specific)
Note: Argentina / Barbados / Canada / China / Guam / Honduras / Jamaica / Mexico / Panama / Philippines / Tahiti / Taiwan / USA
7 = 61 2 447 System connecting cable (country specific)
Note: Japan
61 4 300 Adapter lead for OBD socket
Note: For connecting diagnosis system to OBD socket from 06/2000.
Storage location: Single
SI number: 2 04 00 (561)
Order number: 61 4 300
Adapter lead for OBD socket
Scheme 234
61 4 320 Crimping set with pliers
Minimum set: Measuring and testing equipment
Note: For repairing fibre optics conductors and cables. Universal crimp head 61 4 328 added as from 06/2006.
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
Scheme 235
SI number: 1 14 01 (766)
Order number: 61 4 320
Crimping set with pliers
Consisting of
1 = 61 4 321 Pliers without crimping head
2 = 61 4 322 Crimping head
Note: For stripping insulation and cutting fibre optic cable to length
3 = 61 4 323 Crimping head
Note: For crimping fibre optic cable contacts
4 = 61 4 324 Crimping head
Note: For crimping MQS contacts
5 = 61 4 325 Crimping head
Note: For crimping MPQ contacts
6 = 61 4 326 Substitute blade
Note: For face-cutting fibre optic cables
7 = 61 4 327 Substitute blade
Note: With tool for replacing blade in cable stripping unit. Must be ordered separately, not included in 61 4 320 delivery specification!
8 = 61 4 328 Universal crimping head
Note: For crimping contacts (without seal) and cable cross-sections of 0.35 - 2.5 mm, see .
In conjunction with: in conjunction with 61 4 321
61 4 380 Measuring box, 105-pin, complete
Minimum set: Measuring and testing equipment
Note: For connecting all adapter cables with 61-to 105-pin plug connections
Series: E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
Storage location: G 110, S 205, U 202, U 205
SI number: 2 04 01(710)
Order number: 61 4 380
Scheme 236
Measuring box, 105-pin, complete
Consisting of
1 = 61 4 381 Measuring box, 105-pin
Note: Without accessories
2 = 61 4 382 Test lead, black
Note: 2 mm system, lead length: 750 mm
3 = 61 4 383 Test lead, red
Note: 2 mm system, lead length: 750 mm
4 = 61 4 384 Test lead set
Note: 2/4 mm system, lead length: 200 mm
5 = 61 4 385 Earth/ground cable
Note: For shield pick-off, lead length: 1.5 m
61 4 390 Measuring box, 60-pin
Minimum set: Measuring and testing equipment
Note: For connecting all adapter cables with 27- to 60-pin plug connections
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
Storage location: T 210
Scheme 237
SI number: 2 02 98(308)
Order number: 61 4 390
Measuring box, 60-pin
61 6 100 Angle measuring instrument
Minimum set: Mechanical tools
Note: For measuring contact/approach angle of wiper blades to window (angle when setting wiper arms)
Series: E36, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
SI number: 1 21 05 220
Order number: 61 6 100
Angle measuring instrument
Scheme 238
61 6 110 Setting tool kit
Minimum set: Mechanical tools
Note: For setting wiper arms.
Series: E34, E36, E38, E39, E46, E90, E91, E92, E93
Storage location: A54
SI number: 01 21 05 220
Order number: 61 6 110
Setting tool kit
Consisting of
1 = 61 6 111 Shaped section (2 x)
2 = 61 6 112 Handle (2 x)
Scheme 239
61 6 210 Wiper arm puller
Minimum set: Mechanical tools
Series: E52, E53, E60, E61, E63, E64, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53
SI number: 1 01 05 (172)
Order number: 61 6 210
Wiper arm puller
Scheme 240
61 8 081 Additions to repair kit I
Storage location: K 108
Order number: 61 8 081
Additions to repair kit I
61 8 082 Additions to repair kit II
Storage location: K 108
Order number: 61 8 082
Additions to repair kit II
61 8 083 Additions to repair kit III
Storage location: K 108
Order number: 61 8 083
Additions to repair kit III
61 9 040 Set of tools for repair kit IV
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E83, E85, E87, E90, E91, E92, R50, R52, R53
Storage location: K 108
SI number: 2 02 92(505)
Order number: 61 9 040
Set of tools for repair kit IV
Scheme 241
Consisting of
1 = 61 9 041 Hand pliers without crimper
2 = 61 9 042 Crimper
Note: For crimping butt connectors and contact sleeves for strip connectors
3 = 61 9 043 Cable stripper with wire cutter
4 = 61 9 044 Crimper
Note: For crimping antenna connector (antenna cable/radio plug connection)
61 9 045 Female die
In conjunction with: 61 9 041 Crimping tool
Note: For crimping 2.5 mm (dia.) sleeves
Order number: 61 9 045
Female die
