ENGINE OIL
Oil capacities, specifications and viscosity classes, refer to 03 MAINTENANCE, DIAGNOSIS
Scheme 51
- Bracket for Assemblies Removing and installing, refer to «ACCESSORY ASSEMBLY BRACKET»(/audi/tt/8j-2010-2014/remont/mechanical/#20l-crankshaft-cylinder-block-engine-codes-ccta-ceta-coupe__accessory-assembly-bracket)
- Oil Pressure Switch -F22- 20 Nm Blue insulation Checking in Guided Fault Finding using the vehicle diagnosis tester
- Reduced Oil Pressure Switch -F378- 20 Nm Brown insulation Removing and installing, refer to «Reduced Oil Pressure Switch -F378»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__reduced-oil-pressure-switch-f378) Checking in Guided Fault Finding using the vehicle diagnosis tester
- Gasket Replace
- O-ring No replacement part, part of the valve unit delivery package
- O-ring No replacement part, part of the valve unit delivery package
- Valve Unit With O-rings
- Oil Filter Element Removing and installing. Refer to «ENGINE OIL, DRAINING/EXTRACTING AND REMOVING AND INSTALLING FILTER»(/audi/tt/8j-2010-2014/remont/procedures/#how-to-diagnosis-the-maintenance-maintenance-procedures-coupe) Remove and install using oil filter wrench 3417
- Bolt 23 Nm
- Connection
- Seal Replace
- Engine Oil Cooler See note «OIL PAN AND OIL PUMP OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__oil-pan-and-oil-pump-overview). Make sure there is enough space to the surrounding components Coolant hose connection diagram, refer to «COOLANT HOSE CONNECTION DIAGRAM»(/audi/tt/8j-2010-2014/remont/cooling-fan/#20l-cooling-system-engine-codes-ccta-ceta-coupe__coolant-hose-connection-diagram) Removing and installing, refer to «ENGINE OIL COOLER»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__engine-oil-cooler)
- Gasket Replace
- Bolt Tightening sequence (Scheme 52)
Scheme 52
OIL PAN AND OIL PUMP OVERVIEW
Note. If large quantities of metal particles or other deposits (caused, for example, by partial seizure of the crankshaft or connecting rod damage) are found in the engine oil, the oil passages must be cleaned thoroughly and the oil cooler replaced in order to prevent further damage from occurring.
Oil pressure, checking, refer to OIL PRESSURE, CHECKING .
| CAUTION | Danger of catalytic converter damage. Oil level must not exceed "max" marking. |
Scheme 53
- Oil Level Thermal Sensor -G266- Not for engine code CCTA
- Gasket Replace
- Bolt Replace Tightening sequence (Scheme 54)
- Lower Oil Pan Removing and installing «LOWER OIL PAN»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__lower-oil-pan)
- Bolt 9 Nm
- Oil Baffle Replace
- Bolt M6 - 9 Nm M8 - 20 Nm
- Oil Pump Removing and installing, refer to «OIL PUMP»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__oil-pump)
- Centering Sleeve
- Chain Tensioner
- Bolt 9 Nm
- Bolt 9 Nm
- Oil Pressure Regulation Valve -N428- Removing and installing, refer to «Oil Pressure Regulation Valve -N428»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__oil-pressure-regulation-valve-n428)
- O-ring Replace
- Drive Chain for Oil Pump Mark direction of rotation before removing
- Gasket Replace
- Oil Separator Removing and installing, refer to «OIL SEPARATOR»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__oil-separator)
- Bolt Tightening sequence (Scheme 56)
- Upper Oil Pan Removing and installing, refer to «UPPER OIL PAN»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__upper-oil-pan)
- Bolt 9 Nm
- Bolt Replace Tightening sequence (Scheme 55)
- Suction Line Clean the screen if it is dirty.
