Exterior Lights, Switches (coupe) Audi TT 8J

Exterior Lights 76 illustrations ~9899 words

AUXILIARY HEADLAMPS, ADJUSTING

Retrofitted auxiliary headlamps must be checked and adjusted according to the guidelines used for other systems.

CONTACT CORROSION

Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fasteners with a special surface coating are used.

In addition, rubber or plastic parts and adhesive consist of non-conductive materials.

If there are doubts as to whether parts are suitable or not, use new parts.

Note

  1. We only recommend original replacement parts, they have been tested and are compatible with aluminum.
  2. We recommend using Audi accessories.
  3. Damage resulting from contact corrosion is not covered by warranty.

HID HEADLAMPS, USAGE AND SAFETY PRECAUTIONS

Refer to General Information .

LOCK CYLINDER AND IGNITION SWITCH WITH STEERING LOCK

General Information

  1. The immobilizer induction coil is attached to the lock cylinder and cannot be replaced separately.
  2. If the induction coil is deflective, the lock cylinder must be replaced.
  3. When replacing lock cylinder, observe guidelines regarding immobilizer induction coil. Refer to «General Information»(/audi/tt/8j-2006-2010/remont/door-locks-anti-theft-systems/#interior-lights-switches-general-information-coupe) .

STEERING COLUMN SWITCH MODULE

General Information

  1. The steering column switch module consists of coil connector with slip ring, Steering Angle Sensor -G85-, steering column switch (turn signal indicator switch, wiper switch, cruise control switch), Steering Column Electronic Systems Control Module -J527- and ignition switch.
  2. Fault finding is done in "Guided Fault Finding" using the Vehicle diagnostic tester.

AUTOMATIC HEADLAMP VERTICAL AIM CONTROL OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 1

Scheme 1: AUTOMATIC HEADLAMP VERTICAL AIM CONTROL OVERVIEW
Scheme 1: AUTOMATIC HEADLAMP VERTICAL AIM CONTROL OVERVIEW
  1. Right Headlamp Beam Adjustment Motor -V49
  2. Headlamp Range Control Module -J431- Component location: behind instrument cluster. Removing and installing, refer to «HEADLAMP RANGE CONTROL MODULE -J431»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-range-control-module-j431) .
  3. Screw 3 Nm
  4. Electrical Connector
  5. Screw 3 Nm
  6. Left Rear Level Control System Sensor -G76- Component location: on left rear control arm. Removing and installing, refer to «Removal and Installation»(/audi/tt/8j-2006-2010/remont/suspension-rear/#rear-suspension-coupe) .
  7. Left Front Level Control System Sensor -G78- Component location: On left front control arm Removing and installing, refer to «Removal and Installation»(/audi/tt/8j-2006-2010/remont/suspension-front/#front-suspension-coupe) .
  8. Left Headlamp Beam Adjustment Motor -V48

Scheme 2

Scheme 2: BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW - ENGINE CODE(S): BPY, CBRA, CCTA & CETA
Scheme 2: BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW - ENGINE CODE(S): BPY, CBRA, CCTA & CETA
  1. Screw 4.5 Nm
  2. Headlamp Housing Bracket
  3. Adjusting Nut For adjustment of headlamp to bumper contour.
  4. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- 12V, 21 W H21W Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__front-turn-signal-lamp-bulbs-m5) .
  5. Lamp Socket For the front turn signal
  6. Headlamp Housing Removing and installing, refer to «HEADLAMPS»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__headlamps) .
  7. Screw 2 Nm
  8. HID Headlamp Control Module Left High-intensity Gas Discharge Lamp Control Module -J343- Right High-intensity Gas Discharge Lamp Control Module -J344- Removing and installing, refer to «HID HEADLAMP CONTROL MODULE -J343- /J344»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamp-control-module-j343-j344) .
  9. Screw 4.5 Nm
  10. Housing Cover For daytime running lights
  11. Daytime Running Lamp Bulb Left daytime running lamp -L174- Right daytime running lamp -L175- 12V, 21 W Bulb, replacing, refer to «DAYTIME RUNNING LAMPS -L174- / -L175-, BULBS»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__daytime-running-lamps-l174-l175) .
  12. Lamp Socket For daytime running lamp bulb
  13. Screw 4.5 Nm
  14. Headlamp Beam Adjustment Motor Left Headlamp Beam Adjustment Motor -V48- Right Headlamp Beam Adjustment Motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__headlamp-beam-adjustment-motor-v48) .
  15. Screw 2 Nm
  16. Housing Cover For gas discharge lamp Different versions.
  17. Screw 2 Nm Not present on older versions
  18. Gas-Discharge Lamp With integrated ignition coil Left high intensity gas discharge (HID) lamp -L13- Right high intensity gas discharge (HID) lamp -L14- 35 W, D1S Bulb, replacing, refer to «HID HEADLAMP BULBS -L13- / -L14»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__hid-headlamp-bulbs-l13-l14) .
  19. Screw 4.5 Nm
  20. Impact Screw For aligning headlamp housing to contour of chassis. Must rest against lock carrier.
  21. Adjusting Nut For adjustment of headlamp to bumper contour.
  22. Lamp Socket For parking lamp
  23. Bracket For the parking lamp bulb socket.
  24. Lamp Socket For parking lamp
  25. Parking Lamp Bulb Yellow, 12V, 5 W Bulb, replacing, refer to «LEFT AND RIGHT SIDE MARKER LAMP BULBS -M1- / -M3»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__left-and-right-side-marker-lamp) .
  26. Parking Lamp Bulb Not applicable to USA or Canada
  27. Housing Cover For parking lamp
  28. Headlamp Housing Bracket
  29. Screw 4.5 Nm
  30. Housing Cover For turn signal light

Scheme 3

Scheme 3
Scheme 3

Tighten the bolts -2- and -4- to 6 Nm.

Scheme 4

Scheme 4: BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW - ENGINE CODE(S): CDMA & CEPB
Scheme 4: BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW - ENGINE CODE(S): CDMA & CEPB
  1. Screw 4.5 Nm
  2. Headlamp Housing Bracket
  3. Adjusting Nut For adjustment of headlamp to bumper contour.
  4. Headlamp Housing Removing and installing, refer to «HEADLAMPS»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  5. Screw 2 Nm
  6. HID Headlamp Control Module Left High-intensity Gas Discharge Lamp Control Module -J343- Right High-intensity Gas Discharge Lamp Control Module -J344- Removing and installing, refer to «HID HEADLAMP CONTROL MODULE -J343- /J344»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  7. Screw 4.5 Nm
  8. Housing Cover For the front turn signal
  9. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- 12V, 21 W PY21W Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  10. Lamp Socket For the front turn signal
  11. Screw 4.5 Nm
  12. Headlamp Beam Adjustment Motor Left Headlamp Beam Adjustment Motor -V48- Right Headlamp Beam Adjustment Motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  13. Screw 2 Nm
  14. Housing Cover For gas discharge lamp
  15. Screw 2 Nm
  16. Gas-Discharge Lamp With integrated ignition coil Left high intensity gas discharge (HID) lamp -L13- Right high intensity gas discharge (HID) lamp -L14- 35 W, D1S Bulb, replacing, refer to «HID HEADLAMP BULBS -L13- / -L14»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  17. Screw 4.5 Nm
  18. Impact Screw For aligning headlamp housing to contour of chassis. Must rest against lock carrier.
  19. Adjusting Nut For adjustment of headlamp to bumper contour.
  20. Housing Cover
  21. Headlamp Housing Bracket
  22. Screw 4.5 Nm
  23. Housing Cover

Tighten the bolts -2- and -4- to 6 Nm.

EXTERIOR REARVIEW MIRROR TURN SIGNALS OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 5

Scheme 5: EXTERIOR REARVIEW MIRROR TURN SIGNALS OVERVIEW
Scheme 5: EXTERIOR REARVIEW MIRROR TURN SIGNALS OVERVIEW
  1. Screw 6.5 Nm
  2. Housing For exterior mirror
  3. Screw 0.4 Nm
  4. Exterior Rearview Mirror Turn Signal Bulb Driver exterior mirror turn signal lamp -L131-. Front Passenger exterior mirror turn signal lamp -L132-. Removing and installing, refer to «EXTERIOR MIRROR TURN SIGNAL LAMPS -L131- / -L132»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__exterior-mirror-turn-signal-lamps-l131) .
  5. Electrical Connector
  6. Screw 2.0 Nm
  7. Mirror Mount
  8. Mirror Glass
  9. Mirror Base

Scheme 6

Scheme 6: FOG LAMPS OVERVIEW
Scheme 6: FOG LAMPS OVERVIEW
  1. Air Inlet Grille
  2. Screw 5 Nm
  3. Screw 5 Nm
  4. Electrical Connector
  5. Fog Lamps Removing and installing, refer to «FOG LAMP»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__fog-lamp) .

