Seat Frames (roadster) Audi TT 8J

SEAT VERSIONS OVERVIEW

Note. Power front seats are shown in the illustrations.

Scheme 326

1. Driver seat Manual Front Seat With manual backrest release, Coupe only Without backrest release, with seat belt retaining loop, Roadster only Assembly Overview, refer to «FRONT SEAT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat-assembly-overview) Removing and Installing, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat) Optional equipment: Seat and backrest heating Four-way lumbar support Storage compartment Power Front Seat With manual backrest release, Coupe only Without backrest release, with seat belt retaining loop, Roadster only Assembly Overview, refer to «FRONT SEAT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Optional equipment: Storage compartment
2. Front passenger seat Manual Front Seat With manual backrest release, Coupe only Without backrest release, with seat belt retaining loop, Roadster only Assembly Overview, refer to «FRONT SEAT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat-assembly-overview) Removing and Installing, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat) Optional equipment: Seat and backrest heating Four-way lumbar support Storage compartment LATCH child seat anchor Power Front Seat with manual backrest release, Coupe only without backrest release, with seat belt retaining loop, Roadster only Assembly Overview, refer to «FRONT SEAT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Optional equipment: Storage compartment LATCH child seat anchor
3. Bench seat Undivided Assembly Overview, refer to «BENCH SEAT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «BENCH SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__bench-seat)
4. Backrest Divided evenly Assembly Overview, refer to «1/2 LEFT AND RIGHT BACKREST ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__12-left-and-right-backrest-assembly) Removing and Installing, refer to «BACKREST»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest) Optional equipment: LATCH child seat anchor Versions for specific countries: Child seat anchors (on backrest frame) Top Tether (child seat anchor in backrest shell)

BRINGING FRONT SEATS INTO SERVICE POSITION

Special tools and workshop equipment required

Scheme 327

1. Trim removal wedge 3409

Service Position, Implementing

Bring headrest into lowest lock position.

Move seat as far back and up as possible.

Only with Electrically Adjustable Seat

Scheme 328

Note. The surrounding area was not shown in the illustration for clarity purposes.

Pry cover caps -1- from seat rail covers -3- and seat fore/aft adjustment spindle -2- with Trim Removal Wedge 3409.

Procedure for All Vehicles

Scheme 329

Unclip rear cover -1- with the trim removal wedge 3409 and pull the cover in the direction of -arrow- off of connector station -2-.

Note. Do not disconnect electrical wires.

Service Position, Resetting

Install in reverse order of removal. Note the following

Make sure the cover tab slides into connector station correctly.

Engage the cover correctly with the connector station.

INSTALLING FRONT SEAT ON VAS 6136

Special tools and workshop equipment required

Scheme 330

Scheme 331

1. Engine and transmission holder VAS 6095
2. Fixture for seat repair VAS 6136

Installing the front seat on the fixture for seat repair VAS 6136

1. The front seat is removed from the vehicle.

Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095.

Attach the front seat to the fixture for seat repair VAS 6136.

FRONT SEAT ASSEMBLY OVERVIEW

Note. The overview is based on the driver's seat. The passenger's seat is similar and the components are installed reversed from left to right. The carpet was not shown in the illustration for clarity reasons.

Scheme 332

1. Seat rail cover Right front Removing and Installing, refer to «SEAT RAIL COVERS»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-rail-covers)
2. Bolt 40 Nm Quantity: 4
3. Trim Tunnel side Removing and Installing, refer to «TUNNEL SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__tunnel-side-trim)
4. Front seat Removing and Installing, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat)
5. Handle With entry assist Removing and Installing, refer to «TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__trim-with-entry-assistance-handle-coupe) Coupe only
6. Trim With entry assist Removing and Installing, refer to «TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__trim-with-entry-assistance-handle-coupe) Coupe only
7. Retaining loop with push button For seat belt Roadster only
8. Backrest adjusting wheel Removing and Installing, refer to «BACKREST ADJUSTING WHEEL»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-adjusting-wheel)
9. LATCH child seat anchor Vehicles with For the front passenger seat only Removing and Installing, refer to «FRONT SEAT LATCH CHILD SEAT ANCHORAGE ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster__front-seat-latch-child-seat-anchorage) Check after accident «CHILD SEAT ANCHORAGES, INSPECTING AFTER AN ACCIDENT»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster__child-seat-anchorages-inspecting-after-an)
10. Seat height adjustment handle Assembly Overview, refer to «SEAT HEIGHT ADJUSTER AND SEAT HEIGHT ADJUSTMENT HANDLE ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-height-adjustment-handle)
11. Lumbar support adjustment mechanism Vehicles with Driver Seat Lumbar Support Adjustment Switch -E176-, removing and installing «FRONT SEAT LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Front passenger seat lumbar support adjustment switch -E177-, removing and installing «FRONT SEAT LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Four-way lumbar support, removing and installing «FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) NOTE: For overview purposes, the four-way lumbar support adjuster is not shown in the illustration.
12. Seat rail cover Left front Removing and Installing, refer to «SEAT RAIL COVERS»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-rail-covers)
13. Rear console Welded with floor assembly
14. Front console Welded with floor assembly
15. Trim Sill side Removing and Installing, refer to «SILL SIDETRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__sill-sidetrim)
16. Storage compartment Vehicles with Assembly Overview, refer to «STORAGE COMPARTMENT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__storage-compartment-assembly-overview) Removing and Installing, refer to «STORAGE COMPARTMENT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__storage-compartment) Storage compartment individual parts, assembly overview, refer to «STORAGE COMPARTMENT INDIVIDUAL COMPONENTS ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__storage-compartment-individual-components-assembly-overview) Storage compartment, disassembling and assembling, refer to «STORAGE COMPARTMENT, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__storage-compartment-disassembling-and-assembling)
17. Handle For seat forward/back adjustment Removing and Installing, refer to «SEAT FORWARD/BACK ADJUSTMENT HANDLE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-adjustment-handle)
18. Seat Forward/Back Adjustment Stop Quantity: 2 Clipped Removing and Installing, refer to «SEAT FORWARD/BACK ADJUSTMENT STOP»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-adjustment-stop)

HARNESS CONNECTORS, DISCONNECTING AND CONNECTING

The connector station is located in the vehicle floor under the front seat area. The following describes disconnecting and connecting the connectors on a power front seat.

Connectors, disconnecting and connecting, refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING

AIRBAG ADAPTER, CONNECTING

The following describes connecting an airbag adapter on power front seat.

Airbag adapter, connecting, refer to AIRBAG ADAPTER, CONNECTING

CONNECTOR STATION CONNECTORS

The connectors are routed the same way on the manual seat as on the power seat.

Connector station connectors refer to CONNECTOR STATION CONNECTORS

MODULAR WIRE ROUTING ASSEMBLY OVERVIEW

Note. Check version of front seat and of vehicle and perform repairs accordingly. Note the two possible versions of the modular wiring routing, Modular Light and Modular. Refer to MODULAR WIRING ROUTING VERSIONS .

Scheme 333

1. Bolt For the cable clamp 3.5 Nm
2. Front seat
3. Wiring harness Observe notes for routing wiring harness in corrugated pipe. Refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__modular-wire-routing-with-ridged-tube)
4. Cable tie
5. Cable bracket Note location «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__modular-wire-routing-with-ridged-tube)
6. Corrugated pipe Upper shell Note location «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__modular-wire-routing-with-ridged-tube)
7. Corrugated pipe Lower shell Note location «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__modular-wire-routing-with-ridged-tube)

MODULAR WIRING ROUTING VERSIONS

There are two versions of modular wiring routing

1. «>>MODULAR LIGHT<<»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__modular-light)
2. «>>MODULAR<<»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__modular) .

>>MODULAR LIGHT<<

A characteristic of the >>Modular Light<< versions is that only the side airbag wiring harness leads directly to the connector station in the vehicle floor. There is no additional connector (intermediate coupling) present in the side airbag wiring harness.

All other electrical or electronic components, for example, seat occupied recognition, electrically adjustable headrests, seat and backrest heating, electrical backrest adjustment, etc., have an additional connector (intermediate coupling) -1-, -2-, -3- on the underside of the seat pan upper frame.

Scheme 334

4 - Clip

All wiring harnesses are routed in a two-part corrugated pipe in the seat/connector station area.

>>MODULAR<<

A characteristic of >>Modular<< wiring routing is that all wiring harnesses for electrical or electronic components, for example, side airbag, seat occupied recognition, bladder system, electrically adjustable headrests, seat and backrest heating, electrical backrest adjustment, etc., lead directly to the connector station in the vehicle floor. There are no additional connectors (intermediate couplings) in the electrical or electronic component wiring harnesses.

All wiring harnesses are routed in a two-part corrugated pipe in the seat/connector station area.

MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT

Special tools and workshop equipment required

1. Trim removal wedge 3409

General Information

With the introduction of modular wiring routing (Modular Light or Modular), the complete sheathing of the entire wiring harness with a fabric strap between the seat tray and the connectors to the connector station has been eliminated. A two-shell corrugated pipe in which the individual wires are routed separately has been implemented for this purpose.

Opening Corrugated Pipe and Removing Individual Wire

Remove the front seat

1. Manually Adjustable Front Seat, Removing and Installing, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat)
2. Power Front Seat, Removing and Installing, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

Attach the front seat to the fixture for seat repair VAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Using Trim Removal Wedge 3409, open cable bracket -1-.

Scheme 335

Remove cable bracket -1- from corrugated pipe -2-.

Remove the bolt -1-.

Scheme 336

Remove cable clip -2- from corrugated pipe -3-.

Open fabric band -2- in area of -arrow-.

Scheme 337

Open corrugated pipe -1-.

Replace the faulty wire and the side airbag SIDE AIRBAG . Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

INSTALL INDIVIDUAL WIRES AND CLOSE CORRUGATED PIPE

Install in reverse order of removal. Note the following

When bundling and placing individual wires in corrugated pipe, ensure wires are not twisted.

Note. Note installation position of two-part corrugated pipe to wiring harness and position of cable bracket to corrugated pipe.

The beginning of the corrugated pipe -4- should be placed immediately after the clip -2- or cable tie.

Scheme 338

3 - Wiring harness to the connector station

Ensure two-part corrugated pipe -4- locks cleanly over entire length.

After connecting both halves of the corrugated pipe, wiring bracket -1- should be positioned and clipped into place according to the illustration.

Make sure the side -arrow A- of cable bracket -1- connects to the last rib -arrow B- on the corrugated pipe -4-.

Then bind transition of seat side of corrugated pipe -1- and wiring harness -2- with self-adhesive fabric tape -arrow-.

Secure corrugated pipe -3- and wiring harness to seat pan with a cable clip -2-.

1 - Bolt

Install cable ties, cable bracket and clips in the same positions as before removal.

Scheme 339

1. Front seat
2. Bolt 2.5 Nm
3. Tunnel side trim Can only be replaced with seat removed Removing and Installing, refer to «TUNNEL SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__tunnel-side-trim)
4. Expanding rivet Quantity: 4
5. Backrest adjusting wheel Removing and Installing, refer to «BACKREST ADJUSTING WHEEL»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-adjusting-wheel)
6. Seat height adjustment handle Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-height-adjustment-handle)
7. Driver seat lumbar support adjustment switch -E176- or front passenger seat lumbar support adjustment switch -E177- Vehicles with Assembly Overview, refer to «FRONT SEAT LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
8. Sill-side trim Can be replaced with seat installed Removing and Installing, refer to «SILL SIDETRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__sill-sidetrim)

Scheme 340

1. Sill-side trim
2. Bolt 0.5 Nm Quantity: 2
3. Lumbar support adjustment switch -- Driver side -E176- Passenger side -E177- Removing and Installing, refer to «FRONT SEAT LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat-lumbar-support-adjustment-switches) Switch and operating knob cannot be separated Connector connecting direction from below On manual front seats with passenger occupant detection system (country-specific), the driver seal lumbar support adjustment switch -E176- or -E177- is rotated 180° when installed Connector connecting direction from above

Scheme 341

1. Front seat Mechanically adjustable
2. Sill side retaining bracket Removing and Installing, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__sill-side-retaining-bracket-trim)
3. Bolt 3.5 Nm Quantity: 2
4. Bolt 3.5 Nm
5. Threaded clip

Scheme 342

1. Seat height adjustment handle Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-height-adjustment-handle)
2. Retaining clip Always replace if removed Note location «Clip, Installation Location»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
3. Lever For seat height adjustment handle
4. Seat height adjuster Removing and Installing, refer to «SEAT HEIGHT ADJUSTER»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-height-adjuster)
5. Bolt 8 Nm
6. Nut 12 Nm
7. Retaining plate
8. Bolt 8 Nm Quantity: 2

Scheme 343

1. Seat pan
2. Screw, self-locking 36 Nm Quantity: 4 Replacing Threaded holes for screws must always be cleaned (for example, with thread cutter)
3. Front backrest Removing and Installing, refer to «FRONT BACKREST»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-backrest)
4. Headrest Removing and Installing, refer to «HEADRESTS ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__headrests-assembly-overview)
5. Handle With entry assist Removing and Installing, refer to «TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__trim-with-entry-assistance-handle-coupe) Coupe only
6. Trim With entry assist Removing and Installing, refer to «TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__trim-with-entry-assistance-handle-coupe) Coupe only
7. Retaining loop with push button For seat belt Roadster only
8. Wiring For side airbag depending on optional equipment, there may be more wires, such as for seat heating, lumbar support

Cable Clip to Seat Pan

1- - 3.5 Nm

BACKREST COVER ASSEMBLY OVERVIEW

The backrest cover on a manual front seat is the same as on a power front seat.

Backrest cover, assembly overview, refer to BACKREST COVER

Scheme 344

1. Spring mat Removing and Installing, refer to «SPRING MAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__spring-mat) Can be removed and installed with and without pull-springs
2. Backrest frame
3. Release cable With entry assist Coupe only
4. Pull-spring Each of the five pull-springs have a different number of coils

FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW

The four-way lumber support on the manual front seat is the same as the one on a power front seat.

