Audi SQ8 I (2019-2023) hot at all times Wiring diagrams

4-PIN CONNECTOR BLK WIRE BLU WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 12 FUSE 5 FUSE PANEL E FUSE PANEL F GRN WIRE HIGH TONE HORN HOT AT ALL TIMES LOW TONE HORN MULTI-FUNCTION STEERING WHEEL CONTROL MODULE ORG/BRN WIRE PNK WIRE RED WIRE RED/GRY WIRE SIGNAL HORN ACTIVATION SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/RED WIRE W/ STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE

BLK/BLU WIRE BLK/GRN WIRE BLU/BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM FUSE GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT DOOR SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT SPEAKER LEFT FRONT TREBLE SPEAKER LEFT FRONT TREBLE SPEAKER, MOTOR LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR DOOR SPEAKER LEFT REAR MIDRANGE SPEAKER PNK WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT DOOR SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT FRONT TREBLE SPEAKER, MOTOR RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR DOOR SPEAKER RIGHT REAR MIDRANGE SPEAKER SUBWOOFER VIO/BLU WIRE VIO/BRN WIRE VIO/RED WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

BLK WIRE BLU WIRE BRN WIRE BRN/GRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM FRONT INFORMATION DISPLAY CONTROL HEAD FRONT INFORMATION DISPLAY CONTROL HEAD 2 FUSE 5 FUSE 8 FUSE 9 FUSE PANEL F GRN WIRE GRY/RED WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE MOST DATA BUS CIRCUIT NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRY WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SOUND SYSTEMS WHT WIRE

ACCESS/START AUTHORIZATION BUTTON BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE BRN/RED WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL CENTER COUPLING POINT ON LEFT A-PILLAR COMPUTER DATA LINES SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE DRIVER VOLUME CONTROL FUSE 13 FUSE 15 FUSE 7 FUSE PANEL D FUSE PANEL F FUSE PANEL J GRN WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES NCA WIRE ORG/ WIRE ORG/BRN WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RIGHT REAR FOOTWELL ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA USB CONNECTION 1 USB DISTRIBUTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE

BLK WIRE BLK/BRN WIRE BLU/VIO WIRE BRN/WHT WIRE CENTER CONSOLE SWITCH MODULE 1 COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT FRONT BUMPER FUSE 11 FUSE PANEL F GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR LEFT FRONT PARKING AID SENSOR PARALLEL PARKING ASSISTANCE BUTTON PARALLEL PARKING ASSISTANCE INDICATOR LAMP PARKING AID BUTTON PARKING AID INDICATOR LAMP RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR RIGHT FRONT PARKING AID SENSOR VIO/BLU WIRE WHT/GRY WIRE YEL/BLU WIRE YEL/GRN WIRE

BLK WIRE BLU WIRE BOTTOM LEFT COUPLING POINT ON ENGINE BRN WIRE BRN/BLK WIRE COUPLING POINT 2 IN LEFT FRONT DOOR COUPLING POINT 2 IN RIGHT FRONT DOOR DRIVER ASSISTANCE SYSTEMS CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FRONT PERIPHERAL CAMERA FUSE 1 FUSE 9 FUSE PANEL B FUSE PANEL J GRN WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT COUPLING POINT ON INSTRUMENT PANEL LEFT FRONT DOOR COUPLING POINT LEFT PERIPHERAL CAMERA NCA WIRE ORG/ WIRE REAR PERIPHERAL CAMERA RED WIRE RED/GRN WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT PERIPHERAL CAMERA

ACCESS/START AUTHORIZATION BUTTON BLK WIRE BLU WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE BRN/GRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE FUSE 15 FUSE 7 FUSE PANEL D FUSE PANEL J GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES NCA WIRE ORG/ WIRE ORG/BRN WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RIGHT REAR FOOTWELL ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA USB CONNECTION 1 USB DISTRIBUTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE

ANDROID OPERATING SYSTEM CONTROL MODULE ANTENNA BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/RED WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL DVD PLAYER FUSE 10 FUSE 14 FUSE 2 FUSE PANEL F GRN WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 NCA WIRE ORG/ WIRE PNK WIRE RADIO ANTENNA 2 RED/BLK WIRE RED/YEL WIRE W/O TV TUNER

ACCESS/START AUTHORIZATION BUTTON BATTERY BATTERY INTERRUPT IGNITER BATTERY MONITORING CONTROL MODULE BLK WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL CHARGING CIRCUIT COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM D/S ENGINE ELECTRONICS FUSE ENGINE/MOTOR CONTROL MODULE FUSE 11 FUSE 5 FUSE 9 FUSE PANEL B FUSE PANEL D FUSE PANEL G GRN WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED NCA WIRE ORG/BRN WIRE ORG/GRY WIRE ORG/WHT WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER 1 RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT RIGHT REAR FOOTWELL SELECTOR LEVER SELECTOR LEVER TRANSMISSION RANGE DISPLAY STARTER STARTER RELAY 1 STARTER RELAY 2 SUPPLEMENTAL RESTRAINTS SYSTEM TERMINAL 30 WIRE JUNCTION TRANSMISSION CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE WHT/GRY WIRE WHT/YEL WIRE YEL/GRY WIRE

ANTENNA AMPLIFIER BLK WIRE BLU WIRE BRN WIRE FUSE 10 FUSE PANEL J GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES MOST DATA BUS CIRCUIT NCA WIRE RED WIRE RED/YEL WIRE TV ANTENNA 1 TV CARD READER (RIGHT SIDE OF CARGO AREA) TV TUNER W/ DIGITAL RADIO W/O DIGITAL RADIO