FOG LAMP, CENTER HIGH-MOUNTED BRAKE LIGHT, LICENSE PLATE LAMPS OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 7

Scheme 7: FOG LAMP, CENTER HIGH-MOUNTED BRAKE LIGHT, LICENSE PLATE LAMPS OVERVIEW
Scheme 7: FOG LAMP, CENTER HIGH-MOUNTED BRAKE LIGHT, LICENSE PLATE LAMPS OVERVIEW
  1. Screw 1.2 Nm
  2. Rear Fog Lamps Left Rear Fog Lamp -L46- Removing and installing, refer to «REAR FOG LAMP»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__rear-fog-lamp) .
  3. Nut 1.2 Nm
  4. High Mounted Brake Light High-mount Brake Light -M25- Removing and installing, refer to «HIGH-MOUNTED BRAKE LAMP BULB -M25»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__high-mounted-brake-lamp-bulb-m25) .
  5. Nut 1.2 Nm
  6. License Plate Lamp Left license plate light -X4- Right license plate light -X5- Removing and installing: vehicles through 11.06 «LICENSE PLATE LIGHTS -X4- / -X5-, THROUGH 11.06»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__license-plate-lights-x4-x5) , vehicles from 11.06 «LICENSE PLATE LIGHTS -X4- / -X5-, FROM 11.06»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__license-plate-lights-x4-x5) .
  7. Screw 0.8 Nm Vehicles through 11.06
  8. Screw 0.8 Nm Vehicles through 11.06
  9. Screw 1.2 Nm

Scheme 8

Scheme 8: IGNITION SWITCH -D- CONNECTOR ASSIGNMENT
Scheme 8: IGNITION SWITCH -D- CONNECTOR ASSIGNMENT
  1. Terminal 50
  2. Terminal 30
  3. S terminal
  4. X terminal
  5. Terminal P
  6. Terminal 15

HALOGEN HEADLAMPS OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Scheme 9

Scheme 9: HALOGEN HEADLAMPS OVERVIEW
Scheme 9: HALOGEN HEADLAMPS OVERVIEW
  1. Screw 4.5 Nm
  2. Headlamp Housing Bracket
  3. Adjusting Nut For adjustment of headlamp to bumper contour.
  4. Front Turn Signal Lamp Left front turn signal lamp -M5- Right front turn signal lamp -M7- 12V, 21 W H21W Bulb, replacing, refer to «FRONT TURN SIGNAL LAMP BULBS -M5- / -M7»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  5. Lamp Socket For the front turn signal lamp.
  6. Headlamp Housing Removing and installing, refer to «HEADLAMPS»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  7. Screw 4.5 Nm
  8. Housing Cover For the high beam headlamps.
  9. High Beam Headlamp Bulb Left high beam headlamp -M30- Right high beam headlamp -M32- H7 - 12V, 55 W Bulb, replacing, refer to «HIGH BEAM HEADLAMP BULBS -M30- / -M32»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__high-beam-headlamp-bulbs-m30) .
  10. Screw 4.5 Nm
  11. Headlamp Beam Adjustment Motor Left Headlamp Beam Adjustment Motor -V48- Right Headlamp Beam Adjustment Motor -V49- Removing and installing, refer to «HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  12. Housing Cover For the low beam headlamps. Different versions.
  13. Screw 2 Nm Not present on older versions.
  14. Screw 2 Nm
  15. Low Beam Headlamp Bulb Left low beam headlamp -M29- Right low beam headlamp -M31- H7 - 12V, 55 W Bulb, replacing, refer to «LOW BEAM HEADLAMP BULB -M29- / -M31»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__low-beam-headlamp-bulb-m29) .
  16. Screw 4.5 Nm
  17. Impact Screw For aligning headlamp housing to contour of chassis. Must rest against lock carrier.
  18. Adjusting Nut For adjustment of headlamp to bumper contour.
  19. Bulb Socket Retainer For parking lamp
  20. Lamp Socket For parking lamp
  21. Parking Lamp Bulb Left Parking Lamp -M1- Right Parking Lamp -M3- Yellow, 12V, 5 W Bulb, replacing, refer to «SIDE MARKER LAMP BULB -M1- / -M3»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__side-marker-lamp-bulb-m1) .
  22. Housing Cover For parking lamp
  23. Headlamp Housing Bracket
  24. Screw 4.5 Nm
  25. Housing Cover For turn signal light

Tighten the bolts -2- and -4- to 6 Nm.

Scheme 10

Scheme 10: LOCK CYLINDER, IGNITION SWITCH, STEERING LOCK OVERVIEW
Scheme 10: LOCK CYLINDER, IGNITION SWITCH, STEERING LOCK OVERVIEW
  1. 2 - Steering Lock Housing Removing and installing, refer to «STEERING LOCK HOUSING»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__steering-lock-housing) .
  2. 3 - Ignition/Starter Switch -D- Removing and installing, refer to «IGNITION SWITCH -D»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__ignition-switch-d) .
  3. 9 - Screw For steering lock housing (shear bolt).
  4. 10 - Screw For steering lock housing (shear bolt).
  5. 11 - Mount
  6. 12 - Ignition Switch Key Lock Solenoid -N376- Audi TT and TTS with DSG transmission. Removing and installing, refer to «IGNITION KEY REMOVAL LOCK SOLENOID -N376»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__ignition-key-removal-lock-solenoid-n376) .
  7. 13 - Adapter Wiring Set For steering lock housing Removing and installing, refer to «STEERING LOCK HOUSING ADAPTER WIRING HARNESS»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__steering-lock-housing-adapter-wiring-harness) .
  8. 14 - Lock Cylinder Removing and installing, refer to «LOCK CYLINDER»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__lock-cylinder) .

STEERING COLUMN SWITCH MODULE OVERVIEW

  1. 1 - Screw 0.4 Nm
  2. 4 - Steering Angle Sensor -G85- Removing and installing, refer to «STEERING ANGLE SENSOR -G85»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__steering-angle-sensor-g85) .
  3. 5 - Transport Protection To secure coil connector with slip ring in center position.
  4. 6 - Coil Connector With Slip Ring Removing and installing, refer to «AIRBAG SPIRAL SPRING/RETURN SPRING WITH SLIP RING»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__airbag-spiral-springreturn-spring-with-slip) . CAUTION: Risk of damaging coil connector. Coil connector with slip ring is not to be turned following removal.
  5. 7 - Turn Signal Switch -E2- On vehicles with cruise control: with auxiliary Cruise Control Switch -E45-. Removing and installing, refer to «TURN SIGNAL SWITCH -E2-, CRUISE CONTROL SWITCH -E45»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__turn-signal-switch-e2-cruise-control) .
  6. 8 - Windshield Wiper/Washer Switch -E22- Removing and installing, refer to «WINDSHIELD WIPER/WASHER SWITCH -E22»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__windshield-wiperwasher-switch-e22) .
  7. 11 - Mount
  8. 15 - Steering Column Electronic Systems Control Module -J527- Removing and installing, refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__steering-column-electronic-systems-control-module) . Connector assignment of Steering Column Electronic Systems Control Module -J527-. Refer to «STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527- CONNECTOR ASSIGNMENT»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__steering-column-electronic-systems-control-module) .

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527- CONNECTOR ASSIGNMENT

The Steering Column Electronic Systems Control Module is part of the complete system "steering column switch module (SCSM)". and receives signals from steering column switch, for example.

Check Steering Column Electronic Systems Control Module in "Guided Fault Finding" using the Vehicle diagnostic tester.

