11 0 070 Engine hoist
Note. For removing and installing engines
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N43, N45, N45T, N46, N46T, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Scheme 31
SI number: 1 16 96 (107)
Order number: 11 0 070
Engine hoist
Consisting of
1 = 11 0 071 Lifting beam
2 = 11 0 072 Carrying chain, long
3 = 11 0 073 Carrying chain, short
4 = 11 0 079 Shackle (2 x)
11 0 090 Engine support plates
In conjunction with: 00 1 450
Note. For securing engine on assembly stand
Engine: M40, M42, M43, M43TU, M44
SI number: 1 03 87 (738)
Order number: 11 0 090
Engine support plates
Scheme 32
11 0 190 Accessories
In conjunction with: 11 1 060, 11 1 065, 11 1 067, 11 3 131, 11 3 132
Note. For removing and installing valve springs
Engine: M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M57, M60, M62, M70, M73, S14, S38, S50B30, S50B32, S54, S62
SI number: 1 09 91(416)
Order number: 11 0 190
Accessories
Scheme 33
Consisting of
2 = 11 0 192 Guide tube
Note. Engine: all
4 = 11 0 194 Valve spring cage
Note. Engine: M41, M51, S50
11 0 240 Coupling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note. For adapting test probes to pressure gauge 11 0 162 Engine: All models
Order number: 11 0 240
Coupling
Scheme 34
11 0 340 Accessories
In conjunction with: 11 1 060
Note. For removing and installing valve springs
Engine: M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M57, M57D25, M57D30, M60, M62, M67, M67TU, M70, M73, N40, N42, N62, N73, S14, S38, S50B30, S50B32, S54, S62
SI number: 1 12 93(701)
Order number: 11 0 340
Accessories
Scheme 35
Consisting of
1 = 11 0 341 Valve spring cage
Note. Engine: M43, M73
2 = 11 0 342 Pressure lever
Note. Engine: all, except M10
3 = 11 0 343 Hook
Note. Length 220 mm - Engine: all, except M10
5 = 11 0 345 Valve spring cage
Note. Engine: M44, M52, M62, S62, S54
6 = 11 0 346 Valve spring cage
Note. Engine: M47, M47TU, M57, N40, N42, M67, M67TU
11 1 200 Drift
Minimum set: Mechanical tools
Note. For fitting valve stem seals
Engine: M20, M21, M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N45, S14, S38, S50B30, S50B32, S54, S62
Storage location: B14, C14
Order number: 11 1 200
Drift
Scheme 36
11 1 260 Impact bush
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note. For fitting rotary shaft seal in rear crankshaft end cover
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M47, M50, M51, M52, M57, M57D25, M57D30, S14, S38, S50B30, S50B32, S54
Storage location: C19
SI number: 1 03 95(900)
Order number: 11 1 260
Impact bush
Scheme 37
11 1 270 Fixture
Note. For fitting rotary shaft seal in timing case cover
Engine: M10, M30, M42
Storage location: C7
Order number: 11 1 270
Fixture
Scheme 38
Consisting of
1 = 11 1 271 Nut
Note. Engine: M10
2 = 11 1 272 Nut
Note. Engine: M30
3 = 11 1 273 Thrust ring
Note. Engine: M10, M30, M42
11 1 430 Fixture
In conjunction with: 11 0 316 (M42, M44), 11 1 450 (M50, M52, S50)
Note. For pressure testing cylinder head
Engine: M42, M44, M50, M52, S50B30, S50B32, S54
SI number: 1 05 89(099)
Order number: 11 1 430
Fixture
Scheme 39
Consisting of
1 = 11 1 431 Sealing strip
Note. With 5 pins and rubber seal - Engine: M42, M44, M50, M52, S54
2 = 11 1 432 Rubber seal
Note. For sealing strip 11 1 431 - Engine: M42, M44, M50, M52
3 = 11 1 433 Sealing strip
Note. With 7 pins and rubber seal - Engine: M42, M44, M50, M52, S54
4 = 11 1 434 Rubber seal
Note. For sealing strip 11 1 433 - Engine: M42, M44, M50, M52
5 = 11 1 435 Formed plate
Note. With rubber seal - Engine: M42, M44
6 = 11 1 436 Bridge
Note. With rubber seal and 2 screws - Engine: M42, M44
7 = 11 1 437 Screw plug
Note. With valve and standard clip - Engine: M42, M44, M50, M52, S50
8 = 11 1 438 Screw plug and standard clip
