Wiper/washer Systems (coupe) Audi TT 8J

Wiper/washer Systems 23 illustrations ~2028 words

CONTACT CORROSION

Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fasteners with a special surface coating are used.

In addition, rubber or plastic parts and adhesive consist of non-conductive materials.

If there are doubts as to whether parts are suitable or not, use new parts.

Note

  1. We only recommend original replacement parts, they have been tested and are compatible with aluminum.
  2. We recommend using Audi accessories.
  3. Damage resulting from contact corrosion is not covered by warranty.

WASHER FLUID LINES

The following descriptions can be found in General Information

  1. Washer fluid line hose connections, disconnecting and connecting
  2. Corrugated hose washer fluid line, repairing

WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION

Note. If windshield wiper motor should run during procedure, hood must be completely closed. Otherwise, voltage supply to wiper motor is interrupted.

If there is a chance of freezing, ensure wiper blades are not frozen.

Vehicles without Driver Information System (DIS)

Briefly switch ignition on and off again.

Activate "one-touch wiping" within 10 seconds.

  1. The windshield wipers run into "service position".

Vehicles with Driver Information System (DIS)

Scheme 13

Scheme 13

Switch on ignition.

Press the Reset button -1- on the windshield wiper switch until the menu display appears.

Select the desired menu item by pressing the wiper switch -2- and confirm the respective end position by pressing the Reset - button

Adjusting
Wiper
Front
Service Position
  1. The windshield wipers run into "service position".

All Vehicles

CAUTIONRisk of damaging the hood by running the wipers back in basic position. Do not drive a vehicle with windshield wiper arms folded up. The windshield wipers automatically go back into basic position above the speed of 6 km/h (4 mph).

Scheme 14

Scheme 14: HEADLAMP WASHER SYSTEM OVERVIEW
  1. Spray Nozzle Removing and installing, refer to «HEADLAMP SPRAY NOZZLES»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__headlamp-spray-nozzles) .
  2. Screw 2.5 Nm
  3. Spray Jet Cover
  4. Screw 2.5 Nm
  5. Hose Clamp Secure all hose connections with standard hose clamps used in production.
  6. Washer Fluid Hose For nozzle

WASHER FLUID RESERVOIR AND FLUID LINES OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 15

Scheme 15: WASHER FLUID RESERVOIR AND FLUID LINES OVERVIEW
  1. Hose Connection For headlamp washer system washer fluid line.
  2. Spray Nozzle Removing and installing, refer to «WINDSHIELD SPRAY NOZZLES»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-spray-nozzles) .
  3. Electrical Connector For spray jet heating. Depending on the vehicle equipment level.
  4. Washer Fluid Line For nozzle
  5. Grommet For washer fluid line in hood.
  6. Washer Fluid Line Clipped into hood bracket.
  7. Cover For washer fluid reservoir.
  8. Grommet For washer fluid line in fender.
  9. Electrical Connector For headlamp washer system pump.
  10. Headlamp Washer System Pump -V11
  11. Electrical Connector For Windshield Washer Pump -V5-.
  12. Windshield Washer Pump -V5-.
  13. Washer Fluid Line For windshield washer system
  14. Washer Fluid Line For headlamp washer system.

WINDSHIELD WIPER SYSTEM OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 16

Scheme 16: WINDSHIELD WIPER SYSTEM OVERVIEW
  1. Nut 8 Nm
  2. Bracket
  3. Nut 6 Nm
  4. Screw Tightening sequence (Scheme 17).
  5. Nut 17 Nm
  6. Cap
  7. Windshield Wiper Arm, Passenger's Side Different lengths. Removing and installing, refer to «WINDSHIELD WIPER ARMS»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-wiper-arms). Adjusting, refer to «WINDSHIELD WIPER ARMS, ADJUSTING»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-wiper-arms-adjusting).
  8. Windshield Wiper Blade, Passenger's Side Different lengths. Replacing, refer to «WINDSHIELD WIPER BLADES, REPLACING»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-wiper-blades-replacing).
  9. Windshield Wiper Blade, Driver's Side Different lengths. Replacing, refer to «WINDSHIELD WIPER BLADES, REPLACING»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-wiper-blades-replacing).
  10. Windshield Wiper Arm, Driver's Side Different lengths. Removing and installing, refer to «WINDSHIELD WIPER ARMS»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-wiper-arms). Adjusting, refer to «WINDSHIELD WIPER ARMS, ADJUSTING»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-wiper-arms-adjusting).
  11. Cap
  12. Nut 17 Nm
  13. Screw Tightening sequence (Scheme 17).
  14. Windshield Wiper Motor With Wiper Motor Control Module -J400-. Removing and installing, refer to «WINDSHIELD WIPER MOTOR WITH CONTROL MODULE -J400»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-wiper-motor-with-control-module).
  15. Screw Tightening sequence (Scheme 17).

Scheme 17

Scheme 17

Tighten bolts -1, 2, 4- in 2 stages as follows

Tighten bolts by hand.

Tighten bolts to 8 Nm.

