Removal & Installation
- Remove shifter handle by firmly pulling straight upward. Do not twist handle. Using appropriate trim tool, remove shift selector cover with shift boot. Disconnect harness connectors as needed. Remove outer trim/switch plate. Disconnect harness connectors as needed. Remove storage tray from center console. Unfasten screws securing support tray. Slightly pull support tray out and disconnect switch and cigarette light harness connectors. Remove support tray.
- Disconnect transmission range switch connector. Disconnect shift cable from lever. Remove shift cable housing bolt. Remove shift cable. Remove set screw securing key interlock cable housing clamp. Disconnect key interlock cable.
- Remove lower steering column trim section. Steering wheel removal may be required. Unscrew key interlock cable and remove. Remove cable from vehicle. Note routing of cable for replacement reference.
- To install key interlock cable, reverse removal procedure. Adjust cable. See «KEY INTERLOCK CABLE»(ref-14694-S00567008992000122800000) under ADJUSTMENTS.
