Installation Audi S6 C5

Suspension - Rear, Awd 6 illustrations ~184 words

Installation

  1. To install, reverse removal procedure. Always use NEW nuts and bolts. Torque fasteners to specification. Bolted connections in rubber bushings should only be torqued to specification once vehicle is resting on its own weight. See «TORQUE SPECIFICATIONS»(/audi/s6/c5-1999-2004/remont/suspension-rear/#suspension-rear-awd__torque-specifications) .
  2. After installation, position of steering wheel must be checked with a road test. If the steering wheel is crooked, an axle alignment must be performed! Check wheel alignment after servicing. See «PROCEDURES & SPECIFICATIONS»(/audi/s6/c5-1999-2004/remont/wheel-alignment/#specifications-procedures) article in WHEEL ALIGNMENT.

Scheme 9

Scheme 9: REAR FINAL DRIVE MOUNT BUSHINGS
Scheme 9: REAR FINAL DRIVE MOUNT BUSHINGS

Scheme 10

Scheme 10: Removal & Installation
Scheme 10: Removal & Installation

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. To replace crossmember bonded rubber bushings (Scheme 10)and. When pressing bushing in, position bonded rubber bushing so that one of the rubber knobs (1) is opposite the marking (arrow). (Scheme 10)
  2. Before removing bonded rubber bushing for final drive transmission support, use a felt-tip pen to mark installation position on transmission support (arrow A). (Scheme 12)
  3. To replace bonded rubber bushing for final drive transmission support (Scheme 13)and (Scheme 13). When installing bushing, position bonded rubber bushing so that one of the rubber knobs (arrow B) is opposite the marking (arrow A). (Scheme 10)