FASTENER TIGHTENING SPECIFICATIONS

ComponentNm
Headlamp Washer Spray Nozzle2.5
Windshield Wiper Frame Bracket Nut 18
Windshield Wiper Frame Bracket Nut 26
Wiper Arm Nut17
1 For bolt tightening clarification, refer to WINDSHIELD WIPER SYSTEM OVERVIEW and see item -1- 2 For bolt tightening clarification, refer to WINDSHIELD WIPER SYSTEM OVERVIEW and see item -3

Windshield Wiper Motor Tightening Sequence

Tighten bolts -1, 2, 4- in 2 stages as follows

Tighten bolts by hand.

Tighten bolts to 8 Nm.

HEADLAMP SPRAY NOZZLES, ADJUSTING

Note. The nozzles are already adjusted by the manufacturer and must not be adjusted after installation.

WINDSHIELD SPRAY NOZZLES, ADJUSTING

Special tools and workshop equipment required

  1. Windshield Washer Aiming Tool T10127 equipped with Replacement Tip 3125/5A

Adjusting

Scheme 18

Scheme 18

Note. The settings indicate the values for a moving vehicle, i.e. the spray from the jets is slightly offset when the vehicle is stationary.

Mark the six points on windshield using a water soluble marker

Dimensions in mmDriver SidePassenger Side
A=300300
B=600600
C=320320
D=335335
E=495495
F=175175

Aim the individual jets at the points using the T10127.

If the spray field does not correspond to the specifications, clean dirty spray jet.

Cleaning the nozzle

Remove nozzle. Refer to WINDSHIELD SPRAY NOZZLES .

Flush nozzle opposite to spray direction using clear water.

To remove remaining impurities, the nozzle must only be blown out opposite to spray direction using compressed air.

If the spray field still does not correspond to the specifications, replace the spray jet.

WINDSHIELD WIPER ARMS, ADJUSTING

Procedure

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.

Remove wiper arms. Refer to WINDSHIELD WIPER ARMS .

Switch on ignition.

Activate "one-touch wiping" and let wiper motor run to end position.

Note. Every second time the wiper motor is switched off, it returns the wiper arms to a slightly lower rest position, thus tipping the wiper blade lips the other way. To do so, the wiper motor moves the wiper arms farther down than to rest position and then a bit up again. This lower rest position must not be used to adjust the wiper crank. Only use end position where wiper arms run directly end position with no understroke. Activate "one-touch wiping" again if necessary.

Turn off the ignition.

Position wiper arm with wiper blade installed at wiper axles and align wiper blade at windshield as follows

Scheme 19

Scheme 19: WINDSHIELD WIPER ARMS, ADJUSTING
  1. Dimension -a- = 5 + 10 mm.
  2. Dimension -b- = 24 + 10 mm.

Note. The dimensions indicate the gap between the wiper blade tips to black cowl grille at lower edge of windshield.

Tighten wiper arm nuts -arrows-.

Scheme 20

Scheme 20
  1. Tightening specification. Refer to «WINDSHIELD WIPER SYSTEM OVERVIEW»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__windshield-wiper-system-overview) .

Switch on ignition.

Operate "one-touch wiping" and let wiper arms run to end position.

Turn off the ignition.

Check adjustment of wiper arms again, correct if necessary.

Press the caps onto the wiper arms.

WINDSHIELD WIPER MOTOR WITH CONTROL MODULE -J400-, REPLACE

Procedure

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" using the Vehicle Diagnostic Tester.

Select the function or path in the "guided functions" operating mode

Vehicle brand
Engine codes
09 Electronic central electrical J519
J400 Replacing (repair group 92)

Follow further instructions on display of Vehicle Diagnostic Tester.

HEADLAMP SPRAY NOZZLES

Special tools and workshop equipment required

  1. Hose Clamp Pliers V.A.G 1275

Removing

Remove front bumper cover. Refer to Removal and Installation .

Note. Protect bumper cover by laying rag underneath and secure nozzle using pliers.

Pull spray nozzle telescope out of bumper cover as far as stop.

Scheme 21

Scheme 21
  1. Hold telescope in extended position with pliers -4-.

Spread side walls on cover -1- for spray jet -arrows- and carefully disengage cover side walls from retaining pins -2 and 3-.

Remove fluid hose -4- from spray nozzle -1-.

Scheme 22

Scheme 22

Remove bolts -2 and 3- and remove spray jet.

Installing

  1. Tightening specification. Refer to «HEADLAMP WASHER SYSTEM OVERVIEW»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe) .

Install in reverse order of removal. Note the following

Note. Secure all hose connections using standard hose clamps.

Make sure that guide pin sits in mount -arrow-.

Install hose clamp using V.A.G 1275.

Install front bumper cover. Refer to Removal and Installation .

WASHER FLUID RESERVOIR

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 23

Scheme 23: WASHER FLUID RESERVOIR

Switch off ignition and remove ignition key.

Remove left front wheel.

Remove left front wheel housing liner. Refer to Removal and Installation .

Open cap -3- on washer fluid reservoir filler neck.

Unhook cap retaining ring -4- on washer fluid reservoir filler neck.