- O-ring Replace
- Gasket
- O-ring Replace
- Non-Return Valve
- Oil Drain Plug 30 Nm Replace
- Nut 9 Nm
Scheme 54
Tighten bolts in 3 stages in -1 to 20- sequence as follows
| Tighten bolts by hand.-- Tighten the bolts to 8 Nm.-- Tighten the bolts an additional 45°. |
Scheme 55
Tighten bolts in 3 stages in -1 to 14- sequence as follows
Note. There may be 13 bolts installed, depending on the version.
| Tighten bolts by hand.-- Tighten the bolts to 15 Nm.-- Tighten the bolts an additional 90°. |
Scheme 56
Tighten the bolts to 9 Nm in the following sequence: -1 to 9-.
FASTENER TIGHTENING SPECIFICATIONS
| Component | Bolt Size | Nm |
|---|---|---|
| Chain Tensioner | 9 | |
| Engine Oil Cooler | 23 | |
| Oil Baffle | 9 | |
| Oil Drain Plug 1 | 30 | |
| Oil Level Thermal Sensor, Nut | 9 | |
| Oil Pressure Regulation Valve | 9 | |
| Oil Pressure Switch | 20 | |
| Oil Pump | ||
| M6 | 9 | |
| M8 | 20 | |
| Reduced Oil Pressure Switch | 20 | |
| Suction Line | 9 | |
| 1 Always replace | ||
Lower Oil Pan, Tightening Sequence
Tighten bolts in 3 stages in -1 to 20- sequence as follows
| Tighten bolts by hand.-- Tighten the bolts to 8 Nm.-- Tighten the bolts an additional 45°. |
Upper Oil Pan, Tightening Sequence
Tighten bolts in 3 stages in -1 to 14- sequence as follows
Note. There may be 13 bolts installed, depending on the version.
| Tighten bolts by hand.-- Tighten the bolts to 15 Nm.-- Tighten the bolts an additional 90°. |
Oil Separator, Tightening Sequence
Tighten the bolts to 9 Nm in the following sequence: -1 to 9-.
OIL LEVEL, CHECKING
Refer to: ENGINE OIL LEVEL, CHECKING
OIL PRESSURE, CHECKING
Special tools and workshop equipment required
- Oil Pressure Gauge V.A.G 1342
Test Prerequisites
- Oil level OK, checking, refer to «ENGINE OIL LEVEL, CHECKING»(/audi/tt/8j-2010-2014/remont/procedures/#how-to-diagnosis-the-maintenance-maintenance-procedures-coupe__engine-oil-level-checking)
- Engine oil temperature at least 80 °C (176 °F) (radiator fan must start up once).
Test Sequence
Note. Place a cloth under the accessory assembly bracket to collect leaking engine oil.
Disconnect the electrical connector -2- on the reduced oil pressure switch -F378-.
Scheme 57
Remove the reduced oil pressure switch -1-.
Screw in the V.A.G 1342 into the oil filter bracket in place of the oil pressure switch.
Install the reduced oil pressure switch in the V.A.G 1342.
Start the engine.
- Oil pressure at idle: 1.2 to 2.1 bar.
- Oil pressure at 2000 RPM: 1.6 to 2.1 bar positive pressure.
- Oil pressure at 3700 RPM: 3.0 to 4.0 bar positive pressure.
Note. During the break-in phase, the oil pressure may be at 2000/min at 3.0 to 4.0 bar.
Assembling
- For the correct tightening specifications, refer to «OIL FILTER AND OIL COOLER OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe) .
Install the oil pressure switch.
OIL PRESSURE SWITCH, CHECKING
Check the oil pressure switch using the vehicle diagnostic tester.
ENGINE OIL COOLER
Special tools and workshop equipment required
- Drip tray for VAS 6100 VAS 6208
Removing
| WARNING | Risk of scalding due to hot steam and hot coolant. The coolant system is under pressure when the engine is warm. Cover the coolant reservoir cap with a cloth and then open it slowly to release the pressure in the system. |
Drain the coolant. Refer to COOLANT, DRAINING AND FILLING .
