Communication (Coupe): Overview Audi TT 8J facelift

FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW

1 - Black 4-pin multi-pin harness connector (T4g)

1 - Microphone 1 to telephone transceiver

2 - Microphone 1 to telephone transceiver

3 - Microphone 2 to digital sound system control module

4 - Microphone 2 to digital sound system control module

2 - Microphone 1

3 - Microphone 2

ROADSTER COMPONENT LOCATIONS, GENERAL OVERVIEW

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(ref-505665-S01723450452012100100000)
2. TV Antenna 2 -R56- Behind the A-pillar trim on the right side Overview, refer to «ANTENNAS, OVERVIEW»(ref-505665-S13216544922012100100000)
3. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(ref-505665-S30255599672012100100000)
4. Navigation System Antenna -R50- Behind front interior light Overview, refer to «ANTENNAS, OVERVIEW»(ref-505665-S13216544922012100100000)
5. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(ref-505665-S14501279722012100100000) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(ref-505665-S01109047202012100100000)
6. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(ref-505665-S17197150412012100100000)
7. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(ref-505665-S14475227682012100100000)
8. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(ref-505665-S13216544922012100100000)
9. Antenna Amplifier -R24- Left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(ref-505665-S13216544922012100100000)
10. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(ref-505665-S38559537902012100100000) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(ref-505665-S31648047042012100100000) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(ref-505665-S42440054442012100100000) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(ref-505665-S00873717142012100100000) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(ref-505665-S35767270092012100100000)
11. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(ref-505665-S17197150412012100100000)
12. Center Speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(ref-505665-S00904147632012100100000)
13. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(ref-505665-S16236300872012100100000)
14. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(ref-505665-S32316424482012100100000)
15. TV Antenna 3 -R57- Behind the A-pillar trim on the left side Overview, refer to «ANTENNAS, OVERVIEW»(ref-505665-S13216544922012100100000)
16. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(ref-505665-S01723450452012100100000)
17. RNS-JP5 Connections/Antenna Connections In the top of the center console Connectors, refer to «CONNECTORS AND CONNECTOR ASSIGNMENTS»(ref-505665-S27344535472012100100000) .
18. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(ref-505665-S06956437612012100100000) . Removing and installing, refer to «CD CHANGER»(ref-505665-S42781384422012100100000) - iPod Baseplate -R192- Connectors Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(ref-505665-S11106673802012100100000) . Removing and installing, refer to «IPOD BASEPLATE»(ref-505665-S11754066252012100100000) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source), refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(ref-505665-S31924605882012100100000) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(ref-505665-S17823356262012100100000) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(ref-505665-S25935289962012100100000) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(ref-505665-S35049698662012100100000) .

Scheme 1

1. Radio, Telephone, Navigation System Antenna -R52
2. Nut 6 Nm
3. Radio/Navigation Display Control Module -J503
4. Radio Removal Tool T10057

Scheme 2

1. Navigation System Antenna -R50- /Telephone Antenna -R65
2. Screw 2 Nm
3. Radio/Navigation Display Control Module -J503
4. Radio Removal Tool T10057

Scheme 3

1. Rear Window Antennas
2. Antenna Amplifier 2 -R111- On Lower Right Area Of Rear Lid
3. Sound Systems
4. Radio/Navigation Display Control Module -J503- In Top Of Center Console
5. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
6. CAN-BUS (Infotainment)
7. External audio source connection -R199- In The Center Console Storage Compartment
8. Telephone Transceiver -R36- In Electronics Box Under Left Front Seat
9. Antenna Amplifier -R24- On Upper Right Side Of Rear Lid
10. Radio, Telephone, Navigation System Antenna -R52- Roof Antenna

Scheme 4

1. Antenna -R11- (AM/FM1) Left Rear Mast Antenna
2. Radio Antenna 2 -R93- (FM2) Behind Right Side Of Rear Lid
3. Antenna Amplifier 2 -R111- Behind Right Side Of Rear Lid
4. Sound Systems
5. Radio/Navigation Display Control Module -J503- In Top Of Center Console
6. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
7. CAN-BUS (Infotainment)
8. External audio source connection -R199- In The Center Console Storage Compartment
9. Telephone Transceiver -R36- In Electronics Box Under Left Front Seat
10. Antenna Amplifier -R24- Left Rear Mast Antenna Base
11. Telephone Antenna -R65- Behind Front Interior Light -W1
12. Navigation System Antenna -R50- Behind Front Interior Light -W1

Scheme 5

1. Connection Block With Four Multi-Pin Connectors And A Fuse For Unit
2. Front Passenger's Airbag Disabled Indicator Lamp -K145
3. GPS Connection (Blue) From Radio, Telephone, Navigation System Antenna -R52- Coupe - GPS Connection (Blue) From Navigation System Antenna -R50- Roadster
4. IF Connection (White) To Antenna Amplifier 2 -R111
5. HF (white) Connection From Antenna Amplifier 2 -R111

Note. Unlisted connector terminals are not assigned.

