INTRODUCTION

Note. Before replacing any component that scan tool suggests are faulty. Ensure that all wiring connections and harness connectors are okay. Ensure that power and ground circuits are functioning properly. For circuit identification, see appropriate WIRING DIAGRAMS article for vehicle being tested.

BODY CONTROLS

Vehicles equipped with body, air conditioning, anti-lock brake or memory computers may require a computer relearn procedure after components are replaced or the vehicle battery is disconnected. Vehicle computers memorize and store vehicle information and operation selections. When the vehicle battery is disconnected, vehicle computer memory may be lost, requiring relearning or resetting. Depending on the vehicle and how it is equipped, the following memories may exist

1. Seat position.
2. Tilt/telescoping steering wheel position.
3. Mirror position.
4. Radio presets and anti-theft code.
5. Clock.
6. Remote keyless entry custom features.
7. Door key lock entry custom features.
8. Power window or sunroof operation.

These do not affect vehicle operation. For systems that do not affect operation, see appropriate article for relearn procedures. Other computer relearn procedures are required for vehicle or system operation. These may include

1. Initial control unit programming.
2. Traction control yaw sensor initializing.
3. Multiplex communication.
4. Anti-theft system or engine immobilizer system passwords.

ENGINE CONTROLS

Vehicles equipped with powertrain control computers may require a computer relearn procedure after the vehicle battery is disconnected. Vehicle computers memorize and store vehicle operation patterns for optimum driveability and performance. When the vehicle battery is disconnected, this memory is lost, which may result in a driveability problem. Depending on the vehicle and how it is equipped, the following driveability problems may exist

1. Rough or unstable idle.
2. Hesitation or stumble.
3. Rich or lean running.
4. Poor fuel mileage.
5. Harsh or poor transmission/transaxle shift quality.

Default data is used until NEW data from each key start is stored. As the computer restores its memory from each new key start, driveability is restored.

Driveability problems may occur during the computer relearn stage. To accelerate computer relearn process after battery removal and installation, specified computer relearn procedures should be performed. See appropriate procedures for specified manufacturer.

POWERTRAIN CONTROL MODULE RESET PROCEDURE/CLEARING DIAGNOSTIC TROUBLE CODES (ALL MODELS)

Note. Some models have an anti-theft code built into radio circuit. Clearing codes cancels clock and radio settings; make note of anti-theft code and station presets before beginning reset procedure. After PCM reset, radio will not operate until anti-theft code is entered.

Note. If service check connector is connected and no DTC is stored in PCM, MIL will remain on when the ignition is turned on.

To reset Powertrain Control Module (PCM) (clear DTCs), use Honda PGM tester or OBD-II scan tool following manufacturer's instructions. After DTCs are cleared and PCM is reset, remove SCS service connector, if connected. Disconnect Honda PGM Tester or scan tool from DLC. DTCs can also be cleared by turning ignition off and removing BACK UP (RADIO) fuse (7.5-amp) from underhood fuse/relay block (located next to battery). On all models, leave fuse out for at least 10 seconds to reset PCM.

KNOWN-GOOD POWERTRAIN CONTROL MODULE SUBSTITUTION

Note. Use this procedure when diagnostic testing suggests substituting PCM with known-good unit.

On models equipped with engine immobilizer system, acquire key cut from non-immobilizer key blank. Remove PCM from test vehicle. Install known-good PCM from donor vehicle into test vehicle. Tape donor vehicle's ignition key head-to-head to test vehicles temporary key. PCM will recognize code from donor vehicle's key and allow test vehicle to be started and tested.

SYSTEM READINESS TEST CODES

If battery has been disconnected, DTCs have been cleared or PCM has been reset, readiness codes will reset. In some states part of emission testing is to ensure readiness codes are complete. If readiness codes are not complete, emission test cannot be finished.

To check if readiness codes are complete, turn ignition switch on, engine off. MIL will illuminate for 15-20 seconds. If MIL goes off, readiness codes are complete. If MIL blinks several times, one or more readiness codes are not complete.

To set each code, drive vehicle or run engine as described in following procedures.

Catalytic Converter Codes

Note. Once test is started DO NOT turn ignition switch off. When negative battery cable is disconnected, all readiness codes are cleared. When PCM is cleared with scan tool, all readiness codes are cleared.

For test purposes ensure ambient temperature is 20-95°F (-7-35°C).

1. Connect scan tool to DLC. Start engine and hold at 3000 RPM with no load until radiator fan comes on.
2. Drive vehicle for about 10 minutes, without stopping. Preferably on highway where speed can be varied.
3. With A/T in "D" position, M/T in 5th gear, drive at steady speed between 50 and 62 MPH for 30 seconds.
4. Repeat step 4 three times. Between each repetition, close throttle completely for 1-2 seconds. If engine is stalls or is shut off during this part of procedure, repeat procedure starting in step 2 .
5. Readiness code should now be set. Use scan tool to check readiness code.

EVAP Leak Monitor Code

Note. When negative battery cable is disconnected, all readiness codes are cleared. When PCM is cleared with scan tool, all readiness codes are cleared. If engine is stalls or is shut off between steps 6 - 16 , repeat procedure again.

1. Ensure fuel level is between 60 and 90 percent of fuel tank capacity (not full).
2. Turn ignition switch off.
3. Let vehicle set for more than 8 hours.
4. Ensure outside temperature is 20-95°F (-7-35°C)
5. Connect scan tool to DLC.
6. Start engine and drive for about 20 minutes.
7. Maintain vehicle at steady speed between 50 and 70 MPH, without moving accelerator pedal, for about one minute.
8. Bring vehicle to a stop. Leave engine running at idle speed.
9. Repeat steps 7 and 8 two more times.
10. Using scan tool, check readiness code. If readiness code is not complete go to next step.
11. When ambient temperature is less than 32°F (0°C), hold engine speed at 3,000 RPM with no load (in park or neutral) until radiator fan comes on.
12. When ambient temperature is more than 86°F (30°C), remove and install gas cap.
13. Drive vehicle on highway for about 20 minutes.
14. Maintain vehicle at steady speed between 50 and 70 MPH, without moving accelerator pedal, for about one minute.
15. Bring vehicle to a stop. Leave engine running at idle speed.
16. Repeat steps 14 and 15 two more times.
17. Readiness code should now be set. Use scan tool to check readiness code.

HO2S Monitor Code

Note. Once test is started DO NOT turn ignition switch off. When negative battery cable is disconnected, all readiness codes are cleared.

Ensure ambient temperature is 20-95°F (-7-35°C).

1. Connect scan tool to DLC.
2. Start engine and hold at 3000 RPM with no load (in park or neutral) until radiator fan comes on.
3. Let engine idle for 5 seconds.
4. Drive vehicle at steady speed between 50 and 62 MPH for about two minutes
5. With A/T in "D" position, M/T in 5th gear, decelerate from 62 MPH by completely releasing throttle for 5 seconds.
6. Bring vehicle to a stop. Leave engine running at idle speed. If engine is stalls or is shut off during this part of procedure, repeat procedure starting in step 4 .
7. Readiness code should now be set. Use scan tool to check readiness code.

HO2S Heater Monitor Code

Note. Once test is started DO NOT turn ignition switch off. When negative battery cable is disconnected, all readiness codes are cleared.

1. Connect scan tool to DLC.
2. Start engine and let idle for 10 minutes.
3. Readiness code should now be set. Use scan tool to check readiness code.

READINESS CODE

Note. While limited diagnostic information is available, vehicle manufacturer does not support diagnostic information using aftermarket scan tools. To properly diagnose vehicle, it is recommended to use VAS 5051 scan tool with VAS 5051/1 adapter cable or VAG 1551 scan tool with 1551/3A adapter cable and VAG 1598/31 test box.

Readiness code must be generated when Engine Control Module (ECM) memory is cleared, battery voltage or ECM is disconnected. Readiness code appears on scan tool as an 8-digit display in display field 1 of MEASURING VALUE BLOCK - 086. Each of the 8 digits is related to a specific exhaust related system. During a test sequence OBD system checks function of each of the 8 systems. Test sequence once started must be run completely. During test sequence if test is successful scan tool changes display digits from "1" to "0". When readiness code is generated, display should read 0 0 0 0 0 0 0 0 in display field 1 of measuring value block 086. If during testing, a malfunction is recognized, a DTC is stored in memory. Retrieve DTCs and repair as necessary. See RETRIEVING DIAGNOSTIC TROUBLE CODES under SELF-DIAGNOSTICS SYSTEM in appropriate SELF DIAGNOSTICS article.

Readiness code is returned to 1 1 1 1 1 1 1 1 if DTC memory is erased, voltage supply to ECM is lost, or a new ECM is installed. To check readiness code, connect VAS 5051 or equivalent scan tool to DLC. DLC is located behind cover under left side of steering column. Turn ignition on. Using scan tool, select vehicle system 01 - ENGINE ELECTRONICS. From selection 1, select diagnostic function 08 - READ MEASURED VALUE BLOCK. From button field 2, enter 086 for DISPLAY GROUP - 086. Press "Q" button to confirm input. Using scan tool, observe display field 1 in display group 086. (Scheme 1)and (Scheme 2). Readiness code should display 0 0 0 0 0 0 0 0 0. If readiness code displays as specified, continue DTC testing. If no DTCs are stored testing is complete. If readiness code does not display as specified, generate readiness code. See GENERATING READINESS CODE.

Scheme 1

Scheme 2

GENERATING READINESS CODE

Note. While limited diagnostic information is available, vehicle manufacturer does not support diagnostic information using aftermarket scan tools. To properly diagnose vehicle, it is recommended to use VAS 5051 scan tool with VAS 5051/1 adapter cable or VAG 1551 scan tool with 1551/3A adapter cable and VAG 1598/31 test box.

Note. During readiness code generating procedure, if test result is indicated as "OK" after selecting a display group, testing has already been carried out and it is okay to proceed to next work step.

Readiness code must be generated if Engine Control Module (ECM) memory is cleared, battery voltage is disconnected or ECM is disconnected. To generate readiness code, vehicle must be stationary, transmission in Park or Neutral, all electrical consumers off, A/C switched off and coolant temperature at least 176°F (80°C). If possible it is best to warm-up vehicle by test driving. Connect VAS 5051 or equivalent scan tool to DLC. DLC is located behind cover under left side of steering column.

Using scan tool, retrieve DTCs. See RETRIEVING DIAGNOSTIC TROUBLE CODES in appropriate SELF DIAGNOSTICS article. If DTCs were stored, perform appropriate test. See DIAGNOSTIC TROUBLE CODE DEFINITIONS in appropriate SELF DIAGNOSTICS article. Using scan tool, clear DTC memory. See FUNCTION 05 - CLEARING DIAGNOSTIC TROUBLE CODES under SELF-DIAGNOSTIC SYSTEM in appropriate SELF DIAGNOSTICS article. After clearing DTC memory. Follow scan tool instructions to complete readiness code generation. Using scan tool, observe display field 1, in display group 086. (Scheme 1)and (Scheme 2). Readiness code should display 0 0 0 0 0 0 0 0. If readiness code displays as specified, testing is complete.

PCM CODING (ALL MODELS)

Note. After coding ECM and starting engine for first time, allow engine to idle for several minutes so ECM can go through learn function. Idle speed may be erratic while ECM is learning.

If Engine Control Module (ECM) is replaced, it is necessary to code new ECM. If new ECM is not properly coded, the following problems may occur

1. Driveability problems (i.e., harsh shifting).
2. False malfunctions stored in ECM memory.
3. Increased fuel consumption.
4. Increased exhaust emissions.
5. Reduction in transmission life.
6. All ECM functions are not carried out (i.e., EVAP system operation).

