BACKREST LOCK ACTUATING LINK, ADJUSTING Audi TT RS 8J

Seat Frames (roadster) 4 illustrations ~302 words

BACKREST LOCK ACTUATING LINK, ADJUSTING

Procedure

Scheme 385

Scheme 385: BACKREST LOCK ACTUATING LINK, ADJUSTING
Scheme 385: BACKREST LOCK ACTUATING LINK, ADJUSTING
  1. Backrest cover removed.

When operating one of the two backrest lock release levers, release pins on left and right of seat frame must be operated at the same time.

Operate backrest lock release lever

  1. Left and right release pins must be operated at the same time.

Release backrest lock release lever

  1. The actuating links must engage the release pins on the backrest hinge as far as stop.
  2. The actuating links must then be relieved.

If necessary, rotate -arrows- adjusters -1 and 2- on actuating links accordingly.

Scheme 386

Scheme 386: REAR SEAT ASSEMBLY OVERVIEW
Scheme 386: REAR SEAT ASSEMBLY OVERVIEW
  1. Bench seat Undivided Assembly Overview, refer to «BENCH SEAT ASSEMBLY OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/seats/#seat-frames-roadster)
  2. Belt latch Assembly Overview, refer to «REAR BELT LATCH ASSEMBLY OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/airbag/#passenger-protection-airbags-seat-belts-roadster)
  3. Cover For backrest center bearing Removing and Installing, refer to «CENTER BEARING COVER CAP»(/audi/tt-rs/8j-2009-2014/remont/seats/#seat-frames-roadster__center-bearing-cover-cap)
  4. Right release Assembly Overview, refer to «LEFT OR RIGHT RELEASE ASSEMBLY OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/seats/#seat-frames-roadster)
  5. 1/2 right backrest Assembly Overview, refer to «1/2 LEFT AND RIGHT BACKREST ASSEMBLY OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/seats/#seat-frames-roadster__12-left-and-right-backrest-assembly)
  6. Left 1/2 backrest Assembly Overview, refer to «1/2 LEFT AND RIGHT BACKREST ASSEMBLY OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/seats/#seat-frames-roadster__12-left-and-right-backrest-assembly)
  7. Left release Assembly Overview, refer to «LEFT OR RIGHT RELEASE ASSEMBLY OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/seats/#seat-frames-roadster)

Scheme 387

Scheme 387: BENCH SEAT ASSEMBLY OVERVIEW
Scheme 387: BENCH SEAT ASSEMBLY OVERVIEW
  1. Bench seat Removing and Installing, refer to «BENCH SEAT»(/audi/tt-rs/8j-2009-2014/remont/seats/#seat-frames-roadster__bench-seat)
  2. 1/2 right backrest
  3. Left 1/2 backrest
  4. Belt latch Assembly Overview, refer to «REAR BELT LATCH ASSEMBLY OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/airbag/#passenger-protection-airbags-seat-belts-roadster) Removing and Installing, refer to «BELT LATCH»(/audi/tt-rs/8j-2009-2014/remont/airbag/#passenger-protection-airbags-seat-belts-roadster__belt-latch)
  5. Omega clips Quantity: 2 Cannot be replaced For securing bench seat
  6. Retaining eyes Welded with bench seat

Scheme 388

Scheme 388: SEAT FRAME ASSEMBLY OVERVIEW
Scheme 388: SEAT FRAME ASSEMBLY OVERVIEW
  1. Seat frame Removing and Installing, refer to «SEAT FRAME»(/audi/tt-rs/8j-2009-2014/remont/seats/#seat-frames-roadster)
  2. Cover with upholstery Do not separate from one another when removing seat frame
  3. Cushion clamp Quantity: 48 Replacing Install in same location as before removal WARNING: Ends of upholstery clips must face in direction of upholstery after installing and must be bent correctly. Otherwise, there is a risk of injury.