Four-way lumbar support, assembly overview, refer to FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW

ENTRY ASSISTANCE ASSEMBLY OVERVIEW, COUPE ONLY

The entry assistance on a manual front seat is the same as on a power front seat.

Entry Assistance, Coupe Only, Assembly Overview, refer to ENTRY ASSISTANCE ASSEMBLY OVERVIEW, COUPE ONLY

ENTRY ASSISTANCE RELEASE CABLES, ADJUSTING, COUPE ONLY

The following describes adjusting the release cables on a power front seat.

Entry Assistance Release Cables, Coupe Only, Adjusting, refer to ENTRY ASSISTANCE RELEASE CABLES ADJUSTING, COUPE ONLY

HEADRESTS ASSEMBLY OVERVIEW

Headrests, assembly overview, refer to HEADRESTS ASSEMBLY OVERVIEW

SEAT PAN ASSEMBLY OVERVIEW

Note. Upper and lower seat pan frames must not be separated. If damaged, replace the entire seat pan.

Scheme 345

1. Upper seat pan frame Do not separate from lower seat pan frame Removing and Installing, refer to «SEAT PAN»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-pan)
2. Shear tension bolts with self-locking collar Quantity: 6 Must not be drilled out
3. Lower seat pan frame Do not separate from upper frame Removing and Installing, refer to «SEAT PAN»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-pan)

STORAGE COMPARTMENT ASSEMBLY OVERVIEW

Storage compartment, assembly overview, refer to STORAGE COMPARTMENT ASSEMBLY OVERVIEW

STORAGE COMPARTMENT INDIVIDUAL COMPONENTS ASSEMBLY OVERVIEW

Storage compartment individual parts, assembly overview, refer to STORAGE COMPARTMENT INDIVIDUAL COMPONENTS ASSEMBLY OVERVIEW

STORAGE COMPARTMENT, DISASSEMBLING AND ASSEMBLING

Storage compartment, disassembling and assembling, refer to STORAGE COMPARTMENT, DISASSEMBLING AND ASSEMBLING

Note. The overview is based on the driver's seat. The passenger's seat is similar and the components are installed reversed from left to right. The carpet was not shown in the illustration for clarity reasons.

Scheme 346

1. Seat rail cover Right front Removing and Installing, refer to «SEAT RAIL AND SPINDLE COVERS»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-rail-and-spindle-covers)
2. Spindle cover Clipped into seat rails at left and right front Removing and Installing, refer to «SEAT RAIL AND SPINDLE COVERS»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-rail-and-spindle-covers)
3. Bolt 40 Nm Quantity: 4
4. Trim Tunnel side Removing and Installing, refer to «SILL AND TUNNEL SIDE TRIM ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
5. Front seat Removing and Installing, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Remove if the seat forward/back adjustment motor -V288- is faulty, refer to «FRONT SEAT, REMOVING A FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR V288»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat-removing-a-faulty-seat) .
6. Handle With entry assist Removing and Installing, refer to «ENTRY ASSISTANCE ASSEMBLY OVERVIEW, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Coupe only
7. Trim With entry assist Removing and Installing, refer to «ENTRY ASSISTANCE ASSEMBLY OVERVIEW, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Coupe only
8. Retaining loop with push button For seat belt Roadster only
9. LATCH child seat anchor Vehicles with For the front passenger seat only Removing and Installing, refer to «FRONT SEAT LATCH CHILD SEAT ANCHORAGE ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster__front-seat-latch-child-seat-anchorage) Check after accident, refer to «CHILD SEAT ANCHORAGES, INSPECTING AFTER AN ACCIDENT»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster__child-seat-anchorages-inspecting-after-an)
10. Actuator For Driver Backrest Adjustment Switch -E96- or -E98- Actuator, removing and installing, refer to «SEAT AND BACKREST ADJUSTMENT ACTUATOR ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Switch, removing and installing, refer to «SEAT FORWARD/BACK, ANGLE, HEIGHT AND BACKREST ADJUSTMENT SWITCHES V288/V243/V244/V245/V246/V45/V46»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-angle-height-and-backrest)
11. Actuator For Driver Seat Fore/Aft Switch -E363- or -E64- For driver seat angle adjustment switch -E222- or -E334- For Driver Seat Height Adjustment Switch -E364- or -E365- Actuator, removing and installing, refer to «SEAT AND BACKREST ADJUSTMENT ACTUATOR ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Switch, removing and installing, refer to «SEAT FORWARD/BACK, ANGLE, HEIGHT AND BACKREST ADJUSTMENT SWITCHES V288/V243/V244/V245/V246/V45/V46»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-angle-height-and-backrest)
12. Driver Seat Lumbar Support Adjustment Switch -E176- or -E177- Switch, removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Four-way lumbar support, removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) NOTE: For overview purposes, the four-way lumbar support adjuster is not shown in the illustration.
13. Rear console Welded with floor assembly
14. Front console Welded with floor assembly
15. Seat rail cover Left front Removing and Installing, refer to «SEAT RAIL AND SPINDLE COVERS»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-rail-and-spindle-covers)
16. Trim Sill side Removing and Installing, refer to «SILL AND TUNNEL SIDE TRIM ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
17. Storage compartment Vehicles with Assembly Overview, refer to «STORAGE COMPARTMENT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «STORAGE COMPARTMENT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Storage compartment individual parts, assembly overview, refer to «STORAGE COMPARTMENT INDIVIDUAL COMPONENTS ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Storage compartment, disassembling and assembling, refer to «STORAGE COMPARTMENT, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

Electrical and Electronic Components Overview

Scheme 347

1. Seat angle adjustment motor Driver side -V243- Passenger side -V244- Assembly Overview, refer to «SEAT ANGLE ADJUSTMENT MOTOR V243/V244 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «DRIVER SEAT ANGLE ADJUSTMENT MOTOR V243/V244»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__driver-seat-angle-adjustment-motor-v243v244)
2. Seat forward/back adjustment motor -V288- Assembly Overview, refer to «SEAT FORWARD/BACK ADJUSTMENT MOTOR V288 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «SEAT FORWARD/BACK ADJUSTMENT MOTOR V288»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-adjustment-motor-v288)
3. Backrest adjustment motor Driver side -V45- Passenger side -V46- Assembly Overview, refer to «FRONT SEAT BACKREST ADJUSTMENT MOTORS V45/V46 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat-backrest-adjustment-motors-v45v46) Removing and Installing, refer to «DRIVER'S BACKREST ADJUSTMENT MOTOR V45 OR V46»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__drivers-backrest-adjustment-motor-v45-or)
4. Lumbar support height adjustment motor Driver side -V129- Passenger side -V130- Assembly Overview, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTORS V129 AND V130»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__lumbar-support-height-adjustment-motors-v129)
5. Lumbar support curvature adjustment motor Driver side -V125- Passenger side -V126- Assembly Overview, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTORS V125 AND V126»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__lumbar-support-curvature-adjustment-motors-v125)
6. Stop switch coupling
7. Housing with stop switch For driver's seat backrest -E69- For passenger's seat backrest -E70- Assembly Overview, refer to «FRONT SEAT BACKREST STOP SWITCHES E69 AND E70 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «FRONT SEAT BACKREST STOP SWITCHES E69 AND E70»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat-backrest-stop-switches-e69) Only stop switch may be removed and installed
8. Seat height adjustment motor Driver side -V245- Passenger side -V246- Assembly Overview, refer to «SEAT HEIGHT ADJUSTMENT MOTORS V245 AND V246 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-height-adjustment-motor-v245-and)
9. Switch Driver Seat Fore/Aft Switch -E363- or -E64- Driver Backrest Adjustment Switch -E96- or -E98- Driver Seat Fore/Aft Switch -E222- or -E334- Driver Seat Fore/Aft Switch -E364- or -E365- NOTE: All switches listed are combined in a single housing and cannot be replaced individually. Assembly Overview, refer to «SEAT ADJUSTMENT SWITCHES, V288/V243/V244/V245/V246/V45/V46 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «SEAT FORWARD/BACK, ANGLE, HEIGHT AND BACKREST ADJUSTMENT SWITCHES V288/V243/V244/V245/V246/V45/V46»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-angle-height-and-backrest)
10. Lumbar support adjustment switch Driver side -E176- Passenger side -E177- Assembly Overview, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__lumbar-support-adjustment-switches-e176-and)

The connector station is located in the vehicle floor under the front seat area.

Disconnecting

Bring seat into service position. Refer to BRINGING FRONT SEATS INTO SERVICE POSITION .

Switch off the ignition.

Disconnect battery ground cable. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

Remove the cable bracket -3- upward from connector station.

Scheme 348

Note. The number of harness connectors may vary depending on the equipment. The description shows the version with the most equipment.

Remove side airbag connector -1-.

Remove seat heating connector -2-.

Disconnect seat adjustment voltage supply connector -4-.

Disconnect the seat belt latch connector -5-.

Connect the airbag adapterVAS 6281 to the side airbag connector on the front seat. Refer to AIRBAG ADAPTER, CONNECTING .

Note. Ensure airbag adapter engages correctly.

Connecting

Connect the connectors in reverse order. Observe the following when doing so

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

The connector station is located in the vehicle floor under the front seat.

Special tools and workshop equipment required

Scheme 349

1. Airbag adapter VAS 6281

Disconnecting

Bring seat into service position. Refer to BRINGING FRONT SEATS INTO SERVICE POSITION .

Switch off the ignition.

Disconnect battery ground cable. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

Release side airbag connector -1- and disconnect it.

Connect Airbag Adapter VAS 6281 -4- to side airbag connector on seat side -1-.

Scheme 350

Connecting

The airbag connectors are connected in reverse order. Observe the following when doing so

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Connector routing, refer to appropriate SYSTEMS WIRING DIAGRAM

Scheme 351

1. Side Airbag
2. Seat heater
3. Seat adjustment power supply
4. Belt latch

Note. The number of harness connectors may vary depending on the equipment. The description shows the version with the most equipment.

Modular wiring routing, assembly overview, refer to MODULAR WIRE ROUTING ASSEMBLY OVERVIEW

The differences between the >>Modular Light<< and >>Modular<< versions are explained in this service information.

Modular wiring routing, versions, refer to MODULAR WIRING ROUTING VERSIONS

The procedure steps and notes about removing and installing the corrugated pipe and wiring are given in the following description.

Modular wiring with corrugated tube on front seat, refer to MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT

Scheme 352

1. Front seat
2. Bolt 2.5 Nm
3. Tunnel side trim Can only be replaced with seat removed Removing and Installing, refer to «TUNNEL SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
4. Expanding rivet Quantity: 4
5. Sill-side trim Can be replaced with seat installed Removing and Installing, refer to «SILL SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__sill-side-trim)
6. Actuator For Driver Backrest Adjustment Switch -E96- or Passenger Backrest Adjustment Switch -E98- Assembly Overview, refer to «SEAT AND BACKREST ADJUSTMENT ACTUATOR ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) The switch -E363-, -E222-, -E364- or switch or button -E64-, -E334- and -E365-; refer to item 7 as well as switch -E96- or -E98- are allocated to the same housing.
7. Actuator for driver seat forward/back adjustment switch -E363- or front passenger seat forward/back adjustment switch -E64- for driver seat angle adjustment switch -E222- or front passenger seat angle adjustment button -E334- for driver seat height adjustment switch -E364- or front passenger seat height adjustment switch -E365- Assembly Overview, refer to «SEAT AND BACKREST ADJUSTMENT ACTUATOR ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) The switch -E363-, -E222-, -E364- or the switch or button -E64-, -E334- and -E365- as well as the switch -E96- or -E98- are allocated to the same housing; refer to item 6 .
8. Driver seat lumbar support adjustment switch -E176- or front passenger seat lumbar support adjustment switch -E177- Assembly Overview, refer to «SEAT AND BACKREST ADJUSTMENT ACTUATOR ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

SILL SIDE TRIM RETAINING BRACKET ASSEMBLY OVERVIEW

The retaining bracket on the power front seat is identical the one on the front manual seat.

Sill side trim retaining bracket, assembly overview, refer to SILL SIDE TRIM RETAINING BRACKET ASSEMBLY OVERVIEW

Scheme 353

1. Actuator For Driver Backrest Adjustment Switch -E96- or Passenger Backrest Adjustment Switch -E98- The switch -E363-, -E222-, -E364- or the switch or button -E64-, -E334- and -E365- as well as the switch -E96- or -E98- are allocated to the same housing; refer to item 2) in (Scheme 353). Actuator, removing and installing «BACKREST ADJUSTMENT ACTUATOR»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-adjustment-actuator) Switch, removing and installing «SEAT ADJUSTMENT SWITCHES, V288/V243/V244/V245/V246/V45/V46 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
2. Actuator For driver seat forward/back adjustment switch -E363- or front passenger seat forward/back adjustment switch -E64- For driver seat angle adjustment switch -E222- or front passenger seat angle adjustment button -E334- For driver seat height adjustment switch -E364- or front passenger seat height adjustment switch -E365- The switch -E363-, -E222-, -E364- or the switch or button -E64-, -E334- and -E365- as well as the switch -E96- or -E98- are allocated to the same housing; refer to item 1) in (Scheme 353). Actuator, removing and installing, refer to «SEAT ADJUSTMENT ACTUATOR»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-adjustment-actuator) Switch, removing and installing, refer to «SEAT ADJUSTMENT SWITCHES, V288/V243/V244/V245/V246/V45/V46 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
3. Driver seat lumbar support adjustment switch -E176- or front passenger seat lumbar support adjustment switch -E177- Do not disconnect actuator and switch, they can only be replaced as a complete assembly unit. Removing and Installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177 ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

Scheme 354

1. Seat pan
2. Screw, self-locking 35 Nm Quantity: 4 Replacing Threaded holes for screws must always be cleaned (for example, with thread cutter)
3. Front backrest Removing and Installing, refer to «FRONT BACKREST»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
4. Headrest Removing and Installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
5. Trim With entry assist Removing and Installing, refer to «ENTRY ASSISTANCE ASSEMBLY OVERVIEW, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Coupe only
6. Handle With entry assist Removing and Installing, refer to «ENTRY ASSISTANCE ASSEMBLY OVERVIEW, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Coupe only
7. Retaining loop with push button For seat belt Roadster only
8. Wiring For side airbag
9. Wiring harness

Cable Clip to Seat Pan

1- - 3.5 Nm

Note. A front seat with Coupe backrest cover is shown in the illustration. The back rest cover on the Coupe and Roadster is the same.