2 - Right front speaker (+) (not used)

3 - Left front speaker (+) (not used)

6 - Right front speaker (-) (not used)

7 - Left front speaker (-) (not used)

1 - Left LF-In from the external audio source connection

2 - Signal ground to CD changer/iPod base plate

3 - LF-In ground from the external audio source connection

4 - Continuous plus to the CD changer/iPod base plate

5 - BOSE coding to ground (only with BOSE)

6 - CD data to CD changer/iPod base plate

7 - Right LF-In from the external audio source connection

8 - Left signal from CD changer/iPod base plate

9 - Right signal from CD changer/iPod base plate

10 - Positive switched to CD changer/iPod base plate

11 - CD data in from the CD changer/iPod base plate

12 - CLK from CD changer/iPod base plate

1 - Speed signal (not used)

2 - Signal from back-up light switch (not used)

3 - Left front signal to digital sound system control module

5 - Left rear signal to digital sound system control module

6 - LF (-) from telephone transceiver/preliminary setup for cellular telephone package

7 - K diagnostic (not used)

8 - Signal ground to digital sound system control module

9 - Right front signal to digital sound system control module

11 - Right rear signal to digital sound system control module

12 - LF (+) from telephone transceiver/preliminary setup for cellular telephone package

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute from preliminary setup for cellular telephone preparation

12 - Terminal 31

13 - Positive switched to digital sound system control module

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive to PIN 15 (anti-theft protection)

Scheme 6

1. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(ref-505665-S01723450452012100100000)
2. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(ref-505665-S06956437612012100100000) . Removing and installing, refer to «CD CHANGER»(ref-505665-S42781384422012100100000) - iPod Baseplate In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(ref-505665-S11106673802012100100000) . Removing and installing, refer to «IPOD BASEPLATE»(ref-505665-S11754066252012100100000) - External audio source connection Inside the glove compartment / center console Connectors (connection for an external audio source) refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(ref-505665-S31924605882012100100000) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(ref-505665-S17823356262012100100000) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(ref-505665-S25935289962012100100000) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(ref-505665-S35049698662012100100000) .
3. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(ref-505665-S30255599672012100100000)
4. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(ref-505665-S14501279722012100100000) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(ref-505665-S01109047202012100100000)
5. Antenna Amplifier -R24- On upper right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(ref-505665-S40624478342012100100000)
6. Radio, Telephone, Navigation System Antenna -R52- Overview, refer to «ANTENNAS OVERVIEW»(ref-505665-S40624478342012100100000)
7. Antenna Amplifier 2 -R111- On lower right of rear lid Overview, refer to «ANTENNAS OVERVIEW»(ref-505665-S40624478342012100100000)
8. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(ref-505665-S38559537902012100100000) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(ref-505665-S31648047042012100100000) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(ref-505665-S42440054442012100100000) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(ref-505665-S00873717142012100100000) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(ref-505665-S35767270092012100100000)
9. Left Rear Treble Speaker -R14- /Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(ref-505665-S17197150412012100100000)
10. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- Behind rear side trim Removing and installing, refer to «LEFT REAR MID/LOW RANGE LOUDSPEAKER, COUPE»(ref-505665-S26803453132012100100000)
11. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(ref-505665-S16236300872012100100000)
12. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(ref-505665-S32316424482012100100000)
13. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(ref-505665-S01723450452012100100000)
14. Radio/Navigation Display Control Module -J503- In the top of the center console Connectors, refer to «RADIO/NAVIGATION DISPLAY CONTROL MODULE, CONNECTIONS»(ref-505665-S34293640402012100100000) . Removing and installing, refer to «RADIO/NAVIGATION DISPLAY CONTROL MODULE»(ref-505665-S33052293612012100100000)

Scheme 7

1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(ref-505665-S01723450452012100100000)
2. Center Mid/High Range Loudspeaker -R158- In front instrument panel, center Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(ref-505665-S30255599672012100100000)
3. Navigation System Antenna -R50- Behind front interior light Overview, refer to «ANTENNAS, OVERVIEW»(ref-505665-S13216544922012100100000)
4. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(ref-505665-S14501279722012100100000) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(ref-505665-S01109047202012100100000)
5. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(ref-505665-S32316424482012100100000)
6. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(ref-505665-S14475227682012100100000)
7. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(ref-505665-S13216544922012100100000)
8. Antenna Amplifier -R24- Left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(ref-505665-S13216544922012100100000)
9. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(ref-505665-S38559537902012100100000) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(ref-505665-S31648047042012100100000) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(ref-505665-S42440054442012100100000) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(ref-505665-S00873717142012100100000) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(ref-505665-S35767270092012100100000)
10. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(ref-505665-S32316424482012100100000)
11. Center speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(ref-505665-S00904147632012100100000)
12. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(ref-505665-S16236300872012100100000)
13. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(ref-505665-S32316424482012100100000)
14. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(ref-505665-S01723450452012100100000)
15. Radio/Navigation Display Control Module -J503- In the top of the center console Connectors, refer to «RADIO/NAVIGATION DISPLAY CONTROL MODULE, CONNECTIONS»(ref-505665-S34293640402012100100000) . Removing and installing, refer to «NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE»(ref-505665-S29100042562012100100000)
16. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(ref-505665-S06956437612012100100000) . Removing and installing, refer to «CD CHANGER»(ref-505665-S42781384422012100100000) - iPod Baseplate In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(ref-505665-S11106673802012100100000) . Removing and installing, refer to «IPOD BASEPLATE»(ref-505665-S11754066252012100100000) - External audio source connection Inside the glove compartment / center console Connectors (connection for an external audio source), refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(ref-505665-S31924605882012100100000) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(ref-505665-S17823356262012100100000) . Removing and installing (connection for an external audio source), refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(ref-505665-S25935289962012100100000) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(ref-505665-S35049698662012100100000) .