Note. Engine: M42, M44, M50, M52
9 = 11 1 439 Standard parts
Note. Engine: M42, M44, M50, M52
11 1 440 Accessories
In conjunction with: 11 1 060, 11 1 065, 11 1 067, 11 1 068
Note. For removing and installing valve springs
Engine: M42, M44, M47, M47TU, M50, M52, M57, M67
SI number: 1 05 89(099)
Order number: 11 1 440
Accessories
Scheme 40
Consisting of
1 = 11 1 441 Placement board
2 = 11 1 442 Mounting bracket
Note. Engine: M52, M44, M50, M52, M47, M47TU, M57
In conjunction with: 11 1 065
11 1 443 Mounting bracket
Note. Engine: M67
In conjunction with: 11 1 065
11 1 480 Pliers
Minimum set: Mechanical tools
Note. For removing valve stem seal
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N12, N14, N43, N45, N47, N47S, N52, N53, N54, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11
Storage location: B10
SI number: 1 01 93 (621)
Order number: 11 1 480
Scheme 41
Pliers
11 2 010 Extractor
Minimum set: Mechanical tools
Note. For removing guide bearing in crankshaft, stem diameter 12 mm
Engine: M10, M20, M21, M30, M40, M42, M50, M60, M62, S14, S38, S62, S85
Storage location: C25
Order number: 11 2 010
Extractor
Scheme 42
Consisting of
1 = 11 2 011 Extractor claw I
Note. With threaded bush - Engine: except M60, M62
2 = 11 2 012 Extractor claw II
Note. Engine: except M60, M62
3 = 11 2 013 Pressure spindle
Note. Engine: except M60, M62
4 = 11 2 014 Sleeve
Note. Engine: except M60, M62
5 = 11 2 015 Threaded bush
Note. Engine: except M60, M62
6 = 11 2 016 Pressure spindle
Note. Engine: M60/B30, M62, S62
11 2 030 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note. For driving the guide bearing into the crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving the centering support into the propeller shaft
Series: E28, E30, E32, E34, E36, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E92, RR1
Storage location: A28
Order number: 11 2 030
Scheme 43
Drift
11 2 170 Holder
Minimum set: Mechanical tools
Note. For locking flywheel in position
Engine: M20, M21, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, S50B30, S50B32, S54
Storage location: C4
Order number: 11 2 170
Holder
Scheme 44
11 2 250 Torx socket E12
Minimum set: Mechanical tools
Note. With 1/2" extension for releasing and tightening cylinder head bolts
Engine: M42, M43, M44, M50, M52, M60, M62, S85
Storage location: A22
SI number: 1 05 89(099)
Order number: 11 2 250
Torx socket E12
Scheme 45
11 2 290 Placement board
Note. For placing pistons with connecting rods
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M50, M51, M52, M60, M62, M70, M73, M88, S14, S38, S50B30, S50B32
Order number: 11 2 290
Placement board
Scheme 46
11 2 300 Plug mandrel
Minimum set: Mechanical tools
Note. For locking crankshaft in ignition TDC position when adjusting timing
Engine: M21, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57T2, M57TU, M60, M62, M62VAN, M70, M73, S50B30, S50B32, S54, S62
Storage location: C15
Order number: 11 2 300
Plug mandrel
Scheme 47
11 2 310 Extractor tool
Minimum set: Mechanical tools
Note. For removing rotary shaft seal in lower timing case cover
Engine: M40, M42, M43, M44
Storage location: C26
SI number: 1 03 87(739)
Order number: 11 2 310
Extractor tool
Scheme 48
Consisting of
1 = 11 2 311 Extractor
3 = 11 2 313 Thrust piece
Note. Engine: M42, M43, M44
4 = 11 2 314 Spindle M12x150
11 2 330 Mounting plate
Minimum set: Mechanical tools
Note. For timing case cover without removing cylinder head (M42, M43, M44), as well as for mounting top timing case cover (M43, M44)
Engine: M42, M43, M44
Storage location: C10, C11
SI number: 1 05 89(099)
Order number: 11 2 330
Mounting plate
Scheme 49
11 2 340 Extractor
Minimum set: Mechanical tools
In conjunction with: 11 2 016 (M60, M62)
