WHEELS AND TIRES
Refer to the General Information .
TIRE PRESSURE MONITORING SYSTEM, INDIRECT SYSTEM
Tire pressure monitoring is a system that detects slow to moderate reductions in tire pressure at a wheel position. With the help of the ABS sensors, the TPMS compares the speed and rolling circumference of the individuals wheels. If the rolling circumference changes, the tire pressure monitoring indicator in the instrument cluster lights up and a warning tone is heard. On vehicles with a center instrument cluster display, the location of the tire is given.
After changing from run-flat tires (SST) to non-run-flat tires or vice versa the control module must be recoded.
The rolling circumference of the tire can change if
- The tire pressure is too low.
- The tire has structural damage.
- The vehicle is loaded on one side.
- The tires on one axle are loaded more heavily (e.g. when towing a trailer or driving up and down inclines).
- The spare tire is installed.
- One wheel per axle was changed. (also if exchanging the tires from front to rear or vice versa).
System Malfunction in TPMS
A system malfunction is stored in the Tire Pressure Monitoring Control Module 2 -J793- and indicated by the constant yellow TPMS lamp in the instrument cluster. The TPMS lamp cannot be turned off by pressing the TPMS button. If there is a DTC memory entry, connect -VAS- -5051 and select "Guided Fault Finding" => .
Perform Calibration: (Readapt Tire Pressure)
After each change to the tires, the tire pressure monitoring system button -- in the center console must be pressed while the ignition is switched on and the vehicle is still until the TPMS lamp in the instrument cluster blinks several times. Blinking several times confirms the calibration procedure and the readapting of the tire pressures.
TIRE PRESSURE MONITORING SYSTEM, DIRECT SYSTEM
Observe notes about usage in your Owner's Manual.
The tire pressure monitoring system monitors the pressure of the four tires while driving.
Damaged tire pressure sensors should be replaced for safety reasons.
Do not clean tire pressure sensors with steam blasting or strong compressed air.
For safety reasons, the tire pressure monitoring sensor should be replaced and the rim cleaned after using tire sealant.
The tire pressure monitoring system consists of a control module, a central antenna integrated in the control module and one tire pressure sensor in each of the four wheels.
If wheel positions on the vehicle are changed, tires are changed, tire pressure sensors are replaced or pressures are changed, control module must be readapted.
Note. When changing a tire with tire pressure monitoring sensors (summer/winter tires), tire pressure must be checked and the sensor readapted to the control module.
A fault may be saved in the DTC memory if
There is a system malfunction.
When installing less than four wheels with tire pressure sensors.
When installing winter tires or incorrect tire pressure sensors. (If this is the case, the yellow warning lamp in instrument cluster "system malfunction diagram" is set and cannot be deactivated by the system.)
The system has detected new sensors but the tire pressure monitoring button -E226- has not been pressed yet to confirm the current pressures. (In this case, the system malfunction is erased by pressing the button.)
TIRE PRESSURE MONITORING SYSTEM USAGE, DIRECT SYSTEM
Function
The tire pressure monitoring system is controlled by the Tire Pressure Monitoring Button -E226-, which is installed in the center console switch strip.
The system monitors the tire pressure you have set and entered for monitoring.
Tire pressures must first be checked, corrected and saved using the tire pressure monitoring button.
Then check and correct the tire pressure for the tires on the vehicle (including spare tire) according to the specifications on the sticker on the fuel filler flap/B-pillar.
Tire Pressure Monitoring Active
If the TPMS detects a loss of pressure in one or more tires, it notifies the driver by switching the TPMS warning lamp in the instrument cluster on continuously. A tire pressure warning symbol with the text "Check tire pressure" also appears in the instrument cluster driver information system. In this case, the tire pressures must be checked (according to the specifications on the label on the fuel tank door/B-pillar). If the tire pressure is very different in one or more tires, check that tire for damage or foreign objects. Replace the tire if necessary. Refer to TIRES, CHANGING, WITH TIRE PRESSURE MONITORING SYSTEM .
