BUZZERS, RELAYS & TIMERS
| Component | Location |
|---|---|
| Auxiliary Engine Coolant (EC) Pump Relay (1) | On right kick panel relay & fuse panel. (Scheme 71) |
| Battery Switch-Off Relay | In luggage compartment, in front of battery. (Scheme 13) |
| Brake Booster Relay (1) | On right kick panel relay & fuse panel. (Scheme 71) |
| Cold Start Fuel Pump (FP) Relay (3) | In relay & fuse carrier, right side of luggage compartment. (Scheme 139) |
| Compressor Level Control System Relay (1) | On relay & fuse panel at left side of dash. (Scheme 70) |
| Coolant Fan 3 Relay (6.0L) (1) | On right kick panel relay & fuse panel. (Scheme 71) |
| Engine Component Power Supply Relay (5.2L) (4) | On right kick panel relay & fuse panel. (Scheme 71) |
| Fuel Pump (FP) Relay (4) | On right kick panel relay & fuse panel. (Scheme 71) |
| Fuel Pump (FP) 2 Relay (3) | In relay & fuse carrier, right side of luggage compartment. (Scheme 139) |
| Headlamp Washer Relay (5) | On right kick panel relay & fuse panel. (Scheme 71) |
| Horn Relay (2) | On relay & fuse panel at left side of dash. (Scheme 70) |
| Level Control System Compressor Relay (1) | On relay & fuse panel at left side of dash. (Scheme 70) |
| Motronic Engine Control Module (ECM) Power Supply Relay (3) | On plenum chamber E-box relay panel. (Scheme 138) |
| Parking Warning Buzzer | Under right side of rear shelf. (Scheme 99) |
| Power Supply Relay (Terminal 15) (3) | On relay & fuse panel at left side of dash. (Scheme 70) |
| Power Supply Relay 1 (Terminal 75) (6) | On relay & fuse panel at left side of dash. (Scheme 70) |
| Power Supply Relay (2) | In relay & fuse carrier, right side of luggage compartment. (Scheme 139) |
| Rear Window Defogger Relay (1) | In relay & fuse carrier, right side of luggage compartment. (Scheme 139) |
| Secondary Air Injection (AIR) Pump Relay (1) | On plenum chamber E-box relay panel. (Scheme 138) |
| Secondary Air Injection (AIR) Pump Relay 2 (4) | On plenum chamber E-box relay panel. (Scheme 138) |
| Starter Relay (2) | On right kick panel relay & fuse panel. (Scheme 71) |
| Starter Relay 2 (3) | On right kick panel relay & fuse panel. (Scheme 71) |
| Voltage Supply Terminal 15 (B+) Relay (3) | On relay & fuse panel at left side of dash. (Scheme 70) |
| Windshield Washer Fluid Heating Relay (4) | On relay & fuse panel at left side of dash. (Scheme 70) |
BUZZERS, RELAYS & TIMERS LOCATION
CIRCUIT PROTECTION DEVICES
| Component | Location |
|---|---|
| Front Passenger's Power Set Adjustment Circuit Breaker 1 (B) | On right kick panel relay & fuse panel. (Scheme 71) |
| Front Passenger's Power Set Adjustment Circuit Breaker 2 (D) | On right kick panel relay & fuse panel. (Scheme 71) |
| Fuse Holder (Instrument Panel - Left) | In left end of dash. (Scheme 159) |
| Fuse Holder (Instrument Panel - Right) | In right end of dash. (Scheme 160) |
| Fuse Holder (Luggage Compartment - Left) | Left side of luggage compartment. (Scheme 109) |
| Fuse Holder (Luggage Compartment - Right) | Right side of luggage compartment. (Scheme 161) |
| Power (Memory) Seat Circuit Breaker | On relay & fuse carrier at left side of dash. (Scheme 64) |
| Power Rear Seat Circuit Breaker 1 (B) | In relay & fuse carrier, right side of luggage compartment. (Scheme 139) |
| Power Rear Seat Circuit Breaker 2 (C) | In relay & fuse carrier, right side of luggage compartment. (Scheme 139) |
| Power Seat Circuit Breaker | Right kick panel. (Scheme 65) |
| Power Seat Circuit Breaker 1 (D) | In fuse & relay carrier behind left side of dash. (Scheme 70) |
| Power Seat Circuit Breaker 2 (E) | In fuse & relay carrier behind left side of dash. (Scheme 70) |
| Power Window Circuit Breaker (C) | In fuse & relay carrier behind left side of dash. (Scheme 70) |
CIRCUIT PROTECTION DEVICES LOCATION
CONTROL UNITS
| Component | Location |
|---|---|
| ABS Control Module (W/EDL) | At left side of engine compartment. (Scheme 4) |
| Access/Start Control Module | Under driver's seat. (Scheme 5) |
| Air Bag Control Module | Below center of dash, on transmission tunnel. (Scheme 6) |
| Antenna Selection Control Module | Behind left rear edge of roof trim. (Scheme 105) |