Scheme 355

1. Front seat
2. Release cable With entry assist
3. Tab Formed to backrest cover
4. Backrest cover Removing and Installing, refer to «BACKREST COVER»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
5. Bracket Quantity: 2 Formed to backrest cover
6. Groove For engaging backrest cover
7. Clip Quantity: 2 Clipped into backrest cover Replace if damaged
8. four-way lumbar support Manual seat: Assembly Overview, refer to «FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__four-way-lumbar-support-assembly-overview) Removing and Installing, refer to «FOUR-WAY LUMBAR SUPPORT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__four-way-lumbar-support) Power seats: Assembly Overview, refer to «FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «FOUR-WAY LUMBAR SUPPORT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) «FOUR-WAY LUMBAR SUPPORT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
9. Spring mat Manual seat: Assembly Overview, refer to «SPRING MAT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «SPRING MAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__spring-mat)

Note. The cover with upholstery in the backrest is not shown for clarity purposes.

Scheme 356

1. Four-way lumbar support Removing and Installing, refer to «FOUR-WAY LUMBAR SUPPORT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
2. Release cable With entry assist Coupe only
3. Clip For release cable guide; refer to item 4
4. Release cable For lumbar support height adjustment can only be replaced with Driver Seat Lumbar Support Height Adjustment Motor -V129- or Front passenger Seat Lumbar Support Height Adjustment Motor -V130
5. Driver Seat Lumbar Support Height Adjustment Motor -V129- or Front passenger Seat Lumbar Support Height Adjustment Motor -V130- Removing and Installing, refer to «LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTORS V129 AND V130»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__lumbar-support-height-adjustment-motors-v129)
6. Backrest frame
7. Rivet Rivet using special pop rivet pliers V.A.G 1753A before riveting, a plastic washer must be placed between lumbar support and backrest frame; refer to item 10
8. Release cable For lumbar support curvature adjustment Can only be replaced with Driver Seat Lumbar Support Curvature Adjustment Motor -V125- or Front Passenger's Seat Lumbar Support Curvature Adjustment Motor -V126
9. Clip
10. Plastic washer Between four-way lumbar support and backrest frame
11. Retaining plate
12. Retainer
13. Cable tie
14. Driver Seat Lumbar Support Curvature Adjustment Motor -V125- or Front Passenger's Seat Lumbar Support Curvature Adjustment Motor -V126- Removing and Installing, refer to «LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTORS V125 AND V126»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__lumbar-support-curvature-adjustment-motors-v125)

Note. The four-way lumbar support was not shown in the illustration for clarity purposes.

Scheme 357

1. Backrest frame
2. Release cable adjuster for right release cable
3. Cable tie
4. Right release cable Removing and Installing, refer to «LEFT AND RIGHT RELEASE CABLES, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
5. Pull-spring engaged in operating lever and release cables bracket
6. Lever For the entry assistance handle Riveted to backrest frame
7. Stop button For left and right release cable Do not disengage release cables from bracket
8. left release cable Removing and Installing, refer to «LEFT AND RIGHT RELEASE CABLES, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
9. Mount For left and right release cable Do not disengage release cables from bracket Bracket clipped into backrest frame
10. Bolt 4 Nm Quantity: 2
11. Trim with handle With entry assist Cannot be removed without destroying through 10.06 Trim is clipped with bracket; refer to item 12 Removing and Installing through 10.06, refer to «TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY THROUGH 10.06»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__trim-with-entry-assistance-handle-coupe) Removing and Installing from 11.06, refer to «TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY FROM 11.06»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__trim-with-entry-assistance-handle-coupe)
12. Bracket With entry assist Bolted to backrest frame Removing and Installing, refer to «ENTRY ASSISTANCE BRACKET, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
13. Release cable adjuster For left release cable
14. left release cable bracket Riveted to backrest frame
15. right release cable bracket Riveted to backrest frame
16. Rivet Quantity: 2

1. Cover and upholstery removed, refer to «BACKREST COVER AND UPHOLSTERY»(/audi/tt/8j-2006-2010/remont/seats/#seat-upholstery-covers-roadster__backrest-cover-and-upholstery) .
2. Left and right release cables installed, refer to «LEFT AND RIGHT RELEASE CABLES, COUPE ONLY»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

Pins (release pins) -2- are in locked position on both sides (delivery position, that means - lower basic position).

Scheme 358

1 - Release cable

Bring lever -1- to a distance of a = 3 mm to edge of opening -arrow-.

Scheme 359

Adjust left and right release cables -1- and -2- at release cable adjusters -4-.

Scheme 360

Note. Right release cable adjuster not shown in the illustration for overview purposes.

To adjust, turn upper part -arrow A- and lower part -arrow B- of release cable adjuster -4- against each other.

Adjust release cable adjuster -4- so release cable -1- is free of tension and release cable is loose.

Note. Proceed the same way with the release cable that is not pictured. When adjusting the release cable, do not pull on release pins -2-.

After adjusting release cables, check function of backrest lock.

When pressing lever -1-, backrest must be released when lever is at a distance of a = 9 mm to edge of opening.

Scheme 361

If it does not release or only releases partially, check release cable routing or repeat adjustment.

Note. The cover with upholstery in the backrest is not shown for clarity purposes. The illustration shows a Coupe backrest frame. The headrest guides and headrests are allocated and secured the same way on the Coupe and Roadster.

Scheme 362

1. Front backrest
2. Headrest guide without release button Removing and Installing, refer to «HEADREST GUIDE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Always installed on right side of backrest
3. Headrest Removing and Installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
4. Headrest guide with release button Removing and Installing, refer to «HEADREST GUIDE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Always installed on left side of backrest

Note. The upper and lower seat pan frames can be separated and replaced individually on a power front seat. When removing seat pan, ensure bushings in bearing points (upper and lower frame threaded connection) are not damaged. These bushings cannot be replaced with workshop materials.

Scheme 363

1. Screw, self-locking 29 Nm Quantity: 3 Replacing Threaded holes for screws must always be cleaned (for example, with thread cutter)
2. Upper seat pan frame Removing and Installing, refer to «SEAT PAN, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-pan-disassembling-and-assembling)
3. Bushing Inserted in all bracket locations Cannot be replaced with workshop materials If the bushing is damaged, assembly part must be replaced
4. Lower seat pan frame Removing and Installing, refer to «SEAT PAN, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-pan-disassembling-and-assembling)
5. Bolt 27 Nm Always replace if removed Before installing new bolts, clean threads on seat pan nuts
6. Driver Seat Height Adjustment Motor -V245- or Front Passenger's Seat Height Adjustment Motor -V246- Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-height-adjustment-motor-v245-and)
7. Seat forward/back adjustment motor -V288- Cannot be removed and installed with workshop materials Stays on the lower seat pan frame; refer to item 4
8. Driver seat angle adjustment motor -V243- or front passenger seat angle adjustment motor -V244- Removing and Installing, refer to «DRIVER SEAT ANGLE ADJUSTMENT MOTOR V243/V244»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__driver-seat-angle-adjustment-motor-v243v244)
9. Screw, self-locking For the correct tightening specifications (Scheme 375)Replacing Threaded holes for screws must always be cleaned (for example, with thread cutter)

SEAT PAN, DISASSEMBLING AND ASSEMBLING

Disassembling

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove the backrest. Refer to FRONT BACKREST .

Remove cover with seat pan upholstery. Refer to SEAT PAN COVER AND UPHOLSTERY .

Disconnect the harness connectors if applicable.

Replace Upper Seat Pan Frame

Remove wiring harnesses and individual wires from seat pan upper frame.

Continuation: Upper or Lower Frame, Replacing

Scheme 364

Remove bolts -1- (quantity: 3).

Remove the bolt -4-.

Remove the bolt -5-.

Remove upper frame -2- upward from lower frame -3- of the seat pan.

Be careful of bushings -1- in bearing points.

Scheme 365

2 - Lower seat pan frame

Remove Driver Seat Height Adjustment Motor -V245- or Front Passenger's Seat Height Adjustment Motor -V246- SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246 .

Remove the driver seat angle adjustment motor -V243- or front passenger seat angle adjustment motor -V244- DRIVER SEAT ANGLE ADJUSTMENT MOTOR V243/V244 .

Seat pan, Assembling

Install in reverse order of removal. Note the following

Install removed driver seat height adjustment motor -V245- or front passenger seat height adjustment motor -V246- in new lower seat pan frame. Refer to SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246 .

Install the driver seat angle adjustment motor -V243- or front passenger seat angle adjustment motor -V244- in the new lower seat pan frame. Refer to DRIVER SEAT ANGLE ADJUSTMENT MOTOR V243/V244 .

Do not damage bushings -1- during further assembly.

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Scheme 366

1. Storage compartment Removing and Installing, refer to «STORAGE COMPARTMENT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Storage compartment individual parts, assembly overview, refer to «STORAGE COMPARTMENT INDIVIDUAL COMPONENTS ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Disassembling and assembling, refer to «STORAGE COMPARTMENT, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
2. Bolt 3.5 Nm Quantity: 4
3. Seat pan
4. Threaded clip Quantity: 4

Scheme 367

1. Axle For handle with locking mechanism, refer to item 3) in (Scheme 368)
2. Torsion spring As a replacement part only with handle with locking mechanism, refer to item 3) in (Scheme 368) and axle (Scheme 368)
3. Handle with locking mechanism As replacement part handle with locking mechanism, axle (Scheme 368) and torsion spring (Scheme 368)
4. Trim Clipped with inner part
5. Insert
6. Inner part As a replacement part only with the outer part (Scheme 368)
7. Outer part As replacement part only with inner part (Scheme 368)

Note. The seat must not be removed to disassemble and assemble storage compartment. The storage compartment can be assembled and disassembled when installed. It is necessary to remove the front seat and the storage compartment in order to replace the outer part 7 .

Scheme 368

Remove the inner part from the outer part INNER PART, REMOVING FROM OUTER PART .

Using the trim removal wedge3409, unclip the trim -1- from the retaining tabs -arrows- (quantity: 4) on the inner part -2-.

Scheme 369

Remove trim TRIM, REMOVING .

Remove axle -1- from inner part -3-.

Remove handle with locking mechanism -4-, torsion spring -2- and axle -1-.

Scheme 370

Note. The insert is placed in the inner part and is not secured by any additional means. For overview purposes, the storage compartment is shown removed and without trim and release handle in the following illustrations.

Open storage compartment.

Remove insert -1- from inner part -2-.

Scheme 371

Open storage compartment.

Press retainers -2- (quantity: 2) upward in direction of -arrow A-.

Tip inner part -1- down in direction of -arrow B-.

Remove outer part -1- from guide -arrow- on inner part -2-.

Scheme 372

Scheme 373

Assembling is reverse of removal, noting the following

Engage the torsion spring -1- so that the shorter side -arrow A- is supported on the inner part -2- and the longer side -arrow B- is supported on the handle.

Scheme 374

1. Seat angle adjustment motor Driver side -V243- Passenger side -V244- Removing and Installing, refer to «DRIVER SEAT ANGLE ADJUSTMENT MOTOR V243/V244»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__driver-seat-angle-adjustment-motor-v243v244)
2. Bolt 14 Nm Quantity: 4
3. Screw, self-locking 22 Nm Replacing Threaded holes for screws must always be cleaned (for example, with thread cutter)
4. Connector

DRIVER SEAT ANGLE ADJUSTMENT MOTOR V243/V244

Removing

Remove the seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove bolts -2- (quantity: 4).

Scheme 375

Remove the bolt -3-.

Remove connector -4-.

Remove Driver Seat Inclination Adjustment Motor -V243- or -V244- -1-.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again. .

Scheme 376

1. Upper seat pan frame Separate the seat pan upper and lower frames and assemble. Refer to «SEAT PAN, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-pan-disassembling-and-assembling)
2. Lower seat pan frame Separate the seat pan upper and lower frames and assemble. Refer to «SEAT PAN, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-pan-disassembling-and-assembling)
3. Seat forward/back adjustment motor -V288- Removing and Installing, refer to «SEAT FORWARD/BACK ADJUSTMENT MOTOR V288»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-adjustment-motor-v288)

FRONT SEAT BACKREST ADJUSTMENT MOTORS V45/V46 ASSEMBLY OVERVIEW

Note. For clarity reasons, the backrest is shown without lumbar support, padding and cover. A Coupe backrest frame is shown in the illustration. The Roadster backrest frame is the same, only the entry assistance release cable shown in the illustration is not installed.

