A/C UNIT COMPONENTS Audi TT RS 8J

Air Conditioning (roadster) 1 illustration ~1014 words

A/C UNIT COMPONENTS

Observe notes for control and regulation of components in passenger compartment. Refer to A/C SYSTEM CONTROL AND REGULATION COMPONENTS INSIDE PASSENGER COMPARTMENT .

Note. Air guide in air conditioner and in vehicle; refer to AIR GUIDE IN EVAPORATOR HOUSING and AIR GUIDE IN AIR DISTRIBUTION HOUSING . Heating & A/C unit, removing and installing; refer to A/C UNIT . The structure of the heater is basically the same as the A/C unit but there are differences because various components are not present HEATER COMPONENTS .

Scheme 124

Scheme 124: A/C UNIT COMPONENTS
Scheme 124: A/C UNIT COMPONENTS
  1. A/C Unit With Evaporator May only be removed when refrigerant circuit has been discharged; bring vehicle to a workshop that has the necessary tools and in which the work can be performed accordingly by qualified personnel. Refer to «General, Technical Data»(/audi/tt-rs/8j-2009-2014/remont/exhaust/#general-technical-data-refrigerant-r134a-servicing-roadster-2-of-2) or refer to «General, Technical Data»(/audi/tt-rs/8j-2009-2014/remont/general-servicing-all-makes/#general-technical-data-refrigerant-r134a-servicing-roadster-1-of-2) . Heating and A/C unit, removing and installing, refer to «A/C UNIT»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__ac-unit) . Heating and A/C unit, disassembling and assembling; refer to «DISASSEMBLY AND ASSEMBLY»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster) . Clean air conditioning system evaporator with Ultrasound A/C Cleaner VAS 6189. Refer to «EVAPORATOR, CLEANING WITH ULTRASOUND A/C CLEANER»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__evaporator-cleaning-with-ultrasound-ac-cleaner) .
  2. Defroster Door Motor -V107- With Defroster Door Motor Position Sensor -G135-. Lever color identification: blue. Removing and Installing, refer to «DEFROSTER DOOR MOTOR -V107»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__defroster-door-motor-v107) . NOTE: This motor is fastened on the right on air distributor housing in vehicles with right-side steering.
  3. Left Footwell Vent Temperature Sensor -G261- Removing and installing, refer to «LEFT FOOTWELL VENT TEMPERATURE SENSOR -G261»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__left-footwell-vent-temperature-sensor-g261) .
  4. Central Air Door Motor -V70- With Central Door Motor Position Sensor -G112-. Removing and installing, refer to «CENTRAL AIR DOOR MOTOR -V70- / -V145»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__central-air-door-motor-v70) . NOTE: Depending on the version of the Climatronic control module -J255-, the Central Air Door Motor -V70- (with Central Door Motor Position Sensor -G112-) may be designated as Front Air Distribution Motor -V145- (with Front Air Distribution Motor Position Sensor -G470-) in On Board Diagnostic (OBD).
  5. Auxiliary Air Heater Heating Element -Z35- Only intended for vehicles with Diesel engine.
  6. Heater Core For Heater Unit Removing and installing, refer to «HEATER CORE»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__heater-core) .
  7. Left Temperature Door Motor -V158- With Left Temperature Door Potentiometer/Actuator -G220-. Lever color identification: white. Removing and installing, refer to «LEFT TEMPERATURE DOOR MOTOR -V158»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__left-temperature-door-motor-v158) . NOTE: On the Audi TT, both positioning motors for left and right temperature doors are controlled via one characteristics curve, depending on the programmed end stops (only one temperature setting on the Climatronic control module -J255- is possible). Depending on the measured temperatures, the calculated sunlight intensity and setting on Climatronic control module, the calculated specified outflow temperature and therefore, the specified position of the positioning motor, may be different for the left and right side.
  8. Back Pressure Door Motor -V71- With Back Pressure Door Motor Position Sensor -G113-. Removing and installing, refer to «AIR FLOW DOOR MOTOR -V71-, FUNCTION»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__air-flow-door-motor-v71-function) .
  9. Recirculation Door Motor -V113- With Recirculation Door Motor Position Sensor -G143-. Removing and installing, refer to «RECIRCULATION DOOR MOTOR -V113»(/audi/tt-rs/8j-2009-2014/remont/automatic-hvac-system/#air-conditioning-roadster__recirculation-door-motor-v113) .