Scheme 11

Scheme 11: STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527- CONNECTOR ASSIGNMENT
Scheme 11: STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527- CONNECTOR ASSIGNMENT
  1. A - Tiptronic Switch Connector Mount 1 - Analog value Tiptronic left down 2 - Ground Tiptronic left 3 - Ground Tiptronic right 4 - Analog value Tiptronic left up
  2. B - Turn Signal/Cruise Control Connector Mount 1 - Voltage supply (terminal 15) 2 - Locked "Off" 3 - Res ("+")/Set ("-") 4 - On/off 5 - Ground (GND) 6 - Lighting (terminal 58) 7 - Headlamp flasher 8 - High beams 9 - Turn signal 10 - Ground turn signal
  3. C - Electrical System Connector Mount Pin assignment (Scheme 12).
  4. D - Airbag control module connector mount Pin assignment see scheme 16.
  5. E - Ignition Switch/Ignition Key Removal Lock Connector Mount 1 - Not used 2 - Not used 3 - Ignition key removal lock on terminal 30 4 - Ignition switch ground 5 - Not used 6 - Not used 7 - Ignition switch output terminal 50 8 - Voltage supply terminal 30 to ignition switch 9 - Out put ignition switch terminal S 10 - Output ignition switch terminal X 11 - Output ignition switch terminal P 12 - Output ignition switch terminal 15
  6. F - Connector Mount Wiper System/Dis 1 - Windshield washer switch signal 2 - Windshield washer ground 3 - Not used 4 - Not used 5 - DIS signal 6 - DIS/interval potentiometer ground 7 - Signal interval speeds 8 - Not used
  7. G - Spiral Spring/Airbag/Multi-Function Steering Wheel/Signal Horn Connector Mount 1 - Not used 2 - Not used 3 - Airbag 1 "+" 4 - Airbag 1 "-" 5 - Airbag 2 "+" 6 - Airbag 2 "-" 7 - Ground (for coil spring/multi-function steering wheel/horn) 8 - Cruise control locked "Off" /horn signal 9 - LIN Bus or temperature signal with steering wheel heating 10 - Voltage supply terminal 15 with multi-function steering wheel
  8. H - Steering Angle Sensor Connector Mount 1 - Light barrier 5 2 - Light barrier 3 3 - Light barrier 1 4 - 12 volt voltage supply 5 - 5 volt voltage supply 6 - Light barrier 6 7 - Light barrier 4 8 - Light barrier 2 - Steering angle sensor ground 10 - Light barrier 7

Scheme 12

Scheme 12
Scheme 12
  1. Not assigned
  2. Not assigned
  3. Not assigned
  4. Not assigned
  5. Not assigned
  6. Not assigned
  7. Not assigned
  8. Not assigned
  9. Not assigned
  10. Powertrain CAN Bus shielding
  11. Powertrain CAN bus Low
  12. Power CAN bus High
  13. Cruise control latched Off
  14. Comfort CAN bus High
  15. Comfort CAN bus Low
  16. P-IN (Selector lever P contact)
  17. Auxiliary output terminal 15
  18. Auxiliary output terminal 50
  19. Terminal 30 voltage supply
  20. Terminal 31 voltage supply
  1. Airbag 1 "-"
  2. Airbag 1 "+"
  3. Airbag 2 "+"
  4. Airbag 2 "-"

PARKING AID OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 13

Scheme 13: PARKING AID OVERVIEW
Scheme 13: PARKING AID OVERVIEW
  1. Rear Parking Aid Warning Buzzer -H15- Coupe: Behind right rear speaker trim. Removing and installing, refer to «REAR PARKING AID WARNING BUZZER -H15-, COUPE»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__rear-parking-aid-warning-buzzer-h15) . Roadster: Behind left rear bulkhead trim. Removing and installing, refer to «REAR PARKING AID WARNING BUZZER -H15-, ROADSTER»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__rear-parking-aid-warning-buzzer-h15) .
  2. Parking Aid Control Module -J446- In luggage compartment at rear, right side, below side trim. Removing and installing, refer to «PARKING AID CONTROL MODULE -J446»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__parking-aid-control-module-j446) .
  3. Right Rear Parking Aid Sensor -G206- In rear bumper. Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  4. Right Rear Center Parking Aid Sensor -G205- In rear bumper. Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  5. Left Rear Center Parking Aid Sensor -G204- In rear bumper. Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .
  6. Left Rear Parking Aid Sensor -G203- In rear bumper. Removing and installing, refer to «REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .

TAIL LAMPS OVERVIEW

Observe notes on contact corrosion Refer to CONTACT CORROSION .

Scheme 14

Scheme 14: TAIL LAMPS OVERVIEW
Scheme 14: TAIL LAMPS OVERVIEW
  1. Retaining Bolts Bolted in housing.
  2. Rear Turn Signal Bulb Left rear turn signal lamp -M6- Right rear turn signal lamp -M8- 12V, 18 W W16W Bulb, replacing, refer to «TAIL LAMP BULB CARRIER»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamp-bulb-carrier) .
  3. Bulb Left rear turn signal lamp -M6- Right rear turn signal lamp -M8- 12V, 18 W W16W Bulb, replacing, refer to «TAIL LAMP BULB CARRIER»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamp-bulb-carrier) .
  4. Bulb For The Rear Brake/Tail/Side Marker Lamps 12V, 21 W Replacing, refer to «TAIL LAMP BULB CARRIER»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamp-bulb-carrier) .
  5. Screw 1.7 Nm
  6. Bulb Holder Removing and installing, refer to «TAIL LAMP BULB CARRIER»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamp-bulb-carrier) .
  7. Bulb For The Rear Brake/Tail/Side Marker Lamps 12V, 21 W Bulb, replacing, refer to «TAIL LAMP BULB CARRIER»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamp-bulb-carrier) .
  8. Left Back-Up Lamp Left back-up lamp -M16- Right Back-Up Lamp -M17- 12V, 18 W W16W Bulb, replacing, refer to «TAIL LAMP BULB CARRIER»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamp-bulb-carrier) .
  9. Tail Lamp Removing and installing, refer to «TAIL LAMP»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamp) .
  10. Threaded Studs 3.5 Nm

FASTENER TIGHTENING SPECIFICATIONS

ComponentFastener SizeNm
Exterior Rearview Mirror Housing to Base9.5
Exterior Rearview Mirror Turn Signal Bulb0.4
Exterior Rearview Mirror Mount2
Fog Lamp Housing5
Headlamp Housing Bracket Screw4.5
Headlamp Beam Adjustment Motor2
Headlamp Housing Cover2
Headlamp Range Control Module3
License Plate Lamp0.8
Rear Fog Lamp1.2
Steering Column Electronic Systems Control Module0.4
Tail Lamp Bulb Holder1.7
Tail Lamp Housing3.5

Tightening Specification, Headlamp Housing Repair Set

Tighten the bolts -2- and -4- to 6 Nm.

HEADLAMPS CHECKING AND ADJUSTING CONDITIONS

  1. Tire pressure OK
  2. Headlamp lenses must be clean and dry.
  3. Headlamps lenses must not be damaged.
  4. Headlamp reflectors and bulbs OK.
  5. Vehicle load must be created.

Vehicle load on driver's seat in otherwise unloaded vehicle (curb weight).

  1. One person or 75 kg.

The curb weight is the weight of the operational vehicle with completely full fuel tank, including the weight of all equipment carried in operation.

  1. Fuel tank: at least 90% full.
  2. Equipment: such as spare wheel, tools, vehicle jack, fire extinguisher, etc.

If the fuel tank is not at least 90% full, the load must be created as follows.

Check fuel tank fill lever in instrument cluster tank gauge and compare with the following table. Place additional weight in the luggage compartment, if necessary.

Additional Weight in kg (lbs)
Tank GaugeFront wheel drive/all wheel drive
1/440 (88)
1/225 (55)
3/410 (22)
Full0

Example: If the fuel tank is half full, an additional 25 kg (55 pounds) must be placed in the luggage compartment.

Note. Use fuel containers filled with water as additional weight (a 5 liter fuel container filled with water weighs 5 kg) (5 gallons of water weighs approximately 41.75 pounds).

  1. Roll the vehicle several yards or move it back and forth several times to seat the springs.
  2. Vehicle and headlamp adjusting unit must be on a level surface.
  3. Parking brake must not be engaged so vehicle is not under stress.

Headlamp adjusting unit must be aligned to vehicle. Refer to Headlamp adjusting unit operating instructions.

Scheme 15

Scheme 15
Scheme 15
  1. The headlamp adjuster must be distance -a- 30 to 70 cm (12 to 27.5 inches) in front of the headlamp and should not deviate more than dimension -b- = 3 cm (1.2 inch) from the headlamp center point.

Set the angle dimension on the headlamp adjusting unit. Refer to Headlamp adjusting unit operating instructions.

Scheme 16

Scheme 16
Scheme 16
  1. The angle dimension -arrow- is stamped on the upper edge of the headlamp -1- in "%".

Note. The headlamp must be adjusted according to the angle dimension stamped on the headlamp. The percentage indicator is based on a 10 meter (32.8 feet) projection distance. For example, an angle dimension of 1.0% corresponds to 10 cm.

HEADLAMPS, ADJUSTING

Procedure

Follow the complete test and adjustment requirements. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Vehicles with halogen headlamps

Set range control knurled wheel to "0" position.