| Battery Monitoring Control Module | Right side of luggage compartment. (Scheme 12) |
| Central Control Module (Comfort System) | Right side of luggage compartment. (Scheme 14) |
| Comfort System Central Control Module (6) | Right side of luggage compartment, behind side trim. (Scheme 190) |
| Control Module For Navigation W/CD | Left side of luggage compartment. (Scheme 104) |
| Coolant Fan Control (FC) Control Module | On coolant fan. (Scheme 19) |
| Coolant FC (Fan Control) Control Module No. 2 | On right coolant fan motor. (Scheme 20) |
| Curtain Air Bag Unit (Driver's/Front Passenger's) (6) | In respective roof rail. (Scheme 152) |
| Digital Sound System Control Module (1) | Left side of luggage compartment. (Scheme 192) |
| Distance Regulation Control Module | Behind center of front bumper. (Scheme 115) |
| Door Closing Control Module | Right side of luggage compartment, behind battery. (Scheme 24) |
| Door Control Module (Driver Side) | Integrated in driver's door window regulator motor. (Scheme 25) |
| Door Control Module (Left Rear) | Integrated in left rear door window regulator motor. (Scheme 27) |
| Door Control Module (Passenger Side) | Integrated in right front door window regulator motor. (Scheme 26) |
| Door Control Module (Right Rear) | Integrated in right rear door window regulator motor. (Scheme 28) |
| Electro-Mechanical Parking Brake Control Module (2) | Right side of luggage compartment. (Scheme 191) |
| Energy Management Control Module (2) | Right side of luggage compartment, behind side trim. (Scheme 190) |
| Engine Control Module (ECM) (Except 5.2L) | In passenger's side plenum chamber E-box. (Scheme 31) |
| Engine Control Module (ECM) 2 (5.2L) (1) | Right rear of engine compartment. (Scheme 183) |
| Engine Control Module (ECM) 2 (6.0L) (4) | In passenger's side plenum chamber E-box. (Scheme 140) |
| Engine Control Module (ECM) (5.2L) (3) | Right rear of engine compartment. (Scheme 183) |
| Fresh Air Blower Control Module | At right rear of engine compartment, next to fresh air blower motor. (Scheme 15) |
| Front Information Display Control Head Control Module | Behind glove compartment. (Scheme 100) |
| Garage Door Opener Control Module | Behind right side of front bumper. (Scheme 162) |
| Headlight Range Control Module | Behind instrument cluster. (Scheme 37) |
| Heated Windshield Control Module (1) | Right side of luggage compartment. (Scheme 191) |
| High-Intensity Gas Discharge Lamp Control Module (Left/Right) | At respective headlight assembly. (Scheme 168) |
| Inclination-/Anti-Theft Control Module | Under right side of rear seat. (Scheme 38) |
| Instrument Cluster Control Module | Behind instrument cluster. (Scheme 113) |
| Left/Right Rear Heated Seat Control Module | Under center of rear seat. (Scheme 108) |
| Level Control System Control Module | Behind glove compartment. (Scheme 51) |
| Memory Seat/Steering Column Adjustment Control Module | Under driver's seat. (Scheme 112) |
| Multi-Function Steering Wheel Control Module | In steering wheel. (Scheme 16) |
| Navigation System W/CD Drive Control Module (3) | Left side of luggage compartment. (Scheme 192) |
| Parking Aid Control Module (4) | Left side of luggage compartment. (Scheme 192) |
| Power Sunroof Control Module | In front of roof module. (Scheme 66) |
| Radio Receiver & Speech Input Control Module (5) | Left side of luggage compartment. (Scheme 192) |
| Rear Lid Control Module | Right rear of luggage compartment. (Scheme 68) |
| Rear Lid Taillight Control Module (Left Right) | In respective taillight assembly. (Scheme 169) |
| Rear Memory Seat Control Module | Under center of rear seat. (Scheme 108) |
| Rear Taillight Control Module (Left Right) | In respective taillight assembly. (Scheme 170) |
| Roof Electronics Control Module | Under front of roof module. (Scheme 80) |
| Solar Operation Control Module | Underside of solar roof. (Scheme 116) |
| Steering Column Electronic Systems Control Module | Top of steering column. (Scheme 107) |
| Telephone/Telematic Control Module | Left front footwell, under carpet. (Scheme 106) |