System Malfunction in Tire Pressure Monitoring System
A system malfunction is stored in the Tire Pressure Monitoring Control Module -J502-. If a malfunction occurs or there is already one present, this is indicated when the "ignition is on" by the yellow malfunction lamp in the instrument cluster blinking for 1 minute and then staying on continuously. The yellow malfunction lamp cannot be switched off by pressing the tire pressure monitoring button in the center console switch strip. A "tire pressure warning symbol" with the text "Check tire pressure" also appears in the instrument cluster driver information system. If there is a DTC memory entry, connect Vehicle diagnosis, testing and information system VAS 5051 A and select "Guided Fault Finding".
Coding Tire Pressure Monitoring Control Module
If Tire Pressure Monitoring Control Module -J502- is replaced, new control module must be coded. To do this, proceed as follows.
Connect VAS 5051 A perform vehicle-specific entry into Guided Fault Finding and select GO TO button "function/component selection".
Then
"Chassis (Repair group 01; 40 - 49)"
"Tire pressure monitoring (Repair group 01; 44)"
"01- On Board Diagnostic (OBD) capable systems"
"65 - Tire pressure monitoring J502"
"J502 - Tire Pressure Monitoring Control Module, functions"
"65 - Replacing control module (repair group 44)"
Tire pressure saving must be initiated after every desired change to the specified pressures.
Saving Tire Pressures
The correct saving of the specified values in the basic requirement for dependable tire pressure monitoring.
After each change to the tires, the tire pressure monitoring button in the center console must be pressed for approximately 5 seconds with ignition switched on and vehicle still until a signal tone is heard and the yellow "system malfunction diagram" in the instrument cluster blinks several times. Blinking several times confirms the calibration procedure and the readapting of the tire pressures.
The procedure for saving the tire pressures must be initiated each time the tire specified pressures are changed. The procedure takes place while driving.
Changing a Tire or Replacing a Tire Pressure Sensor
Adapting the tire pressure sensors is a basic requirement for the tire pressure monitoring system to function properly.
Each time a tire is changed or a tire pressure sensor is replaced, the tire pressure monitoring button in the center console must be pressed for approximately 5 seconds with the ignition switched on and vehicle still under a signal tone is heard and the yellow "system malfunction diagram" in the instrument cluster blinks several times.
If the tire pressure monitoring button is not pressed, the system learns the new sensors but still activates the malfunction lamp to request active operation.
The vehicle must now stand for 20 minutes and then be driven on a 3-minute adaptation drive at speeds greater than 25 km/h.
If the standing time is not followed, control module is not in learning mode so system recognizes a malfunction and can only automatically learn wheel electronics after standing 20 minutes.
Wheel alignment must only performed using VW/Audi-approved wheel alignment equipment!
Each time wheels are aligned, both front and rear wheels must be aligned.
Otherwise, proper vehicle drivability cannot be ensured.
Note. Wheels should not be aligned until the vehicle has been driven 1, 000 to 2, 000 km, since it takes this long for the coil springs to settle. The individual specifications should be followed as exactly as possible when making adjustments. Vehicle instability can also be caused by the wheels having a residual imbalance and/or radial runout which is too great.
| WARNING | After making adjustments on the suspension on vehicles with ESP or ABS, the steering angle sensor -G85- must be calibrated and steering must be readapted after vehicle alignment using the Vehicle diagnosis, testing and information system VAS 5051 A in Guided Functions. |
Then
03-Brake electronics J104
03-Steering Angle Sensor -G85- calibration
If the installed position of the rear axle and thereby the direction of travel of the vehicle are not considered, a crooked steering wheel may result.
Steering wheel and steering column are marked.
Scheme 1
These positions must not be changed!
A
Marked line on steering wheel.
B
Punch mark on steering column.
Otherwise centering of toothed shaft cannot be guaranteed!
Steering columns supplied as a spare part do not have a center punch mark.
If the steering column or steering wheel is replaced, marking should be remade after alignment and road test.