Scheme 377

1. Backrest adjustment motor Driver side -V45- Passenger side -V46- May not be replaced. Refer to «DRIVER'S BACKREST ADJUSTMENT MOTOR V45 OR V46»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__drivers-backrest-adjustment-motor-v45-or) If there is damage to the motor, replace backrest frame with backrest adjustment motor, shaft and housing. Refer to «DRIVER'S BACKREST ADJUSTMENT MOTOR V45 OR V46»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__drivers-backrest-adjustment-motor-v45-or)
2. Front backrest Only backrests shown
3. Rivet Do not remove
4. Housing with stop switch coupling Driver Backrest Stop Switch -E69- or front passenger backrest stop switch -E70- are installed in the housing do not remove the housing from the shaft, refer to item 5 or the component will be damaged The driver backrest stop switch -E69- or front passenger backrest stop switch -E70- may not be replaced. Refer to «FRONT SEAT BACKREST STOP SWITCHES E69 AND E70»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat-backrest-stop-switches-e69)
5. Shaft Do not remove

Scheme 378

1. Backrest frame
2. Stop switch coupling
3. Housing For driver backrest stop switch -E69- or front passenger backrest stop switch -E70- CAUTION: Housing with adjusting element, refer to item 5 , must not be separated from shaft, refer to item 4 , because end positions cannot be found again.
4. Shaft CAUTION: Do not remove shaft from housing with adjusting element.
5. Actuator For driver backrest stop switch -E69- or front passenger backrest stop switch -E70- Must not be removed from shaft, refer to item 4 CAUTION: Housing with adjusting element, refer to item 4 must not be separated from shaft because end positions cannot be found again.
6. Driver Backrest Stop Switch -E69- or Front Passenger Backrest Stop Switch -E70- Removing and Installing, refer to «FRONT SEAT BACKREST STOP SWITCHES E69 AND E70»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat-backrest-stop-switches-e69)

Scheme 379

1. Clip For release cable guide, refer to item 3
2. Release cable With entry assist Coupe only
3. Release cable For four-way lumbar support height adjustment Can only be replaced together with Driver Seat Lumbar Support Height Adjustment Motor -V129- or Front passenger Seat Lumbar Support Height Adjustment Motor -V130
4. Driver Seat Lumbar Support Height Adjustment Motor -V129- or Front passenger Seat Lumbar Support Height Adjustment Motor -V130- Removing and Installing, refer to «LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTORS V129 AND V130»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__lumbar-support-height-adjustment-motors-v129)
5. Driver Seat Lumbar Support Curvature Adjustment Motor -V125- or Front Passenger's Seat Lumbar Support Curvature Adjustment Motor -V126- Removing and Installing, refer to «LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTORS V125 AND V126»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__lumbar-support-curvature-adjustment-motors-v125)
6. Backrest frame
7. Four-way lumbar support
8. Rivet Quantity: 2 per motor Rivet using special pop rivet pliers V.A.G 1753A
9. Connector
10. Release cable For four-way lumbar support curvature adjustment Can only be replaced together with Driver Seat Lumbar Support Curvature Adjustment Motor -V125- or Front Passenger's Seat Lumbar Support Curvature Adjustment Motor -V126
11. Retaining plate
12. Retainer
13. Cable tie

Scheme 380

1. Upper seat pan frame With cover and upholstery Removing and Installing, refer to «SEAT PAN, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-pan-disassembling-and-assembling)
2. Toothed segment Plastic toothed segment Removing and Installing, refer to «SEAT HEIGHT ADJUSTER TOOTHED SEGMENT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-height-adjuster-toothed-segment) Clipped to fitting
3. Driver Seat Height Adjustment Motor -V245- or Front Passenger's Seat Height Adjustment Motor -V246- Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-height-adjustment-motor-v245-and)
4. Screw, self-locking 31 Nm Quantity: 2 Replacing Threaded holes for screws must always be cleaned (for example, with thread cutter)
5. Lower seat pan frame Removing and Installing, refer to «SEAT PAN, DISASSEMBLING AND ASSEMBLING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-pan-disassembling-and-assembling)

Scheme 381

1. Sill-side trim
2. Bolt 0.5 Nm Quantity: 2
3. Lumbar support adjustment switch Driver side -E176- Passenger side -E177- Removing and Installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__lumbar-support-adjustment-switches-e176-and) Switch and actuator cannot be disconnected and replaced separately Connector connecting direction from below On power front seats with passenger occupant detection system (country-specific), the driver seal lumbar support adjustment switch -E176- or -E177- is rotated 180° when installed Connector connecting direction from above

CONNECTORS, DISCONNECTING

Procedure

Scheme 382

Loosen seat mounting bolts. Refer to SEAT .

Tip front seat back.

Release cover cap -1- in direction of -arrow-.

Remove wiring bracket -3-.

Scheme 383

Release clip in direction of -arrow- with a small screwdriver and disconnect electrical connector -1- with side airbag terminal resistance.

Note. The side airbag terminal resistance is a separate connector housing without a cable. The side airbag cable, as shown in the illustration above, is not in the TT.

Press in tab on connector for heated seat -2- on tunnel side and disconnect connector for heated seat.

For vehicles with seat belt fasten sensor

Press in tab on connector for seat belt fasten sensor on tunnel side and disconnect connector for seat belt fasten sensor.

Scheme 384

1. Backrest lock actuating link Removing and Installing, refer to «BACKREST LOCK ACTUATING LINK»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-lock-actuating-link)
2. Actuating link adjuster Left
3. Bolt Tightening specification 2.5 Nm Replace with locking compound Locking compound
4. Left release lever cover
5. Edge protection
6. Bolt Tightening specification 2.5 Nm Replace with locking compound Locking compound
7. Right release lever cover
8. Edge protection
9. Right backrest lock release lever Removing and Installing, refer to «BACKREST LOCK ACTUATING LINK»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-lock-actuating-link)
10. Plastic disc For release lever
11. Right release lever mount
12. Left release lever mount
13. Backrest frame
14. Backrest frame mount
15. Bolt Tightening specification 22 Nm Replace with locking compound Locking compound
16. Pop rivet 6 mm (steel)
17. Plastic washer For release lever
18. Left backrest lock release lever Removing and Installing, refer to «BACKREST LOCK ACTUATING LINK»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-lock-actuating-link)
19. Actuating link adjuster Right

BACKREST LOCK ACTUATING LINK, ADJUSTING

Procedure

Scheme 385

1. Backrest cover removed.

When operating one of the two backrest lock release levers, release pins on left and right of seat frame must be operated at the same time.

Operate backrest lock release lever

1. Left and right release pins must be operated at the same time.

Release backrest lock release lever

1. The actuating links must engage the release pins on the backrest hinge as far as stop.
2. The actuating links must then be relieved.

If necessary, rotate -arrows- adjusters -1 and 2- on actuating links accordingly.

Scheme 386

1. Bench seat Undivided Assembly Overview, refer to «BENCH SEAT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
2. Belt latch Assembly Overview, refer to «REAR BELT LATCH ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster)
3. Cover For backrest center bearing Removing and Installing, refer to «CENTER BEARING COVER CAP»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__center-bearing-cover-cap)
4. Right release Assembly Overview, refer to «LEFT OR RIGHT RELEASE ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
5. 1/2 right backrest Assembly Overview, refer to «1/2 LEFT AND RIGHT BACKREST ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__12-left-and-right-backrest-assembly)
6. Left 1/2 backrest Assembly Overview, refer to «1/2 LEFT AND RIGHT BACKREST ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__12-left-and-right-backrest-assembly)
7. Left release Assembly Overview, refer to «LEFT OR RIGHT RELEASE ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

Scheme 387

1. Bench seat Removing and Installing, refer to «BENCH SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__bench-seat)
2. 1/2 right backrest
3. Left 1/2 backrest
4. Belt latch Assembly Overview, refer to «REAR BELT LATCH ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster) Removing and Installing, refer to «BELT LATCH»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster__belt-latch)
5. Omega clips Quantity: 2 Cannot be replaced For securing bench seat
6. Retaining eyes Welded with bench seat

Scheme 388

1. Seat frame Removing and Installing, refer to «SEAT FRAME»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
2. Cover with upholstery Do not separate from one another when removing seat frame
3. Cushion clamp Quantity: 48 Replacing Install in same location as before removal WARNING: Ends of upholstery clips must face in direction of upholstery after installing and must be bent correctly. Otherwise, there is a risk of injury.

1/2 LEFT AND RIGHT BACKREST ASSEMBLY OVERVIEW

Note. When installing left and right 1/2 backrest, follow threaded connection installation sequence.

Tighten the screw and nut -9- hand-tight. Tighten the screws -1- to the tightening specification. Tighten the nut -5- to the tightening specification. Tighten the screw and the nut -9- to the tightening specification.

Scheme 389

1. Bolt 40 Nm Quantity: 4
2. Right release Assembly Overview, refer to «LEFT OR RIGHT RELEASE ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
3. 1/2 right backrest Removing and Installing, refer to «BACKREST»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest)
4. Left 1/2 backrest Removing and Installing, refer to «BACKREST»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest)
5. Nut 55 Nm
6. Left release Assembly Overview, refer to «LEFT OR RIGHT RELEASE ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
7. Center bearing cover cap Removing and Installing, refer to «CENTER BEARING COVER CAP»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__center-bearing-cover-cap)
8. Belt latch Assembly Overview, refer to «REAR BELT LATCH ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster) Removing and Installing, refer to «BELT LATCH»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster__belt-latch)
9. Screw and nut For the correct tightening specification refer to items 3 & 4: «REAR BELT LATCH ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/airbag/#passenger-protection-airbags-seat-belts-roadster)

Scheme 390

1. Left/right release Without trim With release cable Removing and Installing, refer to «LEFT OR RIGHT RELEASE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__left-or-right-release)
2. Bolt 2.0 Nm Quantity: 6
3. Left/right trim Clipped with release, refer to item 1 Removing and Installing, refer to «LEFT OR RIGHT TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__left-or-right-trim)
4. Button For release Removing and Installing, refer to «RELEASE BUTTON»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__release-button)
5. 1/2 left/right backrest Cover removed
6. Left inner filler piece Removing and Installing, refer to «INNER LEFT OR RIGHT SPACER»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__inner-left-or-right-spacer)
7. Left outer filler piece Removing and Installing, refer to «OUTER LEFT OR RIGHT SPACER»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__outer-left-or-right-spacer)

Scheme 391

1. Right backrest shell Removing and Installing, refer to «BACKREST PANEL»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-panel) Front side taped with two-sided adhesive tape Rear side cover with adhesive film
2. Left backrest shell Removing and Installing, refer to «BACKREST PANEL»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-panel) Front side taped with two-sided adhesive tape Rear side cover with adhesive film
3. Bolt 4.0 Nm Quantity: 16
4. Backrest frame Removing and Installing, refer to «BACKREST FRAME»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-frame) Optional equipment: with child seat anchor (LATCH) without child seat anchor
5. Double sided adhesive tape Attach to front side and upper edge of backrest shell

FRONT SEAT

Special tools and workshop equipment required

1. Airbag adapter VAS 6281

Note. The removal and installation procedure describes a driver seat. The procedure for the front passenger seat is identical.

Removing

Bring seat into service position. Refer to BRINGING FRONT SEATS INTO SERVICE POSITION .

Switch off the ignition.

Disconnect battery ground cable. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

Disconnect the connectors on the connector station inside the floor panel. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING

Connect Airbag AdapterVAS 6281. Refer to AIRBAG ADAPTER, CONNECTING .

Roadster Only

Scheme 392

Open retaining loop -1- by loosening push button -arrow-.

Remove seat belt -2- from retaining loop.

Procedure for all vehicles

Scheme 393

Remove front bolts -1- (quantity: 2).

3 - Rear console

4 - Front console

Press the seat forward/back adjustment handle and move the seat -2- as far forward as possible.

Remove rear bolts -1- (quantity: 2).

With help from a second mechanic, lift seat -2- out of vehicle.

Installation

Install in reverse order of removal. Note the following

Remove Airbag AdapterVAS 6281 only after installing seat. Refer to AIRBAG ADAPTER, CONNECTING .

Note. Make sure the connectors are installed all the way in and are secure.

Connect connector to connectors on connector station location in floor. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again..

SEAT RAIL COVERS

1. The removal and installation procedure is described on a power front seat.
2. The removal and installation procedure for the seat rail covers describes the driver seat rail on the sill side. The procedure for the cover on the tunnel side is similar.
3. A spindle cover is only installed on the power front seat. Refer to «SEAT RAIL AND SPINDLE COVERS»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-rail-and-spindle-covers) .

SEAT FORWARD/BACK ADJUSTMENT STOP

Note. The seat fore and aft adjustment stop can be removed and installed with the seat installed. For overview purposes, the stop is only shown on one side.

Removing

Unclip seat fore and aft adjustment stop -1-.

Scheme 394

Installation

Install in reverse order of removal.

BACKREST ADJUSTING WHEEL

Special tools and workshop equipment required

Scheme 395

1. Assembly tool 3399

Removing

Scheme 396

Turn the backrest adjustment wheel -1- until a locking mechanism is visible from behind -arrow A-. It may be necessary to use a flashlight.

Engage Assembly Tool 3399 and pry it in direction of -arrow B-.

Turn backrest adjustment wheel about 120° more.

Engage Assembly Tool 3399 and pry it in direction of -arrow B-.

Remove backrest adjustment wheel.

Installation

Install in reverse order of removal. Note the following

If backrest adjustment wheel is too loose after installation, replace wheel.

SILL SIDETRIM

Note. The sill side trim can be removed and installed with the front seat installed.

Removing

Bring seat as far up as possible.

Remove backrest adjustment wheel. Refer to BACKREST ADJUSTING WHEEL .

Remove seat height adjustment handle. Refer to SEAT HEIGHT ADJUSTMENT HANDLE .

Remove expanding rivets -2- (quantity: 2).

Scheme 397

1. Sill-side trim

Expanding rivets on a power front seat are shown in the illustration.

Open the clips -5- (quantity: 2) and -4-.

Scheme 398

Unclip trim -1- on retaining bracket -3-.

Disengage trim in area of backrest adjustment wheel and seat anchor.

Remove trim forward from retaining bracket -3-.

Note. Ensure bracket -2- is not damaged when removing trim.

Seat with Four-Way Lumbar Support

Scheme 399

Note. On vehicles with manual front seats and passenger occupant detection system (country-specific), the driver seal lumbar support adjustment switch -E176- or E177 must be installed so connector is connected from above.

Remove connector -1- from Driver Seat Lumbar Support Adjustment Switch -E176- -4-.

2 - Sill-side trim

3 - Retaining bracket

Continuation for all Manual Seats

Remove sill side trim.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the sill side trim is engaged correctly on retaining bracket and lock clips are closed. Make sure the wires are as close to the coupling -4- as possible.

FRONT SEAT LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177

Removing

Remove tunnel side trim panel. Refer to SILL SIDETRIM .

Disconnect the connector -4-.

Scheme 400

Note. On vehicles with manual front seats and passenger occupant detection system (country-specific), the connector -4- is connected from above, in contrast to the illustration.

Remove bolts -3- (quantity: 2).

