OUTER CV JOINT, INSTALLING Audi TT 8J facelift

Front Suspension (Roadster) 3 illustrations ~127 words

OUTER CV JOINT, INSTALLING

Before installing CV joint or triple roller star, splines -A- must be lightly coated with grease used in joint.

Install old drive shaft bolt in joint as shown in the illustration.

Drive joint onto shaft with plastic hammer until circlip engages.

Inner CV joint, Disassembling and Assembling

Scheme 229

Scheme 229
Scheme 229

Drive cover down with copper or brass drift.

Scheme 230

Scheme 230: Pressing Off Inner Constant Velocity Joint
Scheme 230: Pressing Off Inner Constant Velocity Joint

Drive out CV joint boot with a drift.

Support ball hub when pressing off.

Before installing CV joint or triple roller star, splines -A- must be lightly coated with grease used in joint.

Scheme 231

Scheme 231
Scheme 231

Press on joint until stop.

Install circlip.

Note. Chamfer on inner diameter of ball hub (splines) must face the contact shoulder on the drive axle.