Remove the accessory assembly bracket. Refer to ACCESSORY ASSEMBLY BRACKET .
Remove the bolts -4 and 5- and remove the engine oil cooler -3- together with the seal -2-.
Scheme 58
Installing
Installation is carried out in the reverse order while noting the following
- For the correct tightening specifications, refer to «OIL FILTER AND OIL COOLER OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe) .
Note. Always replace gaskets and seals. Secure all hose connections with hose clamps of the same type as those equipped by the factory.
Install the engine oil cooler -3- with a new seal -2-.
Install the accessory assembly bracket. Refer to ACCESSORY ASSEMBLY BRACKET .
Replace coolant. Refer to COOLANT, DRAINING AND FILLING => Filling .
LOWER OIL PAN
Special tools and workshop equipment required
- Oil Collecting and Extracting Device V.A.G 1782
- Hand drill with plastic brush attachment
- Protective goggles
- Silicone sealant.
Removing
Remove the noise insulation. Refer to Removal and Installation .
Remove the frame for the noise insulation. Refer to Removal and Installation .
Disconnect the connector -1- from the oil level thermal sensor -G266-.
Scheme 59
Drain the engine oil. Refer to ENGINE OIL, DRAINING/EXTRACTING AND REMOVING AND INSTALLING FILTER
Remove the bolts -1 to 20-.
Remove the oil pan, if necessary loosen by applying light strikes with a rubber hammer.
Installing
- For the correct tightening specifications, refer to «OIL PAN AND OIL PUMP OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__oil-pan-and-oil-pump-overview) .
| CAUTION | Risk of contaminating lubricating system and bearing. Cover open parts of engine. |
- Silicone sealant.
Note. Note the expiration date of the silicone sealant. The oil pan must be installed within 5 minutes after application of silicone sealant.
Spray the sealing surface with sealant remover and allow it to work.
Remove any sealant residue on the upper section of the oil pan using a flat blade scraper.
| WARNING | Danger of eye injury. Wear protective goggles. |
Remove sealant residue on the lower oil pan, for example with a rotating plastic brush.
Scheme 60
Clean sealing surfaces, must be free of oil and grease.
Cut the tube nozzle at the front marking (nozzle diameter: approximately 3 mm).
Scheme 61
Apply silicon sealant to clean sealing surfaces of the lower oil pan as shown in illustration.
Scheme 62
| CAUTION | The lubrication system could be plugged with excess sealant. Do not apply sealant bead thicker than indicated. |
- Thickness of sealant bead: 2 to 3 mm
Note. The oil pan must be installed within 5 minutes after application of silicon sealant. The sealant bead may not be thicker than specified, otherwise excess sealant could enter the oil pan and clog the oil intake tube.
Position the lower oil pan immediately and tighten the bolts, tightening sequence (Scheme 54).
Note. After installing the oil pan, allow sealant to dry for approximately 30 minutes. Only after then may the engine oil be replenished.
Fill engine oil and check oil level. Refer to: ENGINE OIL, FILLING and refer to ENGINE OIL LEVEL, CHECKING .
Assemble in reverse order of disassembly.
Oil Pressure Regulation Valve -N428
Special tools and workshop equipment required
- Oil Collecting and Extracting Device V.A.G 1782
Removing
Remove the noise insulation. Refer to Removal and Installation .
Place the V.A.G 1782 under the engine.
Scheme 63
Disconnect the connector -1-.
Remove the bolt -2- and the oil pressure regulation valve -3-.
Installing
- Tightening specification, refer to «OIL PAN AND OIL PUMP OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__oil-pan-and-oil-pump-overview) .
Installation is carried out in the reverse order while noting the following
Note. Replace the O-ring.
Oil Pressure Switch -F22
Removing
Note. Place a cloth under the accessory assembly bracket to collect leaking engine oil.
