Checking Crimping
Check insulation crimp (8) and wire crimp (9) against following illustrations to ensure crimps are correctly located.
Note. Illustration shows butt connectors and contact sleeves for fan connectors knocked on one side. The crimping procedure is identical here.
Scheme 392
Correct crimping
Visible conductor end (10).
Visible insulation end (11).
Scheme 393
Incorrect crimping
Conductor end (10) inserted too far.
Insulation end (11) in wire crimp.
If necessary, repeat crimping with a new contact.
Scheme 394
Incorrect crimping
Conductor end (10) not visible.
Insulation end (11) not visible.
If necessary, repeat crimping with a new contact.