Coding Engine Control Module (A4, A6 & S4)

Connect VAS 5051 or equivalent scan tool to Data Link Connector (DLC). DLC is located behind cover under left side of steering column. Turn ignition on. On scan tool, select vehicle system 01 - ENGINE ELECTRONICS. From selection 1, select diagnostic function 07 - CODE CONTROL MODULE. Press "Q" button to confirm input. Following scan tool instructions, access ECM coding information. Enter ECM code as necessary. For ECM coding options, see ENGINE CONTROL MODULE CODING OPTIONS (A4) or ENGINE CONTROL MODULE CODING OPTIONS (A6) table.

As an example, a properly coded ECM for an A4 model with Front Wheel Drive (FWD) with traction control (ASR/ESP) and 5-speed automatic transmission would read 16501 on the VAS 0551 scan tool.

ENGINE CONTROL MODULE CODING OPTIONS (A4 & S4)

ENGINE CONTROL MODULE CODING OPTIONS (A6)

Coding Engine Control Module (TT)

Connect VAS 5051 or equivalent scan tool to Data Link Connector (DLC). DLC is located behind cover under left side of steering column. Turn ignition on. On scan tool, select vehicle system 01 - ENGINE ELECTRONICS. From selection 1, select diagnostic function 07 - CODE CONTROL MODULE. Press "Q" button to confirm input. Following scan tool instructions, access ECM coding information. Enter ECM code as necessary. For ECM coding options, see ENGINE CONTROL MODULE CODING OPTIONS (TT) table.

ENGINE CONTROL MODULE CODING OPTIONS (TT)

ALL MODELS

Note. When DME control unit is disconnected or its power supply interrupted, all stored intermittent DTCs as well as substitute values are cleared/lost. Current hard DTCs cannot be cleared.

After disconnecting battery or replacing DME control unit, drive vehicle to enable DME control unit to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until DME control unit completes relearn function. System Readiness Test (SRT) information was not available from manufacturer.

COMPONENT ACTIVATION

Use BMW MoDIC (hand-held scan tester), BMW Service Tester (Sun 2013 Engine Analyzer) and applicable BMW diagnostic software to activate components. Select DRIVE COMPONENTS MODE (D300). Detailed information on this mode is displayed on screen.

POWER WINDOW CALIBRATION

Power windows will require calibration to establish upper and lower stop points is battery is disconnected. Turn ignition on. Lower window(s) to stop and hold switch for 5 seconds. Raise window(s) to stop and hold switch for 5 seconds. Turn ignition off.

3-Series & 7-Series

Push sun roof button in up/tilt direction and hold. After about 20 seconds, sunroof panel will make a small down-up movement. Release button for no more than 5 seconds and push and hold it in up/tilt direction again. Sun roof will run through a full open and close cycle. Once this cycle is completed, initializaton and adaptation is complete.

Note. If motor runs in the wrong direction when pushing the button in the up/tilt direction, preventing proper initialization, get the sunroof to the closed position, and disconnect power to the motor for about 15 seconds. Reconnect the motor and start the initialization procedure again, and it should work properly.

POWERTRAIN CONTROL MODULE RESET PROCEDURE (ALL MODELS)

Note. For Passport reset procedure, see appropriate SELF-DIAGNOSTICS - PASSPORT, RODEO & RODEO SPORT article.

Using Honda PGM Tester or OBD-II scan tool, clear ECM/PCM memory. Follow manufacturer's instructions. On all models except Passport, ECM/PCM may reset without scan tool. Turn ignition off. Remove BACK UP or CLOCK/RADIO (7.5-amp) fuse from underhood fuse/relay box for 10 seconds.

Accord, Odyssey & S2000

Note. Use this procedure when diagnostic testing suggests substituting PCM with known-good unit.

On models equipped with engine immobilizer system, acquire key cut from non-immobilizer key blank. Remove ECM/PCM from test vehicle. Install known-good ECM/PCM from donor vehicle into test vehicle. Tape donor vehicle's ignition key head-to-head to test vehicles temporary key. ECM/PCM will recognize code from donor vehicle's key and allow test vehicle to be started and tested.

Civic, CR-V & Insight

Remove PCM from test vehicle. Install known-good PCM in test vehicle. Using Honda PGM Tester or OBD-II scan tool, rewrite immobilizer code into PCM with scan tool. This will allow known-good PCM to recognize immobilizer code and allow engine to be started and tested. After completing test, reinstall PCMs and rewrite immobilizer code with scan tool.

IMMOBILIZER (ACCORD, INSIGHT, ODYSSEY, PRELUDE & S2000)

ECM/PCM is part of immobilizer system. Replacement ECM/PCM must have immobilizer code rewritten, using Honda PGM Tester. To perform rewrite procedure requires the vehicle, all master keys, all valet keys and a Honda PGM Tester with an immobilizer program card. Any key not learned during rewrite will not start vehicle. Follow Honda PGM Tester instructions. For more information, see appropriate IMMOBILIZER SYSTEMS article in ACCESSORIES & EQUIPMENT.

All Honda engines have specific system readiness codes that are part of the on-board diagnostics for the emissions systems. If the vehicle battery has been disconnected or discharged, these codes are erased. In some states where Inspection/Maintenance (I/M) testing of vehicle emissions is performed, these codes must be set. If all the codes are not set, the I/M test cannot be completed.

The Malfunction Indicator Light (MIL) is used to display state of system readiness. To determine if readiness codes are set, turn ignition on, but do not start engine. MIL should come on for 15-20 seconds. If MIL then goes off, readiness test codes are set. If MIL blinks several times, readiness test codes are not set completely. To reset each code, drive vehicle or run engine as described in following procedures.

Air/Fuel (A/F) Ratio Sensor Monitor

Note. Once procedure is started DO NOT turn ignition off. When negative battery cable is disconnected, all readiness test codes are cleared.

1. Ensure ambient temperature is 20-95°F (-7-35°C). Connect scan tool to DLC. Start engine, and hold at 3000 RPM under no load condition with transaxle in Park or Neutral until radiator cooling fan comes on. Allow engine to idle for 5 seconds.
2. Drive vehicle at a steady speed between 50-62 MPH with transaxle in D4 position for about 2 minutes. With transaxle in D4 position, decelerate from 62 MPH by completely releasing throttle for at least 5 seconds. If engine is stopped, accelerate back up to 62 MPH for about 2 minutes and repeat deceleration process. Readiness code should now be set. Use scan tool to check readiness code.

Catalytic Converter

Note. Once procedure is started DO NOT turn ignition off. When negative battery cable is disconnected, all readiness test codes are cleared.

1. Ensure ambient temperature is 20-95°F (-7-35°C). Connect scan tool to DLC. Start engine, and hold at 3000 RPM under no load condition with transaxle in Park or Neutral until radiator cooling fan comes on.
2. Drive vehicle on highway/freeway for about 10 minutes without stopping. Driving speed can vary.
3. Drive vehicle at a steady speed between 50-60 MPH with transaxle in D4 position for about 30 seconds.
4. Repeat step 3 , three times. Between each repetition, close throttle completely for 1-2 seconds. If engine is stalls or is stopped during this part of the procedure, repeat procedure starting in step 2 . After procedure is complete, use scan too to check readiness code.

EGR Monitor

Note. Once procedure is started DO NOT turn ignition off. When negative battery cable is disconnected, all readiness test codes are cleared.

1. Connect scan tool to DLC. Start engine, and hold at 3000 RPM under no load condition with transaxle in Park or Neutral until radiator cooling fan comes on.
2. Drive vehicle at a steady speed between 50-62 MPH with transaxle in D4 position for more than 10 seconds.
3. With transaxle in D4 position, decelerate from 62 MPH by completely releasing throttle for at least 5 seconds. If engine is stalls or is stopped during this part of the procedure, repeat procedure starting in step 2 . After procedure is complete, use scan too to check readiness code.

EVAP Leak Monitor

Note. When negative battery cable is disconnected, all readiness test codes are cleared. If engine is stalls or is stopped while performing steps 2 - 5 , repeat procedure from beginning.

1. Ensure fuel level is between 60 and 90 percent of fuel tank capacity (not full). Turn ignition off and allow vehicle to sit for more than 8 hours. At start of procedure, ensure ambient temperature is 20-95°F (-7-35°C). Connect scan tool to DLC.
2. Start engine and drive vehicle for about 15 minutes. During drive, keep vehicle speed steady between 50-70 MPH, without moving accelerator pedal, for about 1 minute. Bring vehicle to a stop. Allow engine to run at idle speed.
3. Repeat step 2 , two more times, for a total of 3 times. Readiness code should now be set. Use scan tool to check readiness code. If readiness code is not set, go to next step.
4. If ambient temperature is less than 32°F (0°C), hold engine speed at 3000 RPM under no load condition with transaxle in Park or Neutral until radiator cooling fan comes on.
5. Remove and install gas cap.
6. Drive vehicle for about 20 minutes on highway/freeway. During drive, keep vehicle speed steady between 50-70 MPH, without moving accelerator pedal, for about 1 minute. Bring vehicle to a stop. Allow engine to run at idle speed.
7. Repeat step 6 , two more times, for a total of 3 times. Readiness code should now be set. Use scan tool to check readiness code.

HO2S Monitor

Note. Do not turn ignition off. When negative battery cable is disconnected, all readiness test codes are cleared. Ensure ambient temperature is 20-95°F (-7-35°C).

1. Connect scan tool to DLC. Start engine, and hold at 3000 RPM under no load condition with transaxle in Park or Neutral until radiator cooling fan comes on. Let engine idle for 5 seconds.
2. Drive vehicle at a steady speed between 50-62 MPH with transaxle in D4 position for about 2 minutes.
3. With transaxle in D4 position, decelerate from 62 MPH by completely releasing throttle for at least 5 seconds. If engine is stopped, go back to step 2 and start over. Check for readiness code with scan tool.

HO2S Heater Monitor

Note. When negative battery cable is disconnected, all readiness test codes are cleared.

Connect scan tool to DLC. Start engine, and let idle for 10 minutes. Check for readiness code with scan tool.

HYUNDAI

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

ECM PROGRAMMING

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

ECM is a part of Nissan Anti-Theft System (NATS). Replacement ECM must have immobilizer code rewritten, using CONSULT-II tester. To perform rewrite procedure requires the vehicle, all keys and a CONSULT-II tester with a NATS Program Card (E960U). Any key not learned during rewrite procedure, will not start vehicle. Follow CONSULT-II tester instructions to rewrite immobilizer code.

ISUZU

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function. If testing determines that PCM needs to be replaced, or testing directs that PCM be programmed, see EEPROM PROGRAMMING PROCEDURE .

EEPROM PROGRAMMING PROCEDURE

Note. Refer to latest Isuzu Technical Communication System (ITCS) information for reprogramming or flashing procedures. Programming PCM/EEPROM requires the use of a scan tool and special manufacturer equipment.

Connect TECH 2 scan tool to DLC and retrieve program information from PCM. Ensure that battery is fully charged. Turn ignition on. Ensure that Vehicle Interface Module cable connection is securely connected to DLC. Follow scan tool instructions to program EEPROM using latest software available from ITCS. If PCM fails to program, recheck PCM connections. Ensure that most recent ITCS information is being used. Attempt to program PCM. If it still can not be programmed properly, replace PCM. Reprogram new PCM, then perform On-Board Diagnostic II System Check. See ON-BOARD DIAGNOSTIC II SYSTEM CHECK under SELF-DIAGNOSTIC SYSTEM in appropriate SELF-DIAGNOSTICS article. Start engine and run for one minute. Use scan tool to check for any stored DTCs.