Tightening Specification
| Component | Nm | |
|---|---|---|
| Steering wheel to steering column | Socket head bolt | 50 (1) |
| (1) Replace bolt | ||
| (1) | Replace bolt |
WHEN WHEEL ALIGNMENT IS NECESSARY
- Involved in an accident.
- Vehicle shows handling problems.
- Tire wear patterns are uneven.
- Axle components were removed.
A component on the front/rear suspension was replaced
| A Component on the Front Suspension was Replaced | Wheel Alignment Check Required | A Component on the Rear Suspension was Replaced | Wheel Alignment Check Required | ||
|---|---|---|---|---|---|
| Yes | No | Yes | No | ||
| Suspension Strut | X (2) | Shock Absorbers | X | ||
| Transverse link/bonded rubber bushing | X | Coil spring | X | ||
| Ball joint | X | Wheel Bearing Housing | X | ||
| Wheel Bearing Housing | X | Subframe/bonded rubber bushing | X | ||
| Tie rod end | X | Lower transverse link | X | ||
| Steering Gear | X | Upper control arm | X | ||
| Subframe | X | Tie Rod | X | ||
| Stabilizer Bar | X (1) | Trailing link | X | ||
| Stabilizer Bar | X | ||||
| (1) If subframe was secured with Locating Pins T10096, axle alignment is not necessary. (2) If the location of the nuts -arrows- was marked, an axle alignment is not necessary. | |||||
| (1) | If subframe was secured with Locating Pins T10096, axle alignment is not necessary. |
| (2) | If the location of the nuts -arrows- was marked, an axle alignment is not necessary. |
Scheme 2
A component on the front/rear suspension was removed and reinstalled
| A Component on the Front Suspension was Removed and Reinstalled | Wheel Alignment Check Required | A Component on the Rear Suspension was Removed and Reinstalled | Wheel Alignment Check Required | ||
|---|---|---|---|---|---|
| Yes | No | Yes | No | ||
| Suspension Strut | X (2) | Shock Absorbers | X | ||
| Transverse link/bonded rubber bushing | X | Coil spring | X | ||
| Ball joint | X (2) | Wheel Bearing Housing | X | ||
| Wheel Bearing Housing | X (2) | Subframe/bonded rubber bushing | X | ||
| Tie rod end | X | Lower transverse link | X | ||
| Steering Gear | X | Upper control arm | X | ||
| Subframe | X (1) | Tie Rod | X | ||
| Stabilizer Bar | X (1) | Trailing link | X | ||
| Stabilizer Bar | X | ||||
| (1) If subframe was secured with Locating PinsT10096, axle alignment is not necessary. (2) If the location of the nuts -arrows- was marked, an axle alignment is not necessary. | |||||
| (1) | If subframe was secured with Locating PinsT10096, axle alignment is not necessary. |
| (2) | If the location of the nuts -arrows- was marked, an axle alignment is not necessary. |
PR NUMBER EXPLANATIONS
The vehicle data plate documents which front/rear axle is installed using the corresponding PR numbers.
The vehicle data label can be found in the spare wheel well as well as in the Maintenance booklet.
Front/Rear Suspension
Scheme 3
The front/rear axle PR No. is in illustration -A- and -B
Front axle PR no. is item -A-.
Rear axle PR no. is item -B-.
Suspension Versions
The suspension version PR No. is in illustration -arrow
In this example the vehicle has standard suspension 1BA installed.
1BA = Standard suspension
1BL = Sport suspension Audi magnetic ride (AMR) - electronically-controlled damping
1BV = Sport suspension S Line
1BQ = Sport suspension Audi magnetic ride (AMR) - electronically-controlled damping
1BD = Sport suspension quattro GmbH (TT RS)
Scheme 4
- Tire Pressure Monitoring Button -E226- Component location: Installed in the center console switch strip.
- Display in Instrument Cluster See Vehicle diagnostic, test and information system VAS 5051 A.
