SAFETY PRECAUTIONS
If special testing equipment is required during road test, note the following
Scheme 31
| WARNING | Improperly secured testing and measuring equipment and distraction during a road test increase the risk of an accident. Risk of passenger airbag deploying in an accident. Operating testing and measuring equipment while driving creates a distraction. There is an increased risk of injury due to unsecured testing and measuring equipment. Position passenger's seat as far back as possible. Only use the Vehicle Diagnosis and Service System VAS 5052 or Diagnostic System VAS 5053. Testing and measuring instruments -1- must lay flat on the passenger's thighs and be operated by him or her, as shown in the illustration. |
To reduce the risk of personal injury and/or damage to the fuel injection and ignition system, always observe the following
- Do not touch or remove ignition wires when engine is running or turning at starter speed.
- Always switch ignition off before disconnecting or reconnecting wires for the ignition system, including high voltage wiring and test leads.
- If engine is to be cranked at starting RPM without starting (e.g. for compression testing), disconnect connectors from ignition coils and from fuel injectors. After performing work, check and erase DTC memory.
- Cleaning the engine should only be performed with ignition switched off.
- The battery must only be disconnected and connected with the ignition switched off, since the Engine Control Module can otherwise be damaged.
IGNITION SYSTEM
- The engine control module is equipped with On Board Diagnostics (OBD).
- For the electric components to work properly, a voltage of at least 11.5 Volts is required.
- It is possible that the control module will recognize a malfunction and store a DTC during some tests. Therefore after completing all checks and repairs the DTC memory must be checked and if necessary erased.
- If the engine only starts briefly and then turns off again after troubleshooting, repair or checking of the components, it may be that the immobilizer is blocking the Engine Control Module. DTC memory must then be checked and if necessary, control module must be adapted.
Scheme 32
- Knock Sensor I -G61- Contacts gold plated
- Knock Sensor 2 -G66- Contacts gold plated
- Ignition Coil with Power Output Stage Removing and installing, refer to «IGNITION COILS WITH POWER OUTPUT STAGES»(/audi/tt/8j-2006-2010/remont/ignition-system/#20l-ignitionglow-plug-system-engine-codes-bpy-cdma-coupe-as-of-012008__ignition-coils-with-power-output-stages) To remove, use the ignition coil puller T40039
- Spark Plug 30 Nm To remove, use the Spark Plug Removal Tool 3122 B
- Bolt 20 Nm Tightening specifications affect function of Knock Sensor
- Bolt 10 Nm
- Camshaft Position Sensor -G40- Contacts gold plated
- O-Ring If damaged, replace O-ring
TEST DATA
| Engine Data | 2.0L Turbo FSI engine | ||
|---|---|---|---|
| Idle speed Idle speed cannot be adjusted, it is regulated by idle stabilization | 640 to 800 RPM | ||
| RPM limited by switching off fuel injectors and closing throttle valve | Approximately 6500 RPM | ||
| Ignition timing is regulated by control module. It is not possible to adjust the ignition timing. | |||
| Ignition/Glow Plug System | Single coil ignition system with 4 ignition coils (output stages integrated), that are connected directly to spark plugs via the ignition cables. The ignition coils can be pulled out of the cylinder head using ignition coil puller T40039. | ||
| Ignition sequence | 1-3-4-2 |
IGNITION COILS WITH POWER OUTPUT STAGES
Special tools and workshop equipment required
- Ignition Coil Puller T40039
Removing
Remove both bolts -1- of the connector strip.
Scheme 33
Pull all ignition coils approximately 30 mm out of spark plug shaft using ignition coil puller T40039.
Scheme 34
Release connectors and pull all connectors simultaneously off from the ignition coils.
Scheme 35
Installing
Insert all ignition coils loosely into spark plug shaft.
Align the ignition coils to the connectors and then connect all of the connectors simultaneously onto the ignition coils.
Scheme 36
Press the ignition coils uniformly onto the spark plugs by hand (do not use an impact tool).
SPECIAL TOOLS
Special tools and workshop equipment required
Scheme 37
- Ignition Coil Puller T40039
