- Insert valve and press firmly against valve seat.
Note. If a valve has to be replaced as part of a repair, use the new valve for the measurement.
Scheme 339
- Measure distance -a- between end of valve stem and upper cylinder head surface with a depth gauge.
- Calculate maximum permissible machining dimension using measured distance and minimum dimension.
| Short intake valve | Long intake valve | Short exhaust valve | Long exhaust valve |
|---|---|---|---|
| 31.8 mm | 10.2 mm | 31.8 mm | 10.2 mm |
MEASURED DISTANCE & MINIMUM DIMENSION SPECIFICATIONS
Distance measured minus minimum dimension = maximum permissible machining dimension.
| Distance measured | 10.6 mm | |
|---|---|---|
| Minimum dimension | 10.2 mm | |
| = | Maximum allowable machining dimension | 0.4 mm |
MAXIMUM PERMISSIBLE MACHINING DIMENSION CALCULATION: EXAMPLE
Note. If the maximum allowed machining dimension is 0 mm or less than 0 mm, repeat the measurement using new valve. If the measurement result is still 0 mm or less than 0 mm, replace the cylinder head.