PRINCIPLES OF OPERATION

Newly released modules require configuration after being installed on the vehicle. All configurable modules will be packaged in a kit which contains a warning label and a multi-language sheet reemphasizing requirements to configure replacement modules. Powertrain Control Module (PCM) has to be standard J1962 lead.

MODULE CONFIGURATION

There are two modes of configuration data. First type requires configuration information so that module can interact with vehicle correctly. This information will be transferred into new module so that new module will contain same settings as old module. Modules on vehicle that require configuration when installing a replacement module are

1. Anti-lock brake control module with traction control.
2. Anti-lock brake control module with traction control and dynamitic stability control.
3. Remote keyless entry driver door module.
4. Steering lock control module.
5. Driver seat module.
6. Audio control module.
7. Vehicle emergency message system/Jaguar assist.
8. Dual automatic temperature control.
9. Instrument cluster with message center.
10. Rear electronic module.
11. General electronic module.

To carry out configuration process, upload old information from old module using PDU (if applicable). Install new module. For additional information on the anti-lock brake control module, appropriate ANTI-LOCK article in BRAKES. For additional information on the DDM, see appropriate POWER DOOR LOCK article in ACCESSORIES & EQUIPMENT. For additional information on the instrument cluster, see appropriate INSTRUMENT PANELS article in ACCESSORIES & EQUIPMENT. For additional information on the GEM and the REM, appropriate BODY CONTROL MODULES article in ACCESSORIES & EQUIPMENT. PDU will not retain stored configuration information for longer than 24 hours. Download stored information into new module using PDU (if applicable).

CUSTOMER DRIVEN PREFERENCES

Second type of configuration data is customer preference driven. These are items that the customer may or may not want to have enabled. Typically, customer preference items can be toggled on or off with compatible scan tool. You may need to ask the customer which preferences they had enabled prior to installation of new module. To carry out customer configuration process, use PDU. On PDU select CUSTOMER PREFERENCE INDEX for modules on the vehicle that have customer preference items. Configure items as necessary. See CUSTOMER PREFERENCE INDEX table.

CUSTOMER PREFERENCE INDEX

S-Type

If battery has been disconnected, engine should be allowed to idle for three minutes as stored idle and drive values contained within PCM have been lost. This may cause a driveability concern if following procedure is not carried out. Once the engine reaches normal operating temperature, engine speed should be increased to 1200 RPM and maintained for approximately two minutes. This will allow PCM to relearn idle values. For PCM to complete it's learning strategy, the vehicle should be driven for approximately 5 miles of varied driving.

X-Type

If battery has been disconnected, engine should be allowed to idle until it has reached normal operating temperature as stored idle and drive values contained within the PCM have been lost. Allow vehicle to idle for a further three minutes. Drive vehicle at constant speeds of approximately 30, 40, 50,60 and 70 mph for three minutes each. This will allow PCM to relearn idle values. Driveability concern may exist if procedure is not carried out.

POWER WINDOW CALIBRATION (XK8)

If battery is disconnected, power windows will require calibration to establish upper and lower stop points. Turn ignition on. Lower window(s) to stop and hold switch for 2 seconds. Raise window(s) to stop and hold switch for 2 seconds. Repeat procedure for all power windows. Turn ignition off.

RADIO SECURITY CODE

If battery is disconnected, radio will require anti-theft security code to be entered. Turn radio on. Radio should display CODE. Using preset buttons, enter code number from security card. A "beep" will sound when correct code is entered. If code is incorrectly entered after 3 successive attempts, radio must be left on for one hour before it will accept code entry.

REMOTE KEYLESS ENTRY TRANSMITTER

Note. All remote transmitters are programmable and must be set at the same time. If an attempt is made to program a fifth remote entry device after four remote entry devices have already been programmed, the attempt shall erase all remote entry device associations and start a new set of four remote entry device associations with fifth remote device programming attempt.

Programming (or reprogram) of remote transmitters into remote keyless entry Driver Door Module (DDM) is carried out with PDU. Due to complexity of the electronics involved with the remote keyless entry, of which the DDM is a part, and the multiplexed communication network which are connected to it preclude the use of general electrical test equipment. Therefore, reference should be made to the PDU User Guide for detailed instructions on programming the remote transmitters.

TRANSMISSION CONTROL MODULE DRIVEABILITY COMPUTER RELEARN PROCEDURE

Manufacturer does not provide a specific computer relearn procedure for obtaining proper driveability. If vehicle battery was disconnected or TCM was replaced, driving the vehicle will enable the TCM to perform a computer relearn procedure for obtaining proper driveability. Inform customer that driveability may differ from what they are accustomed to until the TCM completes the computer relearn procedure.

KIA

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

LAND ROVER

To enable shorter cranking times, when ignition is turned off, ECM memorizes crankshaft and camshaft positions. If battery or ECM is disconnected, memory is lost. Drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

IMMOBILIZER

If ECM is replaced ECM must learn identification code for immobilizer ECU and remote handsets. A Land Rover TestBook must be used to reconfigure the immobilization system.

If battery is disconnected, power windows will require calibration to establish upper and lower stop points. Immediately after Central Control Unit (CCU) or battery is connected, CCU will energize down contacts on all window switches. To ensure calibration is successful; ensure that alarm is disarmed and vehicle is unlocked, that all doors and tailgate are in closed position, that sunroof is open to full hardback or softback position. DO NOT open any door until calibration procedure is completed. Turn ignition on, using appropriate window switch raise each window until motor stalls and window is fully closed. Turn ignition off. If calibration is not successful CCU will sound a warning for about .8 seconds and windows will fully lower. If calibration fails, repeat procedure.

LEXUS

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

IMMOBILIZER SYSTEM

Note. Not all models are equipped with immobilizer system. Models equipped with immobilizer system can be identified by ignition key having a solid urethane head.

Note. A valid key must be available when replacing PCM or immobilizer unit, or both components must be replaced. When replacing an immobilizer system component, all working keys need to be reprogrammed into system. Replacing PCM or immobilizer unit will erase previously programmed keys.

NEW TRANSPONDER KEY CODE

Note. This must be done when a new transponder key ECU is installed. The new transponder key ECU is in automatic key code registration mode. Up to 3 key codes and one sub-key can be registered at one time. In automatic registration mode, last key registered becomes sub-key.

1. Security indicator will flash until first key is inserted into ignition switch. Insert NEW key in ignition switch.
2. Once key registration is under way, security indicator should turn off. After key registration is complete, security indicator should illuminate. Remove NEW key.
3. If programming additional keys, repeat process starting with step 1 . If additional keys do not need programming, procedure is complete. Security indicator should go out once last key (sub-key) is registered.
4. After registration is complete and system is operating normally, when ignition key is removed from ignition lock cylinder, security indicator should flash indicating system is properly functioning. If a key is not inserted into ignition switch with transponder key ECU in automatic registration mode, security indicator will remain illuminated indicating keys have not been registered. If ignition key registration cannot be completed with transponder key ECU in automatic registration mode, a code 2-1 will be displayed by security indicator, and when inserting the already registered ignition key, a code 2-2 will be displayed by security indicator.

ADDITIONAL MASTER KEY

Note. Additional master key may be registered by 2 different methods: using ignition switch, or using LEXUS scan tool. It is possible to register up to 5 master key codes and 3 sub-key codes.

Using Ignition Switch

Note. Ensure driver's door is closed and key is not inserted in ignition switch.

1. Insert registered master key in ignition.
2. Perform this step within 35 seconds. Turn ignition switch on/off 5 times. Open/close driver's door 6 times. Remove master key from ignition.
3. Perform this step within 10 seconds. Insert new key to be registered in ignition.
4. After one minute, additional master key is registered. Security indicator should turn off. If programming additional keys, repeat process starting with step 2 . If additional keys do not need programming, remove master key from ignition.

Using LEXUS Scan Tool

1. Insert registered master key in ignition. Turn ignition on.
2. Perform this step within 2 minutes. Select LS430, IMMOBILIZER, KEY CODE UTILITY and TRANSPONDER CODE REGISTRATION from LEXUS scan tool.
3. Perform this step within 20 seconds. Remove master key.
4. Perform this step within 10 seconds. Insert master key to be registered in ignition. Security indicator should flash. After one minute, additional master key is registered. Security indicator should turn off.

REGISTRATION OR CHANGE OF KEY NUMBER

Note. Ensure this operation is performed when transponder key ECU is replaced. Key number is stamped on key number plate.

Registration Of Key Number (Using LEXUS Scan Tool)

1. Insert registered master key in ignition. Turn ignition on.
2. Select LS430, IMMOBILIZER, KEY CODE UTILITY and KEY NO. REGISTRATION.
3. Insert key number of key number plate according to Lexus scan tool screen. Observe scan tool and ensure key number is registered to transponder key ECU.

Change Of Key Number (Using LEXUS Scan Tool)

1. Insert registered master key in ignition. Turn ignition on.
2. Select LS430, IMMOBILIZER, KEY CODE UTILITY and KEY NO. CHANGE.
3. Insert key number of key number plate according to Lexus scan tool screen. Observe scan tool and ensure key number is changed. Remove master key.

ERASURE OF TRANSPONDER KEY CODE

Note. There are 2 different methods to erase the transponder key code: using ignition switch, or using LEXUS scan tool. All other master and sub-key codes are deleted. When using ignition key which was used before deleting, it is necessary to register the code again.

Note. Ensure driver's door is closed and ignition key is not inserted in ignition switch.

1. Insert master key in ignition.
2. Perform this step within 35 seconds. Turn ignition switch on/off 6 times. Open/close driver's door 7 times. Security indicator will be off.
3. Perform this step within 10 seconds. Remove master key. Security indicator should flash for one second, then go off. Procedure is now completed. Key code should now be erased. If key cannot be removed from ignition, key code deletion is canceled. Security indicator will turn off. Repeat procedure from step 1 .

1. Insert master key in ignition. Turn ignition on.
2. Perform this step within 2 minutes. Select LS430 from menu. Select IMMOBILIZER, KEY CODE UTILITY and TRANSPONDER CODE REGISTRATION. After these operations, proceed to additional operations following prompts on tester screen.
3. Perform this step within 10 seconds. Remove master key.
4. Procedure is now completed. Key code should now be erased. If key cannot be removed from ignition, key code deletion is canceled. Security indicator will turn off. Repeat procedure from step 1 .

SUN ROOF REINITIALIZATION

Tilt sun roof to fully tilted position. Release switch, then depress switch again and hold for 10 seconds. Sun roof will tilt down, slide open, slide closed and tilt up in that order. Reinitialization is now complete.

MAZDA

PROGRAMMING POWERTRAIN CONTROL MODULE

Note. Before performing PCM programming procedure, check for any applicable Technical Service Bulletins (TSBs) that may apply to vehicle application.

Description

Flash Electronically Erasable Programmable Read Only Memory (EEPROM) is contained in an Integrated Circuit (IC) inside of Powertrain Control Module (PCM). The EEPROM contains the vehicle strategy and any calibration information specific to vehicle. The IC is reprogrammable and at times it may become necessary to reprogram or reflash the entire contents. This is usually due to an after production strategy change or the Flash Vehicle Identification (VID) Block has been previously reprogrammed and has reached its limit. The VID block can be tailored to accommodate various hardware changes made since vehicle production. This procedure can only be performed using Ford's Service Bay Technical System (SBTS) or equivalent.

