FRONT BUMPER
Special tools and workshop equipment required
- Hose Clamps up to 25 mm diameter. 3094
- Socket T40078
Scheme 21
- Bumper NOTE: On vehicles with headlamp washer system, hose line from washer fluid reservoir must be clamped off using a 3094. Removing -- Unclip covers -2- and -9- -- Remove bolts -3-; -4-; -5- and -6-. -- Loosen wheel housing liner in nut area -10- and pull back (Scheme 24) -- Remove zero gap connection nuts -10-. -- Remove the lower screws from the noise insulation in the bumper area. -- Unclip bumper sideways from guide pieces and pull forward slightly. -- Remove electrical wire to fog lamp, clamp off line to headlamp washer system if necessary. -- Bumper completely from vehicle Installing -- Use markings on radiator grille -arrow- for exact adjustment lengthwise. -- When installing, tighten upper bolts on bumper in -3-; -4-; -5- and -6- sequence.
- Right cover Unclip
- Bolt 5 Nm
- Bolt 5 Nm
- Bolt 5 Nm
- Bolt 5 Nm
- End plate No replacement part Slide into support -8- on lock carrier as shown.
- Carrier piece No replacement part Part of lock carrier delivery package.
- Left cover Unclip
- Nut Use T40078 to loosen or tighten nut. 6.5 Nm
