ERROR MESSAGES ON SCREEN Audi TT 8J facelift

Communication (Roadster) 5 illustrations ~1325 words

ERROR MESSAGES ON SCREEN

If there is a malfunction in the system, either a fault is saved in the DTC and/or an error message is given on the navigation system with CD drive control module display.

The following fault messages can be displayed

Indicator in display

CD/DVD is unreadable Please check the CD/DVD

This error message appears

  1. Navigation DVD cannot be read.
  2. DVD is faulty.
  3. DVD drive is faulty.

See if drive can read a replacement DVD.

Same error

Perform in adaptation channel 41.

Use the vehicle diagnosis, testing and information system to do so.

Indicator in display

CD/DVD drive defect. Unable to read data. Consult your dealer.

This error message appears

  1. Drive cannot read DVD data.
  2. DVD is faulty.
  3. DVD drive is faulty.

See if drive can read a replacement DVD.

Same error

Perform in adaptation channel 41.

Use the vehicle diagnosis, testing and information system to do so.

Scheme 161

Scheme 161: RNS-E, OVERVIEW
Scheme 161: RNS-E, OVERVIEW
  1. Satellite antenna -R170- On The Rear Lid
  2. Telephone Antenna -R65- Behind Front Interior Light -W1
  3. Navigation System Antenna -R50- Behind Front Interior Light -W1
  4. Radio Antenna 2 -R93- (FM2) Behind Right Side Of Rear Lid
  5. Antenna -R11- (AM/FM1) Left Rear Mast Antenna
  6. Antenna Amplifier -R24- Left Rear Mast Antenna Base
  7. Antenna Selection Control Module -J515- In Luggage Compartment Under The Luggage Compartment Floor Covering In the center
  8. Antenna Amplifier 2 -R111- Behind Right Side Of Rear Lid
  9. External audio source connection -R199- In The Center Console Storage Compartment
  10. Navigation System with CD Drive Control Module -J401- In Top Of Center Console
  11. Sound Systems
  12. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
  13. Satellite radio -R146- Inside The Luggage Compartment On The Left Side Under The Luggage Compartment Floor Covering
  14. CAN-BUS (Infotainment)
  15. Telephone Transceiver -R36- In Electronics Box Under Left Front Seat

Scheme 162

Scheme 162: NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE, HARNESS CONNECTORS
Scheme 162: NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE, HARNESS CONNECTORS
  1. GPS connection (blue) from Radio, Telephone, Navigation System Antenna -R52- Coupe - GPS connection (blue) from Navigation System Antenna -R50- Roadster
  2. Connection Block With Four Multi-Pin Connectors And A Fuse For Unit
  3. Front Passenger's Airbag Disabled Indicator Lamp -K145
  4. IF Connection (White) To Antenna Amplifier 2 -R111- Coupe - IF Connector (White) To The Antenna Selection Control Module -J515- Roadster
  5. HF (white) Connection From Antenna Amplifier 2 -R111- Coupe - HF Connector (White) From The Antenna Selection Control Module -J515- Roadster
  6. 32-pin Connector (T32b) From The External Audio Source Connection -R199

Note. Unlisted connector terminals are not assigned.

2 - Right front speaker (+) (not used)

3 - Left front speaker (+) (not used)

6 - Right front speaker (-) (not used)

7 - Left front speaker (-) (not used)

2 - Signal ground to CD changer/satellite radio

3 - Speed signal (not used)

4 - Permanent positive to CD changer

5 - K diagnostic (not used)

6 - Data out to the CD changer

7 - BOSE coding to ground (only with BOSE)

8 - Left signal from CD changer/satellite radio

9 - Right signal from CD changer/satellite radio

10 - Positive switched to CD changer

11 - Data in from the CD changer

12 - CLK from the CD changer

2 - Signal from back-up light switch (not used)

3 - Left front signal to digital sound system control module

5 - Left rear signal to digital sound system control module

6 - LF (-) from telephone transceiver

8 - Signal ground to digital sound system control module

9 - Right front signal to digital sound system control module

11 - Right rear signal to digital sound system control module

12 - LF (+) from telephone transceiver

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute from telephone transceiver

12 - Terminal 31

13 - Positive switched to digital sound system control module

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive (not used)