A replacement PCM will have a label stating PROGRAMMING REQUIRED. This indicates that it is necessary to retrieve VID data from the original PCM before removing PCM from vehicle. This procedure can be performed using New Generation Star (007-00500) scan tool or equivalent. See FLASH VEHICLE IDENTIFICATION BLOCK PROCEDURE . If original PCM is damaged, nonfunctional or incapable of communicating, it will be necessary to manually reprogram VID block. This procedure can only be performed by contacting the "AS BUILT" data center for programming information.

Flash Vehicle Identification Block Procedure

Note. If using a generic scan tool, follow scan tool manufacturer's instructions to perform this procedure.

1. To perform this procedure NGS scan tool, Ford Service Function (FSF) card and NGS Flash Cable (007-00531) must be used. Plug flash cable into scan tool. Plug other end of flash cable into Data Link Connector (DLC). From the scan tool main menu, select SERVICE BAY FUNCTIONS, POWERTRAIN CONTROL MODULE and then PROGRAMMABLE MODULE INSTALLATION.
2. Scan tool display should show 2 selections. The first is selection is for old PCM information to be retrieved and stored. The second selection is for restoring new PCM with information that has been retrieved from the old PCM. Follow scan tool display instructions or refer to instruction sheet included with FSF card. If Flash Vehicle Identification (VID) Block has been reprogrammed previously, scan tool will display a message indicating the need to reflash entire Integrated Circuit (IC). This procedure can only be performed using Ford's Worldwide Diagnostic System (WDS).

Customer Supplied 2 Or More Valid Keys

1. Cut new transponder equipped key(s). Using first key, turn ignition switch to ON position, then LOCK position 5 times. DO NOT leave key in either position for more than one second. Turn first key to ON position. SECURITY light should illuminate. Turn first key to LOCK position and remove from ignition. SECURITY light should go out.
2. Using second key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn second key to LOCK position and remove key.
3. Repeat step 2 with first key. Repeat step 2 with third key. Repeat step 2 with each new or valid key, up to 8 keys total. Waiting 30 seconds will cause program to quit automatically.

Customer Supplied Only One Or No Valid Keys

1. Cut new transponder equipped key(s). Using new key, turn ignition switch to ON position, then LOCK position 5 times. DO NOT leave key in either position for more than one second. Turn new key to ON position. SECURITY light should be flashing at 300-millisecond interval. Turn new key to LOCK position and wait about 5 minutes until SECURITY light flashing has decreased to 1.2-second interval.
2. Input code word. See «INPUTTING CODE WORD»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import__inputting-code-word) . SECURITY light should stop flashing and stay illuminated. Start engine with new key. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn new key to LOCK position and remove key.
3. Using new second key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn new second key to LOCK position and remove key.
4. Repeat step 3 with new third key. Repeat step 3 with each new key, up to 8 keys total. Waiting 30 seconds will cause program to quit automatically.

STEERING LOCK REPLACEMENT

Note. When replacing steering lock, coil and keys should be replaced as a set.

1. Remove old steering lock. See STEERING LOCK under REMOVAL & INSTALLATION in appropriate IMMOBILIZER SYSTEMS article. Connect new steering lock to ignition switch connector. Connect old steering lock to coil connector.
2. Insert valid first key into old steering lock. Insert new key into new steering lock. Turn new key to ON position, then LOCK position 5 times. DO NOT leave key in either position for more than one second. Turn new key to ON position. SECURITY light should illuminate. Turn new key to LOCK position. SECURITY light should go out.
3. Remove valid first key from old steering lock. Place valid second key into old steering lock. Using new key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn new key to LOCK position.
4. Disconnect coil connector from old steering lock and reconnect into new steering lock. Using new key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn new key to LOCK position and remove key.
5. Repeat step 4 with each new key. Waiting 30 seconds will cause program to quit automatically. Complete installation of steering lock.

1. Replace steering lock, see STEERING LOCK under REMOVAL & INSTALLATION in appropriate IMMOBILIZER SYSTEMS article. Using new key, turn ignition switch to ON position, then LOCK position 5 times. DO NOT leave key in either position for more than one second. Turn new key to ON position. SECURITY light should be flashing at a 300-millisecond interval. Turn new key to LOCK position and wait about 5 minutes until SECURITY light flashing has decreased to a 1.2-second interval.
2. Input code word. See «INPUTTING CODE WORD»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import__inputting-code-word) . SECURITY light should stop flashing and stay illuminated. Start engine with new key. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn new key to LOCK position and remove key.
3. Using new second key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn new second key to LOCK position and remove key.
4. Repeat step 3 with new third key. Waiting 30 seconds will cause program to quit automatically.

IMMOBILIZER UNIT

Note. When customer does not supply any valid keys, PCM must also be replaced.

1. Cut new transponder equipped key(s). Using first new key, turn ignition switch to ON position, then LOCK position 5 times. DO NOT leave key in either position for more than one second. Turn first new key to ON position. SECURITY light should be flashing at a 300-millisecond interval. Turn first new key to LOCK position and wait about 5 minutes until SECURITY light flashing has decreased to a 1.2-second interval.
2. Input code word. See «INPUTTING CODE WORD»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import__inputting-code-word) . SECURITY light should stop flashing and stay illuminated. Start engine with first new key. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn first new key to LOCK position and remove from ignition.
3. Using second new key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn second new key to LOCK position and remove key.
4. Repeat step 3 with valid key or new third key. Repeat step 3 with each new key, up to 8 keys total. Waiting 30 seconds will cause program to quit automatically.

Customer Supplied Two Or More Valid Keys

1. Cut new transponder equipped key(s). Using first valid key, turn ignition switch to ON position, then LOCK position 5 times. DO NOT leave key in either position for more than one second. Turn first valid key to ON position. SECURITY light should illuminate. Turn first valid key to LOCK position and remove key from ignition. SECURITY light should go out.
2. Using second valid key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn second new key to LOCK position and remove key.
3. Repeat step 2 with new third key. Repeat step 2 with each new key, up to 8 keys total. Waiting 30 seconds will cause program to quit automatically.

POWERTRAIN CONTROL MODULE

Note. When customer does not supply any valid keys, immobilizer unit must also be replaced.

1. Cut new transponder equipped key(s), if necessary. After PCM is replaced. Using valid first key, turn ignition switch to ON position. SECURITY light should illuminate for 1-2 seconds. Turn valid key to LOCK position.
2. Using valid first key, turn ignition switch to ON position, then LOCK position 6 times. DO NOT leave key in either position for more than one second. Ensure sixth turning is done within one second. Remove valid first key.
3. Using valid second key, turn ignition switch to ON position. SECURITY light should illuminate for 1-2 seconds. Turn valid second key to LOCK position and remove key.
4. Using valid first key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn valid first key to LOCK position and remove key.
5. Repeat step 4 with additional valid key or new third key. Repeat step 4 with each new key, up to 8 keys total. Waiting 30 seconds will cause program to quit automatically.

Customer Supplied Only One Valid Key

1. Cut new transponder equipped key(s), if necessary. After PCM has been replaced. Using new first key, turn ignition switch to ON position. SECURITY light should illuminate for 1-2 seconds. Turn new first key to LOCK position.
2. Using valid key, turn ignition switch to ON position, then LOCK position 6 times. DO NOT leave key in either position for more than one second. Ensure sixth turning is done within one second. SECURITY light should be flashing at a 300-millisecond interval. Wait about 5 minutes until SECURITY light flashing has decreased to a 1.2-second interval.
3. Input code word. See «INPUTTING CODE WORD»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import__inputting-code-word) . SECURITY light should stop flashing and stay illuminated. Using valid key, turn ignition switch to ON position. SECURITY light should illuminate for 1-2 seconds. Turn valid key to LOCK position and remove key.
4. Using new second key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn new second key to LOCK position and remove key.
5. Repeat step 4 with each new key, up to 8 keys total. Wait 30 seconds, program will quit automatically. After reprogramming is complete, clear DTCs with New Generation Star (NGS) tester.

IMMOBILIZER UNIT & POWERTRAIN CONTROL MODULE

Note. Keys may be new or valid. If errors occur during reprogramming in steps 1 or 2 , start over from step 1 . If errors occur during step 3 , go to REPROGRAM ERROR RECOVERY .

1. Cut new transponder equipped key(s), if necessary. After replacing immobilizer unit and PCM. Using first key, turn ignition switch to ON position. SECURITY light should illuminate and then go out. Turn first key to LOCK position and remove key. SECURITY light should flash repeatedly in single pulses.
2. Using second key, turn ignition switch to ON position. SECURITY light should illuminate and then go out. Turn second key to LOCK position and remove key. SECURITY light should flash in double pulses repeatedly.
3. Using third key, turn ignition switch to ON position. SECURITY light should illuminate and then go out. Turn third key to LOCK position and remove key. SECURITY light should flash repeatedly in triple pulses.
4. Repeat step 3 with each new key, up to 8 keys total. Waiting 30 seconds will cause program to quit automatically. After reprogramming is complete, clear DTCs with NGS tester.

REPROGRAM ERROR RECOVERY

1. Using first key, start engine. After SECURITY light illuminates for 1-2 seconds, turn first key to LOCK position. Using first key, turn ignition switch to ON position, then LOCK position 5 times. DO NOT leave key in either position for more than one second.
2. Using first key, turn ignition switch to ON position. SECURITY light should illuminate. Turn first key to LOCK position and remove key. SECURITY light should go out.
3. Using second key, start engine. SECURITY light should illuminate for 1-2 seconds and engine should continue to run. Turn second key to LOCK position and remove key.
4. Repeat step 3 with first key. Repeat step 3 with third key, then with each new key, up to 8 keys total. Waiting seconds will cause program to quit automatically. After reprogramming is complete, clear DTCs with NGS tester.

INPUTTING CODE WORD

1. Code word is comprised of 8 digits from 1-9. The code word is part of immobilizer unit. To obtain code word call manufacturer with immobilizer unit serial number.
2. The immobilizer unit code word is input to PCM by cycling ignition key and counting number of SECURITY light flashes. Wait about 5 minutes until SECURITY light flashing has decreased to 1.2-second interval. Input code word with SECURITY light sequence. (Scheme 3)
3. Turn ignition switch to ON position for length of time required for SECURITY light to flash the same number of times that coincides with first code word digit. Turn ignition switch to LOCK position for at least one flash, but for less than 30 seconds. Repeat procedure for each code word digit. When code word is registered correctly, SECURITY light will stop flashing and stay illuminated. Continue immobilizer system reprogram procedure.

Scheme 3

MERCEDES-BENZ

If battery has been disconnected or replaced, following items must be reset or normalized

1. Reset clock in instrument cluster. Reset timer for stationary heater if equipped. See OWNERS MANUAL.
2. Normalize power windows. See «SYNCHRONIZATION OF POWER WINDOWS»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import__synchronization-of-power-windows) .
3. Normalize steering angle sensor. See «ACTIVATING STEERING ANGLE SENSOR»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import__activating-steering-angle-sensor) .
4. Normalize sliding roof. See «SYNCHRONIZATION OF SLIDING/TILT-UP ROOF»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import__synchronization-of-slidingtilt-up-roof) .
5. Normalize seats (easy entry/exit function). See «EASY ENTRY/EXIT FUNCTION»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import__easy-entryexit-function) .