Note. For guide bearing in crankshaft, stem diameter 15 mm
Engine: M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, M60, M62, M70, M73, N40, N42, N43, N45, N45T, N46, N46T, S50B30, S50B32, S54, S62, S85
Scheme 50
Storage location: C11
SI number: 1 05 90 (207)
Order number: 11 2 340
Extractor
Consisting of
1 = 11 2 341 Extractor claw with threaded bush
2 = 11 2 342 Extractor claw
3 = 11 2 343 Pressure spindle
4 = 11 2 344 Sleeve
11 2 350 Drift
Minimum set: Mechanical tools
Note. For fitting guide bearing of crankshaft
Engine: M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M57, M57TU, M60, M62, M70, M73, N40, N42, N43, N45, N45T, N46, N46T, S50B30, S50B32, S52US, S54, S62, S85
Storage location: A15
SI number: 1 05 90 (207)
Order number: 11 2 350
Drift
Scheme 51
11 3 030 Placement board for tappet
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, M88, S14, S38, S50B30, S50B32, S62
Order number: 11 3 030
Placement board for tappet
Scheme 52
11 3 240 Locking fixture
Note. For locking camshaft in position when adjusting timing
Engine: M42, M44, M50, M52, M52TU, M54, M56, S50US, S52US
Storage location: A11
SI number: 1 05 89(099)
Order number: 11 3 240
Locking fixture
Scheme 53
Consisting of
1 = 11 3 241 Gauge for inlet side
2 = 11 3 242 Gauge for exhaust side
4 = 11 3 244 Bracket
Note. For securing camshaft blocking fixture to cylinder head
11 3 250 Suction cup
Minimum set: Mechanical tools
Note. For lifting out tappets in cylinder head
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, S62
Storage location: A 104
SI number: 1 05 89(099)
Order number: 11 3 250
Suction cup
Consisting of
1 = 11 3 251 Sucker (8 x)
Scheme 54
11 3 260 Fixture
Minimum set: Mechanical tools
Note. For evenly pressing down camshaft (with bearing cap) while releasing and tightening camshaft bearing caps
Engine: M42, M50, M52, M52TU, M54, M56, S50US, S52US
SI number: 1 05 89(099)
Order number: 11 3 260
Fixture
Scheme 55
Consisting of
1 = 11 3 261 Assembly fixture
2 = 11 3 262 Fastener bolt (2)
11 4 170 Adapter
Minimum set: Mechanical tools
In conjunction with: 13 3 063 or 13 6 051
Note. For pressure gauge 13 3 061 or BMW DIS for checking oil pressure - Model year: up to 08/95
Engine: M40, M42, M43
Storage location: A2, B2
SI number: 1 12 93(701)
Order number: 11 4 170
Adapter
Scheme 56
11 4 190 1/4" extension piece
Minimum set: Mechanical tools
In conjunction with: 11 3 390, 00 2 050
Note. M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage location: B6
SI number: 1 06 94(801)
Order number: 11 4 190
Scheme 57
1/4" extension piece
11 5 040 Open-ended spanner WAF 32
Minimum set: Mechanical tools
In conjunction with: Torque wrench 3/8" connection
Note. For loosening and tightening fan wheel
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57T2, M57TU, M60, M62, M70, M73, M88, N42, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62
Storage location: B9, C9
Scheme 58
SI number: 01 01 87 (670)
Order number: 11 5 040
Open-ended spanner WAF 32
11 5 050 Holder
Minimum set: Mechanical tools
Note. For pulley while loosening and tightening fan
Engine: M40, M41, M42, M43, M44, M60, M62, N62, S62
Storage location: B3, C3
SI number: 1 03 87(739)
Order number: 11 5 050
Holder
Scheme 59
11 7 020 Socket wrench socket WAF 22
Minimum set: Mechanical tools
Note. For loosening and tightening oxygen sensor
Engine: M10, M20, M30, M40, M42, M50, M52TU, M54, M56, M57, M57T2, M60, M70, M73, N12, N14, N42, N45, N46, N47, N47S, N53, N54, N63, S14, S38, S50B30, S50B32, S50US, S52US, S54, W16
Storage location: A9
Order number: 11 7 020
Socket wrench socket WAF 22
Scheme 60
11 7 300 Placement board
Note. For valves, valve springs, hydraulic tappet, rocker fingers etc.