- Tire Pressure Monitoring Control Module -J502- If module is replaced, system must be coded. Refer to «TIRE PRESSURE MONITORING SYSTEM USAGE, DIRECT SYSTEM»(/audi/tt/8j-2006-2010/remont/wheel-tire-system/#wheels-tires-wheel-alignment-coupe__tire-pressure-monitoring-system-usage-direct) .
- Left Front Tire Pressure Monitoring Sensor -G222-, Right Front -G223-, Rear Left -G224- and Rear Right -G225- Removing and installing, refer to «TIRE PRESSURE SENSOR»(/audi/tt/8j-2006-2010/remont/wheel-tire-system/#wheels-tires-wheel-alignment-coupe__tire-pressure-sensor) . If wheel positions on the vehicle are changed, tires are changed, tire pressure sensors are replaced or pressures are changed, control module must be recoded or readapted. Refer to «TIRE PRESSURE MONITORING SYSTEM USAGE, DIRECT SYSTEM»(/audi/tt/8j-2006-2010/remont/wheel-tire-system/#wheels-tires-wheel-alignment-coupe__tire-pressure-monitoring-system-usage-direct) .
Scheme 5
- Left Front Tire Pressure Monitoring Sensor -G222-, Right Front -G223-, Left Rear -G224- and Right Rear -G225- Temperature and pressure can be read via diagnosis with Vehicle Diagnostic, Measuring and Information System VAS 5051 B Replace the valve insert each time a tire is changed. Allocation. When using used tire pressure monitoring sensors, replace the union nut, valve insert, gasket, sealing washer and valve cap. Allocation. Removing and installing, refer to «TIRE PRESSURE SENSOR»(/audi/tt/8j-2006-2010/remont/wheel-tire-system/#wheels-tires-wheel-alignment-coupe__tire-pressure-sensor) .
- Valve Core
- Sealing Washer
- Seal
- Rim Tires, mounting and dismounting, refer to «TIRES, CHANGING, WITH TIRE PRESSURE MONITORING SYSTEM»(/audi/tt/8j-2006-2010/remont/wheel-tire-system/#wheels-tires-wheel-alignment-coupe__tires-changing-with-tire-pressure-monitoring) .
- Union Nut 8 Nm
- Valve Cap Use only original valve caps from the repair set. Allocation. Do not use Comfort valve caps and metal caps.
WHEEL ALIGNMENT TEST PREREQUISITES
- Check suspension, steering and steering linkage for excessive play and damage.
- Tread depth difference may be no more than 2 mm on an axle.
- Prescribed pressure of tires.
- Vehicle accurately aligned, suspension bounced and rocked several times.
- The measurement sensor must be properly adjusted and attached to the vehicle; observe device manufacturer's operating instructions.
- Vehicle empty weight, refer to footnote: 1
- Empty weight means: Weight of the vehicle ready for the road (fuel tank completely filled, spare wheel, vehicle tools and vehicle jack).
- Vehicle alignment platforms and vehicle alignment units/vehicle alignment computers can lose their calibration over a period of time.
- Alignment platforms and alignment units/alignment computers should be calibrated at least once a year during maintenance.
Treat these highly sensitive units carefully and conscientiously.
- If necessary, contact the manufacturer for familiarization with the proper use of the equipment.
- Be sure that sliding plates and turn tables are not touching end stop when checking wheel alignment
- Perform wheel run-out compensation: Permissible axial run-out of the wheel rims can exceed the specified toe setting tolerance. If compensation for wheel run-out is not performed, it will not be possible to obtain a correct toe-in adjustment.
WHEEL ALIGNMENT MEASUREMENT PROCEDURE
Special tools and workshop equipment required
- Alignment Computer V.A.G 1813 or VW-/Audi-approved alignment unit
- Brake pedal actuator V.A.G 1869/2
- Insert tool T10179
- Shock absorber set T10001
Overview
Note. Vehicle must only be measured at empty weight. Refer to WHEEL ALIGNMENT TEST PREREQUISITES .
Observe the following work sequence!