Vehicles with gas discharge headlamps

Select the "basic setting" function in "Guided Fault Finding" or "Guided Functions" using the Vehicle diagnostic tester.

Select the function or path in the "guided functions" operating mode

Vehicle brand
Engine codes
55 Dynamic range control with (with cornering lamp) J431
55 Basic setting (repair group 94)

Follow further instructions on display of Vehicle Diagnostic Tester.

All Vehicles

Scheme 17

Scheme 17
Scheme 17

Switch on low beams.

  1. The horizontal light-dark border must touch the dividing line -1- on the adjusting unit test surface.
  2. The point -2- between the left horizontal part and the right vertical part of the light-dark border must run vertically through the central mark -3-. The bright core of the light beam must be to the right of the vertical.

Note. To determine the inflection point -2- more easily, cover and uncover the left half of the headlamp several times. Then check the low beam again. After correct headlamp adjustment, the center of the high beam light beam must be on the central marking -3-.

To adjust the height of the headlamp, set the light-dark border just under the dividing line with the adjustment screw -1-.

Scheme 18

Scheme 18
Scheme 18

Then adjust the light-dark border, starting from the bottom, on the dividing line.

For side adjustment, turn adjusting screw -2-.

Note. The allocation on the right headlamp is reversed.

Vehicles with gas discharge headlamps

After the headlamp is adjusted, complete the "basic setting". Switch off the ignition and disconnect the diagnostic connector.

FOG LAMPS, ADJUSTING

Procedure

Scheme 19

Scheme 19: FOG LAMPS, ADJUSTING
Scheme 19: FOG LAMPS, ADJUSTING

Complete test and adjustment requirements. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

To adjust headlamp range, turn adjusting screw -arrow-.

  1. Angle dimension: 20 cm (7.9 inch).

Note. Side adjustment is not intended.

DAYTIME RUNNING LAMPS -L174- / -L175-, BULBS

Removing

Scheme 20

Scheme 20: DAYTIME RUNNING LAMPS -L174- / -L175-, BULBS
Scheme 20: DAYTIME RUNNING LAMPS -L174- / -L175-, BULBS

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Right Headlamp

Remove EVAP canister up from bracket -arrow- and lay aside with lines connected.

Continuation for both sides

Scheme 21

Scheme 21
Scheme 21

Remove high beam housing cover -2- from headlamp housing -arrow A-.

Turn socket -1- counterclockwise -arrow B- and remove from headlamp housing.

Remove lamp from socket.

Installing

Install in reverse order of removal. Note the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Secure socket by turning clockwise.

Close the housing lid.

FRONT TURN SIGNAL LAMP BULBS -M5- / -M7

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Scheme 22

Scheme 22: FRONT TURN SIGNAL LAMP BULBS -M5- / -M7
Scheme 22: FRONT TURN SIGNAL LAMP BULBS -M5- / -M7

Remove headlamp. Refer to HEADLAMPS .

Remove turn signal housing cover -1- from headlamp housing -arrow A-.

Turn socket -2- counterclockwise -arrow B- and remove from housing.

Remove lamp from socket.

Installing

Install in reverse order of removal. Note the following

Insert the new bulb in the socket without touching the bulb with bare hands.

Close the housing lid.

Install the headlamp. Refer to HEADLAMPS .

HEADLAMPS

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

WARNINGDanger to life due to high voltage. Usage and safety information for gas discharge headlamps. Refer to General Information .

With ignition switched off, disconnect battery Ground (ND) wire. Refer to BATTERY, DISCONNECTING AND CONNECTING .

Remove the upper cover from the bumper. Refer to Removal and Installation .

Remove bolt -2-.

Scheme 23

Scheme 23
Scheme 23

Guide a long wrench -3- through opening and loosen lower retaining bolt on headlamp housing several turns.

Loosen lower retaining bolt -1- on headlamp housing several turns.

Remove headlamp -4- toward front from body.

Disconnect the connector.

Installing

Scheme 24

Scheme 24
Scheme 24
  1. Tightening specification, refer to «BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Check adjustment nut -1- of adjusting element for smooth running -arrows-.

Turn adjustment nut completely downward, but do not tighten.

Install the headlamp; when doing this, make sure the vent connection on the headlamp housing is pushed into the vent grommet -arrow- above the impact member.

Scheme 25

Scheme 25
Scheme 25

Align headlamp to contours of body (gap widths).

Note. To align headlamps, bolts -arrows- can be loosened and height of brackets -2 and 3- can be changed.

Tighten bolts -1 and 3-.

Note. When tightening the bolts, the adjusting nuts on the adjusters rotate toward headlamp housing mounting point -4- and secure it.

Tighten screws -2-.

Install the upper cover on the bumper. Refer to Removal and Installation .

Adjust headlamps. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Scheme 26

Scheme 26: HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49
Scheme 26: HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49

Remove headlamp. Refer to HEADLAMPS .

If equipped, remove the bolt -2-.

Release spring clip -arrow- and remove gas discharge lamp housing cover -1- from headlamp housing.

Disconnect electrical connector -1-.

Scheme 27

Scheme 27
Scheme 27

Remove screws -arrows-.

By swiveling control motor -2-, push ball end of positioning stem downwards out of socket.

Installing

  1. Tightening specification, refer to «BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Start by inserting ball end of positioning stem from underneath in reflector socket. To do so, pull reflector to rear.

Note. Remove EVAP canister up from bracket -arrow- and lay aside with lines connected.

Connect the connector and close the housing cover.

Secure housing cover using wire clamp.

Install the headlamp. Refer to HEADLAMPS .

HEADLAMP HOUSING REPAIR SET

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Note. If headlamp mounting tabs are broken, they can be replaced by installing the repair set. By doing this, it is not necessary to replace the headlamp. There are different repair kits for left and right headlamps.

Procedure

  1. Tightening specifications (Scheme 3).

Remove headlamp with broken mounting tabs. Refer to HEADLAMPS .

Remove remainder of broken mounting tabs on headlamp housing.

Position repair set mounting tab -1 or 3- on headlamp housing and secure tab with bolts -2 or 4-.

HEADLAMP REFLECTOR ADJUSTMENT SOLENOID -N395- / -N396

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

The screen adjustment magnet is located in headlamp housing beneath gas discharge lamp and cannot be replaced separately if faulty.

Replace headlamp. Refer to HEADLAMPS .

HID HEADLAMP BULBS -L13- / -L14

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

WARNINGRisk of death due to high voltage, injury risk and environmental hazard. Usage and safety information for gas discharge headlamps. Refer to General Information .

Remove headlamp. Refer to HEADLAMPS .

If equipped, remove the bolt -2-.

Release spring clip -arrow- and remove gas discharge lamp housing cover -1- from headlamp housing.

Disconnect electrical connector -4-.

Scheme 28

Scheme 28
Scheme 28

Release spring clips -1 and 3- and remove gas-discharge lamp -2- from housing.

Installing

Install in reverse order of removal. Note the following

Insert the new HID bulb into the housing without touching the bulb with bare hands.

  1. Installation location: The electrical connection faces down.

Secure gas-discharge lamp with spring clips.

Connect the connector and close the housing cover.

Secure housing cover using wire clamp.

Install the headlamp. Refer to HEADLAMPS .

HID HEADLAMP CONTROL MODULE -J343- /J344

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Scheme 29

Scheme 29: HID HEADLAMP CONTROL MODULE -J343- /J344
Scheme 29: HID HEADLAMP CONTROL MODULE -J343- /J344
WARNINGDanger to life due to high voltage. Always disconnect the battery wire strap before working on gas-discharge headlamp components marked with yellow high-voltage symbols.

Remove headlamp. Refer to HEADLAMPS .

Remove screws -arrows-.

Remove control module -1- from headlamp housing.

Disconnect gas-discharge lamp adapter lead -2- at control module -1-.

Scheme 30

Scheme 30
Scheme 30

Installing

  1. Tightening specification, refer to «BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Check seal -3- between gas discharge headlamp control module and headlamp housing for damage.

Install the headlamp. Refer to HEADLAMPS .

LEFT AND RIGHT ADAPTIVE CORNERING LAMP MOTOR V318/V319

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

The dynamic cornering light position motor sits in the headlamp housing and cannot be replaced separately if it is faulty.

Replace the headlamp housing. Refer to HEADLAMPS .