SYNCHRONIZATION OF POWER WINDOWS

Note. C-class models do not require synchronization of rear power windows. Synchronization procedure can also be performed with STAR DIAGNOSIS tester.

Synchronization of power windows links counter reading of window position to relevant Door Control Module (DCM). Synchronization must be performed whenever desynchronization occurs (battery disconnected or control module replaced). Synchronization is necessary for automatic raising/lowering function of power windows.

To synchronize power windows, press appropriate window switch in up position. When window reaches full up position maintain pressure for 3-5 seconds. When DCM detects motor lock-up for specified period position counter is reset to zero. Repeat procedure for each window.

ACTIVATING STEERING ANGLE SENSOR

If battery is disconnected or voltage supply to steering angle sensor is interrupted, ESP control module switches to FAULT. EL. STAB. PROGRAM, LOCATE WORKSHOP will be displayed in multifunction display in instrument cluster and steering angle sensor must be reactivated.

To re-acitvate steering angle sensor, start engine and run at idle speed. Turn steering wheel from lock-to-lock and then back to straightahead position. Fault should clear and FAULT. EL. STAB. PROGRAM, LOCATE WORKSHOP display should go out.

SYNCHRONIZATION OF SLIDING/TILT-UP ROOF

Synchronization must be performed whenever desynchronization occurs (battery disconnected or control module replaced). Synchronization is necessary for convenience opening and closing of sliding/tilt-up roof.

To synchronize sliding/tilt-up roof, press sliding roof switch forward opening sliding/tilt-up roof to full tilt up position. After roof reaches full tilt-up position, maintain pressure on switch for 5 seconds. When DCM detects motor lock-up for specified period, position counter is reset to zero. Sliding/tilt-up roof is now synchronized, allowing sliding roof panel to stop before mechanical limit stop is reached.

EASY ENTRY/EXIT FUNCTION

Note. Synchronization procedure can also be performed with STAR DIAGNOSIS tester. Easy entry/exit function is activated through multifunction display in instrument cluster.

To allow easier entry or exit from vehicle. Driver's seat and steering column are moved to easy entry/exit position. Seat and steering column are move to full-back and full-up positions. To recalibrate easy entry/exit function

1. Using power seat switch, raise head restraint to full-up position. Maintain switch pressure for one second after full-up position is reached.
2. Move seat bottom to full forward position. Maintain switch pressure for one second after full forward position is reached.

Easy entry/exit function is now calibrated, and if activated will move seat to full-back and steering column to full-up positions when transmission is place in Park or Neutral position and door is opened.

CONTROL MODULE VERSION CODING

Note. Hand Held Tester (HHT) or STAR DIAGNOSIS tester is necessary for performing version coding.

All Control Modules (CM) have a version coding feature. Coding must be performed when a new CM is installed. Version coding can be performed automatically or manually using Hand Held Tester (HHT).

Automatic Coding

Before removing Control Module (CM), using HHT read and store existing version code. After installation of new module, download previous version code using HHT.

Manual Coding

If version code number cannot be read, vehicle equipment and version must be determined. A corresponding code number must be obtained from spare parts microfiche and manually entered with HHT. Version coding data for each CM is different, following data is typical of information needed for coding

1. Vehicle model.
2. Country version.
3. Convenience feature.
4. Remote trunk release.
5. Lock confirmation via blinker lights.
6. Engine displacement.
7. Transmission code.
8. Non-catalytic converter or three-way catalyst equipped.
9. 19 MPH (30 km/h) limitation.

ENABLING CODE FUNCTION FOR RADIO

Note. Code must be obtained from customer. When vehicle is shipped new, a CODE CARD is included with the owner's manual.

Audio 5 & 10 Models Or Sound 10, 20 & 30 Models (CLK, E & SLK Class)

Note. Audio 5 & 10 models are identified by similar controls on each side of display and a cassette player above display.

After reconnecting radio, turn ignition on. CODE appears on display. Enter 5-digit code number using station buttons. After entering correct code, press seek-UP/seek-DOWN or SCAN button to confirm. Radio will turn on if code entered is correct.

If wrong code is entered, CODE will be displayed on radio. If wrong code is entered 3 times, WAIT will be displayed and code entry is denied for 10 minutes. If wrong code is entered 9 times, WAIT will be displayed and code entry is denied for 60 minutes. Radio and ignition switch must remain on during the waiting period.

Becker 2000 (CL, S & SL Class)

Turn ignition on. Turn radio on. Retrieve code number from customer or code card. Enter first digit of code number by pressing station button No. 1 until correct digit appears. Enter remaining digits by repeating procedure with second station button and so on. Confirm correct code is displayed by pressing SEEK button. Radio will turn on if correct code is entered.

If wrong code is entered, CODE will be displayed on radio. If wrong code is entered 3 times, WAIT will be displayed and code entry is denied for 15 minutes. If wrong code is entered 9 times, WAIT will be displayed and code entry is denied for 24 hours. Radio and ignition switch must remain on during the waiting period.

Becker Mexico, Grand Prix, Europa & Avus Models (SL Class)

Turn ignition on. Turn radio on. CODE will be displayed on radio. Enter 3-digit customer supplied code number by turning tuning knob to right until first digit is correctly displayed. Press AUTOMATIC button moving display to next digit. Confirm correct code is displayed by pressing AUTOMATIC button. Radio will turn on if correct code is entered.

If wrong code is entered, CODE will be displayed on radio. If wrong code is entered 3 times, WAIT will be displayed and code entry is denied for 15 minutes. Radio and ignition switch must remain on during the waiting period. If wrong code is entered 9 times, "_ _ _ _" will be displayed, radio is no longer operational, and must be returned to manufacturer for reactivation.

Radio With Navigation Control Module (CL, S & SL Class)

Turn ignition on. Turn navigation control unit on. Press buttons No. 1 and 6 simultaneously within 8 minutes after switching unit on. CODE will be displayed. Enter customer supplied code number using station number keys on unit. Confirm correct code is displayed by pressing cursor keys or SCAN button. Unit will turn on if correct code is entered.

If wrong code is entered 3 times, code entry is denied for 15 minutes. If wrong code is entered 9 times, code entry is denied for 24 hours. Radio and ignition switch must remain on during the waiting period.

Radio With 4-Digit Fixed Code (CL, S & SL Class)

Turn ignition on. Turn radio on. CODE will be displayed. Enter customer supplied code number using station number keys on radio. Confirm correct code by pressing SEEK button. Unit will turn on if correct code is entered.

If wrong code is entered 3 times, code entry is denied for 15 minutes. If wrong code is entered 9 times, code entry is denied for 24 hours. Radio and ignition switch must remain on during the waiting period.

Radio & Radio With Navigation Control Module With 5-Digit Fixed Code (CL, S & SL Class)

Turn ignition on. Turn navigation control unit or radio on. CODE will be displayed. Enter customer supplied code number using station number keys on radio. On radios, confirm correct code by pressing TUNE, AUTO/SEEK or SC button. On navigation control unit, confirm correct code by pressing ENTER button. Unit will turn on if correct code is entered.

If wrong code is entered, CODE will be displayed on radio. If wrong code is entered 3 times, WAIT will be displayed and code entry is denied for 10 minutes. If wrong code is entered 9 times, WAIT will be displayed and code entry is denied for 30 minutes. Radio and ignition switch must remain on during the waiting period.

Radio (ML Class)

Turn ignition on. Turn radio on. CODE will be displayed. Enter customer supplied code number using station number keys on radio. Confirm correct code by pressing seek forward or seek back buttons. Unit will turn on if correct code is entered.

If wrong code is entered, CODE will be displayed on radio and code will need to be researched and entered again. If wrong code is entered 3 times, code entry is denied for 10 minutes. If wrong code is entered 9 times, code entry is denied for 60 minutes. Radio and ignition switch must remain on during the waiting period.

PROGRAMMING SUPPLEMENTAL RESTRAINT SYSTEM CONTROL MODULE

Note. Hand-Held Tester (6511 0001 99) is necessary to set control module parameters.

After replacing control module, when ignition is turned on, SRS warning light will continuously blink or stay on, indicating that control module parameters need to be programmed. Turn ignition off. Connect HHT to DLC. DLC is located in right rear corner of engine compartment. It may be necessary to use Adapter (140 589 1463 00) to connect HHT to DLC. Follow HHT prompts to program replacement control module. Currently all control modules are programmed with the same parameters. After control module parameters are set, SRS warning light will go out.

ENGINE CONTROL MODULE

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

ENCRYPTED CODE REGISTRATION METHOD (IMMOBILIZER)

Note. If PCM is replaced, immobilizer-ECU should also be replaced. PCM has an encrypted code for immobilizer-ECU, and encrypted code is registered in immobilizer-ECU and ignition key.

Note. Using key ID register function will cause all key ID's that have been previously registered in immobilizer-ECU to be erased. All keys need to be registered. Those which have been registered before should be on hand before using this function. If registering more than one key, do not disconnect scan tool halfway through the registration process. After registering key IDs, check that engine can be started using all keys that have been registered. If engine will not start, see DIFFICULT TO START/NO START (CRANKS OKAY) in TESTING - NO CODES article.

If Immobilizer-ECU or PCM is replaced, or an ignition key is added encrypted codes of all ignition keys must be registered. (A maximum of eight different ignition key can be registered.) When the immobilizer-ECU has been replaced, scan tool MB991502 (MUT-II) must be used to register immobilizer-ECU and input vehicle secret code and register password (secret code) that owner specifies into immobilizer-ECU. If an attempt is made to start the engine with an unregistered ignition key, cranking occurs, but fuel supply is cut off disabling engine. After about 10 seconds, theft-alarm indicator in instrument cluster will blink for about 30 seconds.

Diagnostic Aids

If none of the functions can be used, use scan tool to check for any stored DTCs. If any DTCs are stored, perform appropriate test. See DIAGNOSTIC TROUBLE CODE DEFINITIONS in appropriate SELF-DIAGNOSTICS article. Then repeat operation. If an incorrect password is input five times in a row, immobilizer-ECU judges that an unauthorized operation is being attempted. Start-prevention mode will be set, and engine operation will stop and all special functions will be disabled. If ignition switch is turned on, and left in that position for approximately 20 minutes, "Unauthorized operation, start- prevention mode" will be cancelled.

Key Id Register

All ignition keys can be registered with MUT-II scan tool or equivalent. Additional ignition keys can be registered with or without scan tool. If an ignition key is registered using scan tool, no registered ignition keys must be lost. Registration with scan tool is as follows

1. Connect MUT-II or equivalent scan tool to Data Link Connector (DLC). Turn ignition switch on.
2. On scan tool at SYSTEM SELECT, press YES. Select IMMOBILIZER, press YES. Select SPECIAL FUNC, press YES. Select KEY ID REGISTER, press YES. If DTC 11 is stored, CAN'T EXECUTE will be displayed. Perform appropriate test procedure, see appropriate IMMOBILIZER SYSTEMS article in ACCESSORIES & EQUIPMENT.
3. Input password. Use UP and DOWN keys to change current password digit to a value between 0 and 9. Use the LEFT and RIGHT keys to move to a different password digit. Press the YES key to accept password. If an incorrect password is input 5 times in a row, this screen is displayed and Immobilizer-ECU switches to unauthorized operation, start-prevention mode.
4. Press YES key to start key ID registration.
5. Scan tool will display COMPLETED when key ID registration is successful. If an error occurs during key ID registration, message CAN'T EXECUTE will be displayed. If key has already been registered, KEY ID HAS BEEN REGISTERED will be displayed.
6. Number of keys currently registered will be displayed on scan tool. To register an additional key, replace the ignition key with next key to be registered within 5 seconds and then press YES key. Key ID registration screen will be displayed, then register another key. A maximum of eight different keys can be registered. If key ID registration is complete, press the NO key.
7. This completes the registration operation. Turn ignition switch to LOCK position and leave it off for about ten seconds.
8. Check that engine can be started with each ignition key that was registered. Using scan tool, check that immobilizer system or MFI system DTCs did not set.
9. Turn ignition switch to LOCK position. Disconnect scan tool.

