Wiper/washer Systems (Coupe): Overview Audi TT 8J facelift

Wiper/washer Systems 3 illustrations ~283 words

WASHER FLUID RESERVOIR AND FLUID LINES OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 13

Scheme 13: WASHER FLUID RESERVOIR AND FLUID LINES OVERVIEW
Scheme 13: WASHER FLUID RESERVOIR AND FLUID LINES OVERVIEW
  1. Hose Connection For headlamp washer system washer fluid line.
  2. Spray Nozzle Removing and installing, refer to «WINDSHIELD SPRAY NOZZLES»(ref-505650-S23903249412012100100000) .
  3. Electrical Connector For spray jet heating. Depending on the vehicle equipment level.
  4. Washer Fluid Line For nozzle
  5. Grommet For washer fluid line in hood.
  6. Washer Fluid Line Clipped into hood bracket.
  7. Cover For washer fluid reservoir.
  8. Grommet For washer fluid line in fender.
  9. Electrical Connector For headlamp washer system pump.
  10. Headlamp Washer System Pump -V11
  11. Electrical Connector For Windshield Washer Pump -V5-.
  12. Windshield Washer Pump -V5-.
  13. Washer Fluid Line For windshield washer system
  14. Washer Fluid Line For headlamp washer system.

WINDSHIELD WIPER SYSTEM OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 14

Scheme 14: WINDSHIELD WIPER SYSTEM OVERVIEW
Scheme 14: WINDSHIELD WIPER SYSTEM OVERVIEW
  1. Nut 8 Nm
  2. Bracket
  3. Nut 6 Nm
  4. Screw Tightening sequence (Scheme 15).
  5. Nut 17 Nm
  6. Cap
  7. Windshield Wiper Arm, Passenger's Side Different lengths. Removing and installing, refer to «WINDSHIELD WIPER ARMS»(ref-505650-S29816070952012100100000). Adjusting, refer to «WINDSHIELD WIPER ARMS, ADJUSTING»(ref-505650-S12386302892012100100000).
  8. Windshield Wiper Blade, Passenger's Side Different lengths. Replacing, refer to «WINDSHIELD WIPER BLADES, REPLACING»(ref-505650-S42778443602012100100000).
  9. Windshield Wiper Blade, Driver's Side Different lengths. Replacing, refer to «WINDSHIELD WIPER BLADES, REPLACING»(ref-505650-S42778443602012100100000).
  10. Windshield Wiper Arm, Driver's Side Different lengths. Removing and installing, refer to «WINDSHIELD WIPER ARMS»(ref-505650-S29816070952012100100000). Adjusting, refer to «WINDSHIELD WIPER ARMS, ADJUSTING»(ref-505650-S12386302892012100100000).
  11. Cap
  12. Nut 17 Nm
  13. Screw Tightening sequence (Scheme 15).
  14. Windshield Wiper Motor With Wiper Motor Control Module -J400-. Removing and installing, refer to «WINDSHIELD WIPER MOTOR WITH CONTROL MODULE -J400»(ref-505650-S30877258112012100100000).
  15. Screw Tightening sequence (Scheme 15).

Scheme 15

Scheme 15
Scheme 15

Tighten bolts -1, 2, 4- in 2 stages as follows

Tighten bolts by hand.

Tighten bolts to 8 Nm.