1
Check front axle camber and adjust if necessary. Refer to FRONT AXLE CAMBER, ADJUSTING .
2
Check rear axle camber and adjust if necessary. Refer to REAR AXLE CAMBER, ADJUSTING .
3
Check rear axle toe and adjust if necessary. Refer to REAR AXLE TOE, ADJUSTING .
4
Check front axle toe and adjust if necessary. Refer to FRONT AXLE TOE, ADJUSTING .
5
If adjustments were made at the suspension during vehicle alignment on vehicles with ESP or ABS, calibrate the steering angle sensor -G85- and reprogram the steering. Refer to WHEEL ALIGNMENT .
6
On vehicles with level control sensor, headlamp range control basic setting must be performed after a vehicle alignment. Refer to LEVEL CONTROL SYSTEM SENSORS .
Use Vehicle Diagnosis, Testing and Information System VAS 5051B for this in Guided Fault Finding" function.
Insert V.A.G 1869/2.
Scheme 6
FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| Tire Pressure Monitoring Sensor Union Nut | 8 |
WHEEL ALIGNMENT SPECIFIED VALUES
Note. Specifications valid for all engine versions.
| Front Suspension | Standard Suspension 1BA | Sport Suspension Audi Magnetic Ride (AMR) 1BL | Sport Suspension 1BV/1BD | Sport Suspension Audi Magnetic Ride (AMR) 1BQ |
|---|---|---|---|---|
| Individual toe | 5' ± 5' | 5' ± 5' | 5' ± 5' | 5' ± 5' |
| Total toe | 10' ± 10' | 10' ± 10' | 10' ± 10' | 10' ± 10' |
| Camber | 41' ± 30' | 41' ± 30' | 41' ± 30' | 41' ± 30' |
| Maximum permissible difference between both sides | Maximum 30' | Maximum 30' | Maximum 30' | Maximum 30' |
| Toe differential angle at 20° steering angle (1) | 1° 18' ± 20' | 1° 18' ± 20' | 1° 20' ± 20' | 1° 20' ± 20' |
| Maximum steering angle at inner wheel | 36° 48' | 36° 48' | 36° 48' | 36° 48' |
| (1) Wheel stop on outer wheel is reduced by this amount. It can also be indicated negatively in alignment computer, depending on manufacturer. | ||||
| (1) | Wheel stop on outer wheel is reduced by this amount. It can also be indicated negatively in alignment computer, depending on manufacturer. |
| Rear Suspension | Standard Suspension 1BA | Sport Suspension Audi Magnetic Ride (AMR) 1BL | Sport Suspension 1BV/1BD | Sport Suspension Audi Magnetic Ride (AMR) 1BQ |
|---|---|---|---|---|
| Total toe | 25' ± 10' | 25' ± 10' | 25' ± 10' | 25' ± 10' |
| Individual toe | 12, 5' ± 5' | 12, 5 '± 5' | 12, 5 '± 5' | 12, 5' ± 5' |
| Maximum permissible deviation from direction of rotation | Maximum 10' | Maximum 10' | Maximum 10' | Maximum 10' |
| Camber | 1° 20' ± 30' | 1° 20' ± 30' | 1° 20' ± 30' | 1° 20' ± 30' |
| Maximum permissible difference between both sides | Maximum 30' | Maximum 30' | Maximum 30' | Maximum 30' |
FRONT AXLE CAMBER, ADJUSTING
Note. Only adjust camber if measured value is outside the specified value tolerance of +/- 30'.
Loosen nuts -arrows-.
Adjust camber using elongated holes in ball joint.
Tighten nuts -arrows-.
Tightening specifications, refer to SUBFRAME, STABILIZER BAR, TRANSVERSE LINK, BALL JOINT, AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .
REAR AXLE CAMBER, ADJUSTING
Special tools and workshop equipment required
- Shock Absorber Set T10001
- Insert Tool T10179
Remove upper transverse link to subframe connection nut -A- and loosely install new nut.
Scheme 7
Adjust camber by turning eccentric bolt with AF 18 nut from T10001.
