Electrical Equipment: Maintenance Audi TT 8N facelift

Cruise Control Systems 4 illustrations ~1468 words

Service Interval Display (SID), resetting after service

Rapid data transfer HELP Select function XX

Indicated on display

  1. Press buttons -1- and -0- and confirm input with Q button.
Adaptation Enter channel number XX

Indicated on display

  1. Press buttons -0- and -2- to access "channel 02"
  2. Press -Q- button to confirm input

Note. The service interval display serves to remind the driver that the vehicle is due for servicing. Messages appear in the Driver's Information Display. The service reminder will first appear 2000 km (1200 mi) before the next service is due. The display message comes up for 5 seconds every time terminal 15 is activated, and changes in steps of 100 km (62 mi.). Example of service interval display message: "SERVICE IN 1300 KM" will appear after the vehicle has been driven 13,700 km.

Note. When the service actually becomes due the message "SERVICE" will appear in the central display window for 5 seconds each time the ignition is switched on. A service is required after an elapsed period of 12 months, even if the distance covered in this time is less than 15,000 km (10,000 mi.). Servicing will always be required every 15000 km (10,000 mi.) in other words the Oil Change and the Inspection Service will be performed together at the end of the 15,000 km (10,000 mi.) interval. The service interval display can also be reset without using VAG 1551 scan tool/1552. Refer to Service interval display, resetting after a service without using VAG 1551/1552 . Software version of instrument cluster. Refer to Instrument cluster On Board Diagnostic (OBD), initiating .

Channel 2 Adaptation 1 --> < - 1 3- >

Indicated on display:: the display will indicate the service interval function

1 - = set service interval: instrument cluster display will then show

"SERVICE"

Note. The service interval display can only be reset via direct input.

  1. Press " button.
Channel 2 Adaptation 1 Enter adaptation value XXXXX

Indicated on display

The service interval is reset (adapted) by entering the following values

Adaptation valueSet / reset service interval
00000Reset
  1. Enter the appropriate adaptation value (00000) via the button pad to reset the service interval.
  2. Press button -0- five times.
Channel 2 Adaptation 1 Q Enter adaptation value 00000

Indicated on display

  1. Press -Q- button to confirm input
Channel 2 Adaptation 0 --> < - 1 3- >

Indicated on display

0 - means service is reset

i.e. "SERVICE IN 15000 km" will be indicated in the instrument cluster after confirming input using the Q-button.

  1. Press -Q- button to confirm input
Channel 2 Adaptation 0 Q Store changed value?

Indicated on display

  1. Press -Q- button to confirm input
Channel 2 Adaptation 0 --> Changed value is stored

Indicated on display

  1. Press --> button to terminate resetting of service interval display.

Service interval display, resetting after a service without using VAG 1551/1552

After a service has been carried out (Oil Change + Inspection Service), the service interval display must be reset accordingly.

The service interval display can be reset using the adaptation function on VAG 1551 scan tool. Refer to Adaptation (function 10) .

The service interval display can also be reset using the following procedure

  1. Switch off ignition.
  2. Press the trip recorder reset button on the instrument cluster and at the same time switch on the ignition.

When the trip recorder reset button is released, the display will show "SERVICE IN ???? km" or "SERVICE."

  1. Within a period of 5 seconds, turn the clock adjuster knob on the instrument cluster counter-clockwise until the message is reset to "SERVICE IN 15000 KM."

The trip recorder display will now read "SERVICE IN 15000 KM."

  1. Switch off ignition.

Fixed service interval values, SID adaptation values

Channel 42 (minimum distance)15000km or 10000 mi
Channel 43 (maximum distance)15000 km or 10000 mi
Channel 44 (maximum time interval until service)365 days
Channel 45 (oil grade, where applicable)1

Note. The descriptions and displays in this section refer only to VAG 1551.

The following adaptation (adjustment) functions are also possible

  1. Adapting fuel gauge sender resistance range
  2. Adapting fuel consumption display
  3. Coding of language versions for on-board computer and Auto Check system
  4. Resetting service interval display
  1. Setting distance/kilometer counter after replacing instrument cluster
Rapid data transfer HELP Select function XX

Indicated on display

  1. Press buttons -1- and -0- and confirm input with Q button.
Adaptation Enter channel number XX

Indicated on display

  1. Press buttons -0- and -2- to access "channel 02"
  2. Press -Q- button to confirm input

Note. The service interval display serves to remind the driver that the vehicle is due for servicing. Messages appear in the Driver's Information Display. The service reminder will first appear 2000 km (1200 mi) before the next service is due. The display message comes up for 5 seconds every time terminal 15 is activated, and changes in steps of 100 km (62 mi.). Example of service interval display message: "SERVICE IN 1300 KM" will appear after the vehicle has been driven 13,700 km.

Note. When the service actually becomes due the message "SERVICE" will appear in the central display window for 5 seconds each time the ignition is switched on. A service is required after an elapsed period of 12 months, even if the distance covered in this time is less than 15,000 km (10,000 mi.). Servicing will always be required every 15000 km (10,000 mi.) in other words the Oil Change and the Inspection Service will be performed together at the end of the 15,000 km (10,000 mi.) interval. The service interval display can also be reset without using VAG 1551 scan tool/1552. Refer to Service interval display, resetting after a service without using VAG 1551/1552 . Software version of instrument cluster. Refer to Instrument cluster On Board Diagnostic (OBD), initiating .

