Engine Controls - Service & Adjustment Specifications Audi S8 D2 рестайлинг 2

Specifications 4 illustrations ~336 words

INTRODUCTION

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This article may be used for quick reference when you are familiar with proper adjustment procedures and only need a specification.

CAPACITIES

CAUTIONWhen battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle.
ApplicationQuantity
Crankcase (Includes Filter) (1)
A8 & S8
4.2L8.0 Qts. (7.5L)
TT
1.8L Turbo4.8 Qts. (4.5L)
Cooling System (Includes Heater) (2)
A8 & S8
4.2L11.6 Qts. (11.0L)
TT
1.8L Turbo7.4 Qts. (7.0L)
Automatic Transmission
Initial Fill
A8 (01L - AWD) (3)10.4 Qts. (9.8L)
TT (09G - FWD) (3)7.4 Qts. (7.0L)
Fluid Change
A8 (01L - AWD) (3)3.7-4.2 Qts. (3.5-4.0L)
TT (09G - FWD)(4)
Final Drive (Differential)
Front Differential
Initial Fill
A8 (01L - AWD) (3)1.4 Qt. (1.3L)
TT (09G - FWD) (3)1.05 Qt. (1.0L)
Fluid Change (4)
Center Differential (SAE 75W-90 Synthetic Oil)
Initial Fill
A8 (01L - AWD) (3).93 Qt. (.88L)
Fluid Change (4)
Rear Differential
Initial Fill
A8 (01L - AWD) (3)1.6 Qts. (1.5L)
TT (09G - AWD) (3)2.75 Qts. (2.6L)
TT (02M - AWD) (3)1.05 Qts. (1.0L)
Fluid Change (4)
Manual Transmission
TT
Initial Fill
02J (5 Spd - FWD) (3)2.10 Qts. (2.0L)
02M (5 & 6 Spd - AWD) (3)2.75 Qts. (2.6L)
Haldex Clutch Unit (5)
Initial Fill14.2 ozs. (.42L)
Fluid Change8.5 ozs. (.25L)
(1) To prevent overfilling, add approximately 1/2 qt. less than capacity. Start engine. Run until operating temperature is reached. Turn ignition off. Wait about 3 minutes. Check oil level. Fill to FULL mark on dipstick. Additional oil may be more or less than 1/2 quart. (2) Only use coolant G 12, meeting specification TL VW 774 D. Identifiable by Red color. (3) Use SAE 75W-90 synthetic oil. (4) Fluid change is not recommended by manufacturer. (5) Use high performance oil for Haldex coupling part No. G 052 175 A1.
(1)To prevent overfilling, add approximately 1/2 qt. less than capacity. Start engine. Run until operating temperature is reached. Turn ignition off. Wait about 3 minutes. Check oil level. Fill to FULL mark on dipstick. Additional oil may be more or less than 1/2 quart.
(2)Only use coolant G 12, meeting specification TL VW 774 D. Identifiable by Red color.
(3)Use SAE 75W-90 synthetic oil.
(4)Fluid change is not recommended by manufacturer.
(5)Use high performance oil for Haldex coupling part No. G 052 175 A1.

FLUID CAPACITIES

SERVICE INTERVALS & SPECIFICATIONS

Component (1)Miles (Km)
Accessory Drive Belt
1.8L Turbo (TT)96,300 (155,000)
2.7L BiTurbo74,500 (120,000)
3.0L96,300 (155,000)
4.2L74,500 (120,000)
Air Filter (All Models)37,500 (60,000)
Automatic Transmission Fluid
Normal Service(2)
Severe Service(3)
Brake FluidEvery 2 Years
Dust & Pollen Filter (All Models)18,600 (30,000)
Haldex Clutch Oil & Filter (TT)18,600 (30,000)
Timing Belt (All Models) (4)96,300 (155,000)
Coolant(5)
Fuel Filter(6)
Oil & Filter6200 (10,000)
Spark Plugs37,200 (60,000)
(1) See FLUID CAPACITIES table for fluid type. (2) Check fluid every 15,000 miles. (3) Replace fluid every 30,000 miles. (4) On 2.7 BiTurbo replace idler pulley and tensioner each time timing belt is replaced. (5) Coolant system is permanently filled. If necessary to add coolant, only use coolant G 12, meeting specification TL VW 774 D. Identifiable by Red color. (6) Information is not available.
(1)See FLUID CAPACITIES table for fluid type.
(2)Check fluid every 15,000 miles.
(3)Replace fluid every 30,000 miles.
(4)On 2.7 BiTurbo replace idler pulley and tensioner each time timing belt is replaced.
(5)Coolant system is permanently filled. If necessary to add coolant, only use coolant G 12, meeting specification TL VW 774 D. Identifiable by Red color.
(6)Information is not available.

REPLACEMENT INTERVALS

ACCESSORY DRIVE BELT INSPECTION

Removing and installing accessory drive belt is an in-depth procedure. Visually inspect accessory drive belt while installed on engine. Ensure belt has no splits, cracks or other damage. If necessary to remove and replace accessory drive belt, see ACCESSORY DRIVE BELTS article in ENGINES.