Disconnect electrical connector -4- on oil pressure switch.
Remove the oil pressure switch -3-.
Installing
- Tightening specification, refer to «OIL FILTER AND OIL COOLER OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe) .
Install in reverse order, paying attention to the following
Note. Replace the seal. To prevent coolant loss, insert the new oil pressure switch in the connecting pieces immediately.
Check oil level. ENGINE OIL LEVEL, CHECKING
OIL PUMP
Special tools and workshop equipment required
- Assembly Tool T10118
Removing
Remove the noise insulation. Refer to Removal and Installation .
Remove the frame for the noise insulation. Refer to Removal and Installation .
Disconnect the connector -1- from the oil level thermal sensor -G266-.
Drain engine oil.
Remove the bolts -1 through 20-.
Remove oil pan, if necessary loosen by applying light strikes with a rubber hammer.
Remove the oil baffle -arrows-.
Scheme 64
Remove the bolts -arrows- and the oil pump.
Scheme 65
Pull the chain tensioner in the direction of the -arrow- using the T10118 and remove the oil pump with the chain sprocket.
Scheme 66
Installing
- For the correct tightening specifications, refer to «OIL PAN AND OIL PUMP OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__oil-pan-and-oil-pump-overview) .
Install in reverse order of removal. Note the following
Make sure both alignment bushings for centering the oil pump are in there.
Replace the baffle plate.
Install lower oil pan. Refer to LOWER OIL PAN .
OIL SEPARATOR
Removing
Remove the noise insulation. Refer to Removal and Installation .
Remove the frame for the noise insulation. Refer to Removal and Installation .
Remove the bolts -1 through 9- and remove the oil separator.
| CAUTION | Risk of contaminating lubricating system. Seal the opening with a clean cloth. |
Installing
Note. Always replace gaskets and seals. Secure all the hose connections with hose clamps appropriate for the model.
Install in reverse order of removal. Note the following
Oil separator tightening sequence (Scheme 56)
Reduced Oil Pressure Switch -F378
Removing
Note. Place a cloth under the accessory assembly bracket to collect leaking engine oil.
Disconnect the electrical connector -2- on the reduced oil pressure switch.
Remove the reduced oil pressure switch -1-.
Installing
- Tightening specification, refer to «OIL FILTER AND OIL COOLER OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe) .
Install in reverse order, paying attention to the following
Note. Replace the seal. To prevent coolant loss, insert the new reduced oil pressure switch in the connecting pieces immediately.
Check oil level. Refer to: ENGINE OIL LEVEL, CHECKING
UPPER OIL PAN
Special tools and workshop equipment required
- Assembly Tool T10118
- Brake Pad Wear Indicator Testing Tool VW 136
- Torque Wrench 5-50 Nm V.A.G 1331
- Hand drill with plastic brush attachment
- Protective goggles
- Silicone sealant.
Removing
Remove the transmission. Refer to Removal and Installation .
Remove the lower oil pan. Refer to LOWER OIL PAN .
Remove the oil pump. Refer to OIL PUMP .
Remove the transmission-side sealing flange. Refer to TRANSMISSION-SIDE SEALING FLANGE .
Remove the right front wheel housing liner. Refer to Wheel Housing Liners .
Remove the bolts -arrows-.
Scheme 67
Lift the clamps -1 and 2- and remove the air guide pipe.
Remove the bolt -1
Scheme 68
Disconnect the wiring bracket mount next to the after-run coolant pump -V51- from the upper oil pan.
Disconnect the connector -1-.
Remove the bolts -arrows-.
Scheme 69
| WARNING | Risk of injury. When removing the upper oil pan the chain tensioner spring for the oil pump motor will jump from the upper oil pan to the lower timing chain cover. When removing the upper oil pan, do not reach between the section and the lower timing chain cover. |
Remove the bolts -1 through 14- and pry out the upper oil pan.
