STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE Audi TT RS 8J

Communication (roadster) 8 illustrations ~1427 words

STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE

Description

The steering column electronic systems control module is a part of the steering column switch module. The steering column switch module consists of

  1. Left and right steering column switch
  2. Airbag spiral spring
  3. Steering angle sensor
  4. Ignition/starter switch
  5. Steering column electronic systems control module

The steering column electronic systems control module exchanges data between vehicle control modules (e.g. vehicle electrical system control module) and steering column modules (e.g. steering column switch) and steering wheel modules (e.g. airbag).

In addition, multi-function steering wheel button signals are process and relayed via CAN BUS.

Fault finding is performed via Guided Fault Finding. Refer to => .

Steering column switch module, removing and installing, refer to [For transmission(s) 02E] [For engine(s) CBRA, BPY, CETA, CCTA, CEPB, CDMA] Description and Operation .

Repair to CAN bus lines, refer to General Information .

Scheme 124

Scheme 124: RADIO SYSTEM ASSEMBLY OVERVIEW
Scheme 124: RADIO SYSTEM ASSEMBLY OVERVIEW
  1. CD Changer -R41
  2. Radio Removal Tool T10057
  3. iPod Baseplate -R192
  4. Front Interior Light -W1- with Microphone Unit (in front roof module) -R164
  5. Satellite Radio -R146
  6. External Audio Source Connection -R199
  7. Screw 1 Nm
  8. Radio -R
  9. Radio Removal Tool T10057

Scheme 125

Scheme 125: RADIO SYSTEM, OVERVIEW
Scheme 125: RADIO SYSTEM, OVERVIEW
  1. Satellite Antenna -R170- (Sat) On Rear Lid
  2. Radio Antenna 2 -R93- (FM2) Behind Right Side Of Rear Lid
  3. Antenna -R11- (AM/FM1) Left Rear Mast Antenna
  4. Antenna Amplifier -R24- Left Rear Mast Antenna Base
  5. Radio -R- In Upper Center Console
  6. Sound Systems
  7. External Audio Source Connection -R199- In The Center Console Storage Compartment
  8. CD Changer -R41- /iPod Baseplate -R192- Inside The Glove Compartment
  9. Satellite radio -R146- Inside The Luggage Compartment On The Left Side Under The Luggage Compartment Floor Covering
  10. CAN-BUS (Infotainment)
  11. Antenna Amplifier 2 -R111- Behind Right Side Of Rear Lid

Scheme 126

Scheme 126: RADIO, HARNESS CONNECTORS
Scheme 126: RADIO, HARNESS CONNECTORS
  1. Connection Block With Four Multi-Pin Connectors And A Fuse For Unit
  2. Front Passenger's Airbag Disabled Indicator Lamp -K145
  3. AM/FM1 Connection (White) From Antenna Amplifier -R24
  4. FM2 (white) Connection From Antenna Amplifier 2 -R111

Note. Unlisted connector terminals are not assigned.

Scheme 127

Scheme 127
Scheme 127

2 - Right front speaker (+) (only on base sound system)

3 - Left front speaker (+) (only on base sound system)

6 - Right front speaker (-) (only on base sound system)

7 - Left front speaker (-) (only on base sound system)

1 - Left LF-In from the external audio source connection

2 - Signal ground to CD changer/satellite radio

3 - LF-In ground from the external audio source connection

4 - Permanent positive to CD changer

5 - BOSE coding to ground (only with BOSE)

6 - Data out to the CD changer

7 - Right LF-In from the external audio source connection

8 - Left signal from CD changer/satellite radio

9 - Right signal from CD changer/satellite radio

10 - Positive switched to CD changer

11 - Data in from the CD changer

12 - CLK from the CD changer

1 - Speed signal (not used)

3 - Left front signal to digital sound system control module

5 - Left rear signal to digital sound system control module

6 - LF (-) from telephone transceiver

7 - K diagnostic (not used)

8 - Signal ground to digital sound system control module

9 - Right front signal to digital sound system control module

10 - Audio Pilot in/out (not used)

11 - Right rear signal to digital sound system control module

12 - LF (+) from telephone transceiver

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - LF mute

12 - Terminal 31

13 - Positive switched to digital sound system control module

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive connected with PIN 15 (anti-theft warning system)

Scheme 128

Scheme 128: SATELLITE RADIO CONNECTORS, THROUGH 10/06
Scheme 128: SATELLITE RADIO CONNECTORS, THROUGH 10/06

A - Black 8-pin connector (T8n)

B - Black 8-pin connector (T8m)

C - Ter connection (brown) from antenna splitter

D - Sat connection (green) from antenna splitter

Note. Unlisted connector terminals are not assigned.

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

3 - Left signal from CD changer/iPod baseplate

4 - Right signal from CD changer/iPod baseplate

5 - Signal ground to radio/navigation system with CD drive control module

6 - Left signal to radio/navigation system with CD drive control module

7 - Right signal to radio/navigation system with CD drive control module

8 - Signal ground from CD changer/iPod baseplate

1 - Terminal 31

2 - Terminal 30

Scheme 129

Scheme 129: SATELLITE RADIO CONNECTORS, FROM 11/06
Scheme 129: SATELLITE RADIO CONNECTORS, FROM 11/06

A - Black 8-pin connector (T8n)

B - Black 8-pin connector (T8m)

C - Sat connection (green) from radio, telephone, navigation system antenna Coupe

Sat connection (green) on the satellite antenna Roadster

Note. Unlisted connector terminals are not assigned.