LEFT AND RIGHT SIDE MARKER LAMP BULBS -M1- / -M3

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Scheme 31

Scheme 31: LEFT AND RIGHT SIDE MARKER LAMP BULBS -M1- / -M3
Scheme 31: LEFT AND RIGHT SIDE MARKER LAMP BULBS -M1- / -M3

Remove headlamp. Refer to HEADLAMPS .

Remove parking lamp/side marker lamp housing cover -2- from headlamp housing -arrow A-.

Pull the socket -1- with the bulb out of the reflector in -the direction of arrow B-.

Turn or pull the bulb for the parking lam/side marker lamp out of the socket.

Installing

Install in reverse order of removal. Note the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Push socket into reflector until it engages noticeably.

Close the housing lid.

Install the headlamp. Refer to HEADLAMPS .

LEFT AND RIGHT SWIVEL MODULE POSITION SENSORS -G474- / -G475

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

The swivel module position sensor is located in headlamp housing beneath gas discharge lamp and cannot be replaced separately if faulty.

Headlamps, removing and installing, refer to HEADLAMPS .

Removing

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Right headlamp

Remove EVAP canister up from bracket -arrow- and lay aside with lines connected.

Continuation for both sides

Remove turn signal housing cover -2- from headlamp housing -arrow A-.

Turn socket -1- counterclockwise -arrow B- and remove from headlamp housing.

Remove lamp from socket.

Installing

Install in reverse order of removal. Note the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Secure socket by turning clockwise.

Close the housing lid.

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

WARNINGDanger to life due to high voltage. Usage and safety information for gas discharge headlamps. Refer to General Information .

With ignition switched off, disconnect battery Ground (ND) wire. Refer to BATTERY, DISCONNECTING AND CONNECTING .

Remove the upper cover from the bumper. Refer to Removal and Installation .

Remove bolt -2-.

Guide a long wrench -3- through opening and loosen lower retaining bolt on headlamp housing several turns.

Loosen lower retaining bolt -1- on headlamp housing several turns.

Remove headlamp -4- toward front from body.

Disconnect the connector.

Installing

  1. Tightening specification, refer to «BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Check adjustment nut -1- of adjusting element for smooth running -arrows-.

Turn adjustment nut completely downward, but do not tighten.

Install the headlamp; when doing this, make sure the vent connection on the headlamp housing is pushed into the vent grommet -arrow- above the impact member.

Align headlamp to contours of body (gap widths).

Note. To align headlamps, bolts -arrows- can be loosened and height of brackets -2 and 3- can be changed.

Tighten bolts -1 and 3-.

Note. When tightening the bolts, the adjusting nuts on the adjusters rotate toward headlamp housing mounting point -4- and secure it.

Tighten screws -2-.

Install the upper cover on the bumper. Refer to Removal and Installation .

Adjust headlamps. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Remove headlamp. Refer to HEADLAMPS .

Remove the safety screw -2-.

Release spring clip -arrow- and remove gas discharge lamp housing cover -1- from headlamp housing.

Disconnect electrical connector -1-.

Remove screws -arrows-.

By swiveling control motor -2-, push ball end of positioning stem downwards out of socket.

Installing

  1. Tightening specification, refer to «BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Start by inserting ball end of positioning stem from underneath in reflector socket. To do so, pull reflector to rear.

Note. Remove EVAP canister up from bracket -arrow- and lay aside with lines connected.

Connect the connector and close the housing cover.

Secure housing cover using wire clamp.

Install the headlamp. Refer to HEADLAMPS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Note. If headlamp mounting tabs are broken, they can be replaced by installing the repair set. By doing this, it is not necessary to replace the headlamp. There are different repair kits for left and right headlamps.

Procedure

  1. Tightening specification see scheme 5.

Remove headlamp with broken mounting tabs. Refer to HEADLAMPS .

Remove remainder of broken mounting tabs on headlamp housing.

Position repair set mounting tab -1 or 3- on headlamp housing and secure tab with bolts -2 or 4-.

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

The screen adjustment magnet is located in headlamp housing beneath gas discharge lamp and cannot be replaced separately if faulty.

Replace headlamp. Refer to HEADLAMPS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

WARNINGRisk of death due to high voltage, injury risk and environmental hazard. Usage and safety information for gas discharge headlamps. Refer to General Information .

Remove headlamp. Refer to HEADLAMPS .

Remove the safety screw -2-.

Release spring clip -arrow- and remove gas discharge lamp housing cover -1- from headlamp housing.

Disconnect electrical connector -4-.

Release spring clips -1 and 3- and remove gas-discharge lamp -2- from housing.

Installing

Install in reverse order of removal. Note the following

Insert the new HID bulb into the housing without touching the bulb with bare hands.

  1. Installation location: The electrical connection faces down.

Secure gas-discharge lamp with spring clips.

Connect the connector and close the housing cover.

Secure housing cover using wire clamp.

Install the headlamp. Refer to HEADLAMPS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

WARNINGDanger to life due to high voltage. Always disconnect the battery wire strap before working on gas-discharge headlamp components marked with yellow high-voltage symbols.

Remove headlamp. Refer to HEADLAMPS .

Remove screws -arrows-.

Remove control module -1- from headlamp housing.

Disconnect gas-discharge lamp adapter lead -2- at control module -1-.

Installing

  1. Tightening specification, refer to «BI-XENON HID HEADLAMPS WITH CORNERING LAMP OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Check seal -3- between gas discharge headlamp control module and headlamp housing for damage.

Install the headlamp. Refer to HEADLAMPS .

LED PARKING LAMP/DRL MODULES -L176- / -L177-, -M1- / -M3

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

The DRL bulbs are LEDs and are integrated inside the headlamp housing. The LED cannot be replaced. The entire headlamp must be replaced.

Replace headlamp. Refer to HEADLAMPS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

The dynamic cornering light position motor sits in the headlamp housing and cannot be replaced separately if it is faulty.

Replace the headlamp housing. Refer to HEADLAMPS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

The swivel module position sensor is located in headlamp housing beneath gas discharge lamp and cannot be replaced separately if faulty.

Replace headlamp. Refer to HEADLAMPS .

EXTERIOR MIRROR TURN SIGNAL LAMPS -L131- / -L132

Special tools and workshop equipment required

  1. Pry Lever 80 - 200
  2. Protective Gloves

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 32

Scheme 32
Scheme 32
WARNINGRisk of injury. Wear protective gloves.

Note. To protect the paint in the area around the mirror housing, tape it off with a soft cloth.

Press mirror glass -1- out of mirror adjusting unit -arrow- using 80 - 200.

If present, disconnect electrical connectors on rear side of mirror glass.

Remove bolt -2-.

Scheme 33

Scheme 33
Scheme 33

Remove housing -1- upward from mirror base -3- -arrow-.

Remove screws -arrows-.

Scheme 34

Scheme 34
Scheme 34

Remove mirror mount -2- from housing -1-.

Remove screws -arrows-.

Scheme 35

Scheme 35
Scheme 35

Remove the turn signal housing -1- from the exterior mirror housing -2-.

Disconnect electrical connector -3-.

Installing

  1. Tightening specifications, refer to «EXTERIOR REARVIEW MIRROR TURN SIGNALS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__exterior-rearview-mirror-turn-signals-overview) .

Install in reverse order of removal. Note the following

Note. The entire exterior mirror turn signal must be replaced if an LED is faulty.

Attach mirror glass at mirror adjusting unit and press on mirror glass.

Note. Make sure to press only in mirror center.

FOG LAMP

Removing

Scheme 36

Scheme 36: FOG LAMP
Scheme 36: FOG LAMP

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Audi TT

Release retaining hooks -A arrows- with a screwdriver.

Remove bumper cover air inlet grille -1- -arrow B-.

Audi TTS

Scheme 37

Scheme 37
Scheme 37

Remove bumper cover air inlet grille -1- -arrows-.

Continuation for all

Scheme 38

Scheme 38
Scheme 38

Remove screws -arrows-.

Remove fog light housing -1- from bumper cover.

Disconnect the connector.

Installing

  1. Tightening specification, refer to «FOG LAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe) .

Install in reverse order of removal. Note the following

Adjusting fog lamps, refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

FOG LAMP BULBS -L22- / -L23

Removing

Scheme 39

Scheme 39: FOG LAMP BULBS -L22- / -L23
Scheme 39: FOG LAMP BULBS -L22- / -L23

Remove fog lamp. Refer to FOG LAMP .

Disconnect the electrical connector -1- on the light.

Rotate the bulb -2- counterclockwise -arrow- and remove it from the fog lamp housing.

Installing

Install in reverse order of removal. Note the following

Insert new bulb (H11 - 12V, 55 W) in housing without touching glass bulb with bare hand.