Scheme 8
Note. The maximum adjustment range is 90° to left or right of center position.
Tighten nut -A- with T10179.
Use special tool as follows.
Scheme 9
After tightening nut -A-, check camber value once more WHEEL ALIGNMENT SPECIFIED VALUES .
Tightening specifications, refer to SUBFRAME, DIAGONAL BRACE, LOWER TRANSVERSE LINK, UPPER TRANSVERSE LINK, TIE ROD AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .
Tightening specifications, refer to SUBFRAME, LOWER TRANSVERSE LINK, UPPER TRANSVERSE LINK, TIE ROD AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW, COUPE .
Tightening specifications, refer to SUBFRAME, DIAGONAL BRACES, CROSSMEMBER, LOWER TRANSVERSE LINK, UPPER TRANSVERSE LINK, TIE ROD AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW, ROADSTER .
REAR AXLE TOE, ADJUSTING
Remove lower transverse link to subframe connection nut -A- and loosely install new nut.
Scheme 10
Adjust toe by turning eccentric screw -B-.
Note. The maximum adjustment range is 90° to left or right of center position.
Tighten nut -A-.
After tightening nut -A-, check toe value once more. Refer to WHEEL ALIGNMENT SPECIFIED VALUES .
Tightening specifications, refer to SUBFRAME, DIAGONAL BRACE, LOWER TRANSVERSE LINK, UPPER TRANSVERSE LINK, TIE ROD AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW .
Tightening specifications, refer to SUBFRAME, LOWER TRANSVERSE LINK, UPPER TRANSVERSE LINK, TIE ROD AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW, COUPE .
Tightening specifications, refer to SUBFRAME, DIAGONAL BRACES, CROSSMEMBER, LOWER TRANSVERSE LINK, UPPER TRANSVERSE LINK, TIE ROD AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW, ROADSTER .
FRONT AXLE TOE, ADJUSTING
To loosen or tighten lock nut -B-, counterhold at tie rod end -A- with a wrench.
Scheme 11
Loosen lock nut -B-.
Adjust toe on left and right-hand wheels with hex -C-.
Note. Make sure that boot on steering gear is not damaged or twisted. Twisted boots wear out quickly. Only tighten lock nuts when vehicle is resting on ground - tie rod end must be parallel to suspension strut steering lever.
Tighten lock nut -B- and check toe-in value again.
After tightening lock nut -B- it is possible that the value deviates slightly.
If the measured toe nevertheless lies within the tolerance, the adjustment is correct.
Tightening specifications, refer to ELECTROMECHANICAL POWER STEERING GEAR
TIRE PRESSURE MONITORING CONTROL MODULE
Removing
Note. The Tire Pressure Monitoring Control Module -J502- is located under the instrument cluster. Before removing control module, read out code using Guided Fault Finding in "Replace control module" function.
Remove instrument cluster. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .
Remove bolts -arrows-.
Scheme 12
Remove tire pressure monitoring control module -2- and disconnect the connector -1-.
Installing
Installation is performed in the reverse order of removal.
If tire pressure monitoring control module is replaced, system must be coded. Refer to TIRE PRESSURE MONITORING SYSTEM USAGE, DIRECT SYSTEM .
TIRE PRESSURE MONITORING CONTROL MODULE 2
Removing
Special tools and workshop equipment required
- Vehicle diagnosis, testing and information system VAS 5051 A
Note. The Tire Pressure Monitoring Control Module 2 -J793- is located under the instrument cluster. Before removing control module, read out code using Guided Fault Finding in "Replace control module" function.
Remove instrument cluster. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .
Remove bolts -arrows-.
Remove tire pressure monitoring control module 2 -2- and disconnect the connector -1-.
Installing
Installation is the reverse of removal, with special attention to the following
If tire pressure monitoring control module 2 is replaced, system must be coded.
Connect VAS 5051 A and select "Guided Functions".