Channel 2 Adaptation 1 --> < - 1 3- >

Indicated on display:: the display will indicate the service interval function

1 - = set service interval: instrument cluster display will then show

"SERVICE"

Note. The service interval display can only be reset via direct input.

  1. Press " button.
Channel 2 Adaptation 1 Enter adaptation value XXXXX

Indicated on display

The service interval is reset (adapted) by entering the following values

Adaptation valueSet / reset service interval
00000Reset
  1. Enter the appropriate adaptation value (00000) via the button pad to reset the service interval.
  2. Press button -0- five times.
Channel 2 Adaptation 1 Q Enter adaptation value 00000

Indicated on display (example only)

  1. Press -Q- button to confirm input
Channel 2 Adaptation 0 --> < - 1 3- >

Indicated on display

0 - means service is reset

i.e. "SERVICE IN 15000 km" will be indicated in the instrument cluster after confirming input using the Q-button.

  1. Press -Q- button to confirm input
Channel 2 Adaptation 0 Q Store changed value?

Indicated on display

  1. Press -Q- button to confirm input
Channel 2 Adaptation 0 --> Changed value is stored

Indicated on display

  1. Press --> button to terminate resetting of service interval display.

After a service has been carried out (Oil Change + Inspection Service), the service interval display must be reset accordingly.

The service interval display can be reset using the adaptation function on VAG 1551 scan tool. Refer to Adaptation (function 10) .

The service interval display can also be reset using the following procedure

  1. Switch off ignition.
  2. Press the trip recorder reset button on the instrument cluster and at the same time switch on the ignition.

When the trip recorder reset button is released, the display will show "SERVICE IN ???? km" or "SERVICE."

  1. Within a period of 5 seconds, turn the clock adjuster knob on the instrument cluster counter-clockwise until the message is reset to "SERVICE IN 15000 KM."

The trip recorder display will now read "SERVICE IN 15000 KM."

  1. Switch off ignition.

Washer fluid reservoir, removing and installing

Note. The washer fluid reservoir supplies washer fluid to both the windshield washers and headlight washer system where equipped.

CAUTIONBefore beginning repairs on the electrical system: Switch off all electrical consumers. Switch ignition off and remove ignition key.

Scheme 19

Scheme 19
Scheme 19
  1. Washer fluid reservoir -1- is located at rear of left wheel housing and secured to fender and A-pillar.

Removing

  1. Lift cap for washer fluid reservoir and remove circlip from filler connection.
  2. Remove front left wheel and wheel housing liner.

Refer to 66 EXTERIOR EQUIPMENT

Scheme 20

Scheme 20
Scheme 20
  1. Remove screws -arrows-.
  2. Lower reservoir slightly in fender opening.

Scheme 21

Scheme 21
Scheme 21
  1. Disconnect electrical connections -1-, -3- and -4
  2. Depress retainer and remove washer hose coupling -2- from pump.
  3. Remove washer hose -5- from pump.
  4. Remove washer fluid hoses from retainers (clips).

Installing

Install in reverse order of removal, noting the following

Note. Ensure washer hose couplings engage audibly when reinstalling.

Tightening torque

ComponentNm
Washer fluid reservoir to body7

Headlight washer fluid reservoir, removing and installing

Note. The washer fluid reservoir supplies washer fluid to both the windshield washers and headlight washer system. Removing and installing. Refer to Washer fluid reservoir, removing and installing .

Scheme 22

Scheme 22: Halogen headlights, assembly
Scheme 22: Halogen headlights, assembly

Note. After performing any repairs or service that could affect headlight aim, check/adjust aim. Refer to Halogen headlights, adjusting . See also: 01 MAINTENANCE .

1 - Headlight housing

  1. Lense bonded to housing, cannot be replaced separately
  2. Removing and installing. Refer to «Headlight housing, removing and installing»(ref-276293-S17125330112008010300000) .

2 - Fog Light bulb -L22-/-L23

  1. H3 - 12 V, 55 W
  2. Replacing. Refer to «Fog light bulbs, replacing»(ref-276293-S37515116252008010300000)

3 - Parking/side marker light bulb -M1-/-M3

  1. H6 - 12 V, 6 W
  2. Replacing. Refer to «Parking/side marker light bulb, replacing»(ref-276293-S09434173352008010300000)

4 - High Beam Headlight bulb -M30-/M32

  1. H7 - 12 V, 55 W
  2. Replacing. Refer to «Halogen high beam bulb, replacing»(ref-276293-S33480908612008010300000)

5 - Bulb holder

  1. for high beam headlight bulb
  2. for parking/side marker light bulb

6 - Cover (small)

7 - Cover (large)

8 - Low Beam Headlight bulb -M29-/M31

  1. H1 - 12 V, 55 W
  2. Replacing. Refer to «Halogen low beam bulb, replacing»(ref-276293-S27775677362008010300000)

9 - Turn signal light bulb bolder

10 - Front Turn Signal Light bulb -M5-/-M7

  1. H21 - 12 V, 21 W
  2. Replacing. Refer to «Turn signal bulb, replacing»(ref-276293-S17298347952008010300000)