Rotate the bulb clockwise to secure.

Adjusting fog lamps, refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Remove headlamp. Refer to HEADLAMPS .

Remove turn signal housing cover -1- from headlamp housing -arrow A-.

Turn socket -2- counterclockwise -arrow B- and remove from housing.

Remove lamp from socket.

Installing

Install in reverse order of removal. Note the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Close the housing lid.

Install the headlamp. Refer to HEADLAMPS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Remove the upper cover from the bumper. Refer to Removal and Installation .

Remove bolt -2-.

Guide a long wrench -3- through opening and loosen lower retaining bolt on headlamp housing several turns.

Loosen lower retaining bolt -1- on headlamp housing several turns.

Remove headlamp -4- toward front from body.

Disconnect the connector.

Installing

  1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview) .

Install in reverse order of removal. Note the following

Check adjustment nut -1- of adjusting element for smooth running -arrows-.

Turn adjustment nut completely downward, but do not tighten.

Install the headlamp; when doing this, make sure the vent connection on the headlamp housing is pushed into the vent grommet -arrow- above the impact member.

Align headlamp to contours of body (gap widths).

Note. To align headlamps, bolts -arrows- can be loosened and height of brackets -2 and 3- can be changed.

Tighten bolts -1 and 3-.

Note. When tightening the bolts, the adjusting nuts on the adjusters rotate toward headlamp housing mounting point -4- and secure it.

Tighten screws -2-.

Install the upper cover on the bumper. Refer to Removal and Installation .

Adjust headlamps. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Remove headlamp. Refer to HEADLAMPS .

If equipped, remove the bolt -2-.

Release spring clip -arrow- and remove low beam/daytime running light bulb housing cover -1- from headlamp housing.

Remove screws -arrows-.

Scheme 40

Scheme 40
Scheme 40

By swiveling control motor -1-, push ball end of positioning stem downwards out of socket.

Press reflector forward and remove adjusting motor.

Disconnect electrical connector -2-.

Installing

  1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview) .

Install in reverse order of removal. Note the following

First reconnect connector and insert adjusting axle ball head into reflector ball head mount from below by pulling reflector back.

Note. The headlamps must be adjusted if the adjusting motors are removed and installed or replaced. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Close the housing lid.

Secure housing cover using wire clamp.

Install the headlamp. Refer to HEADLAMPS .

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Note. If headlamp mounting tabs are broken, they can be replaced by installing the repair set. By doing this, it is not necessary to replace the headlamp. There are different repair kits for left and right headlamps.

Procedure

  1. Tightening specifications see scheme 11.

Remove headlamp with broken mounting tab. Refer to HEADLAMPS .

Remove remains of broken mounting tab at headlamp housing.

Position repair set mounting tab -1 or 3- on headlamp housing and secure tab with bolts -2 or 4-.

HIGH BEAM HEADLAMP BULBS -M30- / -M32

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Right headlamp

Remove EVAP canister up from bracket -arrow- and lay aside with lines connected.

Continuation for both sides

Scheme 41

Scheme 41
Scheme 41

Remove high beam housing cover -2- from headlamp housing -arrow A-.

Remove bulb -3- from spring clips -B arrows-.

Disconnect harness connector -1- at high beam bulb.

Installing

Install in reverse order of removal. Note the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Position the bulb on the lower spring clip.

Press the bulb into the housing past the upper spring clips.

Connect the connector and close the housing cover.

LOW BEAM HEADLAMP BULB -M29- / -M31

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Remove headlamp. Refer to HEADLAMPS .

If equipped, remove the bolt -2-.

Release spring clip -arrow- and remove low beam/daytime running light bulb housing cover -1- from headlamp housing.

Disconnect electrical connector -3- on low beam/daytime running light bulb.

Scheme 42

Scheme 42
Scheme 42

Open the wire clamp -2- and remove the bulb -1- from the housing.

Installing

  1. Tightening specification, refer to «HALOGEN HEADLAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__halogen-headlamps-overview) .

Install in reverse order of removal. Note the following

Insert the new bulb into the housing without touching the bulb with bare hands.

Secure the bulb with spring clip.

Connect the connector and close the housing cover.

Secure housing cover using wire clamp.

Install the headlamp. Refer to HEADLAMPS .

SIDE MARKER LAMP BULB -M1- / -M3

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Note. Headlamps must be adjusted after performing measures that could influence headlamp adjustment. Refer to HEADLAMPS CHECKING AND ADJUSTING CONDITIONS .

Removing

Remove headlamp. Refer to HEADLAMPS .

Remove parking lamp housing cover -2- from headlamp housing -arrow A-.

Pull the socket -1- with the bulb out of the reflector in -the direction of arrow B-.

Remove parking lamp bulb from socket.

Installing

Install in reverse order of removal. Note the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Push socket into reflector until it engages noticeably.

Close the housing lid.

Install the headlamp. Refer to HEADLAMPS .

HEADLAMP RANGE CONTROL MODULE -J431

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" in the Vehicle diagnostic tester.

Remove instrument cluster. Refer to INSTRUMENT CLUSTER .

Remove bolts -arrows- and remove Headlamp Range Control Module -item 1-.

Scheme 43

Scheme 43: HEADLAMP RANGE CONTROL MODULE -J431
Scheme 43: HEADLAMP RANGE CONTROL MODULE -J431

Disconnect electrical connector -2-.

To disconnect electrical connector, press catch -1-, turn retaining bracket in -direction of arrow- and remove connector.

Scheme 44

Scheme 44
Scheme 44

Installing

  1. Tightening specification, refer to «AUTOMATIC HEADLAMP VERTICAL AIM CONTROL OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__automatic-headlamp-vertical-aim-control-overview) .

Install in reverse order of removal. Note the following

Install instrument cluster. Refer to INSTRUMENT CLUSTER .

IGNITION KEY REMOVAL LOCK SOLENOID -N376

Removing

Scheme 45

Scheme 45: IGNITION KEY REMOVAL LOCK SOLENOID -N376
Scheme 45: IGNITION KEY REMOVAL LOCK SOLENOID -N376

Remove steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Releases the retaining clip -arrow- and remove the ignition switch key lock solenoid -item 1- from the steering lock housing.

Installing

Install in reverse order.

IGNITION SWITCH -D

Removing

Scheme 46

Scheme 46: IGNITION SWITCH -D
Scheme 46: IGNITION SWITCH -D

Remove steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Destroy cover cap retainer -2- on the ignition switch.

Pry off the cap -1- on the ignition switch.

Disconnect electrical connector -1-.

Scheme 47

Scheme 47
Scheme 47

Release retaining clip by inserting jeweller's screwdrivers -2-.

If the procedure is not possible because there is not enough space, assisting tools must be created from 2 wire hooks as follows.

Scheme 48

Scheme 48
Scheme 48

Take a 1 mm diameter welding wire and bend the end to form an eye.

Then cut the wire.

  1. Dimension -a- = approximately 50 mm (2 inch).

File the end of the wire hook into a point.

  1. Dimension -b- = 5 mm (0.2 inch)

Pull the ignition switch -item 3- in -direction of arrow- off the steering lock housing; the jeweler's screwdriver or wire hooks must remain inserted.

Installing

Install in reverse order of removal. Note the following

Push the ignition switch into the steering lock housing until it audibly latches into place.

LOCK CYLINDER

Special tools and workshop equipment required

  1. Locking Pin T40011

Removing

Scheme 49

Scheme 49
Scheme 49

Remove steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Note. To remove lock cylinder, replacement key without illumination and radio function is necessary because removal is only possible using a key with flat grip.

Turn replacement key to ignition "on" position, cut out in trim -arrow- aligns with hole in ignition lock.

Note. Right lock position is shown without ignition lock to provide a better illustration.

Insert the T40011 all the way into the hole and remove the lock cylinder -1- with the induction coil from the steering lock housing -2-.

Scheme 50

Scheme 50
Scheme 50
WARNINGRisk of steering lock seizing. Steering lock must not be operated without lock cylinder.

Note. A seized steering lock must be replaced. When replacing lock cylinder, observe guidelines regarding immobilizer induction coil. Refer to General Information .

Disconnect electrical harness connector at induction coil.

Installing

Install in reverse order of removal. Note the following

Place replacement key in lock cylinder and turn to ignition "on" position.

Insert the T40011 again all the way into the front side.

Slide lock cylinder -1- with induction coil into steering lock housing -2-.

Then remove T40011 and press lock cylinder securely in until catch engages audibly.

Connect electrical connector to immobilizer induction coil.