| Throttle Valve Control Module 2 (5.2L) (4) | On cylinder bank No. 2 throttle body. (Scheme 182) |
| Throttle Valve Control Module 2 (6.0L) (3) | On cylinder bank No. 2 throttle body. (Scheme 140) |
| Throttle Valve Control Module (4.2L) | Behind intake manifold, on throttle valve housing. (Scheme 92) |
| Throttle Valve Control Module (5.2L) (7) | On cylinder bank No. 1 throttle body. (Scheme 181) |
| Throttle Valve Control Module (6.0L) (11) | On cylinder bank No. 1 throttle body. (Scheme 140) |
| Tire Pressure Monitoring Control Module | Under left side of rear seat. (Scheme 93) |
| Towing Recognition Control Module (3) | Right side of luggage compartment. (Scheme 191) |
| Transmission Control Module (TCM) | In bottom of transmission. (Scheme 94) |
| Vehicle Electrical System Control Module | Behind left side of dash. (Scheme 98) |
| Vehicle Electrical System Control Module 2 | Under front passenger's seat. |
| Wiper Motor Control Motor | In plenum, on windshield wiper motor. (Scheme 114) |
CONTROL UNITS LOCATION
MOTORS
| Component | Location |
|---|---|
| Belt Height Adjustment Motor (Left/Right Front) | At respective "B" pillar. (Scheme 153) |
| Center Vent Motor (Left) (4) | Behind left instrument panel vent. (Scheme 149) |
| Center Vent Motor (Right) (9) | Behind right instrument panel vent. (Scheme 149) |
| Coolant Fan | Right front of engine compartment. (Scheme 17) |
| Coolant Fan No. 2 | Left front of engine compartment. (Scheme 18) |
| Decklid Central Locking System Motor | In trunk lid. (Scheme 154) |
| Fuel Lid Unlock Motor | Right side of luggage compartment, behind trim. (Scheme 174) |
| Headlight Beam Adjusting Motor (Left/Right) | In respective headlight assembly. (Scheme 165) |
| Headlight Washer Jet Motor (Left) | Behind left front bumper. (Scheme 44) |
| Headlight Washer Jet Motor (Right) | Behind right front bumper. (Scheme 75) |
| High Pressure Pump (Left) (4.2L) (3) | Top of cylinder bank No. 2. (Scheme 146) |
| High Pressure Pump (Left) (5.2L) (12) | Top of cylinder bank No. 2. (Scheme 182) |
| High Pressure Pump (Right) (4.2L) (1) | Top of cylinder bank No. 1. (Scheme 146) |
| High Pressure Pump (Right) (5.2L) (14) | Top of cylinder bank No. 1. (Scheme 181) |
| Intake Flap Motor (4.2L) (5) | Left front of engine. (Scheme 145) |
| Intake Flap Motor (5.2L) (3) | Front of engine. (Scheme 186) |
| Leak Detection Pump (LDP) | In left rear wheel well. (Scheme 40) |
| Level Control System Compressor Motor | In left front wheelwell. (Scheme 52) |
| Lock Unit For Central Locking (Driver's/Front Passenger's) | In respective front door. (Scheme 172) |
| Lock Unit For Central Locking (Left/Right Rear Door) | In respective rear door. (Scheme 173) |
| Open-Close Display Motor | Behind center of dash. (Scheme 60) |
| Parking Brake Motor (Left) | At left rear brake caliper. (Scheme 45) |
| Parking Brake Motor (Right) | At right rear brake caliper. (Scheme 76) |
| Rear Lid Opening Motor | Right side of luggage compartment, behind trim. (Scheme 177) |
| Rear Warm/Cold Flap Air Outlet Motor (Left) (23) | Under left side of center console. (Scheme 150) |
| Rear Warm/Cold Flap Air Outlet Motor (Right) (18) | Under right side of center console. (Scheme 150) |
| Rear Window Shade Motor | Below center of rear parcel shelf. (Scheme 69) |
| Secondary Air Injection (AIR) Pump Motor 2 (6.0L) (15) | In lower part of air filter housing. (Scheme 140) |
| Secondary Air Injection (AIR) Pump Motor (4.2L) | Between right front bumper & wheelwell liner. (Scheme 81) |
| Secondary Air Injection (AIR) Pump Motor (5.2L) (18) | Below right long member. (Scheme 181) |
| Secondary Air Injection (AIR) Pump Motor (6.0L) (16) | In lower part of air filter housing. (Scheme 140) |
| Steering Column Adjustment Motor (Axial) | Left side of steering column. (Scheme 53) |
| Steering Column Adjustment Motor (Vertical) | Right side of steering column. (Scheme 54) |
| Steering Column Lock Actuator | At base of steering column. (Scheme 180) |
| Sunroof Motor | Under rear of roof module. (Scheme 90) |
| Throttle Drive 2 (3) | On cylinder bank No. 2 throttle body. (Scheme 140) |
| Throttle Drive (11) | On cylinder bank No. 1 throttle body. (Scheme 140) |