Note. There may be 13 bolts installed, depending on the version.
| CAUTION | First pry the upper oil pan out on the transmission side. When prying out, be careful not to bend the timing chain cover. |
Installing
- For the correct tightening specifications, refer to «OIL PAN AND OIL PUMP OVERVIEW»(/audi/tt/8j-2010-2014/remont/lubrication-system/#20l-lubrication-engine-codes-ccta-ceta-coupe__oil-pan-and-oil-pump-overview)
- Silicone sealant.
Note. Note the expiration date of the silicone sealant. The oil pan (upper section) must be installed within 5 minutes after application of silicone sealant.
Mount the T10118 and pull the spring in the oil pump drive chain tensioner in the direction of the -arrow-.
Scheme 70
Secure the spring by inserting the VW 136 into the hole in the guide rail as illustrated.
Remove any sealant residue on the cylinder block using a flat blade scraper.
| WARNING | Danger of eye injury. Wear protective goggles. |
Remove the sealant residue on the upper oil pan, for example using a rotating plastic brush.
Scheme 71
Clean sealing surfaces, must be free of oil and grease.
Cut the tube nozzle at the front marking (nozzle diameter: approximately 3 mm).
Apply silicone sealant to clean sealing surface upper oil pan as shown in the illustration -arrows-.
Scheme 72
| CAUTION | The lubrication system could be plugged with excess sealant. Do not apply sealant bead thicker than indicated. |
- Thickness of sealant bead: 2 to 3 mm
Note. The oil pan (upper section) must be installed within 5 minutes after application of silicone sealant. The sealant bead may not be thicker than specified, otherwise excess sealant could enter the oil pan and clog the oil intake tube.
Position the upper oil pan immediately and tighten the bolts, tightening sequence (Scheme 55)
Install the bolts -arrows-. Tightening specification, refer to TIMING CHAIN GUARD AND Camshaft Adjustment Valve 1 -N205- OVERVIEW .
Remove the VW 136 from the guide rail -arrow-. The spring now returns to the installation position.
Scheme 73
Install the sealing flange on the transmission side. Refer to TRANSMISSION-SIDE SEALING FLANGE .
Install the oil pump. Refer to OIL PUMP .
Replace the baffle plate.
Install the lower timing chain cover. Refer to LOWER TIMING CHAIN COVER .
Assemble in reverse order of disassembly.
Scheme 74
Special tools and workshop equipment required
- Assembly Tool T10118
- Brake Pad Wear Indicator Testing Tool VW 136
- Torque Wrench 5-50 Nm V.A.G 1331
Special tools and workshop equipment required
Scheme 75
Scheme 76
Scheme 77
- Oil Pressure Gauge V.A.G 1342
- Oil Collecting and Extracting Device V.A.G 1782
- Drip tray for VAS 6100 VAS 6208
See also:
• 03 MAINTENANCE, DIAGNOSIS
• ACCESSORY ASSEMBLY BRACKET
• ENGINE OIL, DRAINING/EXTRACTING AND REMOVING AND INSTALLING FILTER
• COOLANT HOSE CONNECTION DIAGRAM
• ENGINE OIL LEVEL, CHECKING
• COOLANT, DRAINING AND FILLING
• Removal and Installation
• Removal and Installation
• ENGINE OIL, FILLING
• Removal and Installation
• TRANSMISSION-SIDE SEALING FLANGE
• TIMING CHAIN GUARD AND Camshaft Adjustment Valve 1 -N205- OVERVIEW
• LOWER TIMING CHAIN COVER
• Reduced Oil Pressure Switch -F378
• OIL PAN AND OIL PUMP OVERVIEW
• ENGINE OIL COOLER
• OIL PRESSURE, CHECKING
• LOWER OIL PAN
• OIL PUMP
• Oil Pressure Regulation Valve -N428
• OIL SEPARATOR
• UPPER OIL PAN
• OIL FILTER AND OIL COOLER OVERVIEW