Registration Of Additional Keys (With Scan Tool)

An additional key is registered with MUT-II scan tool while keeping all existing registered key data. To register additional keys with scan tool, no registered keys must be lost. To register an additional key using scan too1 to perform following

1. Connect MUT-II or equivalent scan tool to Data Link Connector (DLC). Turn ignition switch to ON position.
2. On scan tool at SYSTEM SELECT, press YES. Select IMMOBILIZER, press YES. Select SPECIAL FUNC, press YES. Select KEY ID REGISTER, press YES. If DTC 11 is stored, CAN'T EXECUTE will be displayed. Perform appropriate test procedure, see appropriate IMMOBILIZER SYSTEMS article in ACCESSORIES & EQUIPMENT.
3. Follow scan tool instructions to add an additional key. If an error occurs during key ID registration, scan tool will display CAN'T EXECUTE. If key has already been registered, KEY ID HAS BEEN REGISTERED will be displayed.
4. The number of keys currently registered will be displayed. To register an additional key, replace ignition key with next key to be registered within 5 seconds and then press YES key. Key ID registration screen will be displayed, then register another key. A maximum of eight different keys can be registered. If key ID registration is complete, press the NO key.
5. This completes the registration operation. Turn ignition switch to LOCK position and leave it off for approximately ten seconds.
6. Check that engine can be started with each registered ignition key.
7. Using scan tool, check that immobilizer system and/or MFI system DTCs did not set. Turn ignition switch to LOCK position. Disconnect scan tool.

Registration Of Additional Keys (Without Using Scan Tool)

Additional ignition keys can be registered without using the scan tool by operating two ignition keys that already have been registered to the vehicle and operating an additional key to be registered. A maximum of 8 ignition keys can be registered. To register additional keys without using scan tool

1. Using a key (Key A) which has already been registered to the vehicle, turn ignition switch to ON position. Leave Key A in ON position for about 5 seconds. Turn ignition off, and remove Key A.
2. Using a second key (Key B) which has already been registered to the vehicle, turn ignition switch to ON position. Leave Key B in ON position for about 5 seconds. Turn ignition off, and remove Key B. Key B must be turned on within 7 seconds of removing first key.
3. If Key B is correct, immobilizer-ECU enters additional key entry mode. Theft-alarm indicator light in instrument cluster blinks about twice a second. After theft-alarm indicator light begins to blink, turn ignition switch to OFF and ON positions using new transponder key. Time during which new key can be registered is limited to less than 30 seconds after theft-alarm indicator blinks.
4. To register another key, turn ignition to OFF position. Place ignition key to be registered in ignition switch, and turn key to ON position within seven seconds. To add additional keys, repeat procedure. A maximum of 8 ignition keys can be registered. Additional key registration mode is terminated when any following condition is met: Ignition key is in ON position more than 30 seconds (time-out of addition entry mode). Engine control relay is off after key is turned to OFF position. Start communication with scan tool.
5. Ensure additional registered keys can start engine, after ignition is turned off and engine control relay is turned off.

Radio will require anti-theft security code to be entered if battery is disconnected. Turn radio on. Radio should display "codE". Using first 4 preset buttons, enter code number from customer supplied security card. Each preset button applies to code number digit. For example, No. 1 button sets the first digit of code number. Cycle button until desired number appears. Once code is entered, press TAPE or CD (as applicable) button. A "beep" will sound when correct code is entered. If code is incorrectly entered after 3 successive attempts, radio must be left on for one hour before it will accept code entry.

NISSAN

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

IMMOBILIZER PROGRAMMING

ECM is a part of Nissan Anti-Theft System (NATS). Replacement ECM must have immobilizer code rewritten, using CONSULT. To perform rewrite procedure requires the vehicle, all keys and a CONSULT tester with a NATS Program Card (E960U). Any key not learned during rewrite will not start vehicle. Follow CONSULT tester instructions.

SUN ROOF INITIALIZATION

Note. Following procedure should be performed if battery is disconnected and reconnected, or battery is discharged and recharged to provide proper automatic operation and jam protection operation of power sun roof.

Ensure ignition is on. With sun roof in any position. Press and hold power sun roof switch until power sun roof tilts all the way upward. Hold switch in tilt position for 3 seconds. This resets sun roof motor memory.

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

BOXSTER

Note. Ensure all codes are correct before entering. Codes cannot be changed.

Alarm/Drive Block Control Unit Programming

1. If control unit requires replacement, new control unit must be coded. It will be necessary to obtain immobilizer (drive block) code and teaching code from Porsche Cars North America (PCNA) prior to replacement. To obtain codes, complete code request form (Technical Bulletin, Boxster bulletin group 9, number 9801) from nearest Porsche dealer. Proof of ownership (valid title or registration) is required. Original transponders can be reused, but require recoding to new control unit.
2. Install control unit. Connect Porsche System Tester 2 and turn on. Select BOXSTER and begin control unit search sequence. Select ALARM SYSTEM, TEACHING FUNCTIONS AND IMMOBILIZER. Enter 16-digit immobilizer code obtained from PCNA and press ENTER. Confirm code entry by pressing F7.

SAAB

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

PROGRAMMING IMMOBILIZER

If ECM was disconnected or replaced, or battery was disconnected immobilizer must be reset. Connect Tech 2 or equivalent scan tool to DLC. Turn ignition on. On scan tool select BODY, and then TWICE. Select IMMOBILIZING. Immobilizer will self program after about 10 seconds.

SUBARU

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

SUZUKI

After disconnecting battery or replacing ECM, drive vehicle to enable ECM to relearn driveability. Inform your customer that they may experience driveability different from what they are accustomed to until ECM completes relearn function.

SERVICE PRECAUTIONS (PRIUS)

The following service precautions must be followed

Scheme 4

1. Ensure ignition is off and ignition key is removed from ignition before performing any inspection or service procedure in engine compartment, as engine may automatically start and shut off when ignition is on and READY light is illuminated. READY light is displayed just above the shift lever position indicator on instrument cluster at center of instrument panel.
2. Read all service and warning labels in engine compartment before performing any procedures in engine compartment.
3. All high-voltage wiring harness connectors contain Orange connectors. DO NOT touch any wiring harness that contains Orange connectors.
4. High-voltage battery and other high-voltage components may be identified by HIGH VOLTAGE caution labels on them. DO NOT touch these components.
5. If necessary to inspect or service high-voltage system, ensure ignition is off. Remove service plug and wait at least 5 minutes to ensure high voltage is fully discharged before touching any high-voltage wiring harness, connectors or components. Service plug is located on service plug assembly at driver's side front corner of trunk compartment, near high-voltage battery. (Scheme 4) Ensure service plug is stored in a location in which no one may install service plug while technician is working on the vehicle.
6. If necessary to touch any high-voltage wiring harness, connectors or components, ensure service plug is removed and battery voltage or less exists at electrical connector. Use Toyota insulated gloves when touching any high-voltage wiring harness, connectors or components. Ensure insulated gloves are dry and in good condition and that no holes exist in insulated gloves. Test insulated glove by applying air to glove before touching any high-voltage wiring harness, connectors or components.
7. DO NOT wear any metal objects while working on vehicle which may accidently drop and cause a short circuit.
8. If any high-voltage wiring harness connector is disconnected, ensure terminal on wiring harness connector is wrapped with tape to prevent wiring harness connector from contacting any surface.
9. If servicing high-voltage system, place sign on roof of vehicle to indicate to other technicians that high-voltage system is being serviced.

IMMOBILIZER PROGRAMMING (EXCEPT PRIUS)

Note. In the case of having lost all the already registered master ignition keys, you are not able to do additional registration or deletion of ignition key codes. You must change the Engine Control Module (ECM) and then perform ignition key registration.

Ignition Key Registration

Note. This procedure MUST BE performed ONLY when NEW Engine Control Module (ECM) is installed. A new ECM is in automatic registration mode and up to 3 ignition key identification codes may be registered in the ECM at one time. In automatic registration mode, the last ignition key to be registered becomes the sub-key.

Note. A master key is a Black-colored ignition key and a sub-key is a Gray-colored ignition key.

Scheme 5

1. Ensure SECURITY indicator light is flashing. SECURITY indicator light is displayed as a vehicle icon near the center of the tachometer.
2. Insert ignition key into ignition lock cylinder. Note that SECURITY indicator light should now remain on steady.
3. Once ignition key registration is under way, SECURITY indicator light should turn off. After ignition key registration is complete, SECURITY indicator light should come on steady. Remove ignition key.
4. If ignition key registration was complete, and system is operating normally, SECURITY indicator light should flash when ignition key was removed from ignition lock cylinder. If ignition key registration was not completed with ECM in automatic registration mode, a code 2-1 will be displayed by SECURITY indicator light. (Scheme 5) When inserting an already registered ignition key, a code 2-2 will be displayed by SECURITY indicator light. (Scheme 5)
5. If programming additional ignition keys, repeat process starting with step 1. If additional ignition keys do not need programming, procedure is complete. SECURITY indicator light should turn off once last ignition key (sub-key) is registered.
6. To complete automatic registration mode, without removing or installing registered ignition key in ignition lock cylinder, depress and release brake pedal at least 5 times within 15 seconds, or request automatic registration mode completion by using Toyota hand-held tester connected to data link connector No. 3. Data link connector No. 3 is located at driver's side of instrument panel.

ADDITIONAL MASTER KEY REGISTRATION (EXCEPT PRIUS)

Note. A master key is a Black-colored ignition key. Additional master key may be registered by 2 different methods: using brake pedal and accelerator pedal, or using Toyota hand-held tester. It is possible to register up to 7 master key codes including the already registered key code.

Note. When any operation time described in following procedures is over, registration mode completes. When next procedure is performed while timer is working, the timer completes counting time and then the next timer starts.

Using Brake Pedal & Accelerator Pedal

1. Insert registered master key into ignition lock cylinder. Within 15 seconds of inserting master key into ignition lock cylinder, depress and release accelerator pedal 5 times.
2. Within 20 seconds of depressing and releasing accelerator pedal 5 times, depress and release brake pedal 6 times and remove master key from ignition lock cylinder.
3. Within 10 seconds of removing master key from ignition lock cylinder, insert master key to be registered in ignition lock cylinder.
4. Within 10 seconds of inserting master key to be registered in ignition lock cylinder, depress and release accelerator pedal one time. Ensure SECURITY indicator light flashes. SECURITY indicator light is displayed as a vehicle icon near the center of the tachometer.
5. After one minute, additional master key should be registered and SECURITY indicator light should then turn off. If registering additional master keys, repeat process starting with step 3 within 10 seconds.
6. The registration mode is complete after removing master key from ignition lock cylinder and depressing and releasing brake pedal at least once within 10 seconds after SECURITY indicator light has turned off, or at least 10 seconds has passed.