| Trunk Lid Release Motor | Right side of luggage compartment. (Scheme 96) |
| Variable Intake Manifold Runner Motor (4.2L) (4) | Right front of engine. (Scheme 145) |
| Variable Intake Manifold Runner Motor (5.2L) (2) | Right front of engine. (Scheme 186) |
| Window Regulator (Driver's) | In driver's door. (Scheme 55) |
| Window Regulator (Left Rear) | In left rear door. (Scheme 57) |
| Window Regulator (Passenger's) | In passenger's door. (Scheme 56) |
| Window Regulator (Right Rear) | In right rear door. (Scheme 58) |
MOTORS LOCATION
SENDING UNITS/SENSORS
| Component | Location |
|---|---|
| Accelerator Pedal Position Sender 2 | At accelerator pedal. (Scheme 83) |
| Angle Sensor 1 (Throttle Drive 1) (6.0L) (11) | On cylinder bank No. 1 throttle body. (Scheme 140) |
| Angle Sensor 1 (Throttle Drive 2) (6.0L) (3) | On cylinder bank No. 2 throttle body. (Scheme 140) |
| Angle Sensor 2 (Throttle Drive 1) (6.0L) (11) | On cylinder bank No. 1 throttle body. (Scheme 140) |
| Angle Sensor 2 (Throttle Drive 2) (6.0L) (3) | On cylinder bank No. 2 throttle body. (Scheme 140) |
| Body Acceleration Sensor (Left Front) | On left front strut tower. (Scheme 42) |
| Body Acceleration Sensor (Rear) | Behind right rear wheelwell liner. (Scheme 67) |
| Body Acceleration Sensor (Right Front) | On right front strut tower. (Scheme 73) |
| Brake Booster Sender 1 | On ABS-hydraulic control unit. (Scheme 82) |
| Camshaft Position (CMP) Sensor 2 (4.2L) (13) | Top of cylinder bank No. 2. (Scheme 144) |
| Camshaft Position (CMP) Sensor 2 (5.2L) (11) | Left side of cylinder bank No. 2. (Scheme 182) |
| Camshaft Position (CMP) Sensor 2 (6.0L) (7) | Rear of cylinder bank No. 1. (Scheme 140) |
| Camshaft Position (CMP) Sensor 3 (4.2L) (19) | Right side of cylinder bank No. 1. (Scheme 143) |
| Camshaft Position (CMP) Sensor 3 (5.2L) (17) | Right side of cylinder bank No. 1. (Scheme 181) |
| Camshaft Position (CMP) Sensor 3 (6.0L) (6) | Rear of cylinder bank No. 1. (Scheme 140) |
| Camshaft Position (CMP) Sensor (4.2L) (14) | Top of cylinder bank No. 1. (Scheme 143) |
| Camshaft Position (CMP) Sensor 4 (4.2L) (8) | Rear of cylinder bank No. 2. (Scheme 144) |
| Camshaft Position (CMP) Sensor 4 (5.2L) (8) | Left side of cylinder bank No. 2. (Scheme 182) |
| Camshaft Position (CMP) Sensor 4 (6.0L) (10) | Rear of cylinder bank No. 2. (Scheme 140) |
| Camshaft Position (CMP) Sensor (5.2L) (13) | Top of cylinder bank No. 1. (Scheme 181) |
| Camshaft Position (CMP) Sensor (6.0L) (8) | Rear of cylinder bank No. 2. (Scheme 140) |
| Center Air Outlet Sensor (Left) (3) | In left instrument panel vent. (Scheme 149) |
| Center Air Outlet Sensor (Right) (10) | In right instrument panel vent. (Scheme 149) |
| Center Outlet Temperature Sensor (6) | Behind left center of dash. (Scheme 149) |
| Center Vent Motor Position Sensor (Left) (4) | Integral to left center vent motor. (Scheme 149) |
| Center Vent Motor Position Sensor (Right) (9) | Integral to right center vent motor. (Scheme 149) |
| Engine Coolant Temperature (ECT) Sensor (4.2L) (4) | Rear of cylinder bank No. 1. (Scheme 143) |
| Engine Coolant Temperature (ECT) Sensor (5.2L) (2) | Rear of cylinder bank No. 1. (Scheme 185) |
| Engine Speed (RPM) Sensor (4.2L) | Left rear of engine. |
| Engine Speed (RPM) Sensor (5.2L) | Left rear of engine. (Scheme 184) |
| Engine Speed (RPM) Sensor (6.0L) (9) | Left rear of engine. (Scheme 140) |
| Front Air Bag Crash Sensor (Driver's Side) | Left front of engine compartment. (Scheme 30) |
| Front Air Bag Crash Sensor (Passenger's Side) | Right front of engine compartment. (Scheme 63) |
| Front Seat Temperature Sensor (Left) (22) | Under driver's seat. (Scheme 150) |
| Front Seat Temperature Sensor (Right) (17) | Under front passenger's seat. (Scheme 150) |
| Fuel Gauge Sender | Inside left side of fuel tank. (Scheme 84) |
| Fuel Level Sensor No. 2 | Inside right side of fuel tank. (Scheme 33) |
| Fuel Pressure Sensor (4.2L) (11) | Top front of engine. (Scheme 143) |
| Fuel Pressure Sensor (5.2L) (15) | Top front of engine. (Scheme 182) |
| Fuel Supply Sensor 3 | Inside left side of fuel tank. (Scheme 34) |