Remove Driver Seat Lumbar Support Adjustment Switch -E176- or -E177- -1- from trim -2-.

Installation

Install in reverse order of removal. Note the following

Route wires as close to the coupling -4- as possible.

TUNNEL SIDE TRIM

Note. The sill-side trim can only be removed and installed when the front seat is removed. Removal and installation of the sill side trim is described on an electrically adjustable seat.

SILL SIDE RETAINING BRACKET TRIM

Removing

Remove tunnel side trim panel

1. Manual front seat, refer to «SILL SIDETRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__sill-sidetrim)
2. Power front seat, refer to «SILL SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__sill-side-trim) .

Remove the bolt -4-.

Scheme 401

Remove bolts -3- (quantity: 2).

Remove the bracket -2- from the front seat -1-.

Installation

Install in reverse order of removal.

SEAT HEIGHT ADJUSTMENT HANDLE

Special tools and workshop equipment required

1. It is necessary to create an assisting tool «ASSISTING TOOL, CREATING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

Note. The seat height adjustment handle can be replaced with the front seat installed.

Removing

Create an assisting tool. Refer to ASSISTING TOOL, CREATING .

Pull the seat height adjustment handle -1- as far up as possible and hold it in that position.

Scheme 402

Carefully remove the seat height adjustment handle -1- from the front seat.

Guide assisting tool -2- into mount -4-.

Pull assisting tool -2- in direction of -arrow B- while pressing clip spring outward.

Pull seat height adjustment handle -1- in direction of -arrow A- away from lever.

Installation

Install in reverse order of removal. Note the following

Replace clip on seat height adjustment handle while noting clip installation location CLIP, INSTALLATION LOCATION .

Make sure the seat height adjustment handle engages correctly with the clips.

Scheme 403

Bend 3.5 mm wide -2- screwdriver -1- to dimensions

1. A = 20 mm
2. B = maximum of 15 mm.

Scheme 404

Ensure springs -2- (quantity: 2) in clip -3- are positioned on outside of lever -1-.

SEAT HEIGHT ADJUSTER

Removing

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove tunnel side trim panel. Refer to SILL SIDETRIM .

Remove nut -3-.

Scheme 405

Remove bolts -5- (quantity: 2).

Remove the bolt -2-.

Remove seat height adjustment unit -1- and retaining plate -4-.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure. Ensure retaining plate -4- contacts location on backrest frame marked with -arrow-.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

SEAT FORWARD/BACK ADJUSTMENT HANDLE

Removing

Note. The seat fore and aft adjustment handle cannot be removed without destroying it.

Move the front seat all the way forward.

Remove the seat forward/back adjustment handle -1- from its mount -2- using a rubber or plastic mallet.

Scheme 406

Note. The unit is shown rotated 180°.

Installation

Push the seat forward/back adjustment handle back onto its mount.

Hit the seat forward/back adjustment handle all the way back on with a rubber hammer.

Note. Be careful not to damage the handle when hitting it with the rubber hammer.

FRONT BACKREST

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. The removal and installation procedure describes a driver seat. The procedure for the front passenger seat is identical. The steps for disconnecting the connectors on a power front seat are described.

Removing

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove tunnel side trim panel. Refer to SILL SIDETRIM .

Remove tunnel side trim panel. Refer to TUNNEL SIDE TRIM .

Disengage tab -1- at seat pan -2-.

Scheme 407

Using Trim Removal Wedge3409, clip on cable bracket -1-.

Remove cable bracket -1- from corrugated pipe -2-.

Remove the bolt -1-.

Remove cable clip -2- from corrugated pipe -3-.

Open fabric band -2- in area of -arrow-.

Open corrugated pipe -1-.

Remove corrugated pipe -1- from wiring harness.

Disconnect connectors, for example, -1-, -2- and -3-.

Remove clip with cable tie -4-.

Remove bolts -2- (quantity: 4).

Scheme 408

Tip backrest -3- forward onto seat pan -1-.

Press upholstery to side and carefully remove side airbag wire -4- and, if necessary, all additional wires (depending on option equipment) on the seat pan.

Remove backrest.

Installation

Install in reverse order of removal. Note the following

Threaded bolt holes -2- must always be cleaned (for example, with thread cutter).

Replace bolts -2- (quantity: 4) after each removal.

Make sure the upper and lower part of corrugated pipe fit together precisely.

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

BACKREST COVER

The following describes removing and installing the backrest cover on a power front seat.

SPRING MAT

Removing

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the headrests. Refer to HEADRESTS WITH LOCKING MECHANISM .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Disengage pull-springs -3- on backrest frame -1-.

Scheme 409

Note. The pull-springs -3- can also stay engaged in the backrest frame -1- and the spring mat -2- can be disengaged directly at the pull-springs.

Tip spring mat -3- forward.

Scheme 410

Remove spring mat -arrows- from backrest frame -1-.

2 - Pull-spring

Installation

Install in reverse order of removal. Note the following

Make sure the correct pull-spring (number of coils) is engaged at the location determined.

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

FOUR-WAY LUMBAR SUPPORT

The following describes the removing and installing a four-way lumbar support on a power front seat.

Four-way lumbar support, assembly overview, refer to FOUR-WAY LUMBAR SUPPORT

TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY

Note. The trim with the handle can be removed and installed with the front seat installed. The trim and handle are both destroyed during removal. The following describes removing and installing trim on the entry assistance handle on a power front seat. Entry Assistance Handle Trim, Coupe Only, Removing and Installing, refer to TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY THROUGH 10.06

ENTRY ASSISTANCE BRACKET, COUPE ONLY

Note. The entry assistance bracket can be removed and installed with the front seat installed. The following describes removing and installing the entry assistance bracket on a power front seat.

Entry Assistance Bracket, Coupe Only, Removing and Installing, refer to ENTRY ASSISTANCE BRACKET, COUPE ONLY

LEFT AND RIGHT RELEASE CABLES, COUPE ONLY

Note. The left and right release cables cannot be replaced separately. The following describes removing and installing the release cable on a left and right power front seat.

Left and right release cable, Couple only, removing and installing, refer to LEFT AND RIGHT RELEASE CABLES, COUPE ONLY

HEADRESTS WITH LOCKING MECHANISM

Headrest with insertion lock, removing and installing, refer to HEADRESTS WITH LOCKING MECHANISM

HEADREST GUIDE

Headrest Guides Without and With Release Button, Removing and Installing, refer to HEADREST GUIDE

SEAT PAN

Removing

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove front backrest. Refer to FRONT BACKREST .

Remove cover with upholstery from seat pan. Refer to SEAT PAN COVER AND UPHOLSTERY .

Installation

Install removed cover with upholstery in new seat pan.

Installation is in reverse order of removal, noting the following

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

STORAGE COMPARTMENT

Storage compartment, removing and installing. Refer to STORAGE COMPARTMENT

Special tools and workshop equipment required

1. Airbag adapter VAS 6281

Note. The removal and installation procedure describes a driver seat. The procedure for the front passenger seat is identical.

Removing

Roadster Only

Open retaining loop -1- by loosening push button -arrow-.

Remove seat belt -2- from retaining loop.

Procedure for All Vehicles

Bring seat into service position. Refer to BRINGING FRONT SEATS INTO SERVICE POSITION .

Remove front bolts -1- (quantity: 2).

Scheme 411

Operate seat forward/back adjuster and move the seat -2- as far forward as possible.

Remove rear bolts -1- (quantity: 2).

3 - Rear console

4 - Front console

Switch off the ignition.

Disconnect battery ground cable. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

Disconnect the connectors. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING on the connector station inside the floor panel.

Connect Airbag Adapter VAS 6281. Refer to AIRBAG ADAPTER, CONNECTING .

With help from a second technician, lift the front seat out of vehicle.

Installation

Install in reverse order of removal. Note the following

Remove the airbag adapterVAS 6281 only after installing the front seat. Refer to AIRBAG ADAPTER, CONNECTING .

Note. Make sure the connectors are installed all the way in and are secure.

Connect the connectors to the connector station in the floor panel. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

FRONT SEAT, REMOVING A FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR V288

Note. The seat pan is shown without upholstery and backrest in illustration to provide a better overview.

Removing

If possible, move seat as high up as possible.

Remove the bolt -3-.

Scheme 412

Disconnect threaded connection -4-.

Move the seat forward. Remove the steering wheel if necessary.

Note. Check electrical and electronic components and wires before removing seat further to avoid unnecessary repair costs.

Perform the following tests

1. Check fuse, refer to the appropriate SYSTEM WIRING DIAGRAMS information.
2. Check voltage at connector station, perform Fault Finding if necessary, refer to the appropriate SYSTEM WIRING DIAGRAMS information.
3. Check voltage to control module, refer to the appropriate SYSTEM WIRING DIAGRAMS information.
4. Check the voltage to the seat forward/back adjustment motor -V288-. Refer to the appropriate SYSTEM WIRING DIAGRAMS information.

Replace the fuse if faulty, refer to the appropriate SYSTEM WIRING DIAGRAMS information.

If there is no voltage at the connector station, repair or replace the wire. Refer to the appropriate SYSTEM WIRING DIAGRAMS information.

Replace the seat pan lower frame if the seat forward/back adjustment motor -V288- is faulty. Refer to SEAT PAN, DISASSEMBLING AND ASSEMBLING .

Continue removing only if the seat forward/back adjustment motor -V288- is faulty

Disconnect battery ground cable. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

Remove transverse member bolts -2- (quantity: 4) on both sides.

Disconnect connector at Seat Fore/Aft Adjustment Motor -V288-.

Move seat until bolts -1- (quantity: 4) are visible.

Remove bolts -1- (quantity: 4).

Disconnect the harness connectors at the connector station. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Connect Airbag AdapterVAS 6281. Refer to AIRBAG ADAPTER, CONNECTING .

With help from a second technician, lift the front seat out of vehicle.

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Separate the lower frame -5- from the upper frame -6-. Refer to SEAT PAN, DISASSEMBLING AND ASSEMBLING .

Replace seat pan lower frame -4- with Seat Fore/Aft Adjustment Motor -V288- with the transverse member. Refer to SEAT PAN, DISASSEMBLING AND ASSEMBLING .

Installation

Install in reverse order of removal. Note the following

Remove the airbag adapterVAS 6281 only after installing the front seat. Refer to AIRBAG ADAPTER, CONNECTING .

Connect the connectors to the connector station in the floor panel. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Tightening specifications

1. Front Seat Assembly Overview, refer to «FRONT SEAT ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
2. Seat pan, assembly overview, refer to «SEAT PAN ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

SEAT RAIL AND SPINDLE COVERS

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. The removal and installation of spindle covers and seat rail covers is described on the sill-side driver's seat rail. The surrounding area is not shown in the illustration for clarity purposes. The spindle cover is only present on an electrically adjustable seat.

Spindle cover, removing

Bring seat into service position. Refer to FRONT SEAT .

Pry spindle cover -1- from seat rail cover -3- and seat fore/aft adjustment spindle -2- with Trim Removal Wedge3409.

Spindle cover, installing

Install in reverse order of removal. Note the following

Make sure the spindle cover is engaged correctly.

Seat rail cover, removing

Note. The removal and installation procedure for the seat rail covers describes the driver seat rail on the sill side. The procedure for the cover on the tunnel side is similar.

Remove the front seat. Refer to FRONT SEAT .

Unclip retaining tabs -3-, -4- and -5- on cover -1- from seat rail -2-.

Scheme 413

Remove cover -1- forward, preferably parallel to seat rail.

Seat Rail Cover, Installing

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

SILL SIDE TRIM

Note. The sill side trim can be removed and installed with the front seat installed.

Removing

Bring seat as far up as possible.

Remove expanding rivets -2- (quantity: 2).

1. Sill-side trim

Open the clips -4-.

Scheme 414

Unclip trim -1- on retaining bracket -3-.

Disengage trim in seat/backrest stop area.

Pull the trim as far up from the retaining bracket -3- as the electrical wires allow.

Note. Ensure bracket -2- is not damaged when removing trim. On vehicles with electrically adjustable front seat and passenger occupant detection system (for certain countries, the Driver Seat Lumbar Support Adjustment Switch -E176- or E177 and the housing for the Driver Seat Fore/Aft Switch -E363-, E64, E222, E334, E364, E365, E96 and E98 must be installed so the connector can be connected from above.

Disconnect Driver Seat Lumbar Support Adjustment Switch -E176- connector -3-.

Scheme 415

Disconnect connectors -4- and -5- from housing -1-.

The following switches are installed in the housing -1

1. Driver Seat Fore/Aft Switch -E363- or -E64
2. driver seat angle adjustment switch -E222- or -E334
3. Driver Seat Height Adjustment Switch -E364- or -E365
4. Driver Backrest Adjustment Switch -E96- or -E98

Remove sill side trim.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure. Make sure the sill side trim is engaged correctly on retaining bracket and lock clips are closed. Make sure the wires are as close to couplings -3-, -4- and -5- as possible.

Note. The tunnel side trim panel can only be removed and installed when the front seat removed.

Removing

Remove the front seat

1. Manual seat, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat) .
2. Power seat, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove expanding rivets -1- (quantity: 2).

Scheme 416

2 - Tunnel side trim

Remove the seat belt latch -3-. Refer to FRONT BELT LATCH ANCHORAGE POINT .

Scheme 417

Remove the bolt -2-.

Remove tunnel side trim panel -1- upward.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

The following describes removing and installing the trim bracket on the sill side on a manual front seat.

Sill side trim retaining bracket, removing and installing, refer to SILL SIDE RETAINING BRACKET TRIM

SEAT ADJUSTMENT ACTUATOR

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. The seat adjustment actuator can be removed and installed with the front seat installed.

Removing

Using Trim Removal Wedge 3409, pry actuator -1- from retainer for

Scheme 418

1. Driver Seat Fore/Aft Switch -E363- or -E64
2. Driver seat angle adjustment switch -E222- or -E334
3. Driver Seat Height Adjustment Switch -E364- or -E365

Installation

Install in reverse order of removal.

