Engine specifications
| Engine code | AMU | ATC | |
|---|---|---|---|
| Manufactured | From | 10.99 | 07.98 |
| No. of cylinder/valves per cylinder | 4/5 | 4/5 | |
| Capacity | Ltrs | 1.781 | 1.781 |
| Power output | KW @ RPM | 165/5900 | 132/5500-6000 |
| Torque | Nm @ RPM | 280/2200-5500 | 235/2000-4600 |
| Bore | Mm | 81.0 | 81.0 |
| Stroke | Mm | 86.4 | 86.4 |
| Compression ratio | 9.0:1 | 9.5:1 | |
| Engine code | AMU | ATC | |
|---|---|---|---|
| Injection/ignition | Bosch Motronic | Bosch Motronic | |
| RON | Min. | 98 1) premium unleaded (Super Plus) | 98 1) premium unleaded (Super Plus) |
| Hydraulic valve lifters | X | X | |
| On Board Diagnostic (OBD) | X | X | |
| Catalytic converter | X | X | |
| Lambda closed-loop control | X | X | |
| Exhaust gas recirculation | |||
| Turbocharger | X | X | |
1) Premium unleaded gasoline with 95 RON can also be used, but will cause a slight loss of power.
Wheel bolts, tightening to specified torque
Trim cap
Scheme 1
Puller -A- for removing the trim cap is in the vehicle tool kit.
Wheel bolts
The adapter for loosening and tightening the anti-theft wheel bolts is in the vehicle tool kit.
Note. Ensure that wheel bolts are tightened diagonally and alternately to the following tightening torque
| Tightening torque | Nm |
|---|---|
| Wheel bolts | 120 |
- After completing the work, replace adapter and puller in vehicle tool kit.
Oil Capacities > 2000
Note. Oil system capacity with filter change: 4.8 qts. (4.5 liters) Oil system capacity without filter change: 4.2 qts. (4.0 liters)
Oil Capacities 2001 >
> Additional Information, Fluid Capacity Chart for appropriate model year
Viscosity grades
Scheme 2
Select the viscosity grade of the oil according to the chart.
A - High-lubricity multigrade oils; specification. Refer to Oil specifications for vehicles with gasoline engine .
B - Multigrade oils; specification. Refer to Oil specifications for vehicles with gasoline engine .
Note. The oil does not need changing for brief variations of temperature outside the temperature ranges shown.
Viscosity grades and oil specifications
The specifications listed here must appear on the container - either singly or together with other specifications.
Note. When topping off it is permissible to mix different types of oil.
Oil specifications for vehicles with gasoline engine
A - High-lubricity multigrade oils, specification VW 500 00 1)
B - Multigrade oils, specification VW 501 011)
Multigrade oils, specification API-SJ2) or API-SL2)
1) The date given after the VW specification must be not earlier than 10.91.
2) Only use these grades of oil if the approved grades are not available.
- Fill up with engine oil.