STEERING LOCK HOUSING

Special tools and workshop equipment required

  1. Angled Hand Drill
  2. 8.5 mm Diameter Drill

Removing

Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

Remove airbag unit. Refer to Removal and Installation .

Remove steering wheel. Refer to Removal and Installation .

CAUTIONRisk of damaging coil connector. Coil connector with slip ring is not to be turned following removal.

Remove steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Drill out shear bolts -arrows- with an angled hand drill and 8.5 mm bit.

Scheme 51

Scheme 51
Scheme 51

Turn ignition key to "on" position.

Disconnect induction coil wire on steering column switch.

Remove steering column switch module from steering column.

Remove Steering Column Electronic Systems Control Module -J527-. Refer to STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527 .

Release retaining clips -arrows- and remove steering lock housing -2- from mount -1-.

Scheme 52

Scheme 52
Scheme 52

Disconnect the connector on the ignition switch -D-.

In order to replace the steering lock housing, remove the ignition switch and the lock cylinder and the ignition switch key lock solenoid -N376- on vehicles with DSG transmission.

Remove ignition switch. Refer to IGNITION SWITCH -D .

Remove lock cylinder. Refer to LOCK CYLINDER .

Remove the ignition switch key lock solenoid. Refer to IGNITION KEY REMOVAL LOCK SOLENOID -N376 .

Installing

Install in reverse order of removal. Note the following

Tighten bolts -arrows- until heads shear off.

Install steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Install steering wheel. Refer to Removal and Installation .

Install airbag unit. Refer to Removal and Installation .

STEERING LOCK HOUSING ADAPTER WIRING HARNESS

Removing

Scheme 53

Scheme 53: STEERING LOCK HOUSING ADAPTER WIRING HARNESS
Scheme 53: STEERING LOCK HOUSING ADAPTER WIRING HARNESS

Remove Steering Column Electronic Systems Control Module -J527-. Refer to STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527 .

Disconnect electrical connector -3- at ignition switch.

Release the retaining clips in -direction of arrow- and disconnect the -2- ignition switch key lock solenoid -N376- connector.

Remove steering lock housing adapter wiring harness -1-.

Installing

Install in reverse order of removal. Note the following

Install Steering Column Electronic Systems Control Module -J527-. Refer to STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527 .

PARKING AID CONTROL MODULE -J446

Removing

If the control module is replaced, select "Replace" function for the respective control module in "Guided Functions" using the Vehicle diagnostic tester.

Switch off ignition and remove ignition key.

Remove luggage compartment right side trim. Refer to Removal and Installation .

Release retaining clips -1 and 2- and remove Parking Aid Control Module -item 4- from control module bracket.

Scheme 54

Scheme 54: PARKING AID CONTROL MODULE -J446
Scheme 54: PARKING AID CONTROL MODULE -J446

Disconnect electrical connectors -3 and 5-.

Installing

Install in reverse order of removal. Note the following

Install luggage compartment right side trim. Refer to Removal and Installation .

REAR PARKING AID WARNING BUZZER -H15-, COUPE

Removing

Scheme 55

Scheme 55: REAR PARKING AID WARNING BUZZER -H15-, COUPE
Scheme 55: REAR PARKING AID WARNING BUZZER -H15-, COUPE

Switch off ignition and remove ignition key.

Remove right rear side trim. Refer to Removal and Installation .

Release retaining clips -arrows- and remove Rear Parking Aid Warning Buzzer -item 1- from rear side trim.

Installing

Install in reverse order of removal. Note the following

Install right rear side trim. Refer to Removal and Installation .

REAR PARKING AID WARNING BUZZER -H15-, ROADSTER

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 56

Scheme 56: REAR PARKING AID WARNING BUZZER -H15-, ROADSTER
Scheme 56: REAR PARKING AID WARNING BUZZER -H15-, ROADSTER

Switch off ignition and remove ignition key.

Remove right rear bulkhead trim. Refer to Removal and Installation .

Remove expander pins -1 and 2-.

Remove Rear Parking Aid Warning Buzzer -item 3-.

Disconnect electrical connector -4-.

Installing

Install in reverse order of removal. Note the following

Install right rear side trim. Refer to Removal and Installation .

Scheme 57

Scheme 57: REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206
Scheme 57: REAR PARKING AID SENSORS -G203- / -G204- / -G205- / -G206

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Component location: In rear bumper -arrows-.

Removing

To remove outer sensor, grip it from below behind bumper cover.

To remove inner sensor, remove rear bumper cover. Refer to Removal and Installation .

Press both retainer tabs to side -arrows- and press sensor -2- from outside towards inside.

Scheme 58

Scheme 58
Scheme 58

Disconnect electrical harness connector -1- at sensor.

Installing

Install in reverse order of removal. Note the following

Install the cover on the rear bumper. Refer to Removal and Installation .

HIGH-MOUNTED BRAKE LAMP BULB -M25

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 59

Scheme 59: HIGH-MOUNTED BRAKE LAMP BULB -M25
Scheme 59: HIGH-MOUNTED BRAKE LAMP BULB -M25

Do not press brake pedal.

Audi TT and Audi TTS

Manually extend rear spoiler.

Remove lower luggage compartment lid trim. Refer to Removal and Installation .

Audi TTRS

Remove the rear spoiler. Refer to Removal and Installation .

Continuation for all

Remove nuts -2 and 3-.

Disconnect electrical connector -1-.

Tape off area around center high-mounted brake light with fabric tape.

Carefully loosen center high-mounted brake light from sealing strip adhesive on rear lid.

Guide a small screwdriver -3- through the opening and release the retaining spring -2-.

Scheme 60

Scheme 60
Scheme 60

Remove center high-mounted brake light -1- from rear lid -arrow-.

Installing

  1. Tightening specification, refer to «FOG LAMP, CENTER HIGH-MOUNTED BRAKE LIGHT, LICENSE PLATE LAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__fog-lamp-center-high-mounted-brake-light) .

Install in reverse order of removal. Note the following

Note. Entire high-mounted brake light must be replaced in the event of faulty LEDs.

Press center high-mounted brake light into opening until retainers engage.

Audi TT and TTS

Install lower rear lid trim. Refer to Removal and Installation .

Audi TTRS

Install the rear spoiler. Refer to Removal and Installation .

LICENSE PLATE LIGHTS -X4- / -X5-, THROUGH 11.06

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 61

Scheme 61: LICENSE PLATE LIGHTS -X4- / -X5-, THROUGH 11.06
Scheme 61: LICENSE PLATE LIGHTS -X4- / -X5-, THROUGH 11.06

Turn light switch into "0" position.

Remove screws -arrows-.

Pry bulb carrier -2- out of luggage compartment lid.

Remove the bulb -1- (12V, 5 W) out of clamp-type socket.

Installing

  1. Tightening specification, refer to «FOG LAMP, CENTER HIGH-MOUNTED BRAKE LIGHT, LICENSE PLATE LAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__fog-lamp-center-high-mounted-brake-light) .

Install in reverse order.

LICENSE PLATE LIGHTS -X4- / -X5-, FROM 11.06

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 62

Scheme 62: LICENSE PLATE LIGHTS -X4- / -X5-, FROM 11.06
Scheme 62: LICENSE PLATE LIGHTS -X4- / -X5-, FROM 11.06

Turn light switch into "0" position.

Slide the bulb carrier -1- in the -direction of the arrow- and remove it from the luggage compartment lid.

Remove the bulb -1- (12V, 5 W) out of clamp-type socket.

Installing

Install in reverse order.

REAR FOG LAMP

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 63

Scheme 63: REAR FOG LAMP
Scheme 63: REAR FOG LAMP

Remove rear bumper cover. Refer to Removal and Installation .

Disconnect electrical connector -2-.

Remove the screws -arrows- and remove the rear fog lamps -1-.

Installing

  1. Tightening specification, refer to «FOG LAMP, CENTER HIGH-MOUNTED BRAKE LIGHT, LICENSE PLATE LAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__fog-lamp-center-high-mounted-brake-light) .

Install in reverse order of removal. Note the following

Install the cover on the rear bumper. Refer to Removal and Installation .

REAR FOG LAMP BULB CARRIER

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 64

Scheme 64: REAR FOG LAMP BULB CARRIER
Scheme 64: REAR FOG LAMP BULB CARRIER

Reach between bumper cover -1- and heat shield -2-.

Turn socket -3- counterclockwise -arrow- and remove from housing.

Remove lamp from socket.

Installing

Install in reverse order of removal. Note the following

Insert the new bulb in the socket without touching the bulb with bare hands.