BACKREST ADJUSTMENT ACTUATOR

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. The backrest adjustment actuator can be removed and installed with the front seat installed.

Removing

Using Trim Removal Wedge 3409, pry actuator -1- out of catch on Driver Backrest Adjustment Switch -E96- or -E98-.

Scheme 419

Installation

Install in reverse order of removal.

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. The removal and installation procedure describes a driver seat. The procedure for the front passenger seat is identical.

Removing

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove tunnel side trim panel. Refer to SILL SIDE TRIM .

Remove tunnel side trim panel. Refer to TUNNEL SIDE TRIM .

Disengage tab -1- at seat pan -2-.

Using Trim Removal Wedge 3409, clip on cable bracket -1-.

Remove cable bracket -1- from corrugated pipe -2-.

Remove the bolt -1-.

Remove cable clip -2- from corrugated pipe -3-.

Open fabric band -2- in area of -arrow-.

Open corrugated pipe -1-.

Remove corrugated pipe -1- from wiring harness.

Disconnect connectors, for example, -1-, -2- and -3-.

Remove clip with cable tie -4-.

Remove bolts -2- (quantity: 4).

Scheme 420

Tip backrest -3- forward onto seat pan -4-.

Press upholstery to side and carefully remove side airbag wire -5- and, if necessary, all additional wires -5- (depending on optional equipment) on the seat pan.

Remove backrest -3-.

Installation

Install in reverse order of removal. Note the following

Threaded bolt holes -2- must always be cleaned (for example, with thread cutter).

Replace bolts -2- (quantity: 4) after each removal.

Make sure the upper and lower part of corrugated pipe fit together precisely.

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Special tools and workshop equipment required

Scheme 421

1. Trim removal wedge 3409
2. Pry lever 80 - 200

Removing

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Fold up lower edge of cover -1- in area -arrow A-.

Scheme 422

Disengage bottom of cover -1- from slits -arrow C- in backrest cover -2-.

Note. The cover retaining strip can only be unclipped from the backrest cover groove with relatively great force. Use the Trim Removal Wedge 3409 to unclip the retaining strip.

Beginning unclipping clamping strip in area -arrow B- of backrest cover -2-.

Unclip rest of retaining strip from surrounding groove by pulling on strip.

Unclip bottom of backrest cover -1- on both sides.

Scheme 423

2 - Clip (quantity: 2)

Use Pry lever 80 - 200 to unclip.

Remove backrest cover -1- downward from backrest.

Installation

Install in reverse order of removal. Note the following

Check whether clip -2- in backrest cover has stayed in place when unclipping backrest cover -1-.

If that is not the case, unclip clip -2- from backrest frame and clip it into the backrest cover -1-.

When sliding backrest cover -1- in from below, ensure strap -arrow- is located in front of the backrest frame -2-.

Scheme 424

Note. The illustration shows engaging the backrest cover in the backrest frame on a Coupe seat. Engage the backrest cover the same way on the Roadster. The upholstery and cover are not shown in the illustration for clarity purposes. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Note. The illustrations show the four-way lumbar support being removed and installed on a Coupe seat. The four-way lumbar support is removed and installed the same way on the Roadster.

Special tools and workshop equipment required

Scheme 425

1. Special pop rivet pliers V.A.G 1753A

Removing

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Pry fastening strips -2- (quantity: 3) out with a screwdriver.

Scheme 426

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Drill out rivet -3-.

Disengage release -3- from retaining plate -2-.

Scheme 427

Open cable tie -1-.

Guide release -3- out of bracket -4-.

Disengage release -2- from four-way lumbar support -3-.

Scheme 428

Disengage release -2- from clip -1-.

Disengage four-way lumbar support -3- at top left and right from clips -2- and backrest frame -1-.

Scheme 429

Remove four-way lumbar support -3-.

Installation

Install in reverse order of removal. Note the following

Before riveting lumbar support, place a plastic washer -4- between lumbar support -1- and backrest frame -2-.

Scheme 430

3 - Rivet

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY THROUGH 10.06

Note. The trim with the handle can be removed and installed with the front seat installed. The trim and handle are both destroyed during removal.

Removing

Scheme 431

Destroy trim -1- and connecting piece -3- for handle -2-.

Do not damage cover when doing so.

Make sure the no plastic pieces fall into cover or between upholstery and entry assistance bracket.

Remove destroyed trim -1- with entry assistance handle -2- from front seat.

Installation

Scheme 432

Slide new handle -3- onto lever -4- as far as stop.

At the same time, clip trim -2- with bracket -1- on backrest frame.

Make sure the trim -2- cleanly covers the cover opening.

Check function of the entry assistance handle.

TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY FROM 11.06

Note. The trim with the handle can be removed and installed with the front seat installed.

Special tools and workshop equipment required

Scheme 433

1. Pry lever 80 - 200
2. Wedges T10383

Removing

Scheme 434

Carefully loosen the trim -1- at the top -arrows- with a trim removal wedge T10383.

To prevent indents in the trim, cover the trim with reinforced tape -2- as illustrated.

Scheme 435

Remove the handle -1- and the trim using the pry lever80 - 200 -arrow-.

Installation

Install in reverse order of removal. Note the following

Install the handle -1- and the trim until they click into place.

Check function of the entry assistance handle.

Note. The entry assistance bracket can be removed and installed with the front seat installed.

Removing

Remove the entry assistance handle: through 10.06 refer to TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY THROUGH 10.06 , from 11.06 refer to TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY FROM 11.06 .

Remove bolts -1- (quantity: 2).

Scheme 436

Remove the entry assistance bracket -2-.

Note. The surrounding area was not shown in the illustration for clarity purposes.

Installation

Install in reverse order of removal. Note the following

Carefully slide entry assistance bracket under the opening in the cover. Do not damage cover when doing so.

Install the trim and entry assistance handle. Refer to TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY THROUGH 10.06 .

Note. The left and right release cables cannot be replaced separately.

Special tools and workshop equipment required

1. Special pop rivet pliers V.A.G 1753A

Removing

Remove the front seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the headrests. Refer to HEADRESTS WITH LOCKING MECHANISM .

Remove the trim from the entry assistance handle. Refer to TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY THROUGH 10.06 .

Remove cover and padding from backrest. Refer to BACKREST COVER AND UPHOLSTERY .

Note. The lumbar support does not need to be removed when removing and installing the release cables.

Press entry assistance handle lever -3- and fold backrest forward.

Scheme 437

1 - Backrest frame

2 - Bracket

Using pliers, disengage eyes -2- (quantity: 2) from pins -3- (quantity: 2).

Scheme 438

Drill out rivets -4- on left and right release cable brackets -1-.

5 - Backrest frame

Open cable ties on both sides.

Disengage pull-spring -1- from bracket -3-.

Scheme 439

Press retaining tabs -2- (quantity: 2) and pull bracket -3- down out of backrest frame -4-.

Turn the knob -2- in the direction of -arrow- until the nipple on the release cables -arrow A- is horizontal to the center of the backrest.

Scheme 440

Hold knob -2- firmly in this position.

Press knob -2- up out of lever -1-.

Guide knob -2- through release cable opening -arrow B- in backrest frame -3-.

Remove left and right release cables from backrest frame.

Installation

Install in reverse order of removal. Note the following

Ensure release cables -3- (quantity: 2) run behind retaining plates -1- and -2- (quantity: 2).

Scheme 441

4 - Backrest frame

Adjust release cables (quantity: 2) with release cable adjusters (quantity: 2). Refer to ENTRY ASSISTANCE RELEASE CABLES ADJUSTING, COUPE ONLY .

Ensure pins -3- (quantity: 2) release at the same time when the entry assistance handle is pressed.

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Note. The headrests can be removed with the front seats installed. The release button is located on the outer left of the driver's seat and inner left of the passenger's seat (in direction of travel).

Removing

Note. The illustration shows a Coupe backrest. The headrest is released the same way on the Coupe and Roadster.

Find release button pressure point -3-.

Scheme 442

The release button is approximately a = 95 mm under upper edge of backrest.

Press the release button in the direction of -arrow- toward the center of the seat.

Hold release button -3- down in this position.

Pull headrest -1- up out of guides -2- and -4-.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the headrest is engaged correctly in headrest guides.

Removing

Remove the front seat

1. Manual seat, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat) .
2. Power seat, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove backrest panel

1. Manual seat, refer to «BACKREST COVER»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) .
2. Power seat, refer to «BACKREST COVER»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) .

Remove the headrests. Refer to HEADRESTS WITH LOCKING MECHANISM .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Headrest guide without release button

Scheme 443

Press retaining tab -arrow- on headrest guide -1- toward center of headrest guide.

Hold retaining tab -arrow- down.

Pull headrest guide -1- upward out of backrest frame -2-.

Headrest guide with release button

Scheme 444

Press retaining tab on headrest guide -1- toward center of headrest guide.

Hold retaining tab -arrow- down.

Pull headrest guide -1- upward out of backrest frame -2-.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the retaining tab is engaged correctly in backrest frame. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Scheme 445

1. Sill-side trim Removing and Installing, refer to «SILL SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__sill-side-trim)
2. Backrest adjustment actuator «SEAT AND BACKREST ADJUSTMENT ACTUATOR ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «BACKREST ADJUSTMENT ACTUATOR»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-adjustment-actuator) Clipped onto switch
3. Seat fore and aft, inclination and height adjustment actuator «SEAT AND BACKREST ADJUSTMENT ACTUATOR ASSEMBLY OVERVIEW»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) Removing and Installing, refer to «SEAT ADJUSTMENT ACTUATOR»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-adjustment-actuator) Clipped onto switch
4. Bolt 0.5 Nm Quantity: 3
5. Switch Driver Seat Fore/Aft Switch -E363- or -E64- Driver Seat Fore/Aft Switch -E222- or -E334- Driver Seat Fore/Aft Switch -E364- or -E365- Driver Backrest Adjustment Switch -E96- or -E98- Removing and Installing, refer to «SEAT FORWARD/BACK, ANGLE, HEIGHT AND BACKREST ADJUSTMENT SWITCHES V288/V243/V244/V245/V246/V45/V46»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-angle-height-and-backrest) are installed in one housing and cannot be replaced individually Connector connecting direction from below On a power front seat with passenger occupant detection system (country-specific), the seat adjustment switches are rotated 180° when installed Connector connecting direction from above

Note. The following describes the removing and installing the storage compartment on a power seat. Removal and installation on a mechanically adjustable seat is the same.

Removing

Remove the front seat

1. with mechanical adjustment, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-seat) .
2. with electrical adjustment, refer to «FRONT SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Open storage compartment.

Remove bolts -2- (quantity: 4).

Scheme 446

Note. For illustrative purposes, the storage compartment is shown closed in the illustration.

Remove entire storage compartment -1- from front seat -3-.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

SEAT FORWARD/BACK ADJUSTMENT MOTOR V288

Note. If the motor is faulty, the seat pan lower frame must be replaced. Seat is shown without upholstery and without backrest in picture for the sake of a better illustration.

Removing

Remove the seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Separate seat pan upper frame from lower frame. Refer to SEAT PAN, DISASSEMBLING AND ASSEMBLING .

Note. The seat angle adjustment motor and seat height adjustment motor must be installed in the new seat pan lower frame.

Remove the seat angle adjustment motor -V243- or -V244- -1-. Refer to DRIVER SEAT ANGLE ADJUSTMENT MOTOR V243/V244 .

Scheme 447

Remove the seat height adjustment motor -V245- or -V246- -3-. Refer to SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246 .

2 - Driver seat angle adjustment motor -V243- or front passenger seat angle adjustment motor -V244

4 -Lower seat pan frame

Installation

Install in reverse order of removal. Note the following

Install the seat height adjustment motor -V245- or -V246- -3- into the new lower frame -4-.

Install the seat angle adjustment motor -V243- or -V244- -1- into new lower frame -4-.

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

DRIVER'S BACKREST ADJUSTMENT MOTOR V45 OR V46

Removing

Remove the backrest. Refer to FRONT BACKREST .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Remove side airbag. Refer to SIDE AIRBAG .

Remove four-way lumbar support. Refer to FOUR-WAY LUMBAR SUPPORT .

Disconnect electrical connectors.

Remove driver seat lumbar support curvature adjustment motor -V125- or front passenger seat lumbar support curvature adjustment motor -V126-. Refer to LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTORS V125 AND V126 .

Remove Driver Seat Lumbar Support Height Adjustment Motor -V129- or Front passenger Seat Lumbar Support Height Adjustment Motor -V130-. Refer to LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTORS V129 AND V130 .

Remove driver backrest stop switch -E69- or front passenger backrest stop switch -E70-. Refer to FRONT SEAT BACKREST STOP SWITCHES E69 AND E70 .

Remove headrest guides. Refer to HEADREST GUIDE .

Installation

Install in reverse order of removal. Note the following

Install removed assembly parts in new backrest frame. Refer to Caution under DRIVER'S BACKREST ADJUSTMENT MOTOR V45 OR V46

Make sure the headrest guides engage correctly in backrest frame.

Switch on ignition.

Note. Make sure the connectors are installed all the way in and are secure.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

FRONT SEAT BACKREST STOP SWITCHES E69 AND E70

Removing

Remove the backrest. Refer to FRONT BACKREST .

Remove backrest cover panel. Refer to BACKREST COVER .

Disconnect connector -1- from coupling -2-.

Scheme 448

Remove coupling -2- upward from mount on housing -3-.

Clip on housing cover -3-.

Scheme 449

Remove driver backrest stop switch -E69- or front passenger backrest stop switch -E70- -2- with wire and coupling from housing -1-.

Note. The two stop switches in the housing must not be separated and can only be replaced together with wire and coupling.

Installation

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTORS V125 AND V126

Special tools and workshop equipment required

1. Special pop rivet pliers V.A.G 1753A

Removing

Remove backrest cover panel. Refer to BACKREST COVER .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Remove side airbag. Refer to SIDE AIRBAG .

Disconnect the connector -3-.

Scheme 450

Disengage release -3- on retaining plate -2-.

