INSTRUMENT CLUSTER AND CLOCK RECEIVER OVERVIEW

Note. All warning lamps in instrument cluster are fitted with light-emitting diodes. In case an indicator lamp is malfunctioning, the instrument cluster must be replaced.

Scheme 1

Scheme 1: INSTRUMENT CLUSTER AND CLOCK RECEIVER OVERVIEW
  1. Screw 2.5 Nm
  2. Instrument Cluster With the instrument cluster control module -J285-. Removing and installing, refer to «INSTRUMENT CLUSTER»(ref-505564-S09115551842012100100000) .
  3. Electrical connector For instrument cluster.
  4. Screw 2.5 Nm
  5. Gap Cover Removing and installing, refer to Storage Compartments and Covers in «Removal and Installation»(ref-505590-S04428671492012100100000) .
  6. Screw 2.5 Nm
  7. Electrical Connector For Radio Frequency Controlled Clock Receiver -J489-.
  8. Screw 2.5 Nm
  9. Radio Frequency Controlled Clock Receiver -J489- Removing and installing, refer to «RADIO FREQUENCY CONTROLLED CLOCK RECEIVER -J489»(ref-505564-S01957347222012100100000) .

SIGNAL HORNS OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 2

Scheme 2: SIGNAL HORNS OVERVIEW
  1. Electrical Connector For High Tone Horn -H2
  2. Nut 9 Nm
  3. High Tone Horn -H2- Removing and installing, refer to «HORNS -H2- / -H7»(ref-505564-S40095050802012100100000) .
  4. Low Tone Horn -H7- Removing and installing, refer to «HORNS -H2- / -H7»(ref-505564-S40095050802012100100000) .
  5. Nut 9 Nm
  6. Electrical connector For Low Tone Horn -H7-.
  7. Bracket For signal horns.