AIRBAG SPIRAL SPRING/RETURN SPRING WITH SLIP RING

Special tools and workshop equipment required

  1. Feeler Gauge

Removing

Note. Steering must be in center position (wheels in straight ahead position) when removing and installing coil connector with slip ring.

Remove steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Remove Steering Column Electronic Systems Control Module -J527-. Refer to STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527 .

Carefully release fasteners -arrows- and pull Airbag Spiral Spring/Return Spring With Slip Ring -1- off steering column switch module.

Scheme 65

Scheme 65
Scheme 65

Installing

Install in reverse order of removal. Note the following

Make sure all fasteners and electrical connectors are properly engaged.

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527

Special tools and workshop equipment required

  1. 2.5 mm drill diameter; length at least 75 mm

Removing

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" in the Vehicle diagnostic tester.

Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

Remove airbag unit. Refer to Removal and Installation .

Remove steering wheel. Refer to Removal and Installation .

CAUTIONRisk of damaging coil connector. Coil connector with slip ring is not to be turned following removal.

Remove steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Disconnect electrical connector -4- on Steering Column Electronic Systems Control Module -J527- -item 1- by removing fuse -3- -arrow- and pressing release down.

Scheme 66

Scheme 66
Scheme 66
CAUTIONRisk of destroying electronic components with static discharge. To discharge static, touch vehicle ground with hand (while not wearing gloves).

Disconnect electrical connector -2-.

Remove bolt -1-.

Scheme 67

Scheme 67
Scheme 67

At Steering Column Electronic Systems Control Module, slide a 2.5 mm drill diameter -2- approximately 45 mm into the hole -arrow 1-, releasing the retaining detent -arrow 2-.

Pull Steering Column Electronic Systems Control Module down slightly and remove drill.

Release retaining clip -arrow- on connector side of Steering Column Electronic Systems Control Module and remove control module from steering column switch module.

Scheme 68

Scheme 68
Scheme 68

Installing

  1. Tightening specification, refer to «STEERING COLUMN SWITCH MODULE OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__steering-column-switch-module-overview) .

Install in reverse order of removal. Note the following

Install steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Install steering wheel. Refer to Removal and Installation .

Install airbag unit. Refer to Removal and Installation .

STEERING ANGLE SENSOR -G85

Removing

Scheme 69

Scheme 69: STEERING ANGLE SENSOR -G85
Scheme 69: STEERING ANGLE SENSOR -G85

Remove steering column trim. Refer to Storage Compartments and Covers in Removal and Installation .

Remove return spring with slip ring. Refer to AIRBAG SPIRAL SPRING/RETURN SPRING WITH SLIP RING .

Remove Steering Angle Sensor -arrow-.

Installing

Install in reverse order of removal. Note the following

After replacing the steering angle sensor it must adapted in "Guided Fault Finding" or in "Guided Functions" using the Vehicle diagnostic tester.

TURN SIGNAL SWITCH -E2-, CRUISE CONTROL SWITCH -E45

Removing

Scheme 70

Scheme 70: TURN SIGNAL SWITCH -E2-, CRUISE CONTROL SWITCH -E45
Scheme 70: TURN SIGNAL SWITCH -E2-, CRUISE CONTROL SWITCH -E45

Remove Steering Angle Sensor -G85-. Refer to STEERING ANGLE SENSOR -G85 .

Note. To provide a better illustration, the following steps are shown with the steering column switch module removed.

Release retaining clips with 1.0 mm feeler gauge -item 1- -arrows- and remove left lever switch.

Installing

Install in reverse order of removal. Note the following

Make sure all fasteners and electrical connectors are properly engaged.

WINDSHIELD WIPER/WASHER SWITCH -E22

Removing

Scheme 71

Scheme 71: WINDSHIELD WIPER/WASHER SWITCH -E22
Scheme 71: WINDSHIELD WIPER/WASHER SWITCH -E22

Remove Steering Angle Sensor -G85-. Refer to STEERING ANGLE SENSOR -G85 .

Note. To provide a better illustration, the following steps are shown with the steering column switch module removed.

Release retaining clips with 1.0 mm feeler gauge -item 1- -arrows- and remove Windshield Wiper/Washer Switch -E22-.

Installing

Install in reverse order of removal. Note the following

Make sure all fasteners and electrical connectors are properly engaged.

TAIL LAMP

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 72

Scheme 72: TAIL LAMP
Scheme 72: TAIL LAMP

Switch off ignition and remove ignition key.

Turn light switch into "0" position.

Fold cut out area -2- of luggage compartment forward.

Remove bolt -3-.

Slide the tail lamp -1- toward outside -arrow- and disengage from retaining pins on body.

Disconnect electrical harness connector at lamp carrier.

Installing

  1. Tightening specification, refer to «TAIL LAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamps-overview) .

Install in reverse order of removal. Note the following

Note. Make sure seal between body and tail lamp housing seals properly.

Position tail lamps on retaining bolts from outside and press on in direction of vehicle center until it locks.

TAIL LAMP BULB CARRIER

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Removing

Scheme 73

Scheme 73: TAIL LAMP BULB CARRIER
Scheme 73: TAIL LAMP BULB CARRIER

Remove the tail lamps. Refer to TAIL LAMP .

Remove screws -arrows-.

Remove bulb carrier -1- from tail lamp unit -2-.

Turn the bulbs -1- or pull the bulbs -3- out of the socket -2-.

Scheme 74

Scheme 74
Scheme 74

Installing

  1. Tightening specification, refer to «TAIL LAMPS OVERVIEW»(/audi/tt/8j-2006-2010/remont/exterior-lights/#exterior-lights-switches-coupe__tail-lamps-overview) .

Install in reverse order of removal. Note the following

Insert the new bulb into the socket without touching the bulb with bare hands.

Scheme 75

Scheme 75: SPECIAL TOOLS
Scheme 75: SPECIAL TOOLS

Scheme 76

Scheme 76
Scheme 76
  1. Pry Lever 80 - 200
  2. Locking Pin T40011

See also:
• General Information
• General Information
• Removal and Installation
• Removal and Installation
• BATTERY, DISCONNECTING AND CONNECTING
• Removal and Installation
• INSTRUMENT CLUSTER
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• CONTACT CORROSION
• HEADLAMP RANGE CONTROL MODULE -J431
• FRONT TURN SIGNAL LAMP BULBS -M5- / -M7
• HEADLAMPS
• HID HEADLAMP CONTROL MODULE -J343- /J344
• DAYTIME RUNNING LAMPS -L174- / -L175-, BULBS
• HEADLAMP BEAM ADJUSTMENT MOTOR -V48- / -V49
• HID HEADLAMP BULBS -L13- / -L14
• LEFT AND RIGHT SIDE MARKER LAMP BULBS -M1- / -M3
• HEADLAMPS
• EXTERIOR MIRROR TURN SIGNAL LAMPS -L131- / -L132
• FOG LAMP
• REAR FOG LAMP
• HIGH-MOUNTED BRAKE LAMP BULB -M25
• LICENSE PLATE LIGHTS -X4- / -X5-, THROUGH 11.06
• HEADLAMPS CHECKING AND ADJUSTING CONDITIONS
• HIGH BEAM HEADLAMP BULBS -M30- / -M32
• LOW BEAM HEADLAMP BULB -M29- / -M31
• SIDE MARKER LAMP BULB -M1- / -M3
• STEERING LOCK HOUSING
• IGNITION SWITCH -D
• IGNITION KEY REMOVAL LOCK SOLENOID -N376
• STEERING LOCK HOUSING ADAPTER WIRING HARNESS
• LOCK CYLINDER
• STEERING ANGLE SENSOR -G85
• AIRBAG SPIRAL SPRING/RETURN SPRING WITH SLIP RING
• TURN SIGNAL SWITCH -E2-, CRUISE CONTROL SWITCH -E45
• WINDSHIELD WIPER/WASHER SWITCH -E22
• STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE -J527
• REAR PARKING AID WARNING BUZZER -H15-, COUPE
• PARKING AID CONTROL MODULE -J446
• TAIL LAMP BULB CARRIER
• TAIL LAMP
• EXTERIOR REARVIEW MIRROR TURN SIGNALS OVERVIEW
• HALOGEN HEADLAMPS OVERVIEW
• AUTOMATIC HEADLAMP VERTICAL AIM CONTROL OVERVIEW
• FOG LAMP, CENTER HIGH-MOUNTED BRAKE LIGHT, LICENSE PLATE LAMPS OVERVIEW
• STEERING COLUMN SWITCH MODULE OVERVIEW
• TAIL LAMPS OVERVIEW
