Audi SQ8 I (2019-2023) hot at all times Wiring diagrams

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 3 FUSE PANEL C HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT BRAKE PAD WEAR SENSOR LEFT REAR BRAKE PAD WEAR SENSOR ORG/BRN WIRE ORG/GRY WIRE RED WIRE RED/GRN WIRE RIGHT FRONT BRAKE PAD WEAR SENSOR RIGHT REAR BRAKE PAD WEAR SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ FPK ACTIVE INFO DISPLAY W/O FPK ACTIVE INFO DISPLAY YEL WIRE

AIR BAG CONTROL MODULE BRAKE BOOSTER BRAKE FLUID LEVEL WARNING SWITCH BRN WIRE BRN/BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTACT SWITCH DRIVER DOOR CONTROL MODULE DRIVER DOOR LOCK UNIT DRIVER SEAT BELT SWITCH DRIVER SEAT COUPLING POINT FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER SEAT COUPLING POINT FUSE 10 FUSE PANEL E GRN WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER SYSTEM ORG/BRN WIRE ORG/GRY WIRE PNK WIRE RED WIRE SUPPLEMENTAL RESTRAINTS SYSTEM VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ FPK ACTIVE INFO DISPLAY W/O FPK ACTIVE INFO DISPLAY WHT/GRN WIRE

12-PIN CONNECTOR AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOG LAMP BUTTON FUSE 10 FUSE 11 FUSE 12 FUSE PANEL C FUSE PANEL E FUSE PANEL F HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES HUMIDITY SENSOR INTERIOR REAR VIEW MIRROR LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT TURN SIGNAL BULB LEFT HEADLAMP FAN LEFT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR LEFT HEADLAMP TEMPERATURE SENSOR 1 LEFT HEADLAMP TEMPERATURE SENSOR 2 LEFT HEADLAMP TEMPERATURE SENSOR 3 LEFT HEADLAMP TEMPERATURE SENSOR 4 LEFT HEADLAMP TEMPERATURE SENSOR 5 LEFT HIGH BEAM HEADLAMP BULB LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LOW BEAM HEADLAMP BULB LIGHT SWITCH ORG/BRN WIRE ORG/GRY WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR REAR FOG LAMP BUTTON RED WIRE RED/GRY WIRE ROTARY LIGHT SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/GRN WIRE VIO/WHT WIRE WHT/BLK WIRE YEL/BLK WIRE

12-PIN CONNECTOR 4-PIN CONNECTOR AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FOG LAMP BUTTON FUSE 10 FUSE 11 FUSE 12 FUSE PANEL C FUSE PANEL E FUSE PANEL F HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES HUMIDITY SENSOR INTERIOR REAR VIEW MIRROR LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT SIDE MARKER LAMP BULB LEFT FRONT TURN SIGNAL BULB LEFT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR LEFT HEADLAMP TEMPERATURE SENSOR 1 LEFT HEADLAMP TEMPERATURE SENSOR 2 LEFT HEADLAMP TEMPERATURE SENSOR 3 LEFT HEADLAMP TEMPERATURE SENSOR 4 LEFT HIGH BEAM HEADLAMP BULB LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LOW BEAM HEADLAMP BULB LIGHT SWITCH ORG/BRN WIRE ORG/GRY WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR REAR FOG LAMP BUTTON RED WIRE RED/GRY WIRE ROTARY LIGHT SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/GRN WIRE VIO/WHT WIRE WHT/BLK WIRE YEL/BLK WIRE

BOTTOM CENTER COUPLING POINT IN INTERIOR BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM FUSE 6 FUSE PANEL J HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT TIRE PRESSURE MONITORING SENSOR, ANTENNA LEFT REAR TIRE PRESSURE MONITORING SENSOR, ANTENNA ORG/BRN WIRE ORG/GRY WIRE RED/BLU WIRE RIGHT FRONT TIRE PRESSURE MONITORING SENSOR, ANTENNA RIGHT REAR TIRE PRESSURE MONITORING SENSOR, ANTENNA TIRE PRESSURE MONITORING CONTROL MODULE W/ FPK ACTIVE INFO DISPLAY W/O FPK ACTIVE INFO DISPLAY

ACCELERATOR PEDAL MODULE (ON ACCELERATOR PEDAL ASSEMBLY) ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 2 BATTERY INTERRUPT IGNITER BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM ENGINE COMPONENT POWER SUPPLY RELAY ENGINE/MOTOR CONTROL MODULE FUSE 1 FUSE 2 FUSE 3 FUSE PANEL B FUSE PANEL E GRN WIRE GRN/VIO WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ORG/BRN WIRE ORG/WHT WIRE PNK WIRE RED WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 VIO WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

ABS CONTROL MODULE ASSEMBLY MOUNT ACTUATOR 1 ASSEMBLY MOUNT ACTUATOR 2 ASSEMBLY MOUNT CONTROL MODULE ASSEMBLY MOUNT SENSOR 1 ASSEMBLY MOUNT SENSOR 2 AUTOMATIC TRANSMISSION COUPLING POINT BLK WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BOTTOM LEFT COUPLING POINT ON ENGINE BRAKE LAMP SWITCH BRAKE PEDAL POSITION SENSOR BRAKE PEDAL SWITCH (LEFT REAR ENGINE COMPT) BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM ENGINE PRE-WIRING COUPLING POINT 1 FUEL TANK LEAK DETECTION MODULE FUSE 5 FUSE PANEL B GRN WIRE GRN/BLK WIRE GRN/BLU WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/GRY WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE TOP OF TRANSMISSION) TRANSMISSION COOLANT VALVE TRANSMISSION FLUID COOLING PUMP TRANSMISSION MOUNT VALVE 1 TRANSMISSION MOUNT VALVE 2 VIO/RED WIRE WHT/GRN WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/RED WIRE

BANK 2 RECIRCULATION VALVE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/YEL WIRE BRN/BLK WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE ENGINE COVER TEMPERATURE SENSOR ENGINE TEMPERATURE SENSOR FUSE 9 FUSE PANEL F GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BRN WIRE HEATER OXYGEN SENSOR 2 HOT AT ALL TIMES LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT OIL PRESSURE REGULATION VALVE OIL PRESSURE SWITCH OIL TEMPERATURE SENSOR OXYGEN SENSOR 2 BEFORE CATALYTIC CONVERTER OXYGEN SENSOR 2 HEATER RED WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE WHT/GRN WIRE YEL/BLK WIRE