Release line bracket -1 and 2- in -direction of arrow A- and tip bracket to side -arrow B-.

Free up wiring harness.

Place a reservoir under the washer fluid reservoir.

Scheme 24

Scheme 24

Release securing clip -6- and remove washer fluid line -7- at windshield washer system pump.

Disconnect washer fluid hose -5- at headlamp washer system pump.

Disconnect electrical connectors -3, 4, 8-.

Remove bolts -1- and remove washer fluid reservoir -2- forward -arrow-.

Installing

Scheme 25

Scheme 25
  1. Tightening specification, refer to «WASHER FLUID RESERVOIR AND FLUID LINES OVERVIEW»(/audi/tt/8j-2006-2010/remont/wiperwasher-systems/#wiperwasher-systems-coupe__washer-fluid-reservoir-and-fluid-lines) .

Install in reverse order of removal. Note the following

Note. Secure all hose connections using standard hose clamps.

When inserting washer fluid reservoir, ensure securing tab -1- engages in mount -2- -arrow-.

Install left front wheel house liner. Refer to Removal and Installation .

WINDSHIELD SPRAY NOZZLES

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 26

Scheme 26: WINDSHIELD SPRAY NOZZLES

Unclip washer fluid nozzles from bottom of hood -arrow-.

Release securing clip -2- in -direction of arrow- and remove washer fluid line -1- at windshield washer system spray jet.

Scheme 27

Scheme 27

Disconnect electrical harness connector -3-, if present.

Installing

Install in reverse order of removal. Note the following

When connector washer fluid hose, ensure securing clip engages audibly in washer fluid line connection.

Insert nozzle in hood.

WINDSHIELD WIPER ARMS

Special tools and workshop equipment required

  1. Windshield Wiper Arm Tool Set T10369

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Note. If the windshield wiper motor is to be run during the work procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.

Switch on ignition.

Activate one-touch wiping and allow wiper arms to move to end position.

Switch off ignition and remove ignition key.

Using a screw driver, pry cover caps off wiper arms.

Loosen nuts -arrows- one rotation.

Position the puller T10369/1 on the wiper arm -1- as illustrated.

Scheme 28

Scheme 28

Position the thrust piece -2- on the wiper axle.

Rotate the bolt -3- clockwise until the wiper arm is removed from the axle.

Remove the nuts and remove the wiper arm.

Installing

CAUTIONThere is a risk of damaging the body. The driver and passenger side wiper arms are different lengths.

Install in reverse order of removal. Note the following

Adjust wiper arms. Refer to WINDSHIELD WIPER ARMS, ADJUSTING .

WINDSHIELD WIPER BLADES, REPLACING

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Bring windshield wiper into service position. Refer to WINDSHIELD WIPERS, BRINGING INTO SERVICE POSITION .

Lift off wiper arm from front windshield.

Compress clip -arrows 1-.

Scheme 29

Scheme 29: WINDSHIELD WIPER BLADES, REPLACING

Push wiper blade off wiper arm -arrow 2-.

Remove wiper blade.

Installing

CAUTIONThere is a risk of damaging the body. The driver and passenger side wiper blades are different lengths.

Install in reverse order of removal. Note the following

Guide wiper arm tab -2- into wiper blade -1- -arrow-.

Scheme 30

Scheme 30

If the windshield wiper switch is operated or a speed of 6 km/h (4 mph) is exceeded, the wipers leave the "service position".

WINDSHIELD WIPER MOTOR WITH CONTROL MODULE -J400

Special tools and workshop equipment required

  1. Pry Lever 80 - 200

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 31

Scheme 31

Remove wiper arms. Refer to WINDSHIELD WIPER ARMS .

If equipped, remove the bolts -3- and -4-.

Remove rubber seal -1-.

CAUTIONDanger of damaging the plenum chamber cover. Coat the space between the windshield and the plenum chamber cover with some soapy water.

Carefully remove the plenum chamber cover -2- starting at the edge of the glass vertically from the windshield -arrows B-.

Cut through cable ties -arrow-.

Remove the screws -1, 2 and 4-.

Pull wiper frame with linkage and wiper motor -3- slightly toward left in direction of travel.

Turn windshield wiper frame with the linkage and the wiper motor up so it can be pried out of wiring clip -6- with 80 - 200.

Note. For easier removal, use silicon-free lubricating spray.

Disconnect electrical connector -5-.

Remove windshield wiper frame with linkage and motor to left in direction of travel from plenum chamber.

Installing

  1. Tightening specification (Scheme 17).

Install in reverse order of removal. Note the following

Insert wiper motor with wiper frame into vehicle.

Tighten bolts (Scheme 17).

Adjust wiper arms. Refer to WINDSHIELD WIPER ARMS, ADJUSTING .

Scheme 32

Scheme 32: SPECIAL TOOLS

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35
  1. Pry Lever 80 - 200
  2. Windshield Washer Aiming Tool T10127 equipped with Replacement Tip 3125/5A
  3. Windshield Wiper Arm Tool Set T10369
  4. Hose Clamp Pliers V.A.G 1275