| Fuel Supply Sensor 4 | Inside right side of fuel tank. (Scheme 35) |
| Heated Oxygen Sensor (HO2S) 2 W/Oxygen Sensor (O2S) 2 Heater (2) | Upstream of exhaust catalytic converter. (Scheme 187) |
| Heated Oxygen Sensor (HO2S) 2 W/Oxygen Sensor (O2S) 4 Heater (1) | Upstream of exhaust catalytic converter. (Scheme 187) |
| Heated Oxygen Sensor (HO2S) 2 (4.2L) (1) | Upstream of left 3-way catalytic converter. (Scheme 148) |
| Heated Oxygen Sensor (HO2S) 2 (6.0L) (2.1) | Upstream of exhaust bank No. 2 catalytic converter. (Scheme 142) |
| Heated Oxygen Sensor (HO2S) 3 (5.2L) (1) | Downstream of 3-way catalytic converter. (Scheme 188) |
| Heated Oxygen Sensor (HO2S) 3 (6.0L) (3.1) | Upstream of exhaust bank No. 3 catalytic converter. (Scheme 142) |
| Heated Oxygen Sensor (HO2S) (4.2L) (2) | Upstream of right 3-way catalytic converter. (Scheme 147) |
| Heated Oxygen Sensor (HO2S) 4 (6.0L) (4.1) | Upstream of exhaust bank No. 4 catalytic converter. (Scheme 142) |
| Heated Oxygen Sensor (HO2S) (5.2L) (4) | Downstream of 3-way catalytic converter. (Scheme 188) |
| Heated Oxygen Sensor (HO2S) (6.0L) (1.1) | Upstream of exhaust bank No. 1 catalytic converter. (Scheme 142) |
| Heated Steering Wheel Sensor | In steering wheel. |
| Humidity Sensor (5) | In interior rearview mirror mount. (Scheme 149) |
| Instrument Panel Interior Temperature Sensor (15) | Front of center console. (Scheme 149) |
| Intake Air Temperature (IAT) Sensor (Bank 1) (6.0L) (12) | Left front of engine compartment. (Scheme 140) |
| Intake Air Temperature (IAT) Sensor 2 (Bank 2) (6.0L) (1) | Right front of engine compartment. (Scheme 140) |
| Intake Air Temperature (IAT) Sensor (4.2L) (5) | Rear of cylinder bank No. 1. (Scheme 143) |
| Intake Manifold Runner Position Sensor 2 (4.2L) (6) | Front of cylinder bank No. 2. (Scheme 145) |
| Intake Manifold Runner Position Sensor 2 (5.2L) (5) | Front of cylinder bank No. 2. (Scheme 186) |
| Intake Manifold Runner Position Sensor (4.2L) (3) | Front of cylinder bank No. 1. (Scheme 145) |
| Intake Manifold Runner Position Sensor (5.2L) (1) | Front of cylinder bank No. 1. (Scheme 186) |
| Knock Sensor No. 1 (4.2L) (13) | Inner side of cylinder bank No. 1. (Scheme 143) |
| Knock Sensor No. 1 (5.2L) (12) | Inner side of cylinder bank No. 1. (Scheme 181) |
| Knock Sensor No. 1 (6.0L) | Right front of engine crankcase. |
| Knock Sensor No. 2 (4.2L) (10) | Inner side of cylinder bank No. 1. (Scheme 143) |
| Knock Sensor No. 2 (5.2L) (11) | Inner side of cylinder bank No. 1. (Scheme 181) |
| Knock Sensor No. 2 (6.0L) | Right side of engine crankcase. |
| Knock Sensor No. 3 (4.2L) (14) | Inner side of cylinder bank No. 2. (Scheme 144) |
| Knock Sensor No. 3 (5.2L) (13) | Inner side of cylinder bank No. 2. (Scheme 182) |
| Knock Sensor No. 3 (6.0L) | Left side of engine crankcase. |
| Knock Sensor No. 4 (4.2L) (15) | Inner side of cylinder bank No. 2. (Scheme 144) |
| Knock Sensor No. 4 (5.2L) (14) | Inner side of cylinder bank No. 2. (Scheme 182) |
| Knock Sensor No. 4 (6.0L) | Left side of engine crankcase. |
| Level Control Pressure Sensor | Behind left wheelwell liner at "A" pillar. (Scheme 50) |
| Level Control System Sensor (Left Front) | At left side of front axle. (Scheme 43) |
| Level Control System Sensor (Left Rear) | At left side of rear axle. (Scheme 47) |
| Level Control System Sensor (Right Front) | At right side of front axle. (Scheme 74) |
| Level Control System Sensor (Right Rear) | At right side of rear axle. (Scheme 78) |
| Light Recognition Sensor | Top center of windshield. (Scheme 171) |
| Low Fuel Pressure Sensor (4.2L) (2) | Top of cylinder bank No. 2. (Scheme 146) |
| Low Fuel Pressure Sensor (5.2L) (1) | Top rear of cylinder bank No. 1. (Scheme 185) |
| Mass Airflow (MAF) Sensor (Bank 1) (6.0L) (12) | Left front of engine compartment. (Scheme 140) |
| Mass Airflow (MAF) Sensor/Intake Air Temperature (IAT) Sensor (5.2L) (19) | Right front of engine compartment. (Scheme 181) |
| Mass Airflow (MAF) Sensor 2 (Bank 2) (6.0L) (1) | Right front of engine compartment. (Scheme 140) |
| Mass Airflow (MAF) Sensor 2 (5.2L) (7) | Left front of engine compartment. (Scheme 182) |
