Special tools and workshop equipment required
- Radio Removal Tool T10057
If control module is replaced, select Replacement function for appropriate control module in Guided Fault-Finding routine.
Use the Vehicle Diagnosis, Testing and Information System to do so.
Switch off all electrical consumers.
Remove the key.
Removing
Place radio removal tool -arrows- in release slits on radio/navigation display control module until they engage. Points on grip eyes face outward.
Remove radio/navigation display control module from instrument panel using grip eyes on radio removal tool.
Release electrical connectors on radio/navigation display control module and remove it.
Remove radio removal tool by pressing locking tabs on radio/navigation display control module.
Remove front passenger's airbag disabled indicator lamp. Refer to FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP .
Installing
Install front passenger's airbag disabled indicator lamp. Refer to FRONT PASSENGER AIRBAG DISABLED INDICATOR LAMP .
Connect all electrical connectors.
Slide radio/navigation display control module straight into instrument panel until it engages in installation frame.
Required Special Tools and Equipment
- Radio Removal Tool T10057
Switch off all electrical consumers.
Remove the key.
Removing
Open the glove compartment.
If there is a CD still inside the CD changer, remove it.
Insert two clips on radio removal tool in release slits on CD changer until they engage. Points on the grip eyelets of tool face outward.
Remove CD changer from installation frame using grip eyes on radio removal tool.
Disconnect electrical connector on CD changer.
Remove radio removal tool, push locking tabs on CD changer to do so.
Installing
Connect electrical connector.
Slide CD changer into mounting frame until it engages.
Required Special Tools and Equipment
- Trim removal wedge 3409
Switch off all electrical consumers.
Remove the key.
Removing
Open the glove compartment.
Remove iPod -1- from iPod baseplate.
Using trim removal wedge, carefully pry iPod baseplate out of retainer -arrows-.
Remove iPod baseplate from glove compartment and disconnect electrical connector.
Installing
Install in reverse order.