Open cable tie -1-.

Disengage the release cable -3- from the bracket -4-.

Drill out rivets -4- (quantity: 2).

1 -Backrest frame

Remove driver seat lumbar support curvature adjustment motor -V125- -2- or front passenger seat lumbar support curvature adjustment motor -V126- with release cable.

Installation

Install in reverse order of removal. Note the following

Rivet driver seat lumbar support curvature adjustment motor -V125- -2- or front passenger seat lumbar support curvature adjustment motor -V126- with backrest frame -1- using Special Pop Rivet PliersV.A.G 1753A.

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTORS V129 AND V130

Special tools and workshop equipment required

1. Special pop rivet pliers V.A.G 1753A

Removing

Remove backrest cover panel. Refer to BACKREST COVER .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Disconnect the connector -3-.

Scheme 451

Disengage release -2- from clip -1-.

Disengage release -2- from four-way lumbar support -3-.

Drill out rivets -4- (quantity: 2).

2 - Backrest frame

Remove Driver Seat Lumbar Support Height Adjustment Motor -V129- -1- or Front passenger Seat Lumbar Support Height Adjustment Motor -V130- with release cable.

Installation

Install in reverse order of removal. Note the following

Rivet Driver Seat Lumbar Support Height Adjustment Motor -V129- -1- or Front passenger Seat Lumbar Support Height Adjustment Motor -V130- with backrest frame -1- using Special Pop Rivet PliersV.A.G 1753A.

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246

Removing

Remove the seat. Refer to FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to INSTALLING FRONT SEAT ON VAS 6136 .

Remove tunnel side trim panel. Refer to SILL SIDE TRIM .

Remove tunnel side trim panel. Refer to TUNNEL SIDE TRIM .

Remove front backrest. Refer to FRONT BACKREST .

Disconnect electrical connector -4- on Driver Seat Height Adjustment Motor -V245- -2- or Front Passenger's Seat Height Adjustment Motor -V246-.

Scheme 452

Disconnect seat pan upper frame -1- from lower frame -3-. Refer to SEAT PAN, DISASSEMBLING AND ASSEMBLING .

Remove seat pan upper frame with cover and upholstery from lower frame.

Remove the bolts -2-.

Scheme 453

Remove the driver seat height adjustment motor -V245- -1- or front passenger seat height adjustment motor -V246- toward center of seat -3-.

Installation

Install in reverse order of removal. Note the following

Make sure the clip -A- and plastic toothed segment collar -2- as well as locking pins -B arrows- are inserted correctly in holes on fitting -1-.

Scheme 454

Make sure the plastic toothed segment -2- is clipped to fitting -1- correctly.

Plastic toothed segment collar -arrow C- must contact fitting -1- evenly.

Make sure the locking pins -A arrows- are inserted correctly in holes -B arrows- on link plate -1-.

Scheme 455

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

SEAT HEIGHT ADJUSTER TOOTHED SEGMENT

Special tools and workshop equipment required

1. Trim removal wedge 3409

Removing

Remove Driver Seat Height Adjustment Motor -V245- or Front Passenger's Seat Height Adjustment Motor -V246-. Refer to SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246 .

Using Trim Removal Wedge 3409, unclip plastic toothed segment -2- from fitting -1-.

Installation

Clip plastic toothed segment -2- into fitting -1-.

Make sure the clip -A- and plastic toothed segment collar -2- as well as locking pins -B arrows- are inserted correctly in holes on fitting -1-.

Make sure the plastic toothed segment -2- is clipped to fitting -1- correctly.

Plastic toothed segment collar -arrow C- must contact fitting -1- evenly.

Make sure the locking pins -A arrows- are inserted correctly in holes -B arrows- on link plate -1-.

Installation is in reverse order of removal, noting the following

Note. Make sure the connectors are installed all the way in and are secure.

Switch on ignition.

Connect battery ground cable with ignition switched on. Refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation .

If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177

Removing

Scheme 456

Remove sill side trim -1-. Refer to SILL SIDE TRIM .

Disconnect the connector -4-.

Remove bolts -2- (quantity: 2).

Remove driver seal lumbar support adjustment switch -E176- -3- or front passenger seat lumbar support adjustment switch -E177- from sill side trim -1-.

Installation

Install in reverse order of removal. Note the following

Route wires as close to the coupling -4- as possible.

SEAT FORWARD/BACK, ANGLE, HEIGHT AND BACKREST ADJUSTMENT SWITCHES V288/V243/V244/V245/V246/V45/V46

Removing

Remove sill side trim -3-. Refer to SILL SIDE TRIM .

Scheme 457

Disconnect connectors -6- and -7-.

Remove seat and backrest adjustment actuators -4- and -5-. Refer to SEAT AND BACKREST ADJUSTMENT ACTUATOR ASSEMBLY OVERVIEW .

Remove bolts -1- (quantity: 3).

Remove seat fore and aft, inclination, height and backrest adjustment switch -2-.

Installation

Install in reverse order of removal. Note the following

Route wires as close to couplings -6- and -7- as possible.

Special tools and workshop equipment required

Scheme 458

1. Torque wrench V.A.G 1332

Note. The bucket seat does not have a side airbag. The side airbag electrical connector must have a terminal resistance in the vehicle wiring harness. The terminal resistance is a separate connector housing. Refer to CONNECTORS, DISCONNECTING .

Scheme 459

1. Front seat Removing -- Push front seat -1- fully upward and to the rear. -- Remove front bolts -3- (quantity: 2). -- Move seat forward. -- Remove rear bolts -4- (quantity: 2). -- Tip front seat -1- back. -- Disconnect electrical harness connectors. Refer to «CONNECTORS, DISCONNECTING»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__connectors-disconnecting) . -- Remove seat. Installation Install in reverse order of removal.
2. Seat rail covers Removing and Installing, refer to «SEAT RAIL COVERS»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)
3. Front bolts Quantity: 2 Tightening specification 50 Nm
4. Rear bolts Quantity: 2 Tightening specification 50 Nm
5. Seat Forward/Back Adjustment Stop Quantity: 2 Clipped Removing and Installing, refer to «SEAT FORWARD/BACK ADJUSTMENT STOP»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__seat-forwardback-adjustment-stop)

Removing and installing, refer to SEAT FORWARD/BACK ADJUSTMENT STOP

Removing

Remove the seat. Refer to SEAT .

Front Seat Rail Cover

Scheme 460

Carefully release retaining bracket in -direction of arrow A- and remove seat rail cover -1- -arrow B-.

Rear Seat Rail Cover

Scheme 461

Carefully release retaining tab -1-.

Then remove seat rail cover -2- in direction of -arrow-.

Installation

Seat rail cover must be removed until it audibly engages.

SIDE TRIM

Special tools and workshop equipment required

1. Engine and transmission holder VAS 6095
2. Fixture for seat repair VAS 6136

Scheme 462

1. Bolt Tightening specification 1.2 Nm
2. Side trim (sill side) Removing -- Remove the seat. Refer to «SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) . -- Mount the fixture for seat repairVAS 6136 on the engine and transmission holderVAS 6095. -- Attach the front seat to the fixture for seat repairVAS 6136. -- Remove backrest adjustment hand wheel -5-. -- Remove seat height adjustment handle -7-. Refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) . -- Remove expanding clip -6-, press clamping pin through to the inside. -- Remove mounting bolt -1-. -- Remove side panel -2- at lower edge from retaining bracket on seat. -- Swing side panel upward at front edge. -- Remove side panel to side. -- Pull tab at rear of side panel out under backrest trim. Installation Install in reverse order of removal.
3. Side trim (tunnel side) Removing -- Remove the seat. Refer to «SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) . -- Mount the fixture for seat repairVAS 6136 on the engine and transmission holderVAS 6095. -- Attach the front seat to the fixture for seat repairVAS 6136. -- Remove expanding clip -4-, press clamping pin through to the inside. -- Disengage retaining detent at rear side of side panel on tunnel side. -- Remove the trim. Installation Install in reverse order of removal.
4. Expanding clip
5. Hand wheel for backrest adjustment Removing and Installing, refer to «BACKREST ADJUSTMENT HAND WHEEL»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__backrest-adjustment-hand-wheel)
6. Expanding clip
7. Seat height adjustment handle Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster)

BACKREST ADJUSTMENT HAND WHEEL

Removing

Scheme 463

Press side panel -2- lightly in direction of backrest.

Slightly lift and disengage retaining detent -1- using a screwdriver.

Turn backrest adjustment hand wheel -3- and disengage another retaining detent.

Remove hand wheel for backrest adjustment.

Installation

Install in reverse order of removal. Note the following

Hand wheel must be pressed on until it audibly engages.

Note. If the hand wheel for backrest adjustment sits loosely on the adjustment shaft, the hand wheel for backrest adjustment must be replaced.

Removing

Scheme 464

Pull seat height adjustment handle up and hold in this position.

Using a narrow screwdriver, press clips -1- inward -arrow A- and remove seat height adjustment handle -2- from lever -arrow B-.

Installation

Install in reverse order of removal. Note the following

Make sure the clip springs -2- (quantity: 2) -3- are positioned on outside of lever -1-.

FRONT BACKREST AND SEAT PAN

Special tools and workshop equipment required

Scheme 465

1. Torque wrench V.A.G 1331
2. Engine and transmission holder VAS 6095
3. Fixture for seat repair VAS 6136

Scheme 466

1. Bolt Tightening specification 24 Nm Replace with locking compound Locking compound
2. Seat forward/back adjustment handle remove to remove from operating rod.
3. Bolt Tightening specification 24 Nm replace with locking compound Locking compound
4. Electric wire For seat heating
5. Seat pan Removing -- Remove the seat. Refer to «SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster). -- Mount the fixture for seat repairVAS 6136 on the engine and transmission holderVAS 6095. -- Attach the front seat to the fixture for seat repairVAS 6136. -- Remove side trim on sill side. Refer to «SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__side-trim). -- Remove side trim on tunnel side. Refer to «SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__side-trim). -- Disconnect seat heater connector. (Scheme 469) -- Drill out pop rivets on connector retaining plate using a 4.0 mm drill bit and guide seat heating wiring harness out under retaining plate (Scheme 469). -- Free up electrical wires on seat pan. -- Remove bolts -1, 3, 10-. -- Remove bolts -6 and 8- and set backrest aside behind seat pan. -- Remove seat pan. Installation Install in reverse order of removal. Note the following: -- Replace seat pan if threads are damaged or stripped. -- Insert bolts with locking compound
6. Bolt Tightening specification 20 Nm replace with locking compound Locking compound
7. Backrest Removing -- Remove the seat. Refer to «SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster). -- Mount the fixture for seat repair VAS 6136 on the engine and transmission holderVAS 6095. -- Attach the front seat to the fixture for seat repair VAS 6136. -- Remove side trim on sill side. Refer to «SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__side-trim). -- Remove side trim on tunnel side. Refer to «SIDE TRIM»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__side-trim). -- Disconnect backrest heating electrical connector. (Scheme 469) -- Drill out pop rivets on connector retaining plate using a 4.0 mm drill bit and guide backrest heating wiring harness out under retaining plate (Scheme 469). -- Remove bolts -1, 3, 10-. -- Remove bolts -6 and 8- and set backrest aside behind seat pan. -- Remove seat pan -5-. -- Remove backrest and guide electrical wiring harness out of seat frame. Installation Install in reverse order of removal. Note the following: -- Insert bolts with locking compound
8. Bolt Tightening specification 20 Nm replace with locking compound Locking compound
9. Electric wire For backrest heating
10. Bolt Tightening specification 24 Nm replace with locking compound Locking compound
11. Seat frame

Scheme 467

Drill out the blind rivets -arrows- with a 4.0 mm drill bit.

Disconnect electrical connectors

1. Seat heating connector.
2. Backrest heating connector.
3. Belt latch connector.

Special tools and workshop equipment required

Scheme 468

1. Torque wrench V.A.G 1410
2. Engine and transmission holder VAS 6095
3. Fixture for seat repair VAS 6136

Scheme 469

1. Retaining clip
2. Seat height adjustment handle lever
3. Seat height adjuster Removing -- Remove the seat. Refer to «SEAT»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster) . -- Mount the fixture for seat repairVAS 6136 on the engine and transmission holderVAS 6095. -- Attach the front seat to the fixture for seat repairVAS 6136. -- Remove backrest and front seat pan. Refer to «FRONT BACKREST AND SEAT PAN»(/audi/tt/8j-2006-2010/remont/seats/#seat-frames-roadster__front-backrest-and-seat-pan) . -- Remove nut -5-. -- Remove bolts -7- (quantity: 2). -- Remove the bolt -4-. -- Remove seat height adjustment unit -3- and retaining plate -6-. Installation Install in reverse order of removal. Note the following: -- Make sure the retaining plate -6- makes contact on backrest frame at -position of arrow-.
4. Bolt Tightening specification 8 Nm
5. Nut Tightening specification 12 Nm
6. Retaining plate
7. Screws, (quantity: 2) Tightening specification 8 Nm

Special tools and workshop equipment required

1. Pry lever 80 - 200

Scheme 470

1. Right backrest cover Removing and Installing see scheme 210
2. Left backrest cover Removing and Installing see scheme 210
3. Retaining clip
4. Bolt Tightening specification 2.5 Nm Replace with locking compound Locking compound
5. Seat belt guide outer part Removing and Installing see scheme 211
6. Seat belt guide inner part With release lever the version without the backrest release is shown in the illustration To remove, remove backrest cover. Refer to «BACKREST COVER AND UPHOLSTERY»(/audi/tt/8j-2006-2010/remont/seats/#seat-upholstery-covers-roadster) Disassembling (Scheme 479)
7. Backrest frame

Scheme 471

Affix backrest panel all around trim -1- using adhesive tape -2-.

Using pry lever80-200, pry off upper backrest cover at inner side, starting from backrest panel.

Disengage clip at front corner of backrest panel extremely carefully.

Scheme 472

Carefully guide the pry lever80-200 between the backrest cover and belt guide outer part.

Carefully press to disengage outer part of belt guide from inner part of belt guide.