Using Toyota Hand-Held Tester

1. Connect hand-held tester to data link connector No. 3. When using hand-held tester, more detailed procedures may be displayed on tester while performing this procedure.
2. Insert registered master key in ignition lock cylinder. Turn ignition on. Select MASTER KEY REGISTRATION on hand-held tester. Within 20 seconds, remove master key from ignition lock cylinder.
3. Within 10 seconds of removing master key from ignition lock cylinder, insert master key to be registered in ignition lock cylinder. Ensure SECURITY indicator light flashes. SECURITY indicator light is displayed as a vehicle icon near the center of the tachometer.
4. After one minute, additional master key should be registered and SECURITY indicator light should then turn off. The registration mode is complete after removing master key from ignition lock cylinder and depressing and releasing brake pedal at least once within 10 seconds after SECURITY indicator light has turned off, or at least 10 seconds has passed.

ADDITIONAL SUB-KEY REGISTRATION (EXCEPT PRIUS)

Note. A sub-key is a Gray-colored ignition key. Additional sub-key may be registered by 2 different methods: using brake pedal and accelerator pedal, or using Toyota hand-held tester. It is possible to register up to 3 sub-key codes including the already registered key code.

Note. When any operation time described in following procedures is over, registration mode completes. When next procedure is performed while timer is working, the timer completes counting time and then the next timer starts.

Using Brake & Accelerator Pedal

1. Insert registered master key in ignition lock cylinder. Within 15 seconds of inserting master key into ignition lock cylinder, depress and release accelerator pedal 4 times.
2. Within 20 seconds of depressing and releasing accelerator pedal 4 times, depress and release brake pedal 5 times and remove master key from ignition lock cylinder.
3. Within 10 seconds of removing master key from ignition lock cylinder, insert sub-key to be registered in ignition lock cylinder.
4. Within 10 seconds of inserting sub-key in ignition lock cylinder, depress and release accelerator pedal one time. Ensure SECURITY indicator light flashes. SECURITY indicator light is displayed as a vehicle icon near the center of the tachometer.
5. After one minute, additional sub-key should be registered and SECURITY indicator light should then turn off. If registering additional sub-keys, repeat process starting with step 3 within 10 seconds.
6. The registration mode is complete after removing sub-key from ignition lock cylinder and depressing and releasing brake pedal at least once within 10 seconds after SECURITY indicator light has turned off, or at least 10 seconds has passed.

1. Connect hand-held tester to data link connector No. 3. When using hand-held tester, more detailed procedures may be displayed on tester while performing this procedure.
2. Insert registered master key in ignition lock cylinder. Turn ignition on. Select SUB-KEY REGISTRATION on hand-held tester. Within 20 seconds, remove master key from ignition lock cylinder.
3. Within 10 seconds of removing master key from ignition lock cylinder, insert sub-key to be registered in ignition lock cylinder. Ensure SECURITY indicator light flashes. SECURITY indicator light is displayed as a vehicle icon near the center of the tachometer.
4. After one minute, additional sub-key should be registered and SECURITY indicator light should then turn off. The registration mode is complete after removing sub-key from ignition lock cylinder and depressing and releasing brake pedal at least once within 10 seconds after SECURITY indicator light has turned off, or at least 10 seconds has passed.

ERASURE OF TRANSPONDER KEY CODE (EXCEPT PRIUS)

Note. There are 2 different methods to erase the transponder key code: using brake pedal and accelerator pedal, or using Toyota hand-held tester. All other master and sub-key codes are deleted leaving the master key code which was used when performing the operation. When using the ignition key which was used before deleting, it is necessary to register the code again.

Note. When any operation time described in following procedures is over, registration mode completes. When next procedure is performed while timer is working, the timer completes counting time and then the next timer starts.

1. Insert registered master key in ignition lock cylinder. Within 15 seconds of inserting master key into ignition lock cylinder, depress and release accelerator pedal 6 times.
2. Within 20 seconds of depressing and releasing accelerator pedal 6 times, depress and release brake pedal 7 times.
3. Within 10 seconds of depressing and releasing brake pedal 7 times, remove master key from ignition lock cylinder. Procedure should now be complete and transponder key code should now be erased. If master key cannot be removed from ignition lock cylinder, the transponder key code erasure is cancelled.

1. Connect hand-held tester to data link connector No. 3. When using hand-held tester, more detailed procedures may be displayed on tester while performing this procedure.
2. Insert registered master key in ignition lock cylinder. Turn ignition on. Request KEY CODE DELETION from hand-held tester. Ensure SECURITY indicator light flashes. SECURITY indicator light is displayed as a vehicle icon near the center of the tachometer.
3. Within 10 seconds of requesting KEY CODE DELETION on hand-held tester, remove master key from ignition lock cylinder. Procedure is now complete and transponder key code should now be erased. If master key cannot be removed from ignition lock cylinder, transponder key code erasure is cancelled and SECURITY indicator light will turn off.

IMMOBILIZER COMPONENT REPLACEMENT PROGRAMMING PROCEDURES (PRIUS)

Note. Proper procedure must be followed when replacing transponder key Electronic Control Unit (ECU) and/or hybrid vehicle control Electronic Control Unit (ECU).

Programming When Replacing Transponder Key Electronic Control Unit

Once replacement transponder key Electronic Control Unit (ECU) is installed, register ignition keys to transponder key ECU. See IGNITION KEY REGISTRATION . Insert ignition key into ignition lock cylinder and turn ignition switch to ON position. Leave ignition switch in ON position for at least 30 minutes and then start the engine.

Programming When Replacing Hybrid Vehicle Control Electronic Control Unit

Once replacement hybrid vehicle control Electronic Control Unit (ECU) is installed, insert ignition key into ignition lock cylinder and turn ignition switch to ON position. Leave ignition switch in ON position for at least 30 minutes and then start the engine.

Programming When Replacing Transponder Key Electronic Control Unit & Hybrid Vehicle Control Electronic Control Unit

Once replacement transponder key Electronic Control Unit (ECU) and hybrid vehicle control Electronic Control Unit (ECU) are installed, register ignition keys to transponder key ECU. See IGNITION KEY REGISTRATION . Once ignition keys are registered, insert ignition key into ignition lock cylinder and start the engine.

Programming If All Ignition Keys Are Lost

Note. Procedure must be followed if all ignition keys are lost.

Purchase NEW ignition keys along with NEW transponder key Electronic Control Unit (ECU). Replace original transponder key ECU with replacement transponder key ECU. Insert NEW ignition key into ignition lock cylinder and turn ignition switch to ON position. Leave ignition switch in ON position for at least 30 minutes.

Note. This procedure MUST BE performed ONLY when NEW transponder key Electronic Control Unit (ECU) is installed. A new transponder key ECU is in automatic registration mode and up to 2 master key identification codes and one sub-key identification code may be registered in transponder key ECU at one time. In automatic registration mode, the last ignition key to be registered becomes a sub-key.

Note. Master key is a Black-colored ignition key that opens all locks. A sub-key is a Gray-colored ignition key that will not open the trunk.

1. Check that battery is connected and there is no ignition key in the ignition lock cylinder. Check that SECURITY indicator light is flashing. SECURITY indicator light is displayed as a vehicle icon near the clock at the center of instrument panel.
2. To register the first master key, insert master key into ignition lock cylinder. SECURITY indicator light should turn off for one second and then turn back on. Remove master key from ignition lock cylinder.
3. To register the second master key, insert master key into ignition lock cylinder. SECURITY indicator light should turn off for one second and then turn back on. Remove master key from ignition lock cylinder.
4. To register the sub-key, insert sub-key into ignition lock cylinder. SECURITY indicator light should turn off for one second and then turn back on. Remove sub-key from ignition lock cylinder. Ensure SECURITY indicator light starts flashing.
5. If the registration was complete and system is operating normally when ignition key was removed from ignition lock cylinder, the SECURITY indicator light should flash. If ignition key registration was not completed with transponder key Electronic Control Unit (ECU) in automatic registration mode, a code 2-1 will be displayed by SECURITY indicator light. see scheme 6 When inserting an already registered ignition key, a code 2-2 will be displayed by SECURITY indicator light. see scheme 6
6. To complete automatic registration mode after more than one key has been registered, insert master key into ignition lock cylinder and turn ignition switch to from LOCK to ON position 5 times within 10 seconds without removing master key from ignition lock cylinder.

Additional Master Key Registration

Note. Master key is a Black-colored ignition key that opens all locks.

1. Ensure all doors are closed and there is no ignition key in ignition lock cylinder. Insert registered master key into ignition lock cylinder. Within 15 seconds of inserting master key into ignition lock cylinder, repeatedly turn ignition switch to from LOCK to ON position 5 times, and then open and close the driver's door 6 times. Driver's door must be opened and closed within 15 seconds after inserting master key into ignition lock cylinder.
2. Within 20 seconds of opening and closing the driver's door 6 times, remove master key from ignition lock cylinder. Master key must be removed from ignition lock cylinder within 20 seconds after the first opening and closing of the driver's door.
3. Within 10 seconds of removing master key from ignition lock cylinder, insert master key to be registered in ignition lock cylinder.
4. Within 10 seconds of inserting master key to be registered in ignition lock cylinder, turn ignition switch to from LOCK to ON position. Leave ignition switch in ON position for at least 60 seconds.
5. After ignition switch has been in ON position for at least 60 seconds, turn ignition off and remove ignition key from ignition lock cylinder. If registering additional master keys, repeat process starting with step 3 within 10 seconds. Once all master keys are registered, open and close the driver's door.

Additional Sub-Key Registration

Note. A sub-key is a Gray-colored ignition key that will not open the trunk.

1. Ensure all doors are closed and there is no ignition key in ignition lock cylinder. Insert registered master key into ignition lock cylinder. Within 15 seconds of inserting master key into ignition lock cylinder, repeatedly turn ignition switch to from LOCK to ON position 4 times, and then open and close the driver's door 5 times. Driver's door must be opened and closed within 15 seconds after inserting master key into ignition lock cylinder.
2. Within 20 seconds of opening and closing the driver's door 5 times, remove master key from ignition lock cylinder. Master key must be removed from ignition lock cylinder within 20 seconds after the first opening and closing of the driver's door.
3. Within 10 seconds of removing master key from ignition lock cylinder, insert sub-key to be registered in ignition lock cylinder.
4. Within 10 seconds of inserting sub-key to be registered in ignition lock cylinder, turn ignition switch to from LOCK to ON position. Leave ignition switch in ON position for at least 60 seconds.
5. After ignition switch has been in ON position for at least 60 seconds, turn ignition off and remove ignition key from ignition lock cylinder. If registering additional sub-key, repeat process starting with step 3 within 10 seconds. Once all sub-keys are registered, open and close the driver's door.

Note. Procedure is used to erase all key codes from transponder key Electronic Control Unit (ECU). All other master and sub-key codes are deleted leaving the master key code which was used when performing the operation. When using the ignition key which was used before deleting, it is necessary to register the code again.

1. Ensure all doors are closed and there is no ignition key in ignition lock cylinder. Insert registered master key into ignition lock cylinder. Within 15 seconds of inserting master key into ignition lock cylinder, repeatedly turn ignition switch to from LOCK to ON position 6 times, and then open and close the driver's door 7 times. Driver's door must be opened and closed within 15 seconds after inserting master key into ignition lock cylinder.
2. Within 20 seconds of opening and closing the driver's door 7 times, remove master key from ignition lock cylinder. Master key must be removed from ignition lock cylinder within 20 seconds after the first opening and closing of the driver's door.

POWER SLIDING DOOR REINITIALIZATION PROCEDURE (SIENNA)

Note. Following procedure should be performed if power sliding door system does not operate properly under the following conditions: battery is disconnected and reconnected, battery is discharged and recharged, or open power sliding door warning light remains on even with power sliding doors closed.

