Engine Controls - Service & Adjustment Specifications: Other

BATTERY

Application	Amp Hr. Rating
M3, 323i, 323is, 328i & 328is	(1) 75
Z3	70
318i	65
318ti	50
528i	70
540i	90
740i & 740iL	55 Or 110
(1) Convertible amp hour rating is 70.

(1)	Convertible amp hour rating is 70.

BATTERY SPECIFICATIONS

GM Transmissions (A5S360R/390R)

Transmission oil pan will be labeled with either Texaco ETL-7045 or Dexron-III. Fill or top off with proper fluid only. DO NOT mix Texaco ETL-7045 and Dexron-III fluids.

ZF 3HP22, 4HP22 & 4HP24

Transmission identification plate can be utilized to determine proper transmission fitted in vehicle. Transmission utilizes Castrol TQ or Texaco Havoline automatic transmission fluids of the Dexron-III formulation. DO NOT mix any other oil with this transmission fluid when doing repairs or topping off.

A5S325Z (5HP19) & A5S440Z (5HP24)

Transmission identification plate can be utilized to determine proper transmission fitted in vehicle. No subsequent transmission fluid changes are necessary. DO NOT mix any other oil with this transmission fluid when doing repairs or topping off. Use ESSO LT 71141 (BMW Part No. 83229407807).

GA6HP26Z

Transmission identification plate can be utilized to determine proper transmission fitted in vehicle. Transmission fluid has a condition based service interval of approximately 100,000 miles. DO NOT mix any other oil with this transmission fluid when doing repairs or topping off. Use Shell M-1375.4 (BMW Part No. 83220142516).

Transmission Without Dipstick

To top off transmission after a repair, put selector lever to setting "P". Vehicle must be horizontal and secured to prevent it from rolling away. Unfasten filler screw. Top off automatic transmission using filler neck attached to filler aperture until oil emerges at filler/overflow bore. (Scheme 1) Start engine. Top off automatic transmission again until oil emerges at filler/overflow bore. Screw in filler plug. (Scheme 2) Operate brake and, with engine at idle speed, shift transmission through all gears several times. Connect BMW Diagnosis and Information System (DIS) and/or BMW MoDiC to vehicle and perform oil level check in accordance with manufacturer's instructions. Replace sealing ring. Tighten drain plug to 11 ft. lbs. (16 N.m).

Scheme 1

Scheme 1: Transmission Without Dipstick

Scheme 2

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed and throttle wide open. The DME master relay and/or fuel pump relay MUST be pulled out for compression test. See ON-VEHICLE ADJUSTMENTS article for additional information.

Application			Specification
Compression Ratio (1)
4-Cylinder			10.0:1
6-Cylinder
2.5L & 3.2L			10.5:1
2.8L			10.2:1
V8			10.0:1
Compression Pressure
All Models			142-156 psi (10-11 kg/cm 2 )
(1) Specification for V12 is not available.

(1)	Specification for V12 is not available.

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Note. All engines use hydraulic valve lifters. Valve adjustment is not required.

CRANKSHAFT (SPEED/POSITION PULSE) SENSOR

Application	Ohms
All Models	70-90

CRANKSHAFT (SPEED/POSITION PULSE) SENSOR RESISTANCE - Ohms @ 68°F (20°C)

CYLINDER IDENTIFYING SENSOR

Application	Ohms
All Models	1150-1410

CYLINDER IDENTIFYING SENSOR RESISTANCE - Ohms @ 68°F (20°C)

IGNITION COIL

Primary	Secondary
.8 (1)	Not Measurable
(1) Specification is approximate.

(1)	Specification is approximate.

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

SPARK PLUGS

Application	Spark Plug
M Roadster & M Coupe	NGK BKR 7 A
M3	Bosch FGR8KQC
All Others	NGK BKR6 EQUP

SPARK PLUG TYPE

Application	Gap In. (mm)	Torque Ft. Lbs. (N.m)
All Models	(1)	15-22 (20-30)
(1) Spark plug gap is not adjustable.

(1)	Spark plug gap is not adjustable.

SPARK PLUG SPECIFICATIONS

FIRING ORDER & TIMING MARKS

Application	Firing Order
4-Cylinder	1 - 3 - 4 - 2
6-Cylinder	1 - 5 - 3 - 6 - 2 - 4
V8	1 - 5 - 4 - 8 - 6 - 3 - 7 - 2
V12	1-7-5-11-3-9-6-12-2-8-4-10
(1) Timing mark information is not available from manufacturer.

(1)	Timing mark information is not available from manufacturer.

FIRING ORDER (1)

Scheme 3

Scheme 3: Firing Order (6-Cylinder)

Scheme 4

Scheme 4: Firing Order (V8)

Scheme 5

Scheme 5: Firing Order (V12)

IGNITION TIMING

Ignition timing is electronically controlled and is not adjustable.

Note. Timing specifications are not available from the manufacturer.

FUEL PUMP

Note. Fuel pump performance is a measurement of fuel pressure and volume availability, not regulated fuel pressure.

Application	Pressure psi (kg/cm 2 )	Min. Vol. In 30 Sec. Pts. (L)
4-Cylinder	43 (3)	1.85 (0.9)
6 & 8-Cylinder	50 (3.5)	1.85 (0.9)
12-Cylinder	50 (3.5)	2.38 (1.13)

FUEL PUMP PERFORMANCE

INJECTOR RESISTANCE

Application	Ohms
All Models (1)	15-17
(1) Injector group resistance should be 7.5-8.5 ohms for 4-cylinder engine and V8 (each bank), and 5-6 ohms for 6-cylinder engine.

(1)	Injector group resistance should be 7.5-8.5 ohms for 4-cylinder engine and V8 (each bank), and 5-6 ohms for 6-cylinder engine.

INJECTOR RESISTANCE - Ohms @ 68°F (20°C)

IDLE SPEED & MIXTURE

Application	Idle RPM	(1) CO Level %
4-Cylinder	810-890	.5-.7
6-Cylinder	660-740	.2-1.2
V8	750-850	.2-1.2
V12	530-630	—
(1) Measured at exhaust manifold. See ON-VEHICLE ADJUSTMENTS article for additional information.

(1)	Measured at exhaust manifold. See ON-VEHICLE ADJUSTMENTS article for additional information.

IDLE SPEED & CO LEVEL

IDLE SPEED CONTROL (ISC) VALVE ()

Application		Ohms
2-Terminal Connector		15-25
3-Terminal Connector
Terminals No. 1 & 2		15-25
Terminals No. 1 & 3		35-45
(1) ISC valve may be a 2-terminal or 3-terminal type.

(1)	ISC valve may be a 2-terminal or 3-terminal type.

ISC VALVE RESISTANCE - Ohms @ 68°F (20°C)

THROTTLE POSITION (TP) SENSOR

Application		Ohms
4-Cylinder
At Idle		3200-4800
At Wide Open Throttle		800-1200
6-Cylinder		4600
(1) V8 and V12 pecification is not available from manufacturer.

(1)	V8 and V12 pecification is not available from manufacturer.

THROTTLE POSITION (TP) SENSOR SPECIFICATIONS (1)
