Basic Setting (function 04) Audi S6 C5

On Board Diagnostic (OBD) - HVAC 3 illustrations ~188 words

Basic Setting (function 04)

Note. The air conditioning control changes with the 2001 to 2002 model year change. The climate control conversion on the Audi allroad does not occur with the 2001 to 2002 model year change, but instead changes in model year 2002.

  1. Connect VAG 1551 Scan Tool (ST),Press buttons -0- and -8- to insert "AC/Heating Electronics" address word 08 and advance program until "Select function XX" appears on display. See «ON BOARD DIAGNOSTIC (OBD), INITIATING»(/audi/s6/c5-1999-2004/remont/heated-glassdefoggers/#on-board-diagnostic-obd-hvac) .
  2. Switch printer on via the PRINT button (indicator lamp in button lights up).
  3. Check DTC memory. See «CHECK DTC MEMORY (FUNCTION 02)»(/audi/s6/c5-1999-2004/remont/heated-glassdefoggers/#on-board-diagnostic-obd-hvac) and eliminate all displayed malfunctions.
  4. Erase DTC memory. See «ERASE DTC MEMORY (FUNCTION 05) AND END OUTPUT (FUNCTION 06)»(/audi/s6/c5-1999-2004/remont/heated-glassdefoggers/#on-board-diagnostic-obd-hvac)
  5. Check coding. See «A/C CONTROL HEAD -E87-, CODING»(/audi/s6/c5-1999-2004/remont/heated-glassdefoggers/#on-board-diagnostic-obd-hvac__ac-control-head-e87-coding) and correct if necessary.

Indicated on display (function selection)

Scheme 98

Scheme 98
Scheme 98
  1. Press buttons -0- and -4- to select "Basic Setting" function 04.

Indicated on display

Scheme 99

Scheme 99
Scheme 99
  1. Press -Q- button to confirm input.

Indicated on display

Scheme 100

Scheme 100
Scheme 100
  1. Enter display group number "01" or "001" (depending on scan tool software level).
  2. Press -Q- button to confirm input.