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

3 - Left signal from CD changer/iPod baseplate

4 - Right signal from CD changer/iPod baseplate

5 - Signal ground to radio/navigation system with CD drive control module

6 - Left signal to radio/navigation system with CD drive control module

7 - Right signal to radio/navigation system with CD drive control module

8 - Signal ground from CD changer/iPod baseplate

1 - Terminal 31

2 - Terminal 30

Scheme 130

Scheme 130: COMPONENT LOCATIONS, GENERAL OVERVIEW
Scheme 130: COMPONENT LOCATIONS, GENERAL OVERVIEW
  1. Right Front Treble Speaker -R22- In right of instrument panel Removing and installing «LEFT FRONT TREBLE SPEAKER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__left-front-treble-speaker)
  2. Center Mid/High Range Loudspeaker -R158- In the center of the instrument panel Removing and installing, refer to «CENTER MID/HIGH RANGE SPEAKER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__center-midhigh-range-speaker)
  3. Microphone Unit In Front Roof Module -R164- In front interior light Overview, refer to «FRONT ROOF MODULE MICROPHONE UNIT OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__front-roof-module-microphone-unit-overview) Removing and installing, refer to «MICROPHONE UNIT IN FRONT ROOF MODULE»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__microphone-unit-in-front-roof-module)
  4. Right Rear Treble Speaker -R16- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__left-rear-treble-speaker)
  5. Left Rear Mid/Low Range Loudspeaker -R159- /Right Rear Mid/Low Range Loudspeaker -R160- In left and right rear wall Removing and installing, refer to «LEFT REAR MID/LOW RANGE SPEAKER, ROADSTER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__left-rear-midlow-range-speaker)
  6. Antenna Amplifier 2 -R111- Behind right side of rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster)
  7. Satellite Antenna -R170- On rear lid Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster)
  8. Satellite Radio -R146- Inside the luggage compartment on the left side under the luggage compartment floor covering Connections through 10/06, refer to «SATELLITE RADIO CONNECTORS, THROUGH 10/06»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster) Connections from 11/06, refer to «SATELLITE RADIO CONNECTORS, FROM 11/06»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster) Removing and installing, activating, refer to «SATELLITE RADIO»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__satellite-radio)
  9. Digital Sound System Control Module -J525- Behind the luggage compartment left side trim Connectors through MY 2008, refer to «STANDARD SOUND SYSTEM CONNECTORS, THROUGH MY 2008»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__standard-sound-system-connectors-through-my) Connectors from MY 2009, refer to «STANDARD SOUND SYSTEM CONNECTORS, FROM MY 2009»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__standard-sound-system-connectors-from-my) Removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__digital-sound-system-control-module) BOSE connections, refer to «BOSE SOUND SYSTEM CONNECTORS»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster) BOSE, removing and installing, refer to «DIGITAL SOUND SYSTEM CONTROL MODULE (BOSE)»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__digital-sound-system-control-module-bose)
  10. Antenna Amplifier -R24- left rear mast antenna base Overview, refer to «ANTENNAS, OVERVIEW»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster)
  11. Left Rear Treble Speaker -R14- In upper right side trim Removing and installing, refer to «LEFT REAR TREBLE SPEAKER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__left-rear-treble-speaker)
  12. Left Front Midrange Speaker -R103- /Right Front Midrange Speaker -R104- In center of doors Removing and installing, refer to «LEFT FRONT MIDRANGE SPEAKER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__left-front-midrange-speaker)
  13. Center speaker -R148- In center of rear wall Removing and installing, refer to «CENTER LOUDSPEAKER, ROADSTER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__center-loudspeaker)
  14. Left Front Bass Speaker -R21- /Right Front Bass Speaker -R23- In bottom of doors Removing and installing, refer to «LEFT FRONT BASS SPEAKER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__left-front-bass-speaker)
  15. Left Front Treble Speaker -R20- In left of instrument panel Removing and installing, refer to «LEFT FRONT TREBLE SPEAKER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__left-front-treble-speaker)
  16. Radio -R- In the top of the center console Connectors, refer to «RADIO, HARNESS CONNECTORS»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster) . Removing and installing, refer to «RADIO»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__radio) symphony transport mode, activating/deactivating, refer to «SYMPHONY TRANSPORT MODE, ACTIVATING/DEACTIVATING»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__symphony-transport-mode-activatingdeactivating)
  17. CD Changer -R41- In the glove compartment Connectors, refer to «CD CHANGER HARNESS CONNECTORS»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__cd-changer-harness-connectors) . Removing and installing, refer to «CD CHANGER»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster) - iPod Baseplate -R192- In the glove compartment Connectors, refer to «IPOD BASEPLATE, CONNECTIONS»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__ipod-baseplate-connections) . Removing and installing, refer to «IPOD BASEPLATE»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster) - External audio source connection -R199- Inside the glove compartment / center console Connectors (connection for an external audio source) refer to «EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS, AMI»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__external-audio-source-connection-connectors-ami) AUX IN Connectors, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION CONNECTORS»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__aux-in-external-audio-source-connection) . Removing and installing (connection for an external audio source) refer to «AMI EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__ami-external-audio-source-connection) AUX IN, Removing and Installing, refer to «AUX IN EXTERNAL AUDIO SOURCE CONNECTION»(/audi/tt-rs/8j-2009-2014/remont/communication-devices/#communication-roadster__aux-in-external-audio-source-connection) .

Scheme 131

Scheme 131: RADIO PREPARATION
Scheme 131: RADIO PREPARATION

1 - Speaker connector (T8d) brown

2 - Voltage supply connector (T8c) black

3 - Antenna connection (AM/FM1) for the radio

4 - Antenna amplifier on upper right side of rear lid (Coupe)

Antenna amplifier left rear mast antenna base (Roadster)

5 - Rear window antenna 1 AM/FM1 (Coupe)

Antenna (AM/FM1) mast antenna (Roadster)

6 - left front speaker

7 - right front speaker
