RELEASE BUTTON Audi TT RS 8J

RELEASE BUTTON

Special tools and workshop equipment required

1. Trim removal wedge 3409

Note. Removal and installation of the left button is described for a left 1/2 backrest. Removal and installation of the right button is the same.

Removing

Scheme 227

Remove left or right trim. Refer to LEFT OR RIGHT TRIM .

Using Trim Removal Wedge 3409, pry button -1- out of release -2-, beginning at back.

Beginning prying with the pins facing the center of the vehicle -arrow-.

Then pry pins facing in direction of vehicle exterior -arrow-.

Scheme 228

Note. After prying rear pins out of release, leg spring -2- and rocker -3- disengage themselves from the button -1-.

Then pry front pin buttons out of release in the same sequence using the Trim Removal Wedge 3409.

Remove button from rocker.

Installation

Scheme 229

Slide button from behind onto rocker -2- and leg spring -3-.

1. Release

Using trim removal wedge 3409, engage left and right rear pins in release.

Using trim removal wedge 3409, engage left and right front pins in release.

Make sure the leg spring is engaged correctly in the button.

Install left or right trim. Refer to LEFT OR RIGHT TRIM .