Scheme 163

Scheme 163
Scheme 163

6 - Right LF-IN from the external audio source connection

21 - LF-IN ground from the external audio source connection

22 - Left LF-IN from the external audio source connection

Scheme 164

Scheme 164: COMPONENT LOCATIONS, GENERAL OVERVIEW
Scheme 164: COMPONENT LOCATIONS, GENERAL OVERVIEW
  1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(ref-505806-S08273139922012100100000)
  2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(ref-505806-S17677450342012100100000)
  3. Navigation System Antenna -R50- Behind Front Interior Light Overview, refer to «ANTENNAS, OVERVIEW»(ref-505806-S11833182942012100100000)
  4. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(ref-505806-S42818839662012100100000)
  5. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In left and right rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(ref-505806-S15519257102012100100000)
  6. Antenna Selection Control Module -J515- Inside the luggage compartment under the luggage compartment floor covering in the center Overview, refer to «ANTENNAS, OVERVIEW»(ref-505806-S11833182942012100100000)
  7. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(ref-505806-S11833182942012100100000)
  8. Satellite Antenna -R170- On rear lid Overview, refer to «ANTENNAS, OVERVIEW»(ref-505806-S11833182942012100100000)
  9. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(ref-505806-S36936770672012100100000) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(ref-505806-S27850514062012100100000) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(ref-505806-S03125416612012100100000) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(ref-505806-S40829474682012100100000) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(ref-505806-S12840300262012100100000)
  10. Antenna Amplifier -R24- Left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(ref-505806-S11833182942012100100000)
  11. Satellite Radio -R146- Inside the luggage compartment on the left side under the luggage compartment floor covering Connectors. Refer to «SATELLITE RADIO CONNECTORS, THROUGH 10/06»(ref-505806-S42038349562012100100000) . Removing and installing, activating, refer to «SATELLITE RADIO»(ref-505806-S26094495852012100100000)
  12. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(ref-505806-S42818839662012100100000)
  13. Center speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(ref-505806-S41267193382012100100000)
  14. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(ref-505806-S09551314202012100100000)
  15. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(ref-505806-S21521042142012100100000)
  16. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(ref-505806-S08273139922012100100000)
  17. Navigation System with CD Drive Control Module -J401- In the top of the center console Connectors, refer to «NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE, HARNESS CONNECTORS»(ref-505806-S23505092492012100100000) . Removing and installing, refer to «NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE»(ref-505806-S01521657512012100100000)
  18. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(ref-505806-S12754082282012100100000) . Removing and installing, refer to «CD CHANGER»(ref-505806-S24610412052012100100000) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(ref-505806-S18480363032012100100000) . Removing and installing, refer to «IPOD BASEPLATE»(ref-505806-S37028652382012100100000) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source) refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(ref-505806-S12328703322012100100000) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(ref-505806-S33319348732012100100000) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(ref-505806-S37380003002012100100000) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(ref-505806-S16067272242012100100000) .

Scheme 165

Scheme 165: JP4, OVERVIEW
Scheme 165: JP4, OVERVIEW
  1. Radio Antenna 2 -R93- (FM2/TV1) Behind Right Side Of Rear Lid
  2. Antenna (TV2) Right Of Windshield
  3. Antenna -R11- (AM/FM1) Left Rear Mast Antenna
  4. Antenna (TV3) Left Of Windshield
  5. Navigation System Antenna -R50- Behind Front Interior Light -W1
  6. GPS Connection (Blue) From Navigation System Antenna -R50
  7. 12-pin Black Multi-Pin Connector (T12h) From Digital Sound System Control Module -J525
  8. Digital sound system control module -J525- Behind The Luggage Compartment Left Side Trim
  9. Sound Systems
  10. 2-pin Black Multi-Pin Voltage Supply Connection (T2l)
  11. Black 2-pin Multi-pin CAN BUS (Infotainment) Connection (T2m)
  12. TV1/TV2 Connection (Brown) From Antenna Amplifier 2 -R111- /TV Antenna 2 -R56
  13. AM/FM1 connection (white) from Antenna Amplifier -R24
  14. TV3 Connection (Green) From TV Antenna 3 -R57
  15. TV Antenna 3 -R57- Behind The Left A-Pillar Trim
  16. Antenna Amplifier -R24- Left Rear Mast Antenna Base
  17. TV Antenna 2 -R56- Behind The Right A-Pillar Trim
  18. Antenna Amplifier 2 -R111- Behind Right Side Of Rear Lid