1. If power sliding door system does not operate properly and open power sliding door warning light remains on, even with power sliding doors closed, go to next step. If power sliding door system does not operate properly after battery is disconnected and reconnected or battery is discharged and recharged, go to step 4 .
2. Ensure power sliding door main switch is in OFF position. Power sliding door main switch is located on driver's side of instrument panel, just to the left of steering column and is marked as PWR DOOR OFF. Close power sliding door by hand. Disconnect battery for one minute and then reconnect the battery.
3. Turn on power sliding door system by placing power sliding door main switch in the ON position. Wait 5 seconds and then go to next step.
4. Ensure power sliding door main switch is in ON position if not previously done. Power sliding door main switch is located on driver's side of instrument panel, just to the left of steering column and is marked as PWR DOOR OFF. Open one of the power sliding doors by using the power sliding door control switch. Power sliding door control switches are located near center of instrument panel, just below the stereo.
5. Wait 3 seconds after power sliding door stops at the fully open position and then close power sliding door by using power sliding door control switch on instrument panel or by using remote keyless entry transmitter.
6. Wait 3 seconds after power sliding door stops at the fully closed position and then repeat steps 4 and 5 .

Camry

Note. Following procedure should be performed if battery is disconnected and reconnected, or battery is discharged and recharged to provide proper automatic operation and jam protection operation of power sun roof.

1. Ensure ignition is on. Depress and hold TILT UP side of power sun roof switch until power sun roof tilts all the way upward and then tilts downward a little. Power sun roof switch is located on headliner, just in front of power sun roof.
2. Check proper operation of open/closing and tilt up/down function for power sun roof using power sun roof switch. Power sun roof should operate anytime ignition is on, or for 43 seconds after ignition is off provided both front doors are closed. It will stop operating if any front door is opened. Depressing SLIDE OPEN side of power sun roof switch for one second should open power sun roof. Depressing TILT UP side of power sun roof switch for one second should close power sun roof. To tilt power sun roof upward, depress and hold TILT UP side of power sun roof switch for one second. To tilt power sun roof downward, depress and hold SLIDE OPEN side of power sun roof switch for one second.

Celica

Close power sun roof using power sun roof switch and continue to depress power sun roof switch briefly after power sun roof is fully closed. Power sun roof switch is located on headliner, just in front of power sun roof.

VOLKSWAGEN

Note. While limited diagnostic information is available, vehicle manufacturer does not support diagnostic information using aftermarket scan tools. To properly diagnose vehicle, it is recommended to use VAS 5051 scan tool with VAS 5051/1 adapter cable or VAG 1551 scan tool with 1551/3A adapter cable and VAG 1598/31 test box.

Note. If Engine Control Module (ECM) memory is cleared, ECM is disconnected or loses battery voltage, it is necessary to generate a ECM readiness code. See READINESS CODE .

ENGINE CONTROL MODULE PROGRAMMING (ALL MODELS)

Note. Once procedure is started DO NOT turn ignition off during ECM programming. After coding ECM and starting engine for first time, allow engine to idle for several minutes so ECM can go through learn function. Idle speed may be erratic while ECM is learning.

If Engine Control Module (ECM) is replaced, it is necessary to code new ECM. If new ECM is not properly coded, the following problems may occur

1. Driveability problems (e.g., harsh shifting).
2. False malfunctions stored in ECM memory.
3. Increased fuel consumption.
4. Increased exhaust emissions.
5. Reduction in transmission life.
6. All ECM functions are not carried out (e.g., EVAP system operation).
7. On front wheel drive vehicles Anti-Slip Regulation (ASR), (ASR warning lamp comes on).

Before ECM is replaced on any model perform following procedure. Turn ignition off. Connect Scan Tool (VAG 1551/1552) using Adapter cable (VAG 1551/3) to Data Link Connector (DLC). Turn ignition on. Prior to removing original ECM, print out ECM identification. On scan tool, press 0 and 1 buttons to select ADDRESS WORD 01: ENGINE ELECTRONICS. Print out ECM identification by pressing PRINT button. Press right arrow button. On scan tool, press 0 and 6 buttons to select FUNCTION 06: END OUTPUT. Press "Q" button to enter input. Turn ignition off.

Remove original ECM and install new ECM. Turn ignition on. On scan tool, press 0 and 1 buttons to select ADDRESS WORD 01: ENGINE ELECTRONICS. Press right arrow button. Press 0 and 7 buttons to select FUNCTION 07: CODE CONTROL MODULE. Press "Q" button to enter input. Enter appropriate code for vehicle. See appropriate ENGINE CONTROL MODULE CODING TABLE or VARIATION TABLE as follows. After coding ECM, press 0 and 6 buttons to select FUNCTION 06: END OUTPUT. Press "Q" button to enter input.

After installing and/or coding ECM perform following procedures

1. Use scan tool to check DTC memory, erase if necessary. See RETRIEVING DIAGNOSTIC TROUBLE CODES in appropriate SELF-DIAGNOSTICS article.
2. Perform adaptation of throttle valve control module. See ADAPTATION OF THROTTLE VALVE CONTROL MODULE in appropriate SELF-DIAGNOSTICS article.
3. On vehicles equipped with cruise control, activate cruise control to ECM. See CRUISE CONTROL SYSTEMS article in ACCESSORIES & EQUIPMENT.
4. On vehicles equipped with automatic transmission, perform adaptation of kickdown switch or automatic transmission basic setting. See ADAPTATION OF KICKDOWN FUNCTION or AUTOMATIC TRANSMISSION BASIC SETTING PROCEDURE in appropriate SELF-DIAGNOSTICS article.
5. On vehicles equipped with factory alarm system, perform adaptation of immobilizer to ECM. See appropriate ANTI-THEFT & POWER DOOR LOCKS article in ACCESSORIES & EQUIPMENT.
6. Using scan tool, generate a ECM readiness code. See «READINESS CODE»(/audi/s6/c5-1999-2004/remont/computer-relearn/#computer-relearn-procedures-import) .

Engine Control Module Coding Options (1.8L Turbo)

Note. These options relate to Golf, Jetta, Beetle and Passat models equipped with 1.8L engine.

ENGINE CONTROL MODULE CODING VARIATION OPTIONS (BEETLE)

ENGINE CONTROL MODULE CODING OPTIONS (GTI & JETTA)

ENGINE CONTROL MODULE CODING OPTIONS (PASSAT)

Engine Control Module Coding Options (1.9L Diesel)

Note. This procedure relates to GTI, Jetta, and Beetle models equipped with 1.9L diesel engine.

ENGINE CONTROL MODULE CODING VARIATION OPTIONS (1.9L)

Engine Control Module Coding Options (2.0L)

Note. This procedure relates to Cabrio, Golf, GTI, Jetta, Beetle and Passat models equipped with 2.0L engine.

ENGINE CONTROL MODULE CODING VARIATION OPTIONS (2.0L)

Engine Control Module Coding Options (2.8L)

Note. This procedure relates to EuroVan, Jetta, and Passat models equipped with 2.8L engine.

For Passat 2.8L with engine code ATQ (Scheme 6) For EuroVan 2.8L with engine code AXK (Scheme 7) For Jetta with engine code AFP, see ENGINE CONTROL MODULE CODING VARIANTS (2.8L W/ENGINE CODE AFP) table.

ENGINE CONTROL MODULE CODING VARIANTS (2.8L W/ENGINE CODE AFP)

Scheme 6

Scheme 7

Note. Throttle Valve Control Module (TVCM) (J338) adaptation is part of Readiness Code procedures. TVCM adaptation can also be performed by it self, see THROTTLE VALVE CONTROL MODULE in appropriate SELF-DIAGNOSTICS article. For further information, see SELF-DIAGNOSTIC SYSTEMS in appropriate SELF-DIAGNOSTICS article.

Readiness code must be generated whenever ECM memory is cleared, ECM loses battery voltage or is replaced. Readiness code appears as an 8-digit display in diagnostic function MEASURING VALUE BLOCK 086, display field 1 of scan tool. Each of the 8 digits is related to a specific exhaust related system. During a test sequence OBD system checks function of each of the 8 systems. OBD system checks components and generates Readiness Code at regular intervals during normal driving.

Note. Not all eight diagnostic functions in Readiness Code are used. (Scheme 8)

Reading Readiness Code

Readiness code is returned to 0 1 1 0 1 1 0 1 if DTC memory is erased, voltage supply to ECM is lost, or a new ECM is installed. To read readiness code, connect scan tool to DLC. DLC is located left side of steering column. Turn ignition on. Follow scan tool manufacturer's instructions and read Readiness Code. (Scheme 8) Readiness code should display 0 0 0 0 0 0 0 0. If readiness code displays as specified, testing is complete. If readiness code does not display as specified, generate readiness code. See GENERATING READINESS CODE.

Note. Before generating readiness code, perform a long road test. Coolant temperature needs to be greater than 176° F (80° C). Idle, partial throttle, full throttle and overdrive, all must be attained several times. During test drive, apply full throttle until engine speed exceeds 3500 RPM. Read readiness code. OBD system checks components and generates Readiness Code at regular intervals during normal driving.

Note. During readiness code generating procedure, if test result is indicated as OK after selecting a display group, testing has already been carried out and it is okay to proceed to next work step.

1. To generate readiness code, vehicle must be stationary, transmission in Park or Neutral, all electrical consumers off, A/C switched off and coolant temperature at least 176°F (80°C). If possible it is best to warm-up vehicle by test driving. Connect scan tool to DLC. DLC is located at left side of steering column.
2. Using scan tool, retrieve DTCs. See RETRIEVING CODES in appropriate SELF-DIAGNOSTICS article. If DTCs are stored. Perform appropriate test and repair as necessary. See DIAGNOSTIC TROUBLE CODE IDENTIFICATION in appropriate SELF-DIAGNOSTICS article. Using scan tool, clear DTC memory. See CLEARING CODES in appropriate SELF-DIAGNOSTICS article.
3. After clearing DTC memory. Follow scan tool instructions to complete generating readiness code. During test sequence if test is successful scan tool changes display digits from 1 to 0. (Scheme 8) Readiness code should display 0 0 0 0 0 0 0 0. If readiness code displays as specified, testing is complete.

Scheme 8

Engine Control Module Programming

Replacement of Engine Control Module (ECM) or Transmission Control Module (TCM) requires reprogramming with Volvo System Tester. At time of publication, no information was available from manufacturer.

Radio will require anti-theft security code to be entered if battery is disconnected. Turn radio on. Radio should display "COdE". Using first 4 preset buttons, enter code number from customer supplied security card. Each preset button applies to code number digit. For example, No. 1 button sets the first digit of code number. Cycle button until desired number appears. A "beep" will sound when correct code is entered. If code is incorrectly entered after 3 successive attempts, radio must be left on for one hour before it will accept code entry.

See also:
• GENERATING READINESS CODE
• ENGINE CONTROL MODULE CODING OPTIONS (A4)
• EEPROM PROGRAMMING PROCEDURE
• FLASH VEHICLE IDENTIFICATION BLOCK PROCEDURE
• INPUTTING CODE WORD
• REPROGRAM ERROR RECOVERY
• SYNCHRONIZATION OF POWER WINDOWS
• ACTIVATING STEERING ANGLE SENSOR
• SYNCHRONIZATION OF SLIDING/TILT-UP ROOF
• EASY ENTRY/EXIT FUNCTION
• SERVICE PRECAUTIONS (PRIUS)
