Check control module version Audi S8 D2 рестайлинг 2

On Board Diagnostic (OBD) - Abs/edl/asr 3 illustrations ~172 words

Check control module version

  1. Connect Scan tool V.A.G 1551 and select "Brake electronics" with address word 03, see «VAG1551 SCAN TOOL (ST), CONNECTING AND ENTERING ADDRESS WORD»(/audi/s8/d2-2-2002-2003/remont/warning-system/#on-board-diagnostic-obd-absedlasr__vag1551-scan-tool-st-connecting-and) .
  2. Go back to the initial settings of the program by pressing the --> button

Indicated on display

Scheme 35

Scheme 35
Scheme 35
  1. Press buttons -0- and -1- for the function "Check control module version" and confirm entry with -Q-button.

Note. The control module version can only be altered by installing a new control module. Also refer to the Parts List for the correct ABS Control Module (w/EDL) -J104- for the vehicle.

Indicated on display

Scheme 36

Scheme 36
Scheme 36

Code is only shown for vehicles with traction control system (ASR). Encode control module, see ENCODE CONTROL MODULE .

The workshop code, WSC XXXXX, identifies the workshop which performed the last coding of the control module.

  1. Control module index
  2. System designation
  3. Hardware and software status
System designationProd. no. (1)Control module part no.IndexEncodingData transfer via.Notes
FWD; ABS, Bosch 5.31AH4D0 907 379GNot encodableSeparate wiresEDL suction-side control; control module with rough-rod information for On-Board Diagnostics (USA)
4D0 907 379PNot encodableSeparate wiresEDL suction-side control; control module with speed sensor outputs for navigation system.
FWD; ABS/EDL/ASR, Bosech 5.31AJ4D0 907 379MEncodable, see ENCODE CONTROL MODULESeparate wiresEDL-suction side control
4D0 907 379NEncodable, see ENCODE CONTROL MODULESeparate wiresEDL-suction side control
(1) This letter combination is the production number which is allocated to each equipment variation. Production number can also be found on vehicle data sticker. The sticker is in the spare wheel well.
(1)This letter combination is the production number which is allocated to each equipment variation. Production number can also be found on vehicle data sticker. The sticker is in the spare wheel well.

CONTROL MODULE VERSIONS - 1 OF 2

System designationProd. no. (1) )Control module part no.IndexEncodingData transfer viaNotes
4WD; ABS/EDL Bosch 5.31AH4D0 907 379CNot encodableSeparate wiresEDL pressure-side control; control module with wheel speed sensor outputs for automatic transmission and rough-road information for On Board Diagnostics
4D0 907 379JNot encodableSeparate wiresEDL pressure-side control; control module with wheel speed sensor outputs for automatic transmission and rough-road information for On Board Diagnostics
4D0 907 379FNot encodableSeparate wiresEDL-pressure-side control
4D0 907 379KNot encodableSeparate wiresEDL-suction side control
4D0 907 379LNot encodableSeparate wiresEDL suction-side control; control module with wheel speed sensor outputs for automatic transmission and rough-road information for On Board Diagnostics
(1) This letter combination is the production number which is allocated to each equipment variation. Production number can also be found on vehicle data sticker. The sticker is in the spare wheel well.
(1)This letter combination is the production number which is allocated to each equipment variation. Production number can also be found on vehicle data sticker. The sticker is in the spare wheel well.

CONTROL MODULE VERSION - 2 OF 2

Scheme 37

Scheme 37
Scheme 37
  1. Press --> button. Indicated on display
