Power Windows: Wiring BMW 3 series E46

Windows 6 illustrations ~120 words

WIRING DIAGRAMS

Note. Wiring diagrams for BMW 5, 7 and 8-series vehicles are not available from manufacturer at time of publication.

Power Window Wiring Diagram (1997 318i, 318is, 328i, 328is & M3 - 1 Of 2). Scheme 4

Scheme 4: Power Window Wiring Diagram (1997 318i, 318is, 328i, 328is & M3 - 1 Of 2)
Scheme 4: Power Window Wiring Diagram (1997 318i, 318is, 328i, 328is & M3 - 1 Of 2)

Power Window Wiring Diagram (1997 318i, 318is, 328i, 328is & M3 - 2 Of 2). Scheme 5

Scheme 5: Power Window Wiring Diagram (1997 318i, 318is, 328i, 328is & M3 - 2 Of 2)
Scheme 5: Power Window Wiring Diagram (1997 318i, 318is, 328i, 328is & M3 - 2 Of 2)

Power Window Wiring Diagram (1997 318ti & Z3; 1998 Z3). Scheme 6

Scheme 6: Power Window Wiring Diagram (1997 318ti & Z3; 1998 Z3)
Scheme 6: Power Window Wiring Diagram (1997 318ti & Z3; 1998 Z3)

Power Window Wiring Diagram (1998 318i, 323i Convertible, 323is, 328i, 328i Convertible, 328is & M3 - 1 Of 2). Scheme 7

Scheme 7: Power Window Wiring Diagram (1998 318i, 323i Convertible, 323is, 328i, 328i Convertible, 328is & M3 - 1 Of 2)
Scheme 7: Power Window Wiring Diagram (1998 318i, 323i Convertible, 323is, 328i, 328i Convertible, 328is & M3 - 1 Of 2)

Power Window Wiring Diagram (1998 318i, 323i Convertible, 323is, 328i, 328i Convertible, 328is & M3 - 2 Of 2). Scheme 8

Scheme 8: Power Window Wiring Diagram (1998 318i, 323i Convertible, 323is, 328i, 328i Convertible, 328is & M3 - 2 Of 2)
Scheme 8: Power Window Wiring Diagram (1998 318i, 323i Convertible, 323is, 328i, 328i Convertible, 328is & M3 - 2 Of 2)

Power Window Wiring Diagram (1998 318ti). Scheme 9

Scheme 9: Power Window Wiring Diagram (1998 318ti)
Scheme 9: Power Window Wiring Diagram (1998 318ti)