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M50, M51, M52, M60, M62, M70, M73, M88, S14, S38, S50B30, S50B32, S50US, S52US
Order number: 11 7 300
Placement board
Scheme 61
11 7 450 Simulator
In conjunction with: Standard workshop exhaust emission tester
Note. For Bosch oxygen sensor
Engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, S14, S38, S50B30, S50B32, S50US, S52US
Storage location: K 102
SI number: 2 07 93(700)
Order number: 11 7 450
Simulator
Scheme 62
Consisting of
1 = 11 7 451 Simulator (operator unit)
2 = 11 7 452 4-pin connecting cable, coding A
Note. Connection to wiring harness and oxygen sensor - engine: M40, M42, M43, M50, M70
3 = 11 7 453 4-pin plug connection, coding B
Note. Connection to oxygen sensor - engine: S50/B30
4 = 11 7 454 4-pin plug connection, coding B
Note. Connection to wiring harness - engine: S50/B30
5 = 11 7 455 1- and 3/4-pin plug connection
Note. Connection to oxygen sensor with Bosch or Cannon plug connection - engine: M10, M20, M30, S14
6 = 11 7 456 1- and 3/4-pin plug connection
Note. Connection to wiring harness with Bosch or Cannon plug connection - engine: M10, M20, M30, S14
8 = 11 7 458 Plug-in jumper
8 = 11 7 459 Operating instructions
11 9 000 Cylinder head expander tool
Minimum set: Mechanical tools
In conjunction with: Assembly stand 00 1 450
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N12, N14, N40, N42, N45, N46, N51, N52, N53, N54, N62, N62TU, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Scheme 63
Storage location: Single
SI number: 1 03 02 (833)
Order number: 11 9 000
Cylinder head expander tool
Consisting of
1 = 11 9 001 Fixture
2 = 11 9 002 Rod
3 = 11 9 003 Sliding block with M10 thread
4 = 11 9 004 Tab
5 = 11 9 005 Quick tensioner
6 = 11 9 006 Aluminum profile insert
7 = 11 9 007 Slide
8 = 11 9 008 Profile plastic part
9 = 11 9 009 Lever
10= 11 9 011 Hook
11= 11 9 012 Valve spring cage
Note. Engine M41, M51, S50
12= 11 9 013 Valve spring cage
Note. Engine M43, M73
13= 11 9 014 Valve spring cage
Note. Engine M44, M52, M54, M56, M62, S52, S54, S62
14= 11 9 015 Valve spring cage
Note. Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
15= 11 9 016 Valve spring cage
Note. Engine M21, M40
16= 11 8 421 Valve spring cage
Note. Engine: W10, W11, W17
17= 11 9 017 Valve spring cage
Note. Engine N52
11 9 811 Holder
Order number: 11 9 811
Holder
Scheme 64
11 9 812 Screw
Order number: 11 9 812
Screw