Accessory drive belt is adjusted automatically by self adjusting tensioner.

ENGINE COMPRESSION

ApplicationSpecification
Compression Pressure
1.8L Turbo (TT)
Normal145- 189 psi (10.0-13.0 bar)
Minimum102 psi (7.0 bar)
Maximum Variation Between Cylinders44 psi (3.0 bar)
2.7L Turbo
Normal131-189 psi (9.0-13.0 bar)
Minimum102 psi (7.0 bar)
Maximum Variation Between Cylinders44 psi (3.0 bar)
3.0L
Normal145-203 psi (10.0-14.0 bar)
Minimum109 psi (7.5 bar)
Maximum Variation Between Cylinders44 psi (3.0 bar)
4.2L
Normal145-217 psi (10.0-15.0 bar)
Minimum109 psi (7.5 bar)
Maximum Variation Between Cylinders44 psi (3.0 bar)
(1) When checking compression, ensure engine oil temperature is not less than 86°F (30°C). Throttle valve should be fully open during compression check.
(1)When checking compression, ensure engine oil temperature is not less than 86°F (30°C). Throttle valve should be fully open during compression check.

ENGINE COMPRESSION SPECIFICATIONS (1)

VALVE CLEARANCE

Note. All models are equipped with hydraulic lifters. No adjustments are required.

IGNITION COIL(S)

Note. Information on ignition coil resistance was not available from manufacturer.

HIGH TENSION WIRE RESISTANCE

ComponentOhms
2.7L
Spark Plug Connector2000

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

Note. On all models, torque spark plugs to 22 ft. lbs. (30 N.m). Information on spark plug type or gap was not available from manufacturer.

FIRING ORDER

Note. For firing order, refer to appropriate illustration.

Scheme 1

Scheme 1: FIRING ORDER

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

IGNITION TIMING

Note. Idle speed, ignition timing and ignition timing advance are controlled by the ECM and are not adjustable.

FUEL PUMP

ApplicationSpecification
System Pressure
With Engine Idling (1)44 psi (3.0 bar)
With Engine Idling (2)36 psi (2.5 bar)
Residual Pressure (3)22-36 psi (1.5 bar)
Min. Vol. In 30 Sec.
Engine Code AMU5.6-6.2 ozs. (165-183 ml.)
Engine Codes ATC & AWP4.5-5.3 ozs. (133-157 ml.)
(1) With fuel pressure regulator vacuum hose disconnected. (2) With fuel pressure regulator vacuum hose connected. (3) After 10 minutes.
(1)With fuel pressure regulator vacuum hose disconnected.
(2)With fuel pressure regulator vacuum hose connected.
(3)After 10 minutes.

FUEL PUMP PERFORMANCE (1.8L - TT)

ApplicationSpecification
System Pressure
With Engine Idling (1)46-55 psi (3.2-3.8 bar)
With Engine Idling (2)55-61 psi (3.8-4.2 bar)
Residual Pressure
Cold Engine (3)32 psi (2.2 bar)
Warm Engine (3)44 psi (3.0 bar)
Min. Vol. In 30 Sec.3.0-4.2 ozs. (90-125 ml.)
(1) With fuel pressure regulator vacuum hose connected. (2) With fuel pressure regulator vacuum hose disconnected. (3) After 10 minutes.
(1)With fuel pressure regulator vacuum hose connected.
(2)With fuel pressure regulator vacuum hose disconnected.
(3)After 10 minutes.

FUEL PUMP PERFORMANCE (3.0L)

ApplicationSpecification
System Pressure
With Engine Idling (1)50 psi (3.5 bar)
With Engine Idling (2)58 psi (4.0 bar)
Residual Pressure (3)36 psi (2.5 bar)
Min. Vol. In 30 Sec.3.2-3.9 ozs. (95-115 ml.)
(1) With fuel pressure regulator vacuum hose connected. (2) With fuel pressure regulator vacuum hose disconnected. (3) After 10 minutes.
(1)With fuel pressure regulator vacuum hose connected.
(2)With fuel pressure regulator vacuum hose disconnected.
(3)After 10 minutes.

FUEL PUMP PERFORMANCE (4.2L)

FUEL INJECTOR RESISTANCE

Application (1)Ohms
1.8L(2) 12-13
2.7L & 3.0L(2) 13.5-15.5
4.2L(2) 13-16
(1) Measured at room temperature. (2) Add 4-6 ohms if fuel injector is at operating temperature.
(1)Measured at room temperature.
(2)Add 4-6 ohms if fuel injector is at operating temperature.

FUEL INJECTOR RESISTANCE

IDLE SPEED & MIXTURE

Note. Idle speed and air mixture is controlled by the ECM and are not adjustable. When engine is idling the ECM tries constantly to adjust actual engine speed so that it matches specified value. This means that the actual engine speed when idling should always be approximately the same as the specified engine speed.

THROTTLE POSITION SENSOR

Note. Throttle Position (TP) sensor is integral to Throttle Valve Control Module (TVCM) and is not adjustable. For testing procedures, see TVCM related testing procedure in SELF-DIAGNOSTICS or SYSTEM & COMPONENT TESTING article.
