Implementing function "04 - Basic setting"

Indicated on display

Scheme 201

Scheme 201: Implementing function "04 - Basic setting"

Scheme 201: Implementing function "04 - Basic setting"

Press buttons -0- and -4-.

Indicated on display

Scheme 202

Scheme 202

Scheme 202

Confirm entry with -Q- button.

Indicated on display

Scheme 203

Scheme 203

Scheme 203

Press buttons -0-, -0- and -1-.

Indicated on display

Scheme 204

Scheme 204

Scheme 204

Confirm entry with -Q- button.

Indicated on display

Scheme 205

Scheme 205

Scheme 205

This concludes basic setting.
Press --> button.

Indicated on display

Scheme 206

Scheme 206

Scheme 206

Then check display value 4 in measuring value block 002. Display must show mean counter value (32767).
Check basic setting as follows
Move seat backrest to rear as far as it will go.
Press memory button and one of the personalized buttons (e. g. memory position 1).
Then press memory position button selected above (e.g.: 1) again with driver's door open. Backrest moves to rear stop, leaving a safety clearance with respect to rear seat bench (leg room for rear passenger).
