HEX BOLT BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING
Special tools and workshop equipment required
- Angle wrench V.A.G 1756
Loosening
Scheme 1
With vehicle still standing on its wheels, loosen bolt a maximum of 90°, otherwise wheel bearing will be pre-damaged.
Raise vehicle enough that wheels hang freely.
Operate brake (second mechanic required).
Remove bolt -2-.
Tightening
Replace bolt -2-.
Note. Before installing, clean the threads in the constant velocity joint with a tap. Wheels must not yet touch the ground to tighten the drive axle, wheel bearing may otherwise be damaged.
Operate brake (second mechanic required).
Tighten bolt to 200 Nm.
Lower the vehicle onto its wheels.
Tighten bolt an additional 180°.
12-POINT BOLT BETWEEN DRIVE AXLE AND WHEEL HUB, LOOSENING AND TIGHTENING
Special tools and workshop equipment required
- Socket XZN 24T10361
- Angle wrench V.A.G 1756
The wheel bearing must not be under a load while the drive axle threaded connection on the wheel side is loose.
If the bearings are loaded by the vehicle's own weight the wheel bearing will be damaged. This reduces the service life of the wheel bearings. Therefore, observe the following
Vehicles without a drive axle must not be moved, otherwise the wheel bearing will be damaged. If vehicle must be moved, observe the following
Install an outer joint in place of the drive axle.
Tighten outer joint to 120 Nm.
Loosening
Scheme 2
With vehicle still resting on wheels, loosen 12-point bolt with T10361 maximum 90°, otherwise, wheel bearing will be damaged.
Raise vehicle enough that wheels hang freely.
Operate brake (second mechanic required).
Remove 12-point bolt -arrow-.
Note. Before installing, clean the threads in the constant velocity joint with a tap.
Fastening
Replace 12-point bolt.
Note. Wheels must not yet touch the ground to tighten the drive axle, wheel bearing may otherwise be damaged.
Operate brake (second mechanic required).
Tighten 12-point bolt to 70 Nm.
Lower the vehicle onto its wheels.
Tighten 12-point bolt an additional 90°.
FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| ABS Wheel Speed Sensor to Wheel Bearing Housing Bolt | 8 | |
| Ball Joint to Transverse Link Nut (1) | 40 + 45° turn | |
| Ball Joint to Wheel Bearing Housing Nut (1) | 20 + 90° turn | |
| Brake Disc to Wheel Hub Bolt | 4 | |
| Coupling Rod to Stabilizer Bar Nut (1) | 65 | |
| Cover Plate to Wheel Bearing Housing Bolt | 10 | |
| Drive Axle to Transmission Bolt (1) , (5) , (6) | M8 | 40 |
| M10 | 70 | |
| Drive Axle to Wheel Hub Bolt (1) | ||
| Hex Bolt | 200 + 180° turn | |
| 12-Point Bolt | 70 + 90° turn | |
| Level Control System Sensor to Subframe Bolt | 9 | |
| Level Control System Sensor to Transverse Link Nut | 9 | |
| Lower Bonded Rubber Bushing for Pendulum Support to Subframe Bolt (1) , (3) | 100 + 90° turn | |
| Shock Absorber to Suspension Strut Bearing Nut (1) | 60 | |
| Stabilizer Bar to Subframe Bolt (1) | 20 + 90° turn | |
| Subframe to Body Bolt (1) | 70 + 90° turn | |
| Suspension Strut to Suspension Strut Dome Bolt (1) | 15 + 90° turn | |
| Suspension Strut to Wheel Bearing Housing Bolt (1) , (4) | 70 + 90° turn | |
| Tie Rod End to Wheel Bearing Housing Nut (1) | 20 + 90° turn | |
| Transverse Link Mounting Bracket to Body Bolt (1) | 70 + 90° turn | |
| Transverse Link Mounting Bracket to Subframe Bolt (1) | 50 + 90° turn | |
| Transverse Link to Subframe Bolt (1) , (2) | 70 + 180° turn | |
| Wheel Hub to Wheel Bearing Housing Bolt (1) | 70 + 90° turn | |
| (1) Always replace after removal. (2) Tighten only in curb weight position. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION . (3) Only tighten when pendulum support is bolted to transmission. (4) Bolt point must face in direction of travel. (5) Pre-tighten diagonally to 10 Nm. (6) Tighten diagonally. | ||
| (1) | Always replace after removal. |
| (2) | Tighten only in curb weight position. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION . |
| (3) | Only tighten when pendulum support is bolted to transmission. |
| (4) | Bolt point must face in direction of travel. |
| (5) | Pre-tighten diagonally to 10 Nm. |
| (6) | Tighten diagonally. |