| Mass Airflow (MAF) Sensor (4.2L) (5) | Rear of cylinder bank No. 1. (Scheme 143) |
| Oil Level Thermal Sensor | Bottom of engine oil pan. (Scheme 59) |
| Outside Air Temperature Sensor | Behind right side of front bumper. (Scheme 61) |
| Oxygen Sensor (O2S) 2 (4.2L) (2) | Downstream of left 3-way catalytic converter. (Scheme 148) |
| Oxygen Sensor (O2S) 2 (5.2L) (3) | Downstream of 3-Way Catalytic Converter (TWC). (Scheme 188) |
| Oxygen Sensor (O2S) 3 (5.2L) | Downstream of 3-Way Catalytic Converter (TWC). (Scheme 189) |
| Oxygen Sensor (O2S) (4.2L) (1) | Downstream of right 3-way catalytic converter. (Scheme 147) |
| Oxygen Sensor (O2S) 4 (5.2L) (2) | Downstream of 3-Way Catalytic Converter (TWC). (Scheme 188) |
| Oxygen Sensor (O2S) (5.2L) | Downstream of 3-Way Catalytic Converter (TWC). (Scheme 189) |
| Oxygen Sensor (O2S) (6.0L) (1.2) | Downstream of exhaust bank No. 1 catalytic converter. (Scheme 142) |
| Oxygen Sensor (O2S) (6.0L) (2.2) | Downstream of exhaust bank No. 2 catalytic converter. (Scheme 142) |
| Oxygen Sensor (O2S) (6.0L) (3.2) | Downstream of exhaust bank No. 3 catalytic converter. (Scheme 142) |
| Oxygen Sensor (O2S) (6.0L) (4.2) | Downstream of exhaust bank No. 4 catalytic converter. (Scheme 142) |
| Rear Center Console Temperature Sensor (Left/Right) (24, 25) | Under rear of center console. (Scheme 150) |
| Rear Parking Sensor (4) | Behind rear bumper. (Scheme 178) |
| Rear Parking Sensor (4) | In rear bumper. (Scheme 111) |
| Rear Warm/Cold Flap Outlet Motor Position Sensor (Left) (23) | Integral to left rear warm/cold flap outlet motor. (Scheme 150) |
| Rear Warm/Cold Flap Outlet Motor Position Sensor (Right) (18) | Integral to right rear warm/cold flap outlet motor. (Scheme 150) |
| Rotation Rate Sender | On front tunnel, under extension of center console. (Scheme 85) |
| Side Air Bag Crash Sensor (Driver's Side) | At left "B" pillar. (Scheme 21) |
| Side Air Bag Crash Sensor (Left Rear) | At bottom of left "C" pillar. (Scheme 48) |
| Side Air Bag Crash Sensor (Passenger's Side) | At right "B" pillar. (Scheme 22) |
| Side Air Bag Crash Sensor (Right Rear) | At bottom of right "C" pillar. (Scheme 79) |
| Steering Angle Sensor | Behind steering wheel. (Scheme 87) |
| Steering Column Axial Adjustment Sensor | On steering column. (Scheme 88) |
| Steering Column Vertical Adjustment Sensor | On steering column. (Scheme 89) |
| Sunlight Photo Sensor (8) | Under top center of dash. (Scheme 149) |
| Throttle Position Sensor | On accelerator pedal. (Scheme 91) |
| Tire Pressure Sensor (4) | In respective wheel rims. (Scheme 179) |
SENDING UNITS & SENSORS LOCATION
SOLENOIDS & SOLENOID VALVES
| Component | Location |
|---|---|
| Camshaft Adjustment Intake Valve 1 (6.0L) (2) | Rear of cylinder bank No. 1. (Scheme 141) |
| Camshaft Adjustment Valve 1 (Exhaust) (4.2L) (2) | Rear of cylinder bank No. 1. (Scheme 143) |
| Camshaft Adjustment Valve 1 (Exhaust) (5.2L) (3) | Rear of cylinder bank No. 1. (Scheme 181) |
| Camshaft Adjustment Valve 1 (Exhaust) (6.0L) (1) | Rear of cylinder bank No. 1. (Scheme 141) |
| Camshaft Adjustment Valve 1 (4.2L) (6) | Rear of cylinder bank No. 1. (Scheme 143) |
| Camshaft Adjustment Valve 1 (5.2L) (5) | Rear of cylinder bank No. 1. (Scheme 181) |
| Camshaft Adjustment Valve 2 (Exhaust) (4.2L) (7) | Rear of cylinder bank No. 2. (Scheme 144) |
| Camshaft Adjustment Valve 2 (Exhaust) (5.2L) (6) | Rear of cylinder bank No. 2. (Scheme 182) |
| Camshaft Adjustment Valve 2 (Exhaust) (6.0L) (6) | Rear of cylinder bank No. 2. (Scheme 141) |
| Camshaft Adjustment Valve 2 (4.2L) (6) | Rear of cylinder bank No. 2. (Scheme 144) |
| Camshaft Adjustment Valve 2 (5.2L) (5) | Rear of cylinder bank No. 2. (Scheme 182) |
| Camshaft Adjustment Valve 2 (6.0L) (4) | Rear of cylinder bank No. 2. (Scheme 141) |
| Dampening Adjustment Valve (Left/Right Front) | In respective front air spring damper assembly. (Scheme 163) |
| Dampening Adjustment Valve (Left/Right Rear) | In respective rear air spring damper assembly. (Scheme 164) |
| Electro-Hydraulic Engine Mount Solenoid Valve (Left) | Left side of engine compartment. (Scheme 41) |
