Wiring diagram: Computer data lines — Computer data lines circuit BMW 1 series E81/E82/E87/E88 facelift

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• 1 2 Can L Can H
• 11 9 Can H Can L
• 18 2 Can L Can H
• 2 1 Can L Can H
• 2 15 Can L Can H
• 2 3 Can H Can L
• 2 8 Can L Can H
• 3 4 Can H Can L
• 4 3 Can L Can H
• 46 33 Can H Can L
• 5 6 Can H Can L
• 5 6 Can L Can H
• 6 2 Can H Can L
• 6 5 Can L Can H
• 6 7 Can H Can L
• 9 16 Can H Can L
• Active Cruise Control
• Active Steering
• Can H Can L Can H
• Can L
• Can-L Can-H
• Car Information Computer Cic
• Center Roof Function Control
• Comfort Access Control Module
• Controller
• Digital Diesel Electronic Control Module
• Dme Control Module
• Drivers Seat Module
• Dsc Sensor
• Dynamic Stability Control
• Electrochromic Interior Rear View Mirror
• Electronically Controlled Fuel Pump
• Footwell Module
• Junction Box
• Junction Box Electronics
• Longitudinal Dynamics Management
• Multi-Drive Sunroof
• Obdii Socket
• Park Distance Control
• Radio Ccc/M-Ask
• Steering Gear
• Td Sig Can H Can L
• Tire Pressure Control
• Trailer Module
• Transfer Box Control Module
• Transmission Control Unit