Then
4C Tire pressure monitoring II J793
Replacing 4C control module (repair group 44)
TIRE PRESSURE SENSOR
Special tools and workshop equipment required
- Torque wrench V.A.G 1410
Removing
Scheme 13
Remove the union nut -1-.
Remove tire pressure sensor -2- from rim well.
Installing
Note. Damaged sensors must be replaced. When using used wheel electronics, make sure the connection between the wheel electronics and valve is not damaged. After using tire sealant, wipe off the wheel electronics while they are still installed and make sure the hole in the pressure sensor is not plugged. If the hole is plugged, replace the wheel electronics to prevent incorrect measurements. Do not clean the wheel electronics with steam blasting or strong compressed air. When sliding on a new gasket and sealing washer, counterhold the valve body to prevent the antenna connection from being damaged.
Insert the tire pressure sensor with the new seal and sealing washer through the rim from the inside and press the seal into the valve bore.
Install union nut -1- on tire pressure sensor -2-.
Press tire pressure sensor -1- onto rim well and tighten union nut. Refer to TIRE PRESSURE MONITORING SENSOR ASSEMBLY OVERVIEW .
Scheme 14
Note. After installing, tire pressure sensor must lie firmly in its bed. Sealing washer -arrow- becomes slightly deformed when doing this.
TIRES, CHANGING, WITH TIRE PRESSURE MONITORING SYSTEM
Note. Nickel-plated valve insert must be replaced with every tire change. The tire pressure sensor can be reused.
Let air out of tire by removing nickel-plated valve insert.
Dismount tire. Refer to TIRES, CHANGING, WITH TIRE PRESSURE MONITORING SYSTEM .
When reusing used tire pressure sensors, inspect connection between sensor and metal valve visually for damage.
Note. Damaged sensors must be replaced.
Mount tire. Refer to TIRES, CHANGING, WITH TIRE PRESSURE MONITORING SYSTEM .
Install new nickel-plated valve insert.
Fill tires.
Balance tires.
Scheme 15
Roll or press tires off.
When using pressure paddles, first separate tires from side opposite of valve.
| CAUTION | Do not use pressure paddles in hatched area -a-. |
Position mounting head near valve so that so that tire iron can be put on approximately 30° -b- next to tire valve.
Then remove tire in valve area first.
Scheme 16
| CAUTION | Do not use pressure paddles in valve area. |
Position tire pressure sensor approximately 180° opposite the mounting head.
Press tire in bed approximately 90° in front of mounting head -arrow-.
Mount tire.
SPECIAL TOOLS
Special tools and workshop equipment required
Scheme 17
- Vehicle diagnosis, testing and information system VAS 5051 A
- Torque wrench V.A.G 1410
Scheme 18
Special tools and workshop equipment required
- Alignment Computer V.A.G 1813 or VW-/Audi-approved alignment unit
- Brake pedal actuator V.A.G 1869/2
- Insert tool T10179
- Shock absorber set T10001
See also:
• General Information
• LEVEL CONTROL SYSTEM SENSORS
• SUBFRAME, STABILIZER BAR, TRANSVERSE LINK, BALL JOINT, AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW
• SUBFRAME, DIAGONAL BRACE, LOWER TRANSVERSE LINK, UPPER TRANSVERSE LINK, TIE ROD AND LEVEL CONTROL SYSTEM SENSOR ASSEMBLY OVERVIEW
• ELECTROMECHANICAL POWER STEERING GEAR
• [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation
• TIRES, CHANGING, WITH TIRE PRESSURE MONITORING SYSTEM
• TIRE PRESSURE MONITORING SYSTEM USAGE, DIRECT SYSTEM
• TIRE PRESSURE SENSOR
• WHEEL ALIGNMENT TEST PREREQUISITES
• FRONT AXLE CAMBER, ADJUSTING
• REAR AXLE CAMBER, ADJUSTING
• REAR AXLE TOE, ADJUSTING
• FRONT AXLE TOE, ADJUSTING
• WHEEL ALIGNMENT
• WHEEL ALIGNMENT SPECIFIED VALUES