| Electro-Hydraulic Engine Mount Solenoid Valve (Right) (4.2L) | Right front of engine. (Scheme 72) |
| Electro-Hydraulic Engine Mount Solenoid Valve (Right) (6.0L) (11) | Right front of engine. (Scheme 141) |
| Engine Coolant (EC) Switch-Off Valve | Right side of plenum chamber. (Scheme 32) |
| Evaporative Emission (EVAP) Canister Purge Solenoid Valve 2 (4) | Left rear of engine. (Scheme 144) |
| Evaporative Emission (EVAP) Canister Purge Solenoid Valve (4.2L) (4) | Left rear of engine. (Scheme 144) |
| Evaporative Emission (EVAP) Canister Purge Solenoid Valve (5.2L) (9) | Rear of engine. (Scheme 181) |
| Fuel Injectors No. 1 - 6 (6.0L) (9) | Top of cylinder bank No. 1. (Scheme 141) |
| Fuel Injectors No. 7 - 12 (6.0L) (8) | Top of cylinder bank No. 2. (Scheme 141) |
| Fuel Metering Valve 2 (4.2L) (4) | Top of cylinder bank No. 2. (Scheme 146) |
| Fuel Metering Valve 2 (5.2L) (10) | Top of cylinder bank No. 2. (Scheme 182) |
| Fuel Metering Valve (4.2L) (5) | Top of cylinder bank No. 1. (Scheme 146) |
| Fuel Metering Valve (5.2L) (15) | Top of cylinder bank No. 1. (Scheme 181) |
| Headlight Reflector Adjustment Solenoid (Left/Right) | At respective headlight assembly. (Scheme 167) |
| Intake Air Switch-Over Valve (4.2L) (20) | Right front of engine compartment. (Scheme 143) |
| Intake Air Switch-Over Valve (5.2L) (2) | Right front of engine compartment. (Scheme 181) |
| Level Control Accumulator Valve | Behind left wheelwell liner at "A" pillar. (Scheme 49) |
| MAP Controlled Engine Cooling Thermostat (6.0L) (3) | Center rear of engine. (Scheme 141) |
| Secondary Air Injection (AIR) Combi-Valve (Bank 1) (3) | Rear of cylinder bank No. 1. (Scheme 143) |
| Secondary Air Injection (AIR) Combi-Valve (Bank 2) (5) | Rear of cylinder bank No. 2. (Scheme 144) |
| Secondary Air Injection (AIR) Solenoid Valve (4) | Left front of engine. (Scheme 186) |
| Servotronic Solenoid Valve | On steering gear housing. (Scheme 86) |
SOLENOIDS & SOLENOID VALVES LOCATION
SWITCHES
| Component | Location |
|---|---|
| Display Closed Stop Switch | In center of dash. (Scheme 155) |
| Display Open Stop Switch | In center of dash. (Scheme 156) |
| Front Hood Switch | In left hood lock assembly. (Scheme 157) |
| Front Hood Switch 2 | In right hood lock assembly. (Scheme 158) |
| Fuel Tank Lock Switch | Top of fuel filler tube. (Scheme 36) |
| Kick Down Switch | Under accelerator pedal. (Scheme 39) |
| Oil Pressure Switch (6) | Lower left front of engine. (Scheme 186) |
| Rear Lid Closing Assist Lock Stop Switch | At trunk release motor. (Scheme 175) |
| Rear Lid Opening Assist Unlock Stop Switch | At trunk lid release motor. (Scheme 176) |
| Trunk Lid Alarm Switch | Inside trunk lid. (Scheme 95) |
| Trunk Lock/Alarm/Central Locking Switch | Inside trunk lid. (Scheme 97) |
SWITCHES LOCATION
MISCELLANEOUS
| Component | Location |
|---|---|
| Air Bag Igniter (Driver's) (1) | In steering wheel. (Scheme 152) |
| Air Bag Igniter (Front Passenger's) (4) | Above glove box. (Scheme 152) |
| Airbag Spiral Spring | At steering column switch module (SCSM). (Scheme 151) |
| Air Bag Unit (Driver's Side) (1) | In steering wheel. (Scheme 152) |
| Air Bag Unit (Front Passenger's Side) (4) | Above glove box. (Scheme 152) |
| Alarm Horn | Right side of plenum chamber. (Scheme 7) |
| Antenna Amplifier | Behind left rear edge of roof trim. (Scheme 105) |
| Antenna For Navigation System | Behind center rear edge of roof trim. (Scheme 103) |
| Antenna For Telephone | Behind right rear edge of roof trim. (Scheme 102) |
| Antenna For Tire Pressure Check (Left Front) | Left front wheel well. (Scheme 8) |
| Antenna For Tire Pressure Check (Left Rear) | Left rear wheel well. (Scheme 10) |
| Antenna For Tire Pressure Check (Right Front) | Right front wheel well. (Scheme 9) |
| Antenna For Tire Pressure Check (Right Rear) | Right rear wheel well. (Scheme 11) |
| Auxiliary Antenna (Telematic) | In rear bumper. (Scheme 111) |
| Auxiliary Heater Radio Receiver | On left rear wheelhouse. (Scheme 110) |
| Data Bus On Board Diagnostic Interface | Behind glove compartment. (Scheme 23) |