BACKREST LOCK ACTUATING LINK

Special tools and workshop equipment required

Scheme 473

1. Torque wrench V.A.G 1410
2. Pop rivet pliers VAS 5072
3. Drill
4. 6.0 mm drill bit
5. Engine and transmission holder VAS 6095
6. Fixture for seat repair VAS 6136

REMOVING

Remove the seat. Refer to SEAT .

Mount the fixture for seat repairVAS 6136 on the engine and transmission holderVAS 6095.

Attach the front seat to the fixture for seat repairVAS 6136.

Remove backrest and front seat pan. Refer to FRONT BACKREST AND SEAT PAN .

Remove backrest cover. Refer to BACKREST COVER AND UPHOLSTERY .

Remove the bolts -arrows- from the seat belt guide inner part.

Scheme 474

Remove belt guide inner part -1-.

Rotate inner part of belt guide and release retaining tabs -arrows-.

Scheme 475

Remove cover -1-.

Remove the operating cable mounting bracket -3- on the seat belt guide inner part.

Scheme 476

Remove backrest lock release lever -2-.

Disengage actuating link -1- in direction of -arrow-.

Repeat work steps on opposite side.

Remove backrest cover and backrest frame. Refer to BACKREST COVER .

Scheme 477

Remove screws -3 and 4-.

Drill out the blind rivet -2- on the backrest frame mount -1- with a 6.0 mm drill bit.

Move the backrest frame mount to the side and remove the cable mounting bracket -2- on the backrest frame -3-.

Scheme 478

Disengage actuating link eye -1- at backrest lock release lever -4- by sliding eye forward -arrow- and removing.

Remove actuating link upward from backrest frame.

INSTALLATION

Install in reverse order of removal. Note the following

Insert bolts with locking compound; locking compound

Adjust backrest lock actuating link. Refer to BACKREST LOCK ACTUATING LINK, ADJUSTING .

BENCH SEAT

Removing

Scheme 479

Fold the front seat backrest forward as far as possible.

Move the front seats forward as far as possible.

Remove front edge of bench seat -1- in direction of -arrow- from omega clips -2- (quantity: 2).

Pfeil A - Omega clip mount

Tip bench seat -1- onto backrest -2- or -3-.

Scheme 480

Disengage retaining eyes -arrow- on bench seat -1- at left and right of backrest tube frame -2- or -3-.

Remove the bench seat -1- from the vehicle.

Installation

Install in reverse order of removal. Note the following

Make sure the retaining eyes -arrow- on bench seat -1- clamp the backrest frame connecting tube correctly.

2 - 1/2 right backrest

3 - 1/2 left backrest

Make sure the bench seat -1- is engaged correctly with the omega clips -2- (quantity: 2).

Special tools and workshop equipment required

Scheme 481

1. Upholstery clip pliers V.A.G 1634

Removing

Scheme 482

Remove the seat bench. Refer to BENCH SEAT .

Cut the upholstery clips -2-.

Remove cover with upholstery -1- from seat frame -2-.

Installation

Install in reverse order of removal. Note the following

Use new upholstery clips.

Close wire clips with upholstery clip pliersV.A.G 1634.

Place the upholstery clips in their original locations.

BACKREST

Note. The left 1/2 and right 1/2 backrests can only be removed and installed together in the vehicle.

Removing

Fold the front seat backrest forward as far as possible.

Move the front seats forward as far as possible.

Remove the seat bench. Refer to BENCH SEAT .

Remove the luggage compartment floor covering.

Remove left and right side trim. Refer to REAR SIDE TRIM .

Release 1/2 left and 1/2 right backrests and fold them forward.

Remove nut -3-.

Scheme 483

1. Left 1/2 backrest
2. 1/2 right backrest

Remove bolts -2- (quantity: 4).

Scheme 484

1. Left 1/2 backrest

Fold 1/2 left and 1/2 right backrests back into normal position.

Remove the bolt -2-.

Scheme 485

Remove seat belt latch -1-.

Remove 1/2 left and 1/2 right backrests from vehicle together.

Installation

Note. When installing left and right 1/2 backrest, follow threaded connection installation sequence.

Lift the 1/2 left and 1/2 right backrest into the vehicle.

Install the seat belt latch -1- and tighten the screw and nut -2- hand-tight.

Install bolts -2- (quantity: 4) and tighten to the specification.

Install nut -3- and tighten to the specification.

Tighten the screw and nut -2- to the tightening specification.

Further installation is performed in the reverse order of removal.

CENTER BEARING COVER CAP

Removing

Remove the seat bench. Refer to BENCH SEAT .

Disengage cover cap -1- at center bearing -2-.

Scheme 486

Remove cover cap -1- up and toward the front in direction of -arrow-.

Installation

Install in reverse order of removal.

LEFT OR RIGHT RELEASE

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. Removal and installation of the left release is described for a left 1/2 backrest. Removal and installation of the right release is the same.

Removing

Remove the backrest. Refer to BACKREST

Remove left trim. Refer to LEFT OR RIGHT TRIM .

Disengage piping on front part of cover -1- from clamping strip on rear of cover -2-.

Scheme 487

Disengage tab on front part of cover -1- at backrest frame -3-.

Scheme 488

Open cover zip fastener.

Fold cover to side.

Remove filler piece -3-. Refer to OUTER LEFT OR RIGHT SPACER .

Scheme 489

1. Backrest shell
2. Release cable

Open cable tie -3-.

Scheme 490

Unclip release cable -2- from bracket -4-.

Disengage release cable hook -2- on lever -5-.

Thread release cable -2- through opening in back of cover -arrow-.

Pull the cover -1- up just enough so that the screws -2- are visible.

Scheme 491

Remove the bolts -2-.

Loosen upholstery from self-adhesive strips -4- on backrest frame in release area.

Scheme 492

Press upholster -1- to side in release area -2- until bolt -3- is visible.

Remove the bolt -3-.

Remove release with release cable -2- from backrest shell -5-.

Note. Release cable is not designed to be disconnected from the release.

Installation

Install in reverse order of removal. Note the following

It is not possible to adjust the release cable.

LEFT OR RIGHT TRIM

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. Removal and installation of the left trim is described for a left 1/2 backrest. Removal and installation of the right trim is the same.

Removing

Scheme 493

Unclip right rear trim -1- starting at the bottom with Trim Removal Wedge3409.

Press release button -2- forward (in direction of travel) as far as stop and hold in this position.

Pry trim -1- from release with Trim Removal Wedge3409.

Remove trim -1- toward rear.

Installation

Scheme 494

Install in reverse order of removal. Note the following

First engage retaining tab -4- on trim -3- in opening -arrow- on release -1-.

Press button -2- on release -1- forward (in direction of travel) as far as stop and hold in this position.

Press trim down and engage with release.

Make sure the all retaining tabs are engaged.

Make sure the opening on cover is covered correctly and cover does not have any wrinkles in this area.

RELEASE BUTTON

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. Removal and installation of the left button is described for a left 1/2 backrest. Removal and installation of the right button is the same.

Removing

Scheme 495

Remove left or right trim. Refer to LEFT OR RIGHT TRIM .

Using Trim Removal Wedge3409, pry button -1- out of release -2-, beginning at back.

Beginning prying with the pins facing the center of the vehicle -arrow-.

Then pry pins facing in direction of vehicle exterior -arrow-.

Scheme 496

Note. After prying rear pins out of release, leg spring -2- and rocker -3- disengage themselves from the button -1-.

Then pry front pin buttons out of release in the same sequence using the Trim Removal Wedge3409.

Remove button from rocker.

Installation

Scheme 497

Slide button from behind onto rocker -2- and leg spring -3-.

1. Release

Using trim removal wedge3409, engage left and right rear pins in release.

Using trim removal wedge3409, engage left and right front pins in release.

Make sure the leg spring is engaged correctly in the button.

Install left or right trim. Refer to LEFT OR RIGHT TRIM .

OUTER LEFT OR RIGHT SPACER

Note. Removal and installation of the left outer filler piece is described for a left 1/2 backrest. Removal and installation of the right outer filler piece is the same.

Removing

Scheme 498

Unclip filler piece -1- at anchor -4- using a screwdriver -2-.

Insert screwdriver -2- in upper opening -arrow A- and press first retaining tab in direction of center bar -arrow B-.

Then insert screwdriver -2- in lower opening -arrow C- and press second retaining tab in direction of center bar -arrow B-.

Remove filler piece -1- from release cable -3-.

Installing

Install in reverse order of removal. Note the following

Make sure the filler piece is engaged correctly with anchor.

INNER LEFT OR RIGHT SPACER

The left and right inner filler pieces are removed and installed the same way the left and right outer filler pieces are. Refer to OUTER LEFT OR RIGHT SPACER .

BACKREST FRAME

Removing

Remove the backrest. Refer to BACKREST .

Remove center bearing cover cap. Refer to CENTER BEARING COVER CAP .

Remove trim. Refer to LEFT OR RIGHT TRIM .

Vehicles with Top Tether

Remove top tether. Refer to TOP TETHER CHILD SEAT ANCHORAGE .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Procedure for All Vehicles

Remove release. Refer to LEFT OR RIGHT RELEASE .

Remove filler pieces. Refer to OUTER LEFT OR RIGHT SPACER .

Remove the bolts -3-.

Scheme 499

Remove left backrest shell -2- and right backrest shell -1- up out of backrest frame guides -4-.

Installation

Install in reverse order of removal.

BACKREST PANEL

Note. The backrest shell is removed and installed the same way the backrest frame is.

SPECIAL TOOLS

Special tools and workshop equipment required

1. Engine and transmission holder VAS 6095
2. Fixture for seat repair VAS 6136
3. Trim removal wedge 3409

See also:
• FRONT SEAT LATCH CHILD SEAT ANCHORAGE ASSEMBLY OVERVIEW
• CHILD SEAT ANCHORAGES, INSPECTING AFTER AN ACCIDENT
• RESTRAINT SYSTEM COMPONENTS, SAFETY PRECAUTIONS AND TESTING PROCEDURES
• SIDE AIRBAG
• [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation
• [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Removal and Installation
• BACKREST COVER AND UPHOLSTERY
• SEAT PAN COVER AND UPHOLSTERY
• BELT LATCH
• FRONT BELT LATCH ANCHORAGE POINT
• BACKREST COVER AND UPHOLSTERY
• REAR SIDE TRIM
• TOP TETHER CHILD SEAT ANCHORAGE
• FRONT SEAT ASSEMBLY OVERVIEW
• FRONT SEAT
• FRONT SEAT ASSEMBLY OVERVIEW
• BENCH SEAT
• 1/2 LEFT AND RIGHT BACKREST ASSEMBLY OVERVIEW
• BACKREST
• SEAT RAIL COVERS
• TUNNEL SIDE TRIM
• TRIM WITH ENTRY ASSISTANCE HANDLE, COUPE ONLY
• BACKREST ADJUSTING WHEEL
• SEAT HEIGHT ADJUSTMENT HANDLE
• SILL SIDETRIM
• STORAGE COMPARTMENT ASSEMBLY OVERVIEW
• STORAGE COMPARTMENT
• STORAGE COMPARTMENT INDIVIDUAL COMPONENTS ASSEMBLY OVERVIEW
• STORAGE COMPARTMENT, DISASSEMBLING AND ASSEMBLING
• SEAT FORWARD/BACK ADJUSTMENT HANDLE
• SEAT FORWARD/BACK ADJUSTMENT STOP
• MODULAR WIRING ROUTING VERSIONS
• MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT
• >>MODULAR LIGHT<<
• >>MODULAR<<
• INSTALLING FRONT SEAT ON VAS 6136
• FRONT SEAT LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177
• SILL SIDE RETAINING BRACKET TRIM
• SEAT HEIGHT ADJUSTER
• FRONT BACKREST
• HEADRESTS ASSEMBLY OVERVIEW
• SPRING MAT
• SEAT PAN
• SEAT RAIL AND SPINDLE COVERS
• FRONT SEAT, REMOVING A FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR V288
• SEAT FORWARD/BACK, ANGLE, HEIGHT AND BACKREST ADJUSTMENT SWITCHES V288/V243/V244/V245/V246/V45/V46
• DRIVER SEAT ANGLE ADJUSTMENT MOTOR V243/V244
• SEAT FORWARD/BACK ADJUSTMENT MOTOR V288
• FRONT SEAT BACKREST ADJUSTMENT MOTORS V45/V46 ASSEMBLY OVERVIEW
• DRIVER'S BACKREST ADJUSTMENT MOTOR V45 OR V46
• LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTORS V129 AND V130
• LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTORS V125 AND V126
• FRONT SEAT BACKREST STOP SWITCHES E69 AND E70
• SEAT HEIGHT ADJUSTMENT MOTOR V245 AND V246
• LUMBAR SUPPORT ADJUSTMENT SWITCHES E176 AND E177
• BRINGING FRONT SEATS INTO SERVICE POSITION
• MODULAR WIRE ROUTING ASSEMBLY OVERVIEW
• SILL SIDE TRIM
• SILL SIDE TRIM RETAINING BRACKET ASSEMBLY OVERVIEW
• BACKREST ADJUSTMENT ACTUATOR
• SEAT ADJUSTMENT ACTUATOR
• FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW
• FOUR-WAY LUMBAR SUPPORT
• SEAT PAN, DISASSEMBLING AND ASSEMBLING
• SEAT HEIGHT ADJUSTER TOOTHED SEGMENT
• BACKREST LOCK ACTUATING LINK
• CENTER BEARING COVER CAP
• LEFT OR RIGHT RELEASE
• LEFT OR RIGHT TRIM
• RELEASE BUTTON
• INNER LEFT OR RIGHT SPACER
• OUTER LEFT OR RIGHT SPACER
• BACKREST PANEL
• BACKREST FRAME
• CONNECTORS, DISCONNECTING
• BACKREST ADJUSTMENT HAND WHEEL
• SIDE TRIM
• FRONT BACKREST AND SEAT PAN
• BACKREST LOCK ACTUATING LINK, ADJUSTING
