LEFT OR RIGHT RELEASE
Special tools and workshop equipment required
- Trim removal wedge 3409
Note. Removal and installation of the left release is described for a left 1/2 backrest. Removal and installation of the right release is the same.
Removing
Remove the backrest. Refer to BACKREST
Remove left trim. Refer to LEFT OR RIGHT TRIM .
Disengage piping on front part of cover -1- from clamping strip on rear of cover -2-.
Scheme 219
Disengage tab on front part of cover -1- at backrest frame -3-.
Scheme 220
Open cover zip fastener.
Fold cover to side.
Remove filler piece -3-. Refer to OUTER LEFT OR RIGHT SPACER .
Scheme 221
- Backrest shell
- Release cable
Open cable tie -3-.
Scheme 222
Unclip release cable -2- from bracket -4-.
Disengage release cable hook -2- on lever -5-.
Thread release cable -2- through opening in back of cover -arrow-.
Pull the cover -1- up just enough so that the screws -2- are visible.
Scheme 223
Remove the bolts -2-.
Loosen upholstery from self-adhesive strips -4- on backrest frame in release area.
Scheme 224
Press upholster -1- to side in release area -2- until bolt -3- is visible.
Remove the bolt -3-.
Remove release with release cable -2- from backrest shell -5-.
Note. Release cable is not designed to be disconnected from the release.
Installation
Install in reverse order of removal. Note the following
It is not possible to adjust the release cable.