| Data Link Connector (DLC) | Under left side of dash. (Scheme 1) |
| Door Ambient Lighting Voltage Converter (Driver's) | Inside left front door. (Scheme 29) |
| Door Ambient Lighting Voltage Converter (Left Rear) | Inside left rear door. (Scheme 46) |
| Door Ambient Lighting Voltage Converter (Passenger's) | Inside right front door. (Scheme 62) |
| Door Ambient Lighting Voltage Converter (Right Rear) | Inside right rear door. (Scheme 77) |
| Headlight Power Output Stage (Left/Right) | At respective headlight assembly. (Scheme 166) |
| Ignition Coils W/Power Output Stage No. 1 - 4 (4.2L) (18) | Top of cylinder bank No. 1. (Scheme 143) |
| Ignition Coils W/Power Output Stage No. 1 - 4 (5.2L) (16) | Top of cylinder bank No. 1. (Scheme 181) |
| Ignition Coils W/Power Output Stage No. 1 - 6 (6.0L) (10) | Top of cylinder bank No. 1. (Scheme 141) |
| Ignition Coils W/Power Output Stage No. 5 - 8 (4.2L) (9) | Top of cylinder bank No. 2. (Scheme 144) |
| Ignition Coils W/Power Output Stage No. 5 - 8 (5.2L) (9) | Top of cylinder bank No. 2. (Scheme 182) |
| Ignition Coils W/Power Output Stage No. 7 - 12 (6.0L) (7) | Top of cylinder bank No. 2. (Scheme 141) |
| Knee Air Bag (Driver) (12) | Under left side of dash. (Scheme 152) |
| Knee Air Bag (Front Passenger) (3) | Behind glove box. (Scheme 152) |
| Microphone Units 1, 4 & 5 | In front roof module. (Scheme 101) |
| Radio Frequency Controlled Clock Receiver | In rear bumper. (Scheme 111) |
| Rear Footwell Heater (Left) (21) | Under driver's seat. (Scheme 150) |
| Rear Footwell Heater (Right) (16) | Under front passenger's seat. (Scheme 150) |
| Satellite Radio (6) | Left side of luggage compartment. (Scheme 192) |
| Side Air Bag Igniter (Driver's/Front Passenger's) (8) | In respective outer side of front seat cushions. (Scheme 152) |
| Side Air Bag Igniter (Rear Left/Right Passenger's) (9) | In respective outer side of rear seat cushions. (Scheme 152) |
| Side Air Bag Unit (Driver's/Front Passenger's) (7) | In respective outer side of front seat backrests. (Scheme 152) |
| Side Air Bag Unit (Rear Left/Right Passenger's) (10) | In respective outer side of rear seat backrests. (Scheme 152) |
| TV Tuner (2) | Left side of luggage compartment. (Scheme 192) |
MISCELLANEOUS LOCATION
CONNECTORS
| Component | Location |
|---|---|
| T16 (16 Pin) | Under left side of dash. (Scheme 1) |
| T17a (Black, 17 Pin) (A) | On E-box plenum chamber connector station. (Scheme 193) |
| T17b (Green, 17 Pin) (E) | On E-box plenum chamber connector station. (Scheme 193) |
| T17c (Brown, 17 Pin) (B) | On E-box plenum chamber connector station. (Scheme 193) |
| T17d (Blue, 17 Pin) (C) | On E-box plenum chamber connector station. (Scheme 193) |
| T17e (Red, 17 Pin) (D) | On E-box plenum chamber connector station. (Scheme 193) |
| T46b (Black, 46 Pin) | Right end of dash. (Scheme 3) |
| T46 (Black, 46 Pin) | Left end of dash. (Scheme 2) |
CONNECTORS LOCATION
GROUNDS
| Component | Location |
|---|---|
| G12 | Left front chassis member, forward of front axle. (Scheme 117) |
| G13 | Right front chassis member, forward of front axle. (Scheme 118) |
| G34 | Under driver's seat. (Scheme 134) |
| G35 | Under front passenger's seat. (Scheme 122) |
| G43 | Behind right kick panel. (Scheme 121) |
| G44 | Behind left kick panel. (Scheme 135) |
| G50 | Left rear of luggage compartment. (Scheme 130) |
| G51 | Right rear of luggage compartment. (Scheme 126) |
| G606 | Under center console at shifter. (Scheme 136) |
| G610 | Left front of center tunnel. (Scheme 137) |
| G613 | Left side of luggage compartment. (Scheme 131) |
| G640 | Right front of engine compartment. (Scheme 119) |
| G653 | On left "D" pillar. (Scheme 133) |
| G654 | Behind rear seat center backrest. (Scheme 123) |
| G657 | Top of left "D" pillar. (Scheme 128) |
| G658 | Top of left "D" pillar. (Scheme 129) |
| G659 | On right "D" pillar. (Scheme 124) |
| G667 | Left rear of roof. (Scheme 127) |
| G675 | Right side of luggage compartment. (Scheme 125) |
| G676 | Left side of luggage compartment. (Scheme 132) |
| G706 | On auxiliary heat exchanger. (Scheme 120) |
GROUNDS LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
